Honda S2000 (2008 year). Instruction

A tire this worn gives very little
traction on wet roads. You should
replace the tire if you can see three
or more tread wear indicators.

The following charts show the
recommended cold tire pressures for
most normal and high-speed driving
conditions.

Your tires have wear indicators
molded into the tread. When the
tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread left on
the tire.

Excessive tread wear.

Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see fabric or cord.

Bumps or bulges in the tread or
side of the tire. Replace the tire if
you find either of these conditions.

Every time you check inflation, you
should also examine the tires for
damage, foreign objects, and wear.
You should look for:

For convenience, the recommended
cold air pressures and tire sizes are
on a label on the driver’s doorjamb.

For additional information about
your tires, see page

The compact spare tire pressure is:

238

Tire Size

Cold Tire Pressure

Tire Size

Cold Tire Pressure

Tire Size

Cold Tire Pressure

Except CR models

CR models

Except CR models

Recommended Tire Pressures

Tire Inspection

Tires

190

INDICATOR LOCATION MARKS

TREAD WEAR INDICATORS

Front:

Rear:

60 psi (420 kPa , 4.2 kgf/cm )

215/45R17 87W

245/40R17 91W

32 psi (220 kPa ,

2.2 kgf/cm )

32 psi (220 kPa ,

2.2 kgf/cm )

32 psi (220 kPa ,

2.2 kgf/cm )

255/40R17 94W

０７／０７／２６０９：３３：３６３１Ｓ２Ａ６８００１９５

2008 S2000

Table Of Contents

Main Menu

In addition to proper inflation,
correct wheel alignment helps to
decrease tire wear. If you find a tire
is worn unevenly, have your dealer
check the wheel alignment.

Have your dealer check the tires if
you feel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed from the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comfort and tire life. For best results,
have the installer perform a dynamic
balance.

The service life of your tires is
dependent on many factors,
including, but not limited to, driving
habits, road conditions, vehicle
loading, inflation pressure,
maintenance history, speed, and
environmental conditions (even
when the tires are not in use).

In addition to your regular
inspections and inflation pressure
maintenance, it is recommended that
you have annual inspections
performed once the tires reach five
years old. It is also recommended
that all tires, including the spare, be
removed from service after 10 years
from the date of manufacture,
regardless of their condition or state
of wear.

The last four digits of the TIN (tire
identification number) are found on
the sidewall of the tire and indicate
the date of manufacture (See

on page

238

Tire Maintenance

Tire Service Lif e

Tire

Labeling

Tires

int
e

na
nce

191

Improper wheel weights can damage
your vehicle’s aluminum wheels. Use
only Honda wheel weights f or
balancing.

０７／０７／２５１７：５２：５４３１Ｓ２Ａ６８００１９６

2008 S2000

Table Of Contents

Main Menu

You should not rotate your vehicle’s
tires. The front and rear tires are
different sizes, so they cannot be
rotated front-to-rear. The original-
equipment tires on your vehicle have
a unidirectional tread pattern, so
they cannot be rotated side-to-side.

The tires that came on your vehicle
were designed and constructed to
provide superior grip during
acceleration, braking, and cornering.

As a trade-off, they will wear more
rapidly than tires used on ordinary
passenger vehicles. Because of the
vehicle’s weight distribution, and the
fact that the rear wheels are the
driving wheels, you can expect them
to wear more rapidly than the front
tires.

The mileage you can expect from
your vehicle tires is the same as
comparable mid-and rear-engine
sports cars, and it will vary greatly
with your driving habits.

If you drive moderately, the rear
tires could last more than 10,000
miles (16,000 km). However, the
mileage will be substantially less if
you tend to drive your vehicle at the
upper limits of its capabilities.

You should carefully inspect your
vehicle’s tires for wear, damage, and
proper inflation every 7,500 miles
(12,000 km) or when tire inspection
is indicated on the information
display (see page

It is best to replace all four tires at
the same time. If that is not possible
or necessary, replace the two front
tires or two rear tires as a pair.
Replacing just one tire can seriously
affect your vehicle’s handling.

Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s side wall).

Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a different
size or construction can cause the
anti-lock brake and the vehicle
stability assist systems to work
inconsistently.

168

Tires

Tire Rotation

Tire Wear

Replacing Tires and Wheels

192

０７／０７／２５１７：５３：０３３１Ｓ２Ａ６８００１９７

2008 S2000

Table Of Contents

Main Menu

Wheels:

Tires:

See page

for information about

DOT Tire Quality Grading, and page

for tire size and labeling

information.

The ABS works by comparing the
speed of the wheels. When replacing
tires, use the same size originally
supplied with the vehicle. Tire size
and construction can affect wheel
speed and may cause the system to
activate.

If you ever replace a wheel, make
sure that the wheel’s specifications
match those of the original wheels.

Also be sure you use only TPMS
specific wheels. If you do not, the
tire pressure monitoring system will
not work on that tire.

Replacement wheels are available at
your dealer.

236

238

Except CR models

CR models

Wheel and Tire Specif ications

Tires

int
e

na
nce

193

Front:

17 x 7 J

Rear:

17 x 8 1/2 J

Front:

215/45R17 87W

Rear:

245/40R17 91W

255/40R17 94W

Installing improper tires on your
vehicle can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.

Always use the size and type of
tires recommended in this
owner’s manual.

０７／０７／２５１７：５３：１４３１Ｓ２Ａ６８００１９８

2008 S2000

Table Of Contents

Main Menu

＋

If you mount snow tires on your
vehicle, make sure they are radial
tires of the same size and load range
as original tires. Mount snow tires on
all four wheels. The traction
provided by snow tires on dry roads
may be lower than your original tires.
Check with the tire dealer for
maximum speed recommendations.

Because your vehicle has limited tire
clearance, Honda strongly
recommends using the chains listed
below.

When installing cables, follow the
manufacturer’s instructions, and
mount them as tight as you can.
Make sure they are not contacting
the brake lines or suspension. Drive
slowly with them installed. If you
hear them coming into contact with
the body or chassis, stop and
investigate. Remove them as soon as
you begin driving on cleared roads.

For more information on snow tires,
consult your dealer.

Your vehicle’s tires are not suitable
for mounting any traction device.

Mount tire chains on your tires when
required by driving conditions or
local laws. Install them only on the
rear tires.

Your vehicle is equipped with
summer tires. Be aware that these
tires are not designed for winter
driving conditions.

Tires marked ‘‘M

S’’ or ‘‘All

Season’’ on the sidewall have an all-
weather tread design suitable for
most winter driving conditions.

For the best performance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.

Cable-type: Security Chain Company
(SCC) Radial Chain SC1034

Cable-type: RUD 48493

Except CR models

U.S. S2000 model

Canadian model

CR models only

Winter Driving

Tires

Snow Tires

Tire Chains

194

０７／０７／２５１７：５３：２４３１Ｓ２Ａ６８００１９９

2008 S2000

Table Of Contents

Main Menu

Tires

int
e

na
nce

195

Using the wrong chains, or not
properly installing chains, can
damage the brake lines and
cause a crash in which you can
be seriously injured or killed.

Follow all instructions in this
owner’s manual regarding the
selection and use of tire chains.

Traction devices that are the wrong
size or improperly installed can
damage your vehicle’s brake lines,
suspension, body, and wheels. Stop
driving if they are hitting any part of
the vehicle.

０７／０７／２５１７：５３：２７３１Ｓ２Ａ６８００２００

2008 S2000

Table Of Contents

Main Menu

Check the condition of the battery
monthly by looking at the test
indicator window. The label on the
battery explains the test indicator’s
colors.

Check the terminals for corrosion (a
white or yellowish powder). To
remove it, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it off with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
future corrosion.

If your vehicle’s battery is
disconnected, or goes dead, the
clock setting in the instrument panel
will be canceled. To reset the time,
see page

If your vehicle’s battery is
disconnected, or goes dead, the
audio system will disable itself. The
next time you turn on the radio, you
may see ‘‘CODE’’ (U.S. model) or
‘‘Code’’ (Canadian model) in the
frequency display. Use the preset
buttons to enter the code (see page

123

Checking the Battery

196

TEST INDICATOR WINDOW

０７／０７／２５１７：５３：３３３１Ｓ２Ａ６８００２０１

2008 S2000

Table Of Contents

Main Menu

−

If additional battery maintenance is
needed, see your dealer or a
qualified technician.

Battery posts,

terminals, and related accessories
contain lead and lead compounds.

If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative (

) cable first, and

reconnect it last.

WARNING:

Wash your hands af ter handling.

Checking the Battery

int
e

na
nce

197

The battery gives off explosive
hydrogen gas during normal
operation.

A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.

Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.

０７／０７／２５１７：５３：３７３１Ｓ２Ａ６８００２０２

2008 S2000

Table Of Contents

Main Menu

If you need to park your vehicle for
an extended period (more than 1
month), there are several things you
should do to prepare it for storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your vehicle back on the road. If
possible, store your vehicle indoors.

Fill the fuel tank.

Block the rear wheels.

If the vehicle is to be stored for a
longer period, it should be
supported on jackstands so the
tires are off the ground.

Leave one window open slightly (if
the vehicle is being stored
indoors).

Disconnect the battery.

Cover the vehicle with a
‘‘breathable’’ cover, one made
from a porous material such as
cotton. Non-porous materials, such
as plastic sheeting, trap moisture,
which can damage the paint.

Support the front wiper blade
arms with a folded towel or rag so
they do not touch the windshield.

To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehicle body wax to the painted
surfaces that mate with the door
and trunk seals.

If possible, periodically run the
engine until it reaches full
operating temperature (the
cooling fan cycles on and off
twice). Preferably, do this once a
month.

Wash and dry the exterior
completely.

Clean the interior. Make sure the
carpeting, floor mats, etc., are
completely dry.

Raise the convertible top cover.

Leave the parking brake off. Put
the transmission in reverse.

Vehicle Storage

198

０７／０７／２５１７：５３：４６３１Ｓ２Ａ６８００２０３

2008 S2000

Table Of Contents

Main Menu

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you information about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also find instructions
on getting your vehicle towed.

......................

Compact Spare Tire

200

....................

Changing a Flat Tire

201

....................

Repairing a Flat Tire

206

.............

If the Engine Won’t Start

212

................................

Jump Starting

214

..............

If the Engine Overheats

215

.........

Low Oil Pressure Indicator

218

..........

Charging System Indicator

218

.......

Malfunction Indicator Lamp

219

...............

Brake System Indicator

220

.......

Closing the Convertible Top

221

..............................................

Fuses

222

..........

Checking and Replacing

223

..............................

Fuse Locations

226

......................

Emergency Towing

228

..........

If Your Vehicle Gets Stuck

228

Taking Care of the Unexpected

ing
Ca
re

of
th

ne
x

199

０７／０７／２５１７：５３：５０３１Ｓ２Ａ６８００２０４

2008 S2000

Main Menu

Replace the tire when you can see
the tread wear indicator bars. The
replacement should be the same size
and design tire, mounted on the
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed for mounting a regular tire.

Check the inflation pressure of the
compact spare tire every time you
check the other tires. It should be
inflated to:

Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.

Follow these precautions:

Never exceed 50 mph (80 km/h).

This tire gives a harsher ride and
less traction on some road
surfaces. Use greater caution
while driving.

Do not mount tire chains on the
compact spare tire.

Do not use your compact spare
tire on another vehicle unless it is
the same make and model.

Do not mount the compact spare
tire on either rear wheel position;
it will damage the limited slip
differential (see page

The low tire pressure indicator
comes on and stays on after you
replace the flat tire with the
compact spare tire. After several
miles (kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low
tire pressure indicator goes off.

201

Except CR models

Compact Spare Tire

200

INDICATOR LOCATION MARK

TREAD WEAR INDICATOR BAR

60 psi (420 kPa , 4.2 kgf/cm )

０７／０７／２５１７：５３：５９３１Ｓ２Ａ６８００２０５

2008 S2000

Table Of Contents

Main Menu

Open the trunk. Lift up the tool
box lid, and take the jack, the
wheel nut wrench, and the
extension out of the tool box.

The compact spare tire is smaller
than a standard tire, which will affect
the vehicle’s handling. Drive
cautiously when this spare is
mounted on your vehicle.

If you have a flat tire while driving,
stop in a safe place to change it.
Drive slowly along the shoulder until
you get to an exit or an area to stop
that is far away from the traffic lanes.

Turn on the hazard warning lights,
and turn the ignition switch to the
LOCK (0) position. Have your
passenger get out of the vehicle
while you change the tire.

Park the vehicle on firm, level, and
non-slippery ground. Put the
transmission in reverse. Apply the
parking brake.

The size difference may also cause
damage to the rear differential, so do
not mount the compact spare on the
rear. If either rear tire goes flat,
remove the front tire on that same
side, mount the compact spare tire
on the front, then mount the front
tire on the rear.

Your vehicle is equipped with the
tire repair kit instead of the spare
tire. This kit is available for easy
repair of a flat tire (see page

206

CONTINUED

Except CR models

CR models

Changing a Flat Tire

ing
Ca
re

of
th

ne
x

201

TOOL BOX LID

JACK

The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.

Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.

Use the jack that came with your
vehicle. If you try to raise another
vehicle with this jack or use another
jack to raise your vehicle, the vehicle or
jack can be damaged.

０７／０７／２５１７：５４：０９３１Ｓ２Ａ６８００２０６

2008 S2000

Table Of Contents

Main Menu

Unscrew the wing bolt, and take
the spare tire out of the spare tire
shelf.

Remove the three clips holding
the spare tire cover by pulling the
rings straight back. Remove the
spare tire cover.

Loosen each wheel nut 1/2 turn
with the wheel nut wrench.

Place the jack under the jacking
point nearest the tire you need to
change. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the center of the jacking
point tab is resting in the jack
notch.

Changing a Flat Tire

202

SPARE TIRE COVER

WHEEL NUT WRENCH

JACKING
POINT

CLIPS

０７／０７／２５１７：５４：１６３１Ｓ２Ａ６８００２０７

2008 S2000

Table Of Contents

Main Menu

Use the extension and the wheel
nut wrench as shown to raise the
vehicle until the flat tire is off the
ground.

Before mounting the spare tire,
wipe any dirt off the mounting
surface of the wheel and hub with
a clean cloth. Wipe the hub
carefully; it may be hot from
driving.

Remove the wheel nuts, then
remove the flat tire. Handle the
wheel nuts carefully; they may be
hot from driving. Place the flat tire
on the ground with the outside
surface facing up.

10.

CONTINUED

Changing a Flat Tire

ing
Ca
re

of
th

ne
x

203

BRAKE HUB

EXTENSION

０７／０７／２５１７：５４：２３３１Ｓ２Ａ６８００２０８

2008 S2000

Table Of Contents

Main Menu

Put on the spare tire. Put the
wheel nuts back on finger-tight,
then tighten them in a crisscross
pattern with the wheel nut wrench
until the wheel is firmly against
the hub. Do not try to tighten the
wheel nuts fully.

Lower the vehicle to the ground,
and remove the jack.

Tighten the wheel nuts securely in
a crisscross pattern. Have the
wheel nut torque checked at the
nearest automotive service facility.
Tighten the wheel nuts to:

11.

12.

13.

Changing a Flat Tire

204

80 lbf·ft (108 N·m , 11 kgf·m)

０７／０７／２５１７：５４：２９３１Ｓ２Ａ６８００２０９

2008 S2000

Table Of Contents

Main Menu

Put the flat tire in the trunk well
vertically as shown.

Remove the tool box from the
trunk well, and replace the jack,
wheel wrench, and extension in
the tool box.

Place the tool box into the spare
tire shelf in the trunk.

Replace the spare tire cover.
Secure it with the three clips. Push
each clip in securely, and pivot the
ring down flat.

Your vehicle’s original tire has a
tire pressure monitoring system
sensor. To replace a tire, refer to

(see

page

155

17.

18.

16.

14.

15.

Changing a Flat Tire

Changing a Tire with TPMS

ing
Ca
re

of
th

ne
x

205

CLIPS

SPARE TIRE COVER

TOOL BOX

０７／０７／２５１７：５４：３７３１Ｓ２Ａ６８００２１０

2008 S2000

Table Of Contents

Main Menu

Honda S2000 (2008 year). Instruction - part 13
