Windshield
Wiper arms park position
Washer nozzle position
22-240
Wipers/Washers
Wiper Arm/Nozzle Adjustment
B
A
c
f
e
b
c
a
C
1. When the wiper arms stop at the park (automatic stop) position, confirm that they are at the standard position.
a:
Position at about 2.0 in. (52 mm) from the top of cowl cover (A)
b:
Position at about 1.7 in. (43 mm) from the top of cowl cover (A)
2. When you turn on the washers, confirm 50 % or more of the washer fluid lands within the spray area. If the spray
area is not within the standard positions, adjust the nozzles.
c:
Position at about 1.5 in. (37.5 mm) from the top of the black ceramic area (B) at the lower windshield
d:
Position at about 1.5 in. (37.5 mm) from the top of the black ceramic area (B) at the lower windshield
e:
Position at about 12.2 in. (311 mm) from the windshield center line (C)
f:
Position at about 12.2 in. (311 mm) from the windshield center line (C)
