Right Engine Compartment Wire Harness (cont’d)

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

22-24

Connectors and Harnesses

Connector to Harness Index (cont’d)

C101

15

23

Right side of engine compartment

Engine wire harness
(see page 22-18)

C102

16

2

Right side of engine compartment

Engine wire harness
(see page 22-18)

C201

1

10

Under right side of dash

Floor wire harness (see page
22-38)

C202

3

4

Under right side of dash

Dashboard wire harness
(see page 22-32)

C203

39

12

Under left side of dash

Left engine compartment wire
harness (see page 22-26)

C204

40

34

Under left side of dash

Dashboard wire harness
(see page 22-28)

C205

41

14

Under left side of dash

Dashboard wire harness
(see page 22-28)

C206

38

3

Under left side of dash

Dashboard wire harness
(see page 22-28)

G201

19

Right side of engine compartment

Body ground, via right engine
compartment wire harness

G202

17

Right side of engine compartment

Body ground, via right engine
compartment wire harness

＊０２

22-25

2

3

4

5

1

16

17

19

18

20

11

12

14

13 15

26

27

29

28

30

21

22

24

23

25

36

37

39

38

40

31

32

34

33

35

46

41

42

44

43

45

10

6

7

8

9

AUXILIARY UNDER-HOOD
RELAY BOX

RIGHT ENGINE
COMPARTMENT
WIRE HARNESS

47

−
＋

ＳＪＣ８Ａ００Ｊ５４２８３２２４５０１ＤＢＡＴ００

Left Engine Compartment Wire Harness

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

22-26

Connectors and Harnesses

Connector to Harness Index (cont’d)

Auxiliary under-hood fuse box

9

Left side of engine compartment

Brake fluid level switch (

)

13

1

Left side of engine compartment

Brake fluid level switch (

)

14

1

Left side of engine compartment

Horn (low)

1

1

Behind middle of front bumper

Left front turn signal/parking light

6

3

Behind left headlight

Left front wheel sensor

8

2

Left side of engine compartment

Left headlight

2

3

Behind left headlight

SRS left front impact sensor

3

2

Left side of engine compartment

VSA modulator-control unit

7

46

Left side of engine compartment

C203

12

12

Under left side of dash

Right engine compartment
wire harness (see page 22-22)

C301

10

4

Under left side of dash

Dashboard wire harness
(see page 22-28)

C302

11

23

Under left side of dash

Dashboard wire harness
(see page 22-28)

G301

4

Left side of engine compartment

Body ground, via left engine
compartment wire harness

G302

5

Left side of engine compartment

Body ground, via left engine
compartment wire harness

０１

22-27

LEFT ENGINE
COMPARTMENT
WIRE HARNESS

2

3

4

5

1

6

7

8

9

11

12

14

13

10
