Honda Element. Manual - part 351

Fig. 34: Identifying Ring Gear Holder
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Apply super high temp urea grease (P/N 08798-9002) to the splines (B) of the clutch disc (C), the

crankshaft pilot bushing (D), then install the clutch disc using the clutch alignment shaft (E) and remover
handle (F).

4. Install the pressure plate (A) and the mounting bolts (B) finger-tight.

Fig. 35: Identifying Pressure Plate And Mounting Bolts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Torque the mounting bolts in a crisscross pattern. Tighten the bolts in several steps to prevent warping the

diaphragm spring.

Specified Torque: 25 N.m (2.6 kgf.m, 19 lbf.ft)



2007 Honda Element EX

2007-08 TRANSMISSION Clutch - Element



Fig. 36: Tightening Mounting Bolts In Crisscross Pattern
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Remove the ring gear holder (A), clutch alignment shaft (B), and remover handle (C).

7. Make sure the diaphragm spring fingers are all the same height.

RELEASE BEARING REPLACEMENT

1. Remove the release fork boot (A) from the clutch housing (B).

Fig. 37: Identifying Clutch Housing Release Fork Boot
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the release fork (C) from the clutch housing by squeezing the release fork set spring (D) with

pliers. Remove the release bearing (E).

3. Check the play of the release bearing by spinning it with your hand. If there is excessive play or noise,

replace the release bearing.



2007 Honda Element EX

2007-08 TRANSMISSION Clutch - Element



Fig. 38: Checking Play Of Release Bearing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Apply super high temp urea grease (P/N 08798-9002) to the release fork (A), the release fork bolt (B), the

release bearing (C), and the release bearing guide (D) in the shaded areas.

Fig. 39: Identifying Clutch Parts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. With the release fork slid between the release bearing pawls, install the release bearing on the mainshaft

while inserting the release fork through the hole in the clutch housing.

6. Align the detent of the release fork with the release fork bolt, then press the release fork over the release

fork bolt squarely.

7. Install the release fork boot (E). Make sure the boot seals around the release fork and clutch housing.

8. Move the release fork (A) right and left to make sure it fits properly against the release bearing (B) and

NOTE:

The release bearing is packed with grease. Do not wash it in solvent.



2007 Honda Element EX

2007-08 TRANSMISSION Clutch - Element



the release bearing slides smoothly.

Fig. 40: Identifying Release Fork
Courtesy of AMERICAN HONDA MOTOR CO., INC.
