Monitor Execution, Sequence, Duration, DTC Type, OBD Status
MONITOR DESCRIPTION
Enable Conditions
ENABLE CONDITIONS
Malfunction Threshold
A malfunction is detected when the A/F sensor output voltage is 4.9 V or more.
Driving Pattern
Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan
comes on, then let it idle.
Diagnosis Details
Conditions for illuminating the MIL
When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM
memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the
freeze frame data are stored.
Conditions for clearing the MIL
The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic
runs.
The MIL, the DTC, the Temporary DTC, and the freeze frame data can be cleared by using the scan tool Clear
command or by disconnecting the battery.
DTC P1297 (20): ADVANCED DIAGNOSTICS
DTC P1297: ELECTRICAL LOAD DETECTOR (ELD) CIRCUIT LOW VOLTAGE
Execution
Continuous
Sequence
None
Duration
7 seconds or more
DTC Type
Two drive cycles, MIL ON
OBD Status
PASSED/FAILED/EXECUTING/OUT OF (TEST) CONDITION
Condition
No active
DTCs
P0101, P0102, P0103, P0107, P0108, P0117, P0118, P0134, P0135, P0171, P0172, P0300,
P0301, P0302, P0303, P0304, P0335, P0339, P0443, P0496, P0497, P1128, P1129, P1157,
P145C, P2195, P2238, P2252
2007 Honda Element EX
2007 ENGINE PERFORMANCE Advanced Diagnostics - Element
