Honda Civic. Manual - part 992





reset), the MAINTENANCE REQUIRED light will change from Yellow to
Red.

2. When service has been completed, reset MAINTENANCE REQUIRED

reminder light. To reset reminder light, turn ignition off. Insert ignition key in
slot provided to the right of tachometer (or beside the indicator). See Fig. 3.

Fig. 3: Maintenance Reminder Light Reset
Courtesy of AMERICAN HONDA MOTOR CO., INC.

1998-2002 ACCORD

1. When distance driven since maintenance required indicator was reset is less

than 6000 miles, the MAINT REQ'D reminder light will illuminate for 2



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda

































seconds and then go out when ignition switch is turned to ON (II) position.
When mileage is 6000-7500 miles, MAINT REQ'D indicator light will
illuminate for 2 seconds and then blink for 10 seconds when ignition switch is
turned to ON (II) position. When mileage exceeds 7500 miles, MAINT REQ'D
light illuminates and stays on while ignition switch is in ON (II) position.

2. To reset MAINT REQ'D indicator light, turn ignition switch to OFF position.

Push and hold the SELECT/RESET button and turn ignition switch to ON (II)
position. Continue to hold button for more than 10 seconds or until MAINT
REQ'D light goes out.

1998-2001 CR-V

1. At each 7500 mile service interval, the MAINTENANCE REQUIRED light

will change from Green to Yellow. If service is not performed (and light is not
reset), the MAINTENANCE REQUIRED light will change from Yellow to
Red.

2. When service has been completed, reset MAINTENANCE REQUIRED

reminder light. To reset reminder light, turn ignition off. Insert ignition key in
slot provided to the right of tachometer (or beside the indicator). See Fig. 4.



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda

































Fig. 4: Maintenance Reminder Light Reset
Courtesy of AMERICAN HONDA MOTOR CO., INC.

1998-2003 ODYSSEY

1. For the first 6000 miles after maintenance required indicator is reset, the

MAINT REQ'D reminder light illuminates when the ignition is turned on, then
will go out after 2 seconds. Between 6000-7500 miles, the MAINT REQ'D
reminder light will light for 2 seconds, then will flash for 10 seconds, and will
then go out. After exceeding 7500 miles without having scheduled
maintenance performed, MAINT REQ'D reminder light will remain on until it
is reset.

2. To reset the MAINT REQ'D reminder light, turn ignition switch to OFF



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda

































position. Press and hold the SELECT/RESET button. The SELECT/RESET
button is in lower right of instrument cluster between speedometer and fuel
gauge. While still holding button, turn ignition switch to ON position with
engine off. Hold button for about 10 seconds until indicator resets.

1998-2001 PRELUDE

1. At each 7500 mile service interval, the MAINTENANCE REQUIRED light

will change from Green to Yellow. If service is not performed (and light is not
reset), the MAINTENANCE REQUIRED light will change from Yellow to
Red.

2. When service has been completed, reset MAINTENANCE REQUIRED

reminder light. To reset reminder light, turn ignition off. Insert ignition key in
slot provided to the right of tachometer (or beside the indicator). See Fig. 5.



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda
