Examine gears (8, 9, 13 and 14) and oil pump
breather shaft (19) and idler gear shaft (21) for damage or wear. If the
breather valve key (10) is excessively worn and loose on shaft or gear,
replace with a new one. Inspect pump ody plate (5) and cover (11). If
they are worn or damaged, place them. Examine breather valve (19) and
oil pump cover for any wear or damage that might affect its operation.
Insert breather valve (19) in oil pump cover (11). Make sure valve turns
freely in cover and does not bind.
ASSEMBLING OIL PUMP (Figure 3-25)
Reassembly of the oil pump is essentially the reverse order of
disassembly.
Apply a light coating of engine oil to all moving parts before
assembling.
Reassemble check valve. See "ASSEMBLING OIL PUMP CHECK VALVE."
