Harley Davidson Sportster models 2010. Service manual - page 6

SUBJECT PAGE NO.

2.1 FASTENER TORQUE VALUES.................................................................................................2-1

2.2 SPECIFICATIONS.....................................................................................................................2-9

2.3 VEHICLE IDENTIFICATION NUMBER (V.I.N.)........................................................................2-12

2.4 WHEELS..................................................................................................................................2-14

2.5 WHEEL LACING: 16 INCH RIM..............................................................................................2-29

2.6 WHEEL LACING: 19 INCH RIM..............................................................................................2-31

2.7 WHEEL LACING: 21 INCH RIM..............................................................................................2-33

2.8 CHECKING AND TRUING WHEELS......................................................................................2-35

2.9 FRONT BRAKE MASTER CYLINDER....................................................................................2-40

2.10 FRONT BRAKE CALIPER: XL MODELS..............................................................................2-49

2.11 FRONT BRAKE CALIPER: XR MODELS..............................................................................2-57

2.12 REAR BRAKE MASTER CYLINDER: XL MODELS..............................................................2-62

2.13 REAR BRAKE MASTER CYLINDER: XR MODELS.............................................................2-70

2.14 REAR BRAKE MASTER CYLINDER RESERVOIR..............................................................2-75

2.15 REAR BRAKE CALIPER: XL MODELS.................................................................................2-78

2.16 REAR BRAKE CALIPER: XR MODELS................................................................................2-85

2.17 BRAKE LINES.......................................................................................................................2-91

2.18 TIRES....................................................................................................................................2-97

2.19 LEFT SIDE COVER.............................................................................................................2-101

2.20 FRONT FORK: XL MODELS...............................................................................................2-104

2.21 FRONT FORK: XR MODELS..............................................................................................2-110

2.22 FORK STEM AND BRACKET ASSEMBLY.........................................................................2-127

2.23 BELT GUARD AND DEBRIS DEFLECTOR.........................................................................2-129

2.24 REAR FORK........................................................................................................................2-131

2.25 SHOCK ABSORBERS........................................................................................................2-134

2.26 STABILIZER LINKS.............................................................................................................2-136

2.27 FRONT ENGINE MOUNT/ISOLATOR.................................................................................2-138

2.28 REAR ENGINE MOUNT/ISOLATOR...................................................................................2-140

2.29 THROTTLE CABLES: ALL MODELS..................................................................................2-143

2.30 CLUTCH CONTROL...........................................................................................................2-147

2.31 HANDLEBARS....................................................................................................................2-151

2.32 FRONT FENDER................................................................................................................2-157

2.33 REAR FENDER: ALL XL MODELS EXCEPT XL 883N/XL 1200N......................................2-158

2.34 REAR FENDER AND LICENSE PLATE BRACKET: XL 883N/XL 1200N...........................2-162

2.35 REAR FENDER: XR MODELS............................................................................................2-167

2.36 JIFFY STAND......................................................................................................................2-168

2.37 SEAT: XL MODELS.............................................................................................................2-170

2.38 SEAT: XR MODELS.............................................................................................................2-172

2.39 RIDER FOOT CONTROLS: XL MID-MOUNT CONTROLS.................................................2-174

2.40 RIDER FOOT CONTROLS: XL FORWARD CONTROLS...................................................2-176

2.41 RIDER FOOT CONTROLS: XR MODELS...........................................................................2-180

2.42 PASSENGER FOOTRESTS................................................................................................2-182

2.43 FORK LOCK........................................................................................................................2-184
