Harley Davidson 2015 Softail Models. Service manual - page 19

FUEL SYSTEM

SUBJECT PAGE NO.

4.1 FASTENER TORQUE VALUES.................................................................................................4-1

4.2 SPECIFICATIONS; FUEL SYSTEM..........................................................................................4-3

4.3 AIR CLEANER ASSEMBLY....................................................................................................4-4

4.4 FUEL SUPPLY LINE..................................................................................................................4-6

4.5 FUEL PRESSURE TEST...........................................................................................................4-7

4.6 FUEL TANK...............................................................................................................................4-9

4.7 CONSOLE: FXSB...................................................................................................................4-12

4.8 THROTTLE POSITION SENSOR (TPS)...............................................................................4-13

4.9 INTAKE AIR TEMPERATURE SENSOR (IAT).......................................................................4-14

4.10 ENGINE TEMPERATURE SENSOR (ET).............................................................................4-15

4.11 INDUCTION MODULE...........................................................................................................4-16

4.12 IDLE AIR CONTROL (IAC)....................................................................................................4-18

4 13 MANIFOLD ABSOLUTE PRESSURE SENSOR (MAP)........................................................4-19

4.14 OXYGEN (02) SENSOR.......................................................................................................4-20

4.15 FUEL INJECTORS.................................................................................................................4-22

4.16 FUEL PUMP AND FUEL GAUGE SENDING UNIT...............................................................4-24

4.17 EXHAUST SYSTEM..............................................................................................................4-29

4.18 INTAKE LEAK TEST..............................................................................................................4-33

4.19 EVAPORATIVE EMISSIONS CONTROL SYSTEM...............................................................4-35
