SA-71 (b) Tear down the planetary gear shaft to take out the planetary gear, planetary gear stop gasket, half-axle gear and the half axle gear thrust gasket 7. Differential assembly mount (a) Clean the differential housing. (b) Encase the half-axle thrust gasket in the differential housing after covering on the half-shaft gear. (c) Run the half-axle gear to encase the planetary gear and planetary gear stop gasket, and put on the planetary gear shaft. Remark: The half-axle gear and the planetary gear should run freely without stagnant. (d) Measure the clearance between the half axle gear thrust gasket and differential housing. Push the planetary gear to the inside and then measure the clearance between half-axle gear thrust gasket and the differential housing with the dial-indicating lamp. Suitable clearance range: (0.4-0.75)mm Remark:If the clearance fails to fall within the above- mentioned range, change the half-axle gear thrust gasket, and ensure that the thrust gaskets on the both sides are same thick. (e) Tap the pin in the pinhole of differential housing and the planetary gear shaft with SST, and rivet the hole port so as to prevent the pin from missing. Suspension System Automobile Axle (SF/4WD) Front Speed Reducer (Disassembly and Assembly of Front Speed Reducer) |
