Ford F-250 (2024 year). Manual in english

ADAPTIVE FRONT LIGHTING

(IF

EQUIPPED)

HOW DOES ADAPTIVE FRONT
LIGHTING WORK

Adaptive front lighting adapts when you
are steering around a curve or if the camera
detects lane markings indicating a curve.

E161714

Without adaptive front lighting.

With adaptive front lighting.

SWITCHING ADAPTIVE FRONT
LIGHTING ON AND OFF

Set the lighting control to the autolamps
position to use adaptive front lighting.

Note:

Other lighting control positions do

not turn on adaptive front lighting.

EXTERIOR LIGHTING VIDEOS

Intelligent Three Blink Turn Signal Video
Link

Auto High Beams Video Link

Configurable Daytime Running Lamps Video
Link

122

Exterior Lighting

SWITCHING ALL OF THE
INTERIOR LAMPS ON AND OFF

The lamps turn on under the following
conditions:

•

You open any door.

•

You press a button on the remote
control.

•

You press the all lamps on button on
the overhead console.

E259649

Press to switch all interior lamps
on or off.

SWITCHING THE FRONT
INTERIOR LAMPS ON AND OFF

E262162

The front interior lamp switches are on the
overhead console.

Note:

The position of each button on the

overhead console depends on your vehicle.

Individual Map Lamps

E262193

Press to switch the left-hand
individual dome lamp on and off.

Press to switch the right-hand
individual dome lamp on and off.

SWITCHING THE REAR
INTERIOR LAMPS ON AND OFF

E281231

The rear interior lamps may be above the
rear seat or above the rear windows.

E259649

Press to switch the lamps on or
off.

Note:

If you switch the rear lamps on

through the overhead console, you cannot
switch them off with the rear lamp switch.

INTERIOR LAMP FUNCTION

WHAT IS THE INTERIOR LAMP
FUNCTION

The interior lamp function switches the
courtesy and door lamps on or off.

SWITCHING THE INTERIOR LAMP
FUNCTION ON AND OFF

Press to switch the interior lamp
function on and off.

Note:

The indicator lamp illuminates amber

when the door function is off.

123

Interior Lighting

ADJUSTING THE INSTRUMENT
PANEL LIGHTING
BRIGHTNESS

The instrument lighting dimmer buttons
are on the lighting control.

E291299

E296433

Repeatedly press one of the
buttons to adjust the brightness.

AMBIENT LIGHTING

(IF EQUIPPED)

SWITCHING AMBIENT LIGHTING
ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle

3. Press

Ambient Light

4. Switch

Ambient Light

on or off.

Note:

You can also drag the slider all the

way to the left to switch ambient lighting
off.

ADJUSTING AMBIENT LIGHTING

Drag the slider left or right to adjust the
ambient lighting intensity.

INTERIOR LIGHTING –
TROUBLESHOOTING

INTERIOR LIGHTING –
FREQUENTLY ASKED QUESTIONS

Why do my courtesy lamps or
interior lamps turn off when I have
them switched on when I switch
my vehicle off?

•

The battery saver turns the courtesy
lamps and interior lamps off after a
short period of time after you switch
your vehicle off.

124

Interior Lighting

OPENING AND CLOSING THE
WINDOWS

WARNING:

Do not leave children

or pets unattended in your vehicle and
do not let children play with the power
windows. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

When closing the

power windows, verify that they are free
of obstructions and make sure children
and pets are not in the proximity of the
window openings. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

If an obstruction is

detected, release the switch and reverse
the window immediately. Failure to
follow this instruction could result in
personal injury or death.

WARNING:

Do not leave a key or

remote control unattended in the vehicle.
Children or pets could operate the power
windows and could become trapped in
a closing window. Failure to follow this
instruction could result in personal injury
or death.

Press the window control switch
to open the window. Lift the
window control switch to close

the window.

Note:

The power windows operate with the

ignition on, and for several minutes after you
switch the ignition off or until you open a
front door.

To reduce wind noise or pulsing noise when
one window is open, slightly open the
opposite window.

One-Touch Open

Fully press the window control switch and
release it. Press again or lift it to stop the
window.

One-Touch Close

Fully lift the window control switch and
release it. Press again or lift it to stop the
window.

Resetting One-Touch Close

Carry out all steps within 30 seconds of
starting the sequence.

Close the window.

2. Press and hold the window control

switch until the window is fully open.
Keep the window control switch
pressed for a few seconds.

3. Lift and hold the window control switch

until the window is fully closed. Keep
the window control switch held for a
few seconds.

4. Press and hold the window control

switch until the window is fully open.
Keep the window control switch
pressed for a few seconds.

5. Lift and hold the window control switch

until the window is fully closed. Keep
the window control switch held for a
few seconds.

Note:

Repeat the procedure if the window

does not close when you use one-touch.

GLOBAL OPENING

WHAT IS GLOBAL OPENING

You can use the remote control to open
the windows with the ignition off.

125

Windows

USING GLOBAL OPENING

Press and release the unlock button on
the remote control.

2. Press and hold the unlock button on

the remote control.

3. Release the button when the windows

start to open.

Press the lock or the unlock button on the
remote control to stop global opening.

Note:

You can use global opening for a

short period of time when you unlock your
vehicle using the remote control.

SWITCHING GLOBAL OPENING ON
AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Windows

4. Switch

Remote Open

on or off.

WINDOW BOUNCE-BACK

WHAT IS WINDOW BOUNCE-BACK

The window stops and reverses if it detects
an obstruction when closing.

OVERRIDING WINDOW BOUNCE-
BACK

WARNING:

If you override

bounce-back, the window does not
reverse if it detects an obstacle. Take
care when closing the windows to avoid
personal injury or damage to your
vehicle.

Close the window until it reaches the
point of resistance and let it reverse.

2. Lift and hold the window control switch

within two seconds to override
bounce-back and close the window.
Bounce-back is now disabled and you
can close the window manually.

Note:

The window goes past the point of

resistance and you can fully close it.

Note:

If the window does not close, have

your vehicle checked as soon as possible.

LOCKING THE REAR WINDOW
CONTROLS - CREW CAB/
SUPERCAB

WARNING:

When children and pets

are in the rear seat, use the power
window lockout button to prevent
accidental operation of the power
windows.

Press the window control switch
to lock or unlock the rear window
controls. It illuminates when you

lock the rear window controls.

OPENING AND CLOSING THE
SLIDING WINDOWS -
VEHICLES WITH: POWER
SLIDING REAR WINDOW

WARNING:

Do not leave children

or pets unattended in your vehicle and
do not let children play with the power
windows. Failure to follow this
instruction could result in personal injury
or death.

126

Windows

WARNING:

When closing the

WARNING:

If an obstruction is

detected, release the switch and reverse
the window immediately. Failure to
follow this instruction could result in
personal injury or death.

WARNING:

Do not leave a key or

E311430

The sliding rear window control switch is
on the overhead console.

Press and hold the sliding rear window
control switch to open the rear window.
Pull and hold the sliding rear window
control switch to close the rear window.

WINDOWS VIDEOS

One-Touch Power Windows -
Troubleshooting Video Link

127

Windows

INTERIOR MIRROR
PRECAUTIONS

WARNING:

Do not adjust the

mirrors when your vehicle is moving. This
could result in the loss of control of your
vehicle, serious personal injury or death.

Note:

Do not clean the mirror housing or

glass with harsh abrasives, fuel or other
petroleum-based cleaning products.

MANUALLY DIMMING THE
INTERIOR MIRROR

Pull the tab below the mirror toward you
to reduce glare at night.

AUTO-DIMMING INTERIOR
MIRROR

(IF EQUIPPED)

WHAT IS THE AUTO-DIMMING
INTERIOR MIRROR

The mirror dims to reduce the effect of
bright light from behind. It returns to
normal when the bright light from behind
is no longer present or if you shift into
reverse (R).

AUTO-DIMMING INTERIOR
MIRROR LIMITATIONS

Do not block the sensors on the front and
back of the mirror.

Note:

A rear center passenger or raised rear

center head restraint could prevent light
from reaching the sensor.

128

Interior Mirror

ADJUSTING THE EXTERIOR
MIRRORS

WARNING:

Do not adjust the

mirrors when your vehicle is moving. This
could result in the loss of control of your
vehicle, serious personal injury or death.

E311081

Power fold.

Window lock.

Adjustment control.

Right-hand mirror.

Left-hand mirror.

To adjust the mirrors, switch your vehicle
on and place the ignition in accessory or
start.

Select the mirror you want to adjust.
The control light turns on.

2. Use the adjustment control to adjust

the position of the mirror.

3. Press the mirror control again. The

control light turns off.

FOLDING THE EXTERIOR
MIRRORS - VEHICLES WITH:
MANUAL FOLDING MIRRORS

Push the mirror toward the door window
glass.

Make sure that you fully engage the mirror
in its support when returning it to its
original position.

FOLDING THE EXTERIOR
MIRRORS - VEHICLES WITH:
POWER FOLDING MIRRORS

The exterior mirrors fold when you lock
your vehicle and unfold when you unlock
your vehicle.

Note:

This feature requires you to switch

the exterior mirrors auto-fold on.

For tight parking conditions,
press the control switch to fold
the mirrors.

Press the control switch again to unfold
the mirrors.

Note:

Do not stop the mirrors midway

through their movement. Wait until the
mirrors stop moving and press the control
switch again.

The left and right-hand mirrors move at
different rates. For example, one mirror
may stop while the other one continues to
move. This is normal.

If you press the control switch to fold in the
mirrors with auto-fold on, the mirrors do
not unfold when you unlock your vehicle.

Note:

The power folding mirrors operate

with the ignition on, and for several minutes
after you switch the ignition off.

129

Exterior Mirrors

Note:

If you fold and unfold the mirrors

several times within one minute, the power
fold function may turn off to protect the
motors from overheating.

Switching Auto-fold On and Off

Press

Settings

on the touchscreen.

2. Press

Vehicle

3. Press

Mirrors

4. Switch

Autofold

on and off.

Loose Mirror

If you manually fold your power-folding
mirrors, they may not work properly even
after you reposition them. You need to
reset them if:
•

The mirrors vibrate when you drive.

•

The mirrors feel loose.

•

The mirrors do not stay in the folded or
unfolded position.

•

One of the mirrors is not in its normal
driving position.

To reset the mirrors, perform the following
steps:

By hand, fold or retract both mirrors.

2. Using the power folding/power

telescoping mirror control switch,
operate the mirrors until you hear an
audible click.

3. Operate the power folding or power

telescoping mirrors an additional 3 to
4 times to synchronize the mirrors.

EXTENDING THE EXTERIOR
MIRRORS

This optional feature lets you extend the
mirror about 3 in (75 mm). It is useful when
towing a trailer. You can manually pull out
or push in the mirrors to various positions.

Power Telescoping Mirrors

(If

Equipped)

This feature lets you position both mirrors
at the same time.

E218902

A. Extend.
B. Retract.

To adjust your mirrors, make sure you
switch your vehicle on, with the ignition in
accessory mode or the engine running.

Press and release the control switch.

2. Press the adjustment control to

position the mirrors.

3. Press the left arrow to extend the

mirrors out. Press the right arrow to
retract the mirrors in.

Note:

Moving the mirrors 10 or more times

within one minute, or repeated folding and
unfolding of the mirrors when holding the
control down during full travel, could disable
the system to protect the motors from
overheating. Wait approximately three
minutes with the vehicle running, and up to
10 minutes with the vehicle off, for the
system to reset and for function to return to
normal.

130

Exterior Mirrors

OPENING AND CLOSING THE
SUNSHADE

WARNING:

Do not leave a key or

remote control unattended in the vehicle.
Children or pets could operate the
sunshade and get caught in a closing
sunshade. Failure to follow this
instruction could result in personal injury.

WARNING:

Do not leave children

or pets unattended in your vehicle and
do not let children play with the
sunshade. Failure to follow this
instruction could result in personal injury.

The controls are on the overhead console.

Opening the Sunshade

E312249

Press and release the switch to
activate the one-touch open
feature. To stop movement,

press the switch a second time. The
sunshade also opens when you open the
moonroof.

Note:

The sunshade stops short of its fully

opened position for the comfort of rear
passengers. To fully open the sunshade,
press the switch again.

Closing the Sunshade

WARNING:

When closing the

sunshade, verify that it is free of
obstructions and make sure children and
pets are not in the proximity of the
sunshade. Failure to follow this
instruction could result in personal injury.

WARNING:

If an obstruction is

detected, press the switch a second time
and reverse the sunshade immediately.
Failure to follow this instruction could
result in personal injury.

E312250

Press and release the switch to
activate the one-touch close
feature. To stop movement,

press the switch a second time.

Note:

If fully open, the sunshade stops after

covering the rear glass panel. Press and
release again to fully close the sunshade.

OPENING AND CLOSING THE
MOONROOF

WARNING:

Do not leave children

or pets unattended in your vehicle and
do not let children play with the
moonroof. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Do not leave a key or

remote control unattended in the vehicle.
Children or pets could operate the
moonroof and could become trapped in
a closing moonroof. Failure to follow this
instruction could result in personal injury
or death.

The controls are on the overhead console.

Opening the Moonroof

E312251

Press and release the switch to
activate the one-touch open
feature. To stop movement,

press the switch a second time.

131

Moonroof

(If Equipped)

Note:

The moonroof stops short of the fully

opened position to reduce wind noise or
rumbling that may happen with the
moonroof fully open.

Press and release the switch again to fully
open the moonroof.

Closing the Moonroof

WARNING:

When closing the

moonroof, verify that it is free of
obstructions and make sure children and
pets are not in the proximity of the
moonroof. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

If an obstruction is

detected, release the switch and reverse
the moonroof immediately. Failure to
follow this instruction could result in
personal injury or death.

E312252

Press and release the switch to
activate the one-touch close
feature, from either the open or

vent positions. To stop movement, press
the switch a second time.

VENTING THE MOONROOF

WARNING:

Do not leave children

unattended in your vehicle and do not
let them play with the moonroof. Failure
to follow this instruction could result in
personal injury.

The moonroof controls are on the
overhead console.

E312252

With the moonroof in the closed
position, press and release the
switch to vent the moonroof. To

close the moonroof from the vent position,
press and release the switch again.

MOONROOF BOUNCE-BACK

WHAT IS MOONROOF BOUNCE-
BACK

The moonroof stops and reverses some
distance if it detects an obstacle when
closing.

OVERRIDING MOONROOF
BOUNCE-BACK

Press and hold the close switch within two
seconds after the moonroof comes to a
stop.

MOONROOF VIDEOS

Twin-panel moonroof Video Link

132

Moonroof

(If Equipped)

INSTRUMENT CLUSTER OVERVIEW - VEHICLES WITH: 4.2 INCH
SCREEN

E219638

Engine oil pressure gauge.

Engine coolant temperature gauge.

Fuel gauge.

Transmission fluid temperature gauge (gas), turbo boost (diesel).

Speedometer.

Instrument cluster display.

Tachometer.

133

Instrument Cluster

INSTRUMENT CLUSTER OVERVIEW - VEHICLES WITH: 12 INCH
SCREEN

E381908

Tachometer.

Engine coolant temperature gauge.

Configurable gauges. Oil pressure, engine oil temperature, transmission fluid
temperature, turbo boost or diesel exhaust fluid level.

Fuel gauge.

Speedometer.

Odometer.

Compass.

TACHOMETER

Indicates the engine speed.

SPEEDOMETER

Indicates the vehicle speed.

FUEL GAUGE

WHAT IS THE FUEL GAUGE

Indicates approximately how much fuel is
in the fuel tank.

134

Instrument Cluster

FUEL GAUGE LIMITATIONS

The fuel gauge may not provide an
accurate reading when your vehicle is on
an incline.

LOCATING THE FUEL FILLER
DOOR

The arrow adjacent to the fuel pump
symbol indicates on which side of your
vehicle the fuel filler door is located.

WHAT IS THE LOW FUEL
REMINDER

A low fuel level reminder displays and
sounds when the distance to empty
reaches 50 mi (80 km), 25 mi (40 km),
10 mi (20 km) and 0 mi (0 km).

Note:

The low fuel reminder can appear at

different fuel gauge positions depending on
fuel economy conditions. This variation is
normal.

WHAT IS DISTANCE TO EMPTY

Indicates the approximate distance your
vehicle can travel on the fuel remaining in
the tank. Changes in driving pattern can
cause the value to not only decrease but
also increase or stay constant for periods
of time.

Note:

When you have a trailer connected,

your distance to empty accounts for the
trailer.

ENGINE COOLANT
TEMPERATURE GAUGE

Indicates the engine coolant temperature.

ENGINE OIL PRESSURE GAUGE

Indicates the engine oil pressure.

Note:

This is a configurable gauge.

ENGINE OIL TEMPERATURE
GAUGE

Indicates the engine oil temperature.

Note:

This is a configurable gauge.

TRANSMISSION FLUID
TEMPERATURE GAUGE

Indicates the transmission fluid
temperature.

Special operating conditions can cause
higher than normal operating
temperatures. See

General Maintenance

Information

(page 589).

Note:

This is a configurable gauge.

TURBO BOOST GAUGE

Indicates the amount of manifold air
pressure in the engine.

Note:

This is a configurable gauge.

DIESEL EXHAUST FLUID
GAUGE

Indicates the current diesel exhaust fluid
level.

WHAT ARE THE INSTRUMENT
CLUSTER WARNING LAMPS

Warning lamps alert you to a vehicle
condition that could become serious.
Some lamps illuminate when you start
your vehicle to make sure they work. If any
lamps remain on after starting your vehicle,
refer to the respective system warning
lamp for further information.

135

Instrument Cluster

INSTRUMENT CLUSTER
WARNING LAMPS

Depending on your vehicle options, some
warning lamps can appear different or not
at all.

Anti-Lock Brake System

E67020

If it illuminates when you are
driving, this indicates a
malfunction. Your vehicle

continues to have normal braking without
the anti-lock brake system function. Have
your vehicle checked as soon as possible.

Battery

E67021

It illuminates when you switch
the ignition on.

If it illuminates when the engine

is running, this indicates your vehicle
requires service. Have your vehicle
checked as soon as possible.

Brake System

E270480

E67024

It illuminates when you apply the
parking brake and the ignition is
on. If it illuminates when your
vehicle is moving, make sure the
parking brake is released. If the
parking brake is released, this

indicates low brake fluid level or the brake
system requires service. Have your vehicle
checked as soon as possible.

Note:

Indicators may vary depending on

region.

Diesel Exhaust Fluid

E163176

Illuminates when the diesel
exhaust fluid is low,
contaminated or the system

requires service. See

Selective Catalytic

Reduction System

(page 222).

Door Ajar

E249859

It illuminates when you switch
the ignition on and remains on if
any door is open.

Electric Parking Brake

E325775

It illuminates or flashes when the
electric parking brake requires
service.

Note:

Indicators may vary depending on

region.

Engine Coolant Temperature

E103308

If it illuminates, safely stop your
vehicle and switch the vehicle
off.

Fasten Seatbelt

E71880

It illuminates and a tone sounds
until you fasten the seatbelts.

Hood Ajar

E296055

It illuminates when the ignition
is on and the hood is not
completely closed.

Low Fuel Level

It illuminates when the fuel level
is low.

Low Tire Pressure

E139232

It illuminates when your tire
pressure is low. If illuminated,
check your tire pressure as soon

as possible. If it begins to flash at anytime,
have the system checked as soon as
possible.

136

Instrument Cluster

Low Washer Fluid Level

E132353

It illuminates when the washer
fluid is low.

Malfunction Indicator Lamp

E67028

It illuminates when the ignition
is on and the engine is off, this is
normal. If it illuminates when the

engine is on this indicates the emission
control system requires service. If it flashes,
have your vehicle checked immediately.
See

Emission Law

(page 674). See

Starting and Stopping the Engine –
Warning Lamps

(page 204).

Oil Pressure

E67022

It illuminates when the engine
oil pressure is low.

Powertrain Malfunction, Reduced
Power, Electronic Throttle Control,
Check 4X4

Illuminates when the powertrain
or four-wheel drive require
service. Have the system

checked as soon as possible.

Tailgate Ajar

E324523

It illuminates when the ignition
is on and the tailgate is not
completely closed.

Water in Fuel

It illuminates when the fuel and
water separator has a significant
quantity of water in it and

requires immediate draining.

WHAT ARE THE INSTRUMENT
CLUSTER INDICATORS

Indicators notify you of various features
that are active on your vehicle.

INSTRUMENT CLUSTER
INDICATORS

Depending on your vehicle options, some
warning lamps can appear different or not
at all.

Adaptive Cruise Control

E144524

See

Adaptive Cruise Control

(page 294).

Automatic High Beam

E146105

Automatic Regen Control Off

E362285

See

Diesel Particulate Filter

(page 217).

Auto Hold Active

E323448

See

Auto Hold Indicators

(page 263).

Auto Hold Unavailable

E323449

See

Auto Hold Indicators

(page 263).

Blind Spot Monitor

E323542

See

Blind Spot Information

System

(page 324).

137

Instrument Cluster

Cruise Control

E332905

See

Cruise Control

(page 292).

Distance Indication

E381968

Diesel Engine Brake

E171217

E234452

See

Diesel Engine Exhaust

Brake

(page 253).

Electronic Locking Differential

E325779

Four-Wheel Drive

E181778

E181779

E181780

Note:

Some indicators appear different

depending on vehicle options.

Front Airbag

E67017

Front Fog Lamp

High Beam

E67019

Hill Descent

E163171

Lane Centering

E297977

See

Lane Centering Indicators

(page 304).

Lane Keeping System

E382218

Parking Lamps

E71341

See

Exterior Lighting Control

(page 114).

Stability Control and Traction
Control

E138639

E130458

138

Instrument Cluster

USING THE INSTRUMENT
CLUSTER DISPLAY CONTROLS

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

The controls are on the steering wheel.

E309379

Back button.

OK button.

Menu button.

Back Button

Press to go back or to exit a menu.

Button

Press to make a selection.

Menu Button

Press to display the submenus.

Scroll Buttons

Press the up or down buttons to scroll
through the menu items.

Status Indicator

E204495

Menu items with a check box
indicates a feature's status. A
check in the box indicates the

feature is on, and unchecked indicates the
feature is off.

INSTRUMENT CLUSTER
DISPLAY MAIN MENU -
VEHICLES WITH: 4.2 INCH
SCREEN

Depending on your vehicle options, some
menu items can appear different or not at
all.

Note:

For your safety, some features are

speed-dependent and could be unavailable
when your vehicle is above a certain speed.

Menu Item

Select Screens

Truck Info

Towing

Vehicle Maintenance

Settings

140

Instrument Cluster Display

INSTRUMENT CLUSTER
DISPLAY MAIN MENU -
VEHICLES WITH: 12 INCH
SCREEN

Depending on your vehicle options, some
menu items can appear different or not at
all.

Note:

For your safety, some features are

speed-dependent and could be unavailable
when your vehicle is above a certain speed.

Menu Item

MyView

Trip/Fuel

HUD

Gauges

Off Road

Towing

Status/Information

Navigation

Phone

Audio

Vehicle Maintenance

Settings

CUSTOMIZING THE
INSTRUMENT CLUSTER
DISPLAY - VEHICLES WITH: 4.2
INCH SCREEN

Adding Screens Using Select
Screens

Select

Select Screens

2. Use the controls on the steering wheel

to highlight a screen to add.

3. Press the

button.

Note:

The number of screens you can add

is limited. If the selected screen does not
appear you must deselect screens from the
Select Screens menu.

Configuring Gauges

Select

Settings

using the instrument

cluster display controls.

2. Select

Gauge Selection

3. Select to swap or change left-hand

side and right-hand side gauges.

CUSTOMIZING THE
INSTRUMENT CLUSTER
DISPLAY - VEHICLES WITH: 12
INCH SCREEN

Adding Screens Using MyView

Using the instrument cluster display
controls on the steering wheel, select

MyView

2. Select

Configure MyView

3. Select a screen.

4. Press the

button.

Note:

The number of screens you can add

is limited. If the selected screen does not
appear you must deselect screens from the
MyView menu.

Configuring Gauges

Select

Settings

2. Select

Configure Gauges

3. Select to swap or change left-hand

side and right-hand side gauges.

141

Instrument Cluster Display

CHANGING THE LANGUAGE

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Language

4. Select a language.

CHANGING THE
MEASUREMENT UNIT

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Measurement Units

4. Select a measurement unit.

CHANGING THE
TEMPERATURE UNIT

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Temperature Units

4. Select a temperature unit.

CHANGING THE TIRE
PRESSURE UNIT

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Tire Pressure Units

4. Select a pressure unit.

142

Personalized Settings

ACCESSING THE TRIP
COMPUTER - VEHICLES WITH:
4.2 INCH SCREEN

Using Select Screens

Select

Select Screens

2. Use the controls on the steering wheel

to navigate the menu. See

Customizing the Instrument Cluster
Display

(page 141). or See

Customizing the Instrument Cluster
Display

(page 141).

Using the Home Screen

After screens have been added, use the
controls on the steering wheel to view each
trip screen.

ACCESSING THE TRIP
COMPUTER - VEHICLES WITH:
12 INCH SCREEN

Select Trip/Fuel.

2. Select Trip 1 or Trip 2.

RESETTING THE TRIP
COMPUTER

Use the instrument cluster display
controls to navigate the home screen.

2. Select the trip screen you want to reset.

3. Press and hold the

button until the

system reset confirmation appears.

TRIP DATA

Trip 1 and 2

Provides trip timer, trip average fuel
economy and total trip distance traveled.

Note:

Trip 1 and 2 are selectable screens.

See

Accessing the Trip Computer

(page

143). See

Accessing the Trip Computer

(page 143).

143

Trip Computer

WHAT IS THE HEAD UP
DISPLAY

The system displays information on a
display screen in your field of vision,
allowing you to keep your eyes on the road.
You can select which information the
system displays.

SWITCHING THE HEAD UP
DISPLAY ON AND OFF

Using the instrument cluster display
controls on the steering wheel, select
HUD.

2. Switch

Head-Up Display (HUD)

on or

off.

Note:

The system remembers the last

setting when you start your vehicle.

HEAD UP DISPLAY SETTINGS

Using the instrument cluster display
controls on the steering wheel, select
HUD.

Note:

HUD On

is unchecked, other

options of the system are hidden.

You can adjust the following settings in the
HUD menu:
•

Brightness.

•

Vertical position.

•

Image rotation.

•

Content.

•

Drive mode layout.

Note:

The head up display menu

automatically closes after a certain period
of inactivity.

Note:

The head up display image brightness

automatically adjusts to the brightness of
the ambient environment. You have the
ability to adjust the brightness further
according to your preference.

Note:

In some instances, sunlight can cause

some reflections in and around the head up
display image.

Note:

When you save a memory preset

position, your current HUD settings are also
saved to that memory preset position. See

Memory Function

(page 173).

144

Head Up Display

(If Equipped)

HEAD UP DISPLAY – TROUBLESHOOTING

HEAD UP DISPLAY – INFORMATION MESSAGES

Action

Message

The system is malfunctioning or something

is obstructing the display. Make sure that

the head up display is free from obstruction.

If the message continues to appear, have

your vehicle checked as soon as possible.

Head Up Display System Fault See Manual

Press the button on the steering wheel or

center console. The head up display menu

appears in the instrument cluster display.

Make sure the blue frame is fully visible. Do

not manually move the screen. This can

cause damage not covered by your vehicle's

warranty.

Head Up Display To Position Use the

Information Display

145

Head Up Display

(If Equipped)

WHAT IS REMOTE START

The system allows you to remotely start
your vehicle and to adjust the interior
temperature according to the settings that
you chose.

REMOTE START
PRECAUTIONS

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

REMOTE START LIMITATIONS

Remote start does not work under the
following conditions:

•

The alarm horn is sounding.

•

The hood is open.

•

The transmission is not in park (P).

•

The ignition is on.

•

The battery voltage is below the
minimum operating voltage.

•

Remote start is not enabled.

Note:

Do not use remote start if the fuel

level is low.

ENABLING REMOTE START

Press

Settings

on the touchscreen.

2. Press

Vehicle

3. Press

Remote Start Setup

4. Switch

Remote Start

on or off.

Note:

To remote start with FordPass, make

sure that the modem is enabled. See

Connecting FordPass to the Modem

(page 547).

REMOTELY STARTING AND
STOPPING THE VEHICLE

Remotely Starting the Vehicle

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

Note:

You can also use FordPass to start

the vehicle.

Note:

The vehicle doors lock when you

successfully remote start your vehicle.

Note:

The turn signal lamps flash twice.

Note:

The parking lamps turn on when the

vehicle is running.

Note:

The horn sounds if the system fails

to start.

Note:

All other vehicle systems remain off

when you have remotely started the vehicle.

Note:

The vehicle remains secured when

you have remotely started the vehicle. A
valid key must be inside your vehicle to
switch the ignition on and drive your vehicle.

Remotely Stopping the Vehicle

E138625

Press the button on the remote
control.

146

Remote Start

(If Equipped)

EXTENDING THE REMOTE
START DURATION

To extend the remote start duration during
remote start, do the following:

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

If the duration is set to 15 minutes, the
duration extends by another 15 minutes.
This provides a total of 30 minutes.

Note:

Remote start can only be extended

once.

Note:

A maximum of two remote starts, or

one remote start with an extension, are
allowed. To reset the restart procedure
switch the vehicle to on, then to off.

REMOTE START SETTINGS

From the settings menu, press Vehicle.
See

Center Display

(page 562).

2. Press Remote Start Setup.

Switching Climate Control Auto
Mode On and Off

Press Climate Control.

2. Press Auto or Last Setting.

Note:

If you switch the auto mode on, the

system attempts to heat or cool the interior
to 72°F (22°C). When you switch the vehicle
on, the climate control system returns to
the last used settings.

Note:

If you switch the last settings on, the

system remembers the last used settings.

Heated Seat Settings

Press Seats.

2. Press Auto or Off.

Note:

If you switch the heated seat settings

on, the heated seats turn on during cold
weather.

Note:

You cannot adjust the heated seat

settings when you remotely start your
vehicle.

Heated Steering Wheel Settings

Press Seats and Steering Wheel.

2. Press Auto or Off.

Note:

If you switch the heated steering

wheel settings on, the heated steering wheel
turns on during cold weather.

Note:

You cannot adjust the heated

steering wheel settings when you remotely
start your vehicle.

Remote Start Duration

Press Duration.

2. Press the duration you prefer.

147

Remote Start

(If Equipped)

IDENTIFYING THE CLIMATE
CONTROL UNIT

E373067

Depending on your vehicle options, the
controls could look different than what you
see here.

SWITCHING CLIMATE
CONTROL ON AND OFF

Press the button.

SWITCHING RECIRCULATED
AIR ON AND OFF

E351062

Press the button to recirculate
air currently in the passenger
compartment.

Note:

Recirculated air may turn off

automatically, or prevent you from switching
on in all air flow modes except MAX A/C to
reduce the risk of fogging. Recirculation may
also turn on and off automatically in various
air distribution control combinations to
improve heating or cooling efficiency.

SWITCHING AIR
CONDITIONING ON AND OFF

Press the button.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

Note:

To keep the system and its

components fully functional, switch air
conditioning on and let your vehicle idle at
least once per month for a minimum of two
minutes.

SWITCHING DEFROST ON AND
OFF

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen to switch the
windshield air vents on.

E244097

Make sure that the instrument
panel air vents are switched off.

E244098

Make sure that the footwell air
vents are switched off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Press the button.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

Note:

When maximum defrost is on, the air

conditioning compressor may continue to
operate even though you switch off the air
conditioning.

148

Climate Control - Vehicles With: Automatic Temperature

Control

SWITCHING MAXIMUM
COOLING ON AND OFF

Press the button.

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
REAR WINDOW ON AND OFF

Press the button to clear the rear
window of thin ice and fog. The
heated rear window turns off

after a short period of time.

Note:

This button also activates the heated

mirrors.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window as this could cause damage to
the heated rear window grid lines not
covered by the vehicle Warranty.

SETTING THE BLOWER MOTOR
SPEED

E266187

E266186

Press up or down on the control
to select the blower motor
speed.

Note:

For Hybrid Electric Vehicle (HEV) and

Plug-In Hybrid Electric Vehicle (PHEV)
vehicles, the blower motor may run, and you
may feel airflow when the climate control
is off, to provide cooling to the battery.

SWITCHING THE HEATED
MIRRORS ON AND OFF

When you switch the heated rear window
on, the heated exterior mirrors turn on.
See

Switching the Heated Rear Window

On and Off

(page 149).

E266189

You can also turn on and off the
heated exterior mirrors using the
mirror defrost button.

Note:

Do not remove ice from the mirrors

with a scraper or adjust the mirror glass
when it is frozen in place.

Note:

Do not clean the mirror housing or

glass with harsh abrasives, fuel or other
petroleum-based cleaning products. The
vehicle warranty may not cover damage
caused to the mirror housing or glass.

Note:

The engine must be running or your

vehicle must be ready to drive to switch the
system on.

SETTING THE TEMPERATURE

E244115

Turn the control on the left-hand side of
the climate control to set the left-hand
temperature.

149

Climate Control - Vehicles With: Automatic Temperature

Control

Note:

This control also sets the right-hand

side temperature when you switch off dual
zone mode.

Turn the control on the right-hand side of
the climate control to set the right-hand
temperature.

DIRECTING THE FLOW OF AIR

Directing Air to the Windshield Air
Vents

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen.

Directing Air to the Instrument
Panel Air Vents

E265283

Press the button to activate the
selection screen.

E244097

Press the button on the
touchscreen.

Directing Air to the Footwell Air
Vents

E265283

Press the button to activate the
selection screen.

E244098

Press the button on the
touchscreen.

AUTO MODE

SWITCHING AUTO MODE ON AND
OFF

Press the button to switch auto
mode on. Repeatedly press the
button to adjust auto mode.

Note:

When you switch auto mode on,

lights on the blower motor control do not
illuminate to indicate the blower motor
speed.

Adjust the blower motor control or air
distribution control to switch auto mode
off.

SWITCHING DUAL MODE ON AND
OFF

E265280

Press the button.

CLIMATE CONTROL HINTS

General Hints

•

Prolonged use of recirculated air may
cause the windows to fog up.

•

You may feel a small amount of air
from the footwell air vents regardless
of the air distribution setting.

•

To reduce humidity build-up inside your
vehicle, do not drive with the system
switched off or with recirculated air
always switched on.

•

Do not place objects under the front
seats as this may interfere with the
airflow to the rear seats.

•

Remove any snow, ice or leaves from
the air intake area at the base of the
windshield.

•

To improve the time to reach a
comfortable temperature in hot
weather, drive with the windows open
until you feel cold air through the air
vents.

150

Climate Control - Vehicles With: Automatic Temperature

Control

Automatic Climate Control

•

Adjusting the settings when your
vehicle interior is extremely hot or cold
is not necessary. Automatic mode is
best recommended to maintain set
temperature.

•

The system adjusts to heat or cool the
interior to the temperature you select
as quickly as possible.

•

For the system to function efficiently,
the instrument panel and side air vents
should be fully open.

•

If you press

AUTO

during cold outside

temperatures, the system directs air
flow to the windshield and side window
air vents.In addition, the blower motor
may run at a slower speed until the
engine warms up.

•

If you press

AUTO

during hot

temperatures and the inside of the
vehicle is hot, the system uses
recirculated air to maximize interior
cooling. Blower motor speed may also
reduce until the air cools.

Quickly Heating the Interior

Press

AUTO

2. Adjust the temperature function to the

setting you prefer.

Recommended Settings for
Heating

Press

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Quickly Cooling the Interior

Press

MAX A/C

2. Drive with the windows open for a short

period of time.

Recommended Settings for
Cooling

Press

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Defogging the Side Windows in
Cold Weather

Press and release defrost or maximum
defrost.

2. Adjust the temperature control to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

CLIMATE CONTROL VIDEOS

Heated Mirrors

151

Climate Control - Vehicles With: Automatic Temperature

Control

IDENTIFYING THE CLIMATE
CONTROL UNIT

E308141

Depending on your vehicle options, the
controls could look different than what you
see here.

SWITCHING CLIMATE
CONTROL ON AND OFF

Press the button.

SWITCHING RECIRCULATED
AIR ON AND OFF

E351062

Press the button to recirculate
air currently in the passenger
compartment.

Note:

Recirculated air may turn off

SWITCHING AIR
CONDITIONING ON AND OFF

Press the button.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

Note:

To keep the system and its

components fully functional, switch air
conditioning on and let your vehicle idle at
least once per month for a minimum of two
minutes.

SWITCHING DEFROST ON AND
OFF

Press the button to switch the
windshield air vents on.

E244097

Make sure that the instrument
panel air vents are switched off.

E244098

Make sure that the footwell air
vents are switched off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Turn the temperature control
clockwise past the highest
setting to maximize defrosting.

Note:

The temperature control springs back

to the highest setting.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

152

Climate Control - Vehicles With: Manual Temperature Control

SWITCHING MAXIMUM
COOLING ON AND OFF

Turn the temperature control
counterclockwise past the
lowest setting to maximize

cooling.

Note:

The temperature control springs back

to the lowest setting.

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
REAR WINDOW ON AND OFF

(IF

EQUIPPED)

Press the button to clear the rear
window of thin ice and fog. The
heated rear window turns off

after a short period of time.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window as this could cause damage to
the heated rear window grid lines not
covered by the vehicle Warranty.

SETTING THE BLOWER MOTOR
SPEED

E317606

Turn the blower motor control
counterclockwise for a lower blower
setting.

Turn the blower motor control clockwise
for a higher blower setting.

Note:

Lights on the control illuminate to

indicate the blower motor speed.

Note:

When you switch the blower motor

off, air conditioning turns off and the
windows could fog up.

SWITCHING THE HEATED
MIRRORS ON AND OFF

When you switch the heated rear window
on, the heated exterior mirrors turn on.
See

Switching the Heated Rear Window

On and Off

(page 149).

E266189

You can also turn on and off the
heated exterior mirrors using the
mirror defrost button.

Note:

Do not remove ice from the mirrors

with a scraper or adjust the mirror glass
when it is frozen in place.

153

Climate Control - Vehicles With: Manual Temperature Control

Ford F-250 (2024 year). Manual in english - page 4
