Ford F-650 / 750 (2023 year). Manual in english

In satellite radio mode, press and release
to select the next or previous satellite radio
station. If you select a specific category,
such as jazz, rock or news, press to find the
next or previous station in the category you
select.

CONNECTING A BLUETOOTH®
DEVICE

Pairing a Device

E142607

Press the button.

Select

Bluetooth®

and follow the

instructions on the screen.

Note:

When pairing a new device, you can

choose to download contacts, set this as
the primary device and enable Emergency
Assistance.

STREAMING BLUETOOTH
AUDIO

Selecting a

Bluetooth®

Source

E100027

Press the button to display the menu.

2. Repeatedly press the button to scroll

to the

Bluetooth®

device.

3. Press the

button.

Press the button to play the
track. Press the button again to
pause the track.

Press the button to skip to the
next track.

Press and hold the button to fast

forward through the track.

Press the button once to return
to the beginning of the track.
Repeatedly press the button to

return to previous tracks.

Press and hold the button to fast rewind.

Note:

Not all functions are supported by all

phones.

PLAYING MEDIA FROM A USB
DEVICE

Supported Audio File Formats

You can play audio file formats including
MP3, WMA, WAV, M4A, M4B, AAC, and
FLAC.

Note:

The NTFS file system is not

supported.

Selecting the USB Device

E100027

Press the button to display the
menu.

Repeatedly press the button to scroll to
your USB device.

Press the

button.

Playing from the USB Device

Press the button to play a track.
Press the button again to pause
the track.

Press the button to skip to the
next track.

Press and hold the button to fast

forward through the track.

Press the button once to return
to the beginning of a track.
Repeatedly press the button to

return to previous tracks.

Press and hold the button to fast rewind.

312

Audio System

(If Equipped)

Sorting by Categories

You can also sort and play music by
specific categories, for example artist or
album.

Press the

button to view the available

categories.

AUDIO INPUT JACK

(IF EQUIPPED)

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

WARNING:

Always place your

device in a secure location in your vehicle
so it does not become a projectile in a
sudden stop or crash. Failure to follow
this instruction could result in personal
injury.

E191758

The auxiliary input jack allows you to
connect and play music from your portable
music player through your vehicle speakers.
You can use any portable music player
designed for use with headphones. Your
audio extension cable must have male
connectors at each end.

Make sure your vehicle is stationary
with the audio unit and the portable
music player switched off.

2. Plug the extension cable from the

device into the audio input jack.

3. Switch on the radio and select either a

tuned FM station or a CD.

4. Adjust the volume as desired.

5. Switch on your device and adjust the

volume to half the maximum level.

6. Press

AUX

until

LINE

LINE IN

appears in the display. You should hear
music from your device even if it is low.

Adjust the volume on your device until
it reaches the volume level of the FM
station or CD. Do this by switching back
and forth between the

AUX

and FM or

CD controls.

Use the vehicle audio unit buttons to
restore playback from the vehicle audio
unit, while your device remains connected.

Note:

The audio extension cable must be

long enough for you to safely store the
device when your vehicle is moving.

Note:

For optimum performance when

using any auxiliary device set the volume on
the device high. This reduces audio
interference when charging the device using
the vehicle power supply.

Note:

For safety reasons, do not connect

or adjust the settings on your device while
your vehicle is moving.

313

Audio System

(If Equipped)

USB PORT

WARNING:

Driving while distracted

E201595

The USB port allows you to plug in media
playing devices, memory sticks and charge
devices.

Note:

Not all USB ports in your vehicle have

data transfer capabilities. See

Auxiliary

Power Points

(page 95).

USING VOICE RECOGNITION

Phone Voice Service

This system allows you to use the voice
recognition features of your phone and
focus on your driving.

E142599

Press and hold the voice control
button on the audio unit.

Note:

This only works when connected via

Bluetooth. See

Connecting a Bluetooth®

Device

(page 312).

Note:

When using voice recognition use the

language set on the device.

Note:

We recommend that you check your

data plan before using your phone voice
service through the system. Using them
could result in additional charges.

314

Audio System

(If Equipped)

AUXILIARY SWITCHES

(IF

EQUIPPED)

For maximum vehicle performance, keep
the following information in mind when
adding accessories or equipment to your
vehicle:

•

When adding accessories, equipment,
passengers and luggage to your
vehicle, do not exceed the total weight
capacity of the vehicle or of the front
or rear axle (GVWR or GAWR as
indicated on the Safety Compliance
Certification label). Ask an authorized
dealer for specific weight information.

•

The Federal Communications
Commission (FCC) and Canadian
Radio Telecommunications
Commission (CRTC) regulate the use
of mobile communications systems
equipped with radio transmitters, for
example, two-way radios, telephones
and theft alarms. Any such equipment
installed in your vehicle should comply
with Federal Communications
Commission (FCC) and Canadian
Radio Telecommunications
Commission (CRTC) regulations, and
should be installed by an authorized
dealer.

•

An authorized dealer needs to install
mobile communications systems.
Improper installation may harm the
operation of your vehicle, particularly
if the manufacturer did not design the
mobile communication system
specifically for automotive use.

•

If you or an authorized Ford dealer add
any non-Ford electrical or electronic
accessories or components to your
vehicle, you may adversely affect
battery performance and durability. In
addition, you may also adversely affect
the performance of other electrical
systems in the vehicle.

E163431

The auxiliary switch option package
provides four switches, mounted in the
center of the instrument panel. These
switches operate when the ignition is on
or from battery power, depending on the
switchable power distribution box fuse
locations #82 and #83. We recommend,
however, that the engine remain running
to maintain battery charge when using the
auxiliary switches for extended periods of
time or higher current draws.

Note:

When your vehicle has a diesel

engine, use the auxiliary switches only while
the engine is running. The glow plugs also
drain battery power when the ignition key is
in the on position. Using the auxiliary
switches, even for limited amounts of time,
can cause your battery to drain quickly and
prevent your vehicle from restarting.

When switched on, the auxiliary switches
provide 20 amps or 40 amps of electrical
battery power for a variety of personal or
commercial uses.

The relays for the auxiliary switches are in
the power distribution box under the hood
by the right-hand fender. See your
authorized dealer for service.

Each switch includes a power lead, a
blunt-cut and sealed wire below the
instrument panel and to the left of the
steering column in the driver footwell area.

The power leads are coded as shown:

315

Accessories

Fuse
Amp

Rating

Wire

Color

Circuit

Number

Switch

40A

Yellow

CAC05

AUX 1

40A

Green

with

Brown

Trace

CAC06

AUX 2

20A

Violet

with

Green

Trace

CAC07

AUX 3

20A

Brown

CAC08

AUX 4

Learn more about auxiliary switches
by visiting:

Web Address

www.fleet.ford.com/truckbbas/

Upfitter Interface Module

(If Equipped)

The Upfitter Interface Module (UIM) is an
electronic control module that operates
equipment, such as lift buckets, cranes,
motors, salt spreaders and snow plows,
with external relays.

If you replace the module, it will require
additional programming by the upfitter.
Obtain this data directly from the upfitter
company. The upfitter contact information
is in the vehicle door opening.

For more information on the Upfitter
Interface Module and the auxiliary
switches, contact your upfitter.

316

Accessories

PROTECT YOURSELF FROM THE RISING
COST OF VEHICLE REPAIRS WITH A FORD
PROTECT EXTENDED SERVICE PLAN.

Ford Protect Extended Service
Plans (U.S. Only)

Ford Protect extended service plan means
peace of mind. It is the extended service
plan backed by Ford Motor Company, and
provides more protection beyond the New
Vehicle Limited Warranty coverage. When
you visit your Ford Dealer, Insist on Ford
Protect extended service plans!

Ford Protect Can Quickly Pay for Itself

One trip to the Service Center could easily
exceed the price of your Ford Protect
extended service plan. With Ford Protect
extended service plan you minimize your
risk for unexpected repair bills and rising
repair costs.

Up to 1,000+ Covered Vehicle
Components

There are four mechanical Ford Protect
extended service plans with different levels
of coverage. Ask your authorized dealer for
details.

PremiumCARE - Our most
comprehensive coverage. With over
1,000 covered components, this plan
is so complete it is probably easier to
list what is not covered.

2. ExtraCARE - Covers 113 components,

and includes many high-tech items.

3. BaseCARE - Covers 84 components.

4. PowertrainCARE - Covers 29 critical

components.

Ford Protect extended service plans are
honored by all authorized Ford dealers in
the U.S., Canada and Mexico.

That means you get:

•

Reliable, quality service at any Ford or
Lincoln dealership.

•

Repairs performed by factory trained
technicians, using genuine parts.

Rental Car Reimbursement

1st day Rental Benefit

If you bring your car into your dealer for
service, we’ll give you a loaner to use for
the day.

Extended Rental Benefits

If your vehicle is kept overnight for covered
repairs, you are eligible for rental car
coverage, including warranty repairs, and
Field Service Actions.

Roadside Assistance

Exclusive 24/7 roadside assistance,
including:

•

Towing, flat-tire change and battery
jump starts.

•

Out of fuel and lock-out assistance.

•

Travel expense reimbursement for
lodging, meals and rental car.

•

Assistance for taxi, shuttle, rental car
coverage or other transportation.

Transferable Coverage

If you sell your vehicle before your Ford
Protect extended service plan coverage
expires, you can transfer any remaining
coverage to the new owner. Which should
give you and your potential buyer a little
more peace of mind.

317

Ford Protect

Less Cost to Properly Maintain Your
Vehicle

Ford Protect extended service plan also
offers a Premium Maintenance Plan that
covers all scheduled maintenance, and
selected wear items. The coverage is
prepaid, so you never have to worry about
the cost of your vehicle’s maintenance.

Covered maintenance includes:

•

Windshield wiper blades.

•

Spark plugs.

•

The clutch disc (if equipped).

•

Brake pads and linings.

•

Shock absorbers.

•

Struts.

•

Engine belts.

•

Engine coolant hoses, clamps and
O-rings.

•

Diesel exhaust fluid replenishment (if
equipped).

•

Cabin air filter replacement every
20,000 mi (32,000 km) (electric
vehicles only).

Interest Free Finance Options

Just a 5% down payment will provide you
with an affordable, no interest, no fee
payment program allowing you all the
security and benefits Ford Protect
extended service plan has to offer while
paying over time. You are pre-approved
with no credit check or hassles. To learn
more, call our Ford Protect extended
service plan specialists at 800-367-3377.

Ford Protect Extended Service Plan
P.O. Box 321067
Detroit, MI 48232

Ford Protect Extended Service
Plan (CANADA ONLY)

You can get more protection for your
vehicle by purchasing a Ford Protect
extended service plan. Ford Protect
extended service plan is the only service
contract backed by Ford Motor Company
of Canada, Limited. Depending on the plan
you purchase, Ford Protect extended
service plan provides benefits such as:

•

Rental reimbursement.

•

Coverage for certain maintenance and
wear items.

•

Protection against repair costs after
your New Vehicle Limited Warranty
Coverage expires.

•

Roadside Assistance benefits.

There are several Ford Protect extended
service plans available in various time,
distance and deductible combinations.
Each plan is tailored to fit your own driving
needs, including reimbursement for towing
and rental. When you purchase Ford
Protect extended service plan, you receive
added peace-of-mind protection
throughout Canada, the United States and
Mexico, provided by a network of
participating authorized Ford Motor
Company dealers.

Note:

Repairs performed outside of Canada

and the United States are not eligible for
Ford Protect extended service plan
coverage.

This information is subject to change. For
more information; visit your local Ford of
Canada dealer or www.ford.ca to find the
Ford Protect extended service plan that is
right for you.

318

Ford Protect

GENERAL MAINTENANCE
INFORMATION

Why Maintain Your Vehicle?

Carefully following the maintenance
schedule helps protect against major repair
expenses resulting from neglect or
inadequate maintenance and may help to
increase the value of your vehicle when
you sell or trade it. Keep all receipts for
completed maintenance with your vehicle.

We have established regular maintenance
intervals for your vehicle based upon
rigorous testing. It is important that you
have your vehicle serviced at the proper
times. These intervals serve two purposes;
one is to maintain the reliability of your
vehicle and the second is to keep your cost
of owning your vehicle down.

It is your responsibility to have all
scheduled maintenance performed and to
make sure that the materials used meet
the specifications identified in this owner's
manual. See

Motorcraft Parts

(page 291).

Failure to perform scheduled maintenance
invalidates warranty coverage on parts
affected by the lack of maintenance.

Why Maintain Your Vehicle at Your
Dealership?

Factory-trained Technicians

Service technicians participate in extensive
factory-sponsored certification training to
help them become experts on the
operation of your vehicle. Ask your
dealership about the training and
certification their technicians have
received.

Genuine Ford and Motorcraft
Replacement Parts

Dealerships stock Ford, Motorcraft and
Ford-authorized branded re-manufactured
replacement parts. These parts meet or
exceed our specifications. Parts installed
at your dealership carry a nationwide
12-month or 12,500 mi (20,000 km) parts
and labor limited warranty.

If you do not use Ford authorized parts they
may not meet our specifications and
depending on the part, it could affect
emissions compliance.

Convenience

Many dealerships have extended evening
and Saturday hours to make your service
visit more convenient and they offer one
stop shopping. They can perform any
services that are required on your vehicle,
from general maintenance to collision
repairs.

Note:

Not all dealers have extended hours

or body shops. Please contact your dealer
for details.

Protecting Your Investment

Maintenance is an investment that pays
dividends in the form of improved
reliability, durability and resale value. To
maintain the proper performance of your
vehicle and its emission control systems,
make sure you have scheduled
maintenance performed at the designated
intervals.

Diesel Engine

Your vehicle is equipped with the
Intelligent Oil-Life Monitor system, which
displays a message in the information
display at the proper oil change interval.
This interval may be up to one year or
10,000 mi (16,000 km).

319

Scheduled Maintenance

A message appears in the information
display when it is time for an oil change.
Make sure you perform the oil change
within two weeks or 500 mi (800 km) of
the message appearing. Make sure you
reset the Intelligent Oil-Life Monitor after
each oil change. See

Instrument Cluster

(page 63).

If your information display resets
prematurely or becomes inoperative, you
should perform the oil change interval at
six months or 5,000 mi (8,000 km) from
your last oil change. Never exceed one year
or 10,000 mi (16,000 km) between oil
change intervals.

All Vehicles

Your vehicle is very sophisticated and built
with multiple, complex, performance
systems. Every manufacturer develops
these systems using different
specifications and performance features.
That is why it is important to rely upon your
dealership to properly diagnose and repair
your vehicle.

Ford Motor Company has recommended
maintenance intervals for various parts
and component systems based upon
engineering testing. Ford Motor Company
relies upon this testing to determine the
most appropriate mileage for replacement
of oils and fluids to protect your vehicle at
the lowest overall cost to you and
recommends against maintenance
schedules that deviate from the scheduled
maintenance information.

We strongly recommend the use of only
genuine Ford, Motorcraft or
Ford-authorized re-manufactured
replacement parts engineered for your
vehicle.

Additives and Chemicals

This owner's manual and the Ford
Workshop Manual list the recommended
additives and chemicals for your vehicle.
We do not recommend using chemicals or
additives not approved by us as part of
your vehicle’s normal maintenance. Please
consult your warranty information.

Oils, Fluids and Flushing

In many cases, fluid discoloration is a
normal operating characteristic and, by
itself, does not necessarily indicate a
concern or that the fluid needs to be
changed. However, a qualified expert, such
as the factory-trained technicians at your
dealership, should inspect discolored fluids
that also show signs of overheating or
foreign material contamination
immediately.

Make sure to change your vehicle’s oils and
fluids at the specified intervals or in
conjunction with a repair. Flushing is a
viable way to change fluid for many vehicle
sub-systems during scheduled
maintenance. It is critical that systems are
flushed only with new fluid that is the same
as that required to fill and operate the
system or using a Ford-approved flushing
chemical.

Scheduled Maintenance Services

Maintenance service adjustments must
conform to specifications contained in this
manual, and those shown on the Important
Engine Information decal. Perform the
following services at scheduled intervals
because they essential to the life and
performance of your vehicle. Ford
recommends that you perform
maintenance on all designated items to
achieve best vehicle operation.

320

Scheduled Maintenance

There are three types of maintenance
intervals for general vehicle environments:
On-Highway, City and Severe Service. In
all applications, monitoring miles
(kilometers) and time and when the engine
is due for an oil change determine the
actual interval. When the engine oil change
is required before the truck lubrication
interval, perform the lubrication at the
same time in order to reduce your vehicle’s
time out of service.

Air Brake Adjustment

WARNING:

Failure to maintain

proper air brake adjustment can result
in reduction or loss of braking ability.

A qualified service technician, keeping to
the instructions in the service manual,
should perform air brake inspection and
adjustment or repairs.

Cam Brakes - Automatic Slack
Adjusters

WARNING:

Do not manually adjust

the automatic slack adjusters to correct
excessive push rod stroke as it may result
in reduced brake effectiveness and a
vehicle crash. Excessive push rod stroke
indicates that a problem exists with the

automatic adjuster, with the installation
of the adjuster, or with foundation brake
components that manual adjustment
does not remedy. Seek service from a
qualified facility for excessive push rod
stroke.

Inspect standard air brakes equipped with
automatic slack adjusters for proper brake
adjustment as listed in the maintenance
schedule charts.

However, inspect the brakes more
frequently when subjecting them to heavy
use or adverse operating conditions such
as:

•

Frequent brake applications while fully
loaded.

•

Operation on hilly or mountainous
terrain.

•

Frequent operation on dirt, gravel or
mud.

Some aftermarket brake linings also
require more frequent inspections.

Owner Checks and Services

Make sure you perform the following basic
maintenance checks and inspections every
month or at six-month intervals.

Check Every Month

Air filter restriction gauge.

Engine oil level.

Fuel and water separator. Drain if necessary, or if indicated by the information display.

Function of all interior and exterior lights.

Holes and slots in the tail pipe to make sure they are functional and clear of debris.

321

Scheduled Maintenance

Check Every Month

Tires (including spare) for wear and proper pressure.

Windshield washer fluid level.

Diesel engine only.

Check Every Six Months

Battery connections. Clean if necessary.

Body and door drain holes for obstructions. Clean if necessary.

Cooling system fluid level and coolant concentration (freeze-point protection).

Door weatherstrips for wear. Lubricate if necessary.

Hinges, latches and outside locks for proper operation. Lubricate if necessary.

Parking brake for proper operation.

Safety belts and seat latches for wear and function.

Safety warning lamps (brake, ABS, airbag and safety belt) for operation.

Washer spray and wiper operation. Clean or replace blades as necessary.

Tightening Lug Nuts

Tighten the lug nuts to the specified torque

at 500 mi

(800 km) after any wheel disturbance (such as tire rota-
tion, changing a flat tire or wheel removal).

Single rear wheels

Tighten the wheel lug nuts to the specified torque

100 mi (160 km), and again at 500 mi (800 km) of new

vehicle operation and after any wheel disturbance (such

as tire rotation, changing a flat tire or wheel removal).

Dual rear wheels

See

Technical Specifications

(page 286).

322

Scheduled Maintenance

Multi-point Inspection

In order to keep your vehicle running right,
it is important to have the systems on your
vehicle checked regularly. This can help
identify potential issues and prevent major

problems. We recommend having the
following multi-point inspection performed
at every scheduled maintenance interval
to help make sure your vehicle keeps
running great.

Multi-point Inspection

Horn operation

Accessory drive belt(s)

Radiator, cooler, heater and A/C hoses

Battery performance

Suspension component for leaks or

damage

Engine air filter

Steering and linkage

Exhaust system

Tires (including spare) for wear and proper

pressure

Exterior lamps operation

Windshield for cracks, chips or pits

Fluid levels

; fill if necessary

Washer spray and wiper operation

For oil and fluid leaks

Hazard warning system operation

Hood rest for lubrication

Brake, coolant recovery reservoir, automatic transmission, power steering and window

washer.

If your vehicle is equipped with a temporary mobility kit, check the tire sealant expiration

Use By date on the canister. Replace as needed.

Be sure to ask your dealership service
advisor or technician about the multi-point
vehicle inspection. It is a comprehensive
way to perform a thorough inspection of
your vehicle. Your checklist gives you
immediate feedback on the overall
condition of your vehicle.

NORMAL SCHEDULED
MAINTENANCE

Intelligent Oil-Life Monitor™ -
Diesel Engine Only

Your diesel engine has an Intelligent
Oil-Life Monitor that determines when you
should change the engine oil based on how
you use your vehicle. By using several
important factors in its calculations, the
monitor helps reduce the cost of owning
your vehicle and reduces environmental
waste at the same time.

323

Scheduled Maintenance

This means you do not have to remember
to change the oil on a mileage-based
schedule. Your vehicle lets you know when
an oil change is due by displaying a
message in the information display.

The following table provides examples of
vehicle use and its impact on oil change
intervals. It is a guideline only. Actual oil
change intervals depend on several factors
and generally decrease with severity of
use.

When to Expect the OIL CHANGE REQUIRED Message

Vehicle Use and Example

Interval

Normal

7,500–10,000 mi

(12,000–16,000 km)

Normal commuting with highway driving
No, or moderate, load or towing
Flat to moderately hilly roads
No extended idling

Severe

5,000–7,500 mi

(8,000–12,000 km)

Moderate to heavy load or towing
Mountainous or off-road conditions
Extended idling
Extended hot or cold operation

Extreme

3,000–5,000 mi

(4,800–8,000 km)

Maximum load or towing
Extreme hot or cold operation
Use of high sulfur diesel fuel

Note:

Use the appropriate special operating

condition for maintenance information
when using high sulfur diesel fuels,
operating your vehicle off-road or in dusty
conditions, such as unpaved roads.

Normal Maintenance Intervals

Note:

Do not exceed the mileage or time

intervals.

324

Scheduled Maintenance

Gasoline Engines

7,500 mi (12,000 km) or Six Months Whichever Comes First

Rotate the tires, inspect tire wear and measure the tread depth.

Inspect the wheels and related components for abnormal noise, wear, looseness or
drag.

Perform a multi-point inspection, recommended.

Inspect front oil hubs for leaks and check fluid level through hub cap sight glass.

Rotate the front wheels on vehicles with dual rear wheels when specified. Only rotate

the rear wheels if you notice unusual wear.

10,000 mi (16,000 km)/450 Engine Hours or 12 Months Whichever Comes First

Change the engine oil and filter.

15,000 mi (24,000 km) or 12 Months Whichever Comes First

Inspect the automatic transmission fluid level. Consult an authorized dealer for
requirements.

Inspect the brake pads, shoes, rotors, drums, brake linings, hoses and the parking brake.

Inspect the engine cooling system concentration, freeze-point protection, level and
hoses.

Inspect the exhaust system and heat shields.

Inspect the steering linkage, ball joints, suspension, tie-rod ends, driveshaft and the U-
joints. Lubricate any components that have grease fittings.

Brake Fluid Maintenance

Change the brake fluid.

Every 3 Years

Perform this maintenance item every 3 years. Do not exceed the designated time for

the interval.

Brake fluid servicing requires special equipment available at your authorized dealer.

325

Scheduled Maintenance

Other Maintenance Items

Replace the engine air filter.

Every 30,000 mi
(48,000 km)

Replace the front wheel bearing grease and grease seal
if you have non-sealed bearings.

Every 60,000 mi
(96,000 km)

Replace the spark plugs.

Every 97,000 mi
(156,000 km)

Replace the spark plug wires.

Change the rear axle fluid. See

Special Operating

Conditions Scheduled Maintenance

(page 329).

Every 105,000 mi
(168,000 km)

Inspect the accessory drive belt or belts.

Change the automatic transmission fluid and filter. Consult
an authorized dealer for requirements.

Every 150,000 mi
(240,000 km)

Replace the accessory drive belt or belts if not replaced
within the last 100,000 mi (160,000 km).

Replace the front wheel bearings and seals if you have
non-sealed bearings.

Change the engine coolant.

Every 200,000 mi
(320,000 km)

If not replaced, inspect every 15,000 mi (24,000 km).

Initial replacement at 10 years or 200,000 mi (320,000 km), then every five years or

100,000 mi (160,000 km).

Diesel Engine

Note:

Do not exceed the mileage or time

intervals.

At Every Oil Change Interval as Indicated by the Information Display

Change the engine oil and filter.

Drain the fuel filter water trap.

Refill the diesel exhaust fluid tank.

Rotate the tires, inspect the tires for wear and measure the tread depth.

326

Scheduled Maintenance

At Every Oil Change Interval as Indicated by the Information Display

Perform a multi-point inspection, recommended.

Inspect the air filter restriction gauge. Replace the filter if necessary.

Inspect the automatic transmission fluid level. Consult an authorized dealer for
requirements.

Inspect the brake pads, shoes, rotors, drums, brake linings, hoses and the parking brake.

Inspect the engine and secondary coolant concentration, freeze-point protection, level
and hoses.

Inspect the exhaust system and heat shields.

Inspect the steering linkage, ball joints, suspension, tie-rod ends, driveshaft and the U-
joints. Lubricate any components that have grease fittings.

Inspect front oil hubs for leaks and check fluid level through hub cap sight glass.

Do not exceed one year/10,000 mi (16,000 km) or 350 engine hours between service

intervals.

Reset the Intelligent Oil-Life Monitor after engine oil and filter changes. See

Oil Change

Indicator Reset

(page 227).

Rotate the front wheels on vehicles with dual rear wheels when specified. Only rotate

the rear wheels if you notice unusual wear.

Brake Fluid Maintenance

Change the brake fluid.

Every 3 Years

Perform this maintenance item every 3 years. Do not exceed the designated time for

the interval.

Brake fluid servicing requires special equipment available at your authorized dealer.

Other Maintenance Items

Replace the engine-mounted and frame-mounted fuel

filters.

Every 22,000 mi
(36,000 km)

Inspect the engine and secondary cooling system coolant
concentration, freeze-point protection, additive, corrosion
inhibitor, strength, coolant level, and hoses. Add coolant

additive if necessary.

Every 30,000 mi
(48,000 km)

327

Scheduled Maintenance

Ford F-650 / 750 (2023 year). Manual in english - page 20
