OPENING THE TAILGATE

OPENING THE TAILGATE FROM
OUTSIDE YOUR VEHICLE

E323095

Unlock the vehicle with the remote
control or power door unlock control.

Note:

If a passive key is within 3 ft (1 m) of

the tailgate, the tailgate unlocks when you
touch the inside of the tailgate handle.

2. Pull the handle to release the tailgate.

CLOSING THE TAILGATE

CLOSING THE TAILGATE FROM
OUTSIDE YOUR VEHICLE

E323153

Push the tailgate until fully closed.

LOCKING AND UNLOCKING
THE TAILGATE

You can lock or unlock your vehicle with
the remote control or power door lock
control.

Locking

If a passive key is within 5 ft (1 m) of the
tailgate, touch the lock button on the
tailgate handle to lock.

Tailgate

E323094

Unlocking

If a passive key is within 5 ft (1 m) of the
tailgate, touch the back of the tailgate
handle to unlock.

E323096

Emergency Locking

If there is a power door lock fault you can
use the key blade to lock the tailgate door.

E342916

Emergency Unlocking

If there is a power door lock fault you can
use the release lever to unlock the tailgate
door.

Tailgate

E342902

Remove the tailgate trim panel.

2. Remove the inside release lever cover.

3. Using a small tool, pull the release lever

to open the tailgate.

4. Reinstall the inside release lever cover

and trim panel after unlocking the
tailgate.

TAILGATE –
TROUBLESHOOTING

TAILGATE – WARNING LAMPS

E340897

Illuminates when the tailgate is
not completely closed.

TAILGATE – INFORMATION MESSAGES

Tailgate

Details

Message

The tailgate is not completely closed.

Tailgate Ajar

Tailgate

PASSIVE ANTI-THEFT
SYSTEM

WHAT IS THE PASSIVE ANTI-
THEFT SYSTEM

The passive anti-theft system prevents
someone from starting the vehicle with an
incorrectly coded key.

Note:

Do not leave a duplicate coded key

in your vehicle. Always take the keys and
lock all the doors when leaving your vehicle.

HOW DOES THE PASSIVE ANTI-
THEFT SYSTEM WORK

The passive anti-theft system arms when
you switch the ignition off.

It disarms when the ignition is switched on
with a correctly coded key.

Note:

The system is not compatible with

non-Ford aftermarket remote start systems.

Note:

Do not leave a duplicate coded key

in your vehicle. Always take the keys and
lock all doors when leaving your vehicle.

SECURITY – TROUBLESHOOTING

SECURITY – INFORMATION MESSAGES

Action

Message

The system has not detected a correctly coded key.

No Key Detected

The system has malfunctioned. Have your vehicle checked
as soon as possible.

Starting System Fault

Displays when the alarm has been triggered due to unauthor-
ized entry.

Vehicle Alarm To Stop
Alarm, Start Vehicle.

Alarm Announcement

Security

SECURITY – FREQUENTLY ASKED
QUESTIONS

What should I do if there is any
potential alarm problem with my
vehicle?

Take all remote controls to an
authorized dealer if there is any
potential alarm problem with your
vehicle.

What should I do if the vehicle is unable
to start with a correctly coded key?

Have your vehicle checked as soon as
possible.

Security

ADJUSTING THE STEERING
WHEEL

WARNING:

Do not adjust the

steering wheel when your vehicle is
moving.

Note:

Make sure that you are sitting in the

correct position. See

Sitting in the Correct

Position

(page 127).

E359744

Unlock the steering column.

2. Adjust the steering wheel to the

position you prefer.

3. Lock the steering column.

HORN

E270945

Press on the center of the
steering wheel near the horn icon
to activate the horn.

SWITCHING THE HEATED
STEERING WHEEL ON AND OFF

(IF EQUIPPED)

To activate the heated steering
wheel, press the button on the
climate control unit.

On some vehicles, an indicator on the
button illuminates when the heated
steering wheel is on.

Note:

A sensor regulates the temperature

of the steering wheel.

Steering Wheel

WIPERS

WIPER PRECAUTIONS

Do not operate the wipers on a dry
windshield. This could scratch the glass or
damage the wiper blades. Use the
windshield washers before wiping a dry
windshield.

Fully defrost the windshield before you
switch the windshield wipers on.

Switch the windshield wipers off before
entering a car wash.

SWITCHING WINDSHIELD WIPERS
ON AND OFF

E327739

High-speed wipe.

Intermittent wipe.

Off.

E270969

Use the rotary control.

SWITCHING THE REAR
WINDOW WIPER ON AND OFF

E340280

Rotate the control away from you for a
long wipe interval.

Rotate the control toward you for a short
wipe interval.

REVERSE WIPE

WHAT IS REVERSE WIPE

Reverse wipe turns on the rear window
wiper when you shift into reverse (R) and
the windshield wipers are on.

REVERSE WIPE SETTINGS

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Wipers

4. Switch

Rear Wiper On (when in

Reverse)

on or off.

Wipers and Washers

CHECKING THE WIPER
BLADES

E142463

Run the tip of your fingers over the edge of
the blade to check for roughness.

REPLACING THE FRONT
WIPER BLADES

E165804

Pull the wiper blade and arm away
from the glass.

Note:

Do not hold the wiper blade to lift the

wiper arm.

E327597

2. Lift the wiper blade primary locking clip.

E327598

3. Press the wiper blade secondary

locking clip.

4. Remove the wiper blade.

Note:

Make sure that the wiper arm does

not spring back against the glass when the
wiper blade is not attached.

5. To install, reverse the removal

procedure.

Note:

Make sure that the wiper blade locks

into place.

Wipers and Washers

REPLACING THE REAR WIPER
BLADES

E271380

Lift the wiper arm.

Note:

Do not hold the wiper blade to lift the

wiper arm.

2. Remove the wiper blade.

Note:

Make sure that the wiper arm does

not spring back against the glass when the
wiper blade is not attached.

3. To install, reverse the removal

procedure.

Note:

Make sure that the wiper blade locks

into place.

WASHERS

WASHER PRECAUTIONS

WARNING:

If you operate your

vehicle in temperatures below 41°F
(5°C), use washer fluid with antifreeze
protection. Failure to use washer fluid
with antifreeze protection in cold
weather could result in impaired
windshield vision and increase the risk
of injury or accident.

Do not operate the washers when the
washer reservoir is empty. This could cause
the washer pump to overheat.

Keep the outside of the windshield clean.
The rain sensor is very sensitive and the
wipers may operate if dirt, mist or insects
hit the windshield.

USING THE WINDSHIELD WASHER

E311291

E270967

Press and hold the button at the
end of the lever to operate the
windshield washer.

Note:

A courtesy wipe occurs a short time

after the wipers stop to clear any remaining
washer fluid when switched on. See

Switching the Courtesy Wipe On and Off

(page 93).

Wipers and Washers

SWITCHING THE COURTESY WIPE
ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Wipers

4. Switch

Courtesy Wipe

on or off.

USING THE REAR WINDOW
WASHER

E340280

Rotate the control to the top or bottom
position and hold it to operate the rear
window washer.

Note:

A courtesy wipe occurs a short time

after the wipers stop to clear any remaining
washer fluid when switched on. See

Switching the Courtesy Wipe On and Off

(page 93).

ADDING WASHER FLUID

E340983

WASHER FLUID SPECIFICATION

See

Washer Fluid Specification

(page

410).

WIPERS AND WASHERS –
TROUBLESHOOTING

WIPERS AND WASHERS –
WARNING LAMPS

E132353

Illuminates when the windshield
washer fluid is low.

WIPERS AND WASHERS –
FREQUENTLY ASKED QUESTIONS

Why are there streaks and smears on
the windshield?

The wiper blades could be dirty, worn
or damaged. Check the wiper blades.
See

Checking the Wiper Blades

(page 91). If the wiper blades are dirty,
clean them with washer fluid or water
applied with a soft sponge or cloth. If
the wiper blades are worn or damaged,
install new ones. See

Replacing the

Front Wiper Blades

(page 91).

Wipers and Washers

EXTERIOR LIGHTING
CONTROL

E327629

Lamps off.

Parking lamps on.

Autolamps on.

Headlamps on.

Rotate the control to make a selection.

Note:

The lighting control defaults to

autolamps every time you switch your
vehicle on.

HEADLAMPS

USING THE HIGH BEAM
HEADLAMPS

E327570

Push the lever away from you to
switch the high beam on.

Push the lever forward again or pull the
lever toward you to switch the high beams
off.

Slightly pull the lever toward you and
release it to flash the headlamps.

HEADLAMP INDICATORS

Lamps On

Illuminates when you switch the
low beam headlamps or the
parking lamps on.

Headlamp High Beam

Illuminates when you switch the
high beam headlamps on.

HEADLAMPS –
TROUBLESHOOTING

HEADLAMPS – FREQUENTLY
ASKED QUESTIONS

Why is there condensation in the
headlamps?

Headlamps have vents to
accommodate normal changes in air
pressure. Condensation can be a
natural by-product of this design.
When moist air enters the lamp
assembly through the vents, there is a
possibility that condensation can
occur when the temperature is cold.
When normal condensation occurs, a
fine mist can form on the interior of the
lens. The fine mist eventually clears
and exits through the vents during
normal operation.

How much condensation is
acceptable?

The presence of a fine mist, for
example no streaks, drip marks or
large droplets. A fine mist covers less
than 50% of the lens.

Exterior Lighting

How long may it take for the
acceptable condensation to be
cleared?

Clearing time may take as long as 48
hours under dry weather conditions.

How much condensation is
unacceptable?

A water puddle inside the lamp.
Streaks, drip marks or large droplets
present on the interior of the lens.

What should I do if unacceptable
condensation is present?

Have your vehicle checked as soon as
possible.

Why do my headlamps turn off when I
have them switched on when I switch
my vehicle off?

The battery saver turns the headlamps
off after a short period of time after
you switch your vehicle off.

AUTOLAMPS

WHAT ARE AUTOLAMPS

WARNING:

The system does not

relieve you of your responsibility to drive
with due care and attention. You may
need to override the system if it does not
turn the headlamps on in low visibility
conditions, for example daytime fog.

Autolamps turn the headlamps on in low
light situations or when the windshield
wipers operate.

AUTOLAMP SETTINGS

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Lighting

4. Press

Autolamp Delay

5. Press a setting.

EXTERIOR LAMPS

SWITCHING THE TURN SIGNAL
LAMPS ON AND OFF

E311431

Push the lever up or down to
switch the turn signal lamps on.

Set the lever to the middle position to
switch the turn signal lamps off.

Note:

Tap the lever up or down to make the

turn signal lamps flash three times.

SWITCHING THE DAYTIME
RUNNING LAMPS ON AND OFF -
VEHICLES WITH: CONFIGURABLE
DAYTIME RUNNING LAMPS

WARNING:

The daytime running

lamps system does not activate the rear
lamps and may not provide adequate
lighting during low visibility driving
conditions. Make sure you switch the
headlamps on, as appropriate, during all
low visibility conditions. Failure to do so
may result in a crash.

Press

Settings

on the touchscreen.

Exterior Lighting

2. Press

Vehicle Settings

3. Press

Lighting

4. Switch

Daytime Running Lights

on or

off.

The daytime running lamps turn on when
all of the following occur:
•

You switch the system on.

•

You switch your vehicle on.

•

The transmission is not in park (P) for
vehicles with automatic transmissions
or you release the parking brake for
vehicles with manual transmissions.

•

The lighting control is in the autolamps
position.

•

The headlamps are off.

Note:

Other lighting control positions do

not turn on the daytime running lamps.

SWITCHING THE DAYTIME
RUNNING LAMPS ON AND OFF -
VEHICLES WITH: DAYTIME
RUNNING LAMPS (DRL)

WARNING:

The daytime running

Daytime running lamps are always on
unless you switch on the headlamps or
your vehicle is in park (P).

SWITCHING THE FRONT FOG
LAMPS ON AND OFF

(If Equipped)

The front fog lamp button is on the lighting
control.

Press the button to switch the
front fog lamps on or off.

Note:

Only switch the front fog lamps on

during reduced visibility.

Note:

The brightness of the daytime running

lamps may decrease when the front fog
lamps are switched on.

Note:

When the lighting control is in the

autolamps position, you cannot switch the
fog lamps on unless the headlamps are on.

SWITCHING THE SPOT LAMPS ON
AND OFF

(If Equipped)

The spot lamp buttons are near the lighting
control.

E340436

Press the button to switch on the
left-hand spot lamp.

E340437

Press the button to switch on the
right-hand spot lamp.

Move the position of the exterior mirrors
to adjust the aim.

Note:

The lighting control must be set to

the parking lamp position.

Note:

The spot lamps illuminate the area

in front of and to the side of your vehicle.

EXTERIOR LAMP INDICATORS

Front Fog Lamp

It illuminates when you switch
the front fog lamps on.

Turn Signal Lamp

It flashes when you switch the
turn signal lamps on.

Note:

An increase in the rate of flashing

warns of a failed turn signal lamp.

Exterior Lighting

EXTERIOR LAMP AUDIBLE
WARNING

Exterior Lamps On

Sounds when you open the driver door and
the exterior lamps are on.

EXTERIOR ZONE LIGHTING

(IF

EQUIPPED)

WHAT IS EXTERIOR ZONE
LIGHTING

Exterior zone lighting divides the exterior
lighting into zones and allows you to switch
them on and off to provide lighting around
the perimeter of your vehicle.

USING THE EXTERIOR ZONE
LIGHTING

Press

Features

on the touchscreen.

2. Press

Zone Lighting

E343474

On and off button.

Settings menu.

Exterior lamp indicators.

Individual zones on and off.

All zones on and off.

You can use zone lighting when your
vehicle is on or off. When it is off, the
lighting turns off after a certain period of
time.

You can also use individual zone controls
to switch on each zone.

Note:

Make sure to remove exterior lighting

covers when using zone lighting.

Note:

When your vehicle is off and the timer

has one minute remaining, the turn signals
flash six times.

Note:

Indicators on the touchscreen

illuminate when the lights outside of the
zone lighting control are on.

Note:

You can remotely control the zone

lighting using the FordPass app.

EXTERIOR ZONE LIGHTING
SETTINGS

Press

Features

on the touchscreen.

2. Press

Zone Lighting

3. Press the settings menu in the upper

right-hand corner.

4. Press a setting.

Enable Autolamp Override

This setting allows your vehicle to override
the autolamps when using zone lighting.

When you access zone lighting for the first
time, you can choose this setting. You can
change this setting at any time.

Exterior Lighting

AUTOMATIC HIGH BEAM
CONTROL

HOW DOES AUTOMATIC HIGH
BEAM CONTROL WORK

Automatic high beam control turns the
high beams on if it is dark enough and no
other traffic is present. If it detects an
approaching vehicle’s headlamps or tail
lamps, or street lighting ahead, the system
turns the high beams off.

A camera sensor, centrally mounted
behind the windshield of your vehicle,
continuously monitors conditions to turn
the high beams on and off.

E327596

Without automatic high beam
control.

With automatic high beam
control.

AUTOMATIC HIGH BEAM
CONTROL PRECAUTIONS

WARNING:

The system does not

relieve you of your responsibility to drive
with due care and attention. You may
need to override the system if it does not
turn the high beams on or off.

Exterior Lighting

WARNING:

The system may not

switch the high beams off if the lights of
oncoming vehicles are hidden by
obstacles, for example guard rails.

WARNING:

Do not use the system

in poor visibility, for example fog, heavy
rain, spray or snow.

WARNING:

You may need to

override the system when approaching
other road users.

WARNING:

You may need to

override the system during inclement
weather.

AUTOMATIC HIGH BEAM
CONTROL REQUIREMENTS

The system turns the high beams on if all
of the following occur:
•

You switch the system on.

•

You set the lighting control to the
autolamps position.

•

The ambient light level is low enough
that you require high beams.

•

There is no traffic in front of your
vehicle.

•

The vehicle speed is greater than
approximately 32 mph (52 km/h).

AUTOMATIC HIGH BEAM
CONTROL LIMITATIONS

The system turns the high beams off if any
of the following occur:
•

You switch the system off.

•

You set the lighting control to any
position except autolamps.

•

The ambient light level is high enough
that you do not require high beams.

•

The system detects an approaching
vehicle's headlamps or a leading
vehicle's tail lamps.

•

The system detects severe rain, snow
or fog.

•

The system detects street lighting.

•

The camera has reduced visibility.

•

The vehicle speed falls below
approximately 27 mph (44 km/h).

SWITCHING AUTOMATIC HIGH
BEAM CONTROL ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Lighting

4. Switch

Auto Highbeam

on or off.

AUTOMATIC HIGH BEAM
CONTROL INDICATORS

Illuminates to confirm when the
system is ready to assist.

OVERRIDING AUTOMATIC HIGH
BEAM CONTROL

E308790

Push the lever away from you to switch
the high beams on.

Exterior Lighting

Content .. 3 4 5 6 ..
