Ford E-350 (2022 year). Manual in english

BRAKE FLUID SPECIFICATION

Use fluid that meets the defined
specification.

If you do not use fluid that meets the
defined specification, it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced brake performance.

Note:

Keep brake fluid clean and dry.

Contamination with dirt, water, petroleum
products or other materials could result in
brake system damage and failure.

Capacities

Quantity

Variant

Fill as required.

Hydroboost Brake System.

Fill as required.

Vacuum Brake System.

Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid(U.S.)
Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid / Liquide de frein automobile
haute performance DOT 4 LV Motorcraft®(Canada)
PM-20(U.S. & Canada)

WSS-M6C65-A1

Motorcraft® High Performance DOT 3 Motor Vehicle
Brake Fluid(U.S.)
Motorcraft® High Performance DOT 3 Motor Vehicle
Brake Fluid / Liquide de frein automobile DOT 3
haute performance Motorcraft®(Canada)
PM-1-C(U.S.)
CPM-1-C(Canada)

Note:

We recommend using DOT 4 Low

Viscosity (LV) High Performance Brake Fluid
for vehicles with vacuum brake booster
systems. High Performance DOT 3 brake
fluid is also acceptable to use.

Note:

Use of any fluid other than the

recommended fluid could cause reduced
brake performance and not meet our
performance standards.

REAR AXLE FLUID CAPACITY
AND SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

231

Capacities and Specifications

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:

•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Limited Slip Axle

Capacities

Quantity

Variant

3.28 qt (3.1 L)

E-350 Dana axle M70FF (M267FF).

4.86 qt (4.6 L)

E-450 Dana axle M70HD (M273HD).

Fill Dana rear axles to 0.24–0.55 in (6–14 mm) below the bottom of the fill hole.

Materials

Specification

Name

WSL-M2C192-A

Motorcraft® SAE 75W-140 Synthetic Rear Axle
Lubricant(U.S.)
Motorcraft® SAE 75W-140 Synthetic Rear Axle
Lubricant / Lubrifiant synthétique pour pont arrière
SAE 75W-140 Motorcraft®(Canada)
XY-75W140-QL(U.S.)
CXY-75W140-1L(Canada)

Conventional Axle

Capacities

Quantity

Variant

3.28 qt (3.1 L)

E-350 Dana axle M70FF (M267FF).

4.86 qt (4.6 L)

E-450 Dana axle M70HD (M273HD).

Fill Dana rear axles to 0.24–0.55 in (6–14 mm) below the bottom of the fill hole.

232

Capacities and Specifications

Materials

Specification

Name

WSP-M2C197-A

Motorcraft® SAE 80W-90 Premium Rear Axle
Lubricant(U.S.)
Motorcraft® SAE 80W-90 Premium Axle Lubricant
/ Lubrifiant pour essieux de très haute qualité SAE
80W-90 Motorcraft®(Canada)
XY-80W90-QL(U.S.)
CXY-80W90-1L(Canada)

HYDRAULIC POWER
STEERING FLUID CAPACITY
AND SPECIFICATION

Use fluid that meets the defined
specification.

If you do not use fluid that meets the
defined specification, it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Capacities

Quantity

Variant

Fill as required.

All.

Materials

Specification

Name

WSS-M2C938-AMERCON® LV,

Motorcraft® MERCON® LV Automatic Transmission
Fluid(U.S.)
Motorcraft® MERCON® LV Automatic Transmission
Fluid / Huile pour boîte automatique MERCON® LV
Motorcraft®(Canada)
XT-10-QLVC(U.S.)
CXT-10-LV6(Canada)

233

Capacities and Specifications

VEHICLE IDENTIFICATION
NUMBER

LOCATING THE VEHICLE
IDENTIFICATION NUMBER

The vehicle identification number is on the
left-hand side of the instrument panel.

E311767

Note:

In the illustration, XXXX is

representative of your vehicle identification
number.

VEHICLE IDENTIFICATION
NUMBER OVERVIEW

The vehicle identification number contains
the following information:

E142477

World manufacturer identifier.

Brake system, gross vehicle
weight rating, restraint devices
and their locations.

Make, vehicle line, series, body
type.

Engine or motor type.

Check digit.

Model year.

Assembly plant.

Production sequence number.

234

Vehicle Identification

CONNECTED VEHICLE
REQUIREMENTS

Connected service and related feature
functionality requires a compatible vehicle
network.

Some remote features require additional
service activation. Log in to your Ford
account for details. Some restrictions, third
party terms and message or data rates
may apply.

CONNECTED VEHICLE
LIMITATIONS

Evolving technology, cellular networks, or
regulations could affect functionality and
availability, or continued provision of some
features. These changes could even stop
some features from functioning.

CONNECTING THE VEHICLE TO
A MOBILE NETWORK

WHAT IS THE MODEM

The modem allows access to a
range of features built into your
vehicle.

ENABLING AND DISABLING THE
MODEM

Press

Settings

2. Press

FordPass Connect

3. Press

Connectivity Settings

4. Switch connectivity features on or off.

DISABLING THE CONNECTIVITY
DEVICE

To disable the connectivity device, contact
the Ford Customer Relationship Center.

CONNECTING FORDPASS TO THE
MODEM

Make sure that the modem is enabled
using the vehicle settings menu.

2. Open the FordPass app on your device

and log in.

3. Add your vehicle or select your vehicle

if already added.

4. Select the option to activate your

vehicle.

5. Make sure that the name on the screen

matches the name shown in your
FordPass account.

6. Confirm that FordPass account is

connected to the modem.

CONNECTED VEHICLE – TROUBLESHOOTING

CONNECTED VEHICLE – FREQUENTLY ASKED QUESTIONS

Possible Cause and Resolution

Symptom

I cannot confirm the
connection of my FordPass
account to the modem.

–

Modem is not enabled.
•

Switch vehicle connectivity on.

–

Weak network signal.
•

Move your vehicle closer to a place where the
network signal is not obstructed.

235

Connected Vehicle

GENERAL INFORMATION

WARNING:

Driving while distracted

hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Radio Frequencies and Reception
Factors

Note:

Listening to loud audio for long

periods of time could damage your hearing.

Radio Reception Factors

The further you travel from an AM or FM station, the
weaker the signal and the weaker the reception.

Distance and strength

Hills, mountains, tall buildings, bridges, tunnels, freeway
overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with the reception.

Terrain

When you pass a ground-based broadcast repeating
tower, a stronger signal may overtake a weaker one and
result in the audio system muting.

Station overload

AUDIO UNIT

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

E305609

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Note:

Some features, such as satellite

radio, may not be available in your location.
Check with an authorized dealer.

236

Audio System

(If Equipped)

Accessing the Sound Settings

E280315

Press the button to adjust the
sound settings. You can also
activate and set the sensitivity

of the adaptive or speed compensated
volume.

Accessing the System Settings

Press the button.

Adjusting the Volume

E260697

Turn to adjust the volume.

Changing Radio Stations

E260687

Auto or Manual tuning.

Station name tuning.

Note:

You can change between auto or

manual tuning with the rotary control using
the system settings.

Note:

You can change radio stations using

the seek buttons.

Note:

You can recall radio stations using

the numeric preset buttons.

Pausing or Playing Media

In media mode, press and
release the button to pause
playback. Press the button again

to resume playback.

In radio mode, press the button to mute
the signal. Press the button again to
restore the signal.

Returning to the Previous Screen

E281480

Press and release the button.

Scrolling Through the Menu
Options

E260782

Selecting Media

E100027

Press the button to select media
mode.

Repeatedly press the button, or

rotate the right-hand rotary control to
scroll through the available media sources.

237

Audio System

(If Equipped)

Selecting a Menu Option

E260781

Selecting the Radio

Press the button to select radio
mode.

Press the button again to display

the available radio sources. Repeatedly
press the button, or rotate the right-hand
rotary control to scroll through the
available radio sources.

Setting a Memory Preset

Tune to a station then press and hold one
of the numbered memory preset buttons.
The audio mutes briefly while the system
saves the station and returns once the
station is stored.

Switching the Audio Unit On and
Off

E260686

Press and release the button.

Using a Cell Phone

Press the button to either
answer an incoming phone call
or to make a phone call.

E265040

Press and hold the button to end
a phone call.

Using Seek, Fast Forward and
Reverse

Press and release the button to
skip to the next track.

Press and hold the button to fast

forward through the track.

Press and release the button to
return to the beginning of a track.

Repeatedly press the button to

return to previous tracks.

Press and hold the button to rewind.

In radio mode, select a frequency band and
press and release either button. The
system stops at the first station it finds in
that direction.

238

Audio System

(If Equipped)

In satellite radio mode, press and release
to select the next or previous satellite radio
station. If you select a specific category,
such as jazz, rock or news, press to find the
next or previous station in the category you
select.

DIGITAL RADIO

Note:

HD Radio broadcasts are not

available in all markets.

HD Radio technology is the digital
evolution of analog AM/FM radio. Your
system has a special receiver that allows
it to receive digital broadcasts, where
available, in addition to the analog
broadcasts, it already receives. Digital
broadcasts provide a better sound quality
than analog broadcasts with free,
crystal-clear audio and no static or
distortion. For more information, and a
guide to available stations and
programming, please visit
www.hdradio.com.

When HD Radio is on and you tune to a
station broadcasting HD Radio technology,
you may notice the HD Radio logo on your
screen. When this logo is available, you
may also see Title and Artist fields
on-screen.

The multicast indicator appears in FM
mode, only, if the current station is
broadcasting multiple digital broadcasts.
The highlighted numbers signify available
digital channels where new or different
content is available. HD1 signifies the main
programming status and is available in
analog and digital broadcasts. Other
multicast stations, HD2 through HD7, are
only available digitally.

When HD Radio broadcasts are active, you
can access the following functions:
•

Memory presets

allow you to save an

active channel as a memory preset.
Touch and hold a memory preset slot
until the sound returns. There is a brief
mute while the radio saves the station.
Sound returns when finished. When
switching to an HD2 or HD3 memory
preset, the sound mutes before the
digital audio plays, because the system
has to reacquire the digital signal.

Note:

As with any saved radio station, you

cannot access the saved station if your
vehicle is outside the station’s reception
area.

239

Audio System

(If Equipped)

HD Radio Reception and Station Troubleshooting

Potential Reception Issues

If you are listening to a multicast station and you are on
the fringe of the reception area, the station may mute due
to weak signal strength.

Reception area

If you are listening to HD1, the system switches back to
the analog broadcast until the digital broadcast is available
again. However, if you are listening to any of the possible
HD2-HD7 multicast channels, the station mutes and stays
muted unless it is able to connect to the digital signal
again.

When the system first receives a station, aside from HD2-
HD7 multicast stations, it first plays the station in the
analog version. Once the receiver verifies the station is an
HD Radio station, it shifts to the digital version. Depending
on the station quality, you may hear a slight sound change
when the station changes from analog to digital. Blending
is the shift from analog to digital sound or digital back to
analog sound.

Station blending

In order to provide the best possible
experience, use the contact form to report
any station issues found while listening to
a station broadcasting with HD Radio
technology. Independent entities own and
operate each station. These stations are
responsible for the accuracy of all audio
streams and data fields.

240

Audio System

(If Equipped)

Potential Station Issues

Action

Cause

Issues

No action required. This is a
broadcast issue.

This is poor time alignment
by the radio broadcaster.

Echo, stutter, skip or repeat
in audio.
Increase or decrease in
audio volume.

No action required. The
reception issue may clear up
as you continue to drive.

The radio is shifting between
analog and digital audio.

Sound fading or blending in
and out.

No action required. This is
normal behavior. Wait until
the audio is available.

The digital multicast is not
available until the HD Radio
broadcast is decoded. Once
decoded, the audio is avail-
able.

There is an audio mute
delay when selecting HD2 or
HD3, multicast preset or
direct tune.

No action required. The
station is not available in
your current location.

The previously stored
multicast preset or direct
tune is not available in your
current reception area.

Cannot access the HD2 or
HD3 multicast channels
when recalling a preset or
from a direct tune.

Fill out the station issue
form at website listed

below.

Data service issue by the
radio broadcaster.

Text information does not
match currently playing
audio.

Fill out the station issue
form at website listed

below.

Data service issue by the
radio broadcaster.

There is no text information
shown for currently selected
frequency.

http://hdradio.com/stations/feedback.

HD Radio Technology manufactured under
license from iBiquity Digital Corporation
and foreign patents. HD Radio and the HD
and HD Radio logos are proprietary
trademarks of DTS. Ford and DTS are not
responsible for the content sent using HD
Radio technology. Content may be
changed, added or deleted at any time at
the station owner's discretion.

CONNECTING A BLUETOOTH®
DEVICE

Pairing a Device

E142607

Press the button.

Select

Bluetooth®

and follow the

instructions on the screen.

241

Audio System

(If Equipped)

Note:

When pairing a new device, you can

choose to download contacts, set this as
the primary device and enable Emergency
Assistance.

SATELLITE RADIO

SiriusXM® Satellite Radio broadcasts a
variety of music, news, sports, weather,
traffic and entertainment satellite radio
channels. For more information and a
complete list of SiriusXM satellite radio
channels, visit www.siriusxm.com in the
United States, www.siriusxm.ca in Canada,
or call SiriusXM at 1-888-539-7474.

Note:

This receiver includes the eCos

real-time operating system. eCos is
published under the eCos License.

Satellite Radio Reception Factors

Potential satellite radio reception issues

For optimal reception performance, keep the antenna
clear of snow and ice build-up and keep luggage and other
material as far away from the antenna as possible.

Antenna obstructions

Hills, mountains, tall buildings, bridges, tunnels, freeway
overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with your reception.

Terrain

When you pass a ground-based broadcast-repeating
tower, a stronger signal may overtake a weaker one and
the audio system may mute.

Station overload

Your display may show ACQUIRING . . . to indicate the
interference and the audio system may mute.

Satellite radio signal interfer-
ence

SiriusXM Satellite Radio Service

Note:

SiriusXM reserves the unrestricted

right to change, rearrange, add or delete
programming including canceling, moving
or adding particular channels, and its prices,
at any time, with or without notice to you.
Neither SiriusXM and its affiliates, nor Ford
Motor Company and its affiliates will be
liable to you or any third party for any such
modifications, suspension, or termination.

E208625

242

Audio System

(If Equipped)

SiriusXM satellite radio is a
subscription-based satellite radio service
that broadcasts a variety of music, sports,
news, weather, traffic and entertainment
programming. Your factory-installed
SiriusXM satellite radio system includes
hardware and a limited subscription term,
which begins on the date of sale or lease
of your vehicle. See an authorized dealer
for availability.

For more information on extended
subscription terms (a service fee is
required), the online media player and a
complete list of SiriusXM satellite radio
channels, and other features, please visit
www.siriusxm.com in the United States,
www.siriusxm.ca in Canada, or call
SiriusXM at 1-888-539-7474.

Satellite Radio Electronic Serial
Number (ESN)

You need your ESN to activate, modify or
track your satellite radio account. When in
satellite radio mode, tune to channel 0.

Troubleshooting

Action

Condition

Message

No action required. This
message should disappear
shortly.

Radio requires more than
two seconds to produce
audio for the selected
channel.

Acquiring…

If this message does not
clear shortly, or with an igni-
tion key cycle, your receiver
may have a fault. See an
authorized dealer for service.

There is an internal module
or system failure present.

Satellite antenna fault

SIRIUS system failure

Tune to another channel or
choose another preset.

The channel is no longer
available.

Invalid Channel

Contact SiriusXM at 1-888-
539-7474 to subscribe to
the channel, or tune to
another channel.

Your subscription does not
include this channel.

Unsubscribed Channel

The signal is blocked. When
you move into an open area,
the signal should return.

The signal is lost from the
SiriusXM satellite or Siri-
usXM tower to your vehicle
antenna.

No Signal

No action required. The
process may take up to
three minutes.

Update of channel
programming in progress.

Updating…

243

Audio System

(If Equipped)

Action

Condition

Message

Contact SiriusXM at 1-888-
539-7474 to resolve
subscription issues.

Your satellite service is no
longer available.

Questions? Call

1-888-539-7474

Use the channel guide to
turn off the Lock or Skip
function on that station.

All the channels in the
selected category are either
skipped or locked.

None found

Check Channel Guide

No action required.

SiriusXM has updated the
channels available for your
vehicle.

Subscription Updated

STREAMING BLUETOOTH
AUDIO

Selecting a

Bluetooth®

Source

E100027

Press the button to display the menu.

2. Repeatedly press the button to scroll

to the

Bluetooth®

device.

3. Press the

button.

Press the button to play the
track. Press the button again to
pause the track.

Press the button to skip to the
next track.

Press and hold the button to fast

forward through the track.

Press the button once to return
to the beginning of the track.
Repeatedly press the button to

return to previous tracks.

Press and hold the button to fast rewind.

Note:

Not all functions are supported by all

phones.

PLAYING MEDIA FROM A USB
DEVICE

Supported Audio File Formats

You can play audio file formats including
MP3, WMA, WAV, M4A, M4B, AAC, and
FLAC.

Note:

The NTFS file system is not

supported.

Selecting the USB Device

E100027

Press the button to display the
menu.

Repeatedly press the button to scroll to
your USB device.

Press the

button.

Playing from the USB Device

Press the button to play a track.
Press the button again to pause
the track.

Press the button to skip to the
next track.

Press and hold the button to fast

forward through the track.

244

Audio System

(If Equipped)

Press the button once to return
to the beginning of a track.
Repeatedly press the button to

return to previous tracks.

Press and hold the button to fast rewind.

Sorting by Categories

You can also sort and play music by
specific categories, for example artist or
album.

Press the

button to view the available

categories.

USB PORT

WARNING:

Driving while distracted

E201595

The USB port allows you to plug in media
playing devices, memory sticks and charge
devices.

Note:

Not all USB ports in your vehicle have

data transfer capabilities. See

Auxiliary

Power Points

(page 80).

USING VOICE RECOGNITION

Phone Voice Service

This system allows you to use the voice
recognition features of your phone and
focus on your driving.

E142599

Press and hold the voice control
button on the audio unit.

Note:

This only works when connected via

Bluetooth. See

Connecting a Bluetooth®

Device

(page 241).

Note:

When using voice recognition use the

language set on the device.

Note:

We recommend that you check your

data plan before using your phone voice
service through the system. Using them
could result in additional charges.

245

Audio System

(If Equipped)

For a complete listing of the accessories
that are available for your vehicle, please
contact your authorized dealer or visit the
online store web site:

Web Address (United States)

www.Accessories.Ford.com

Web Address (Canada)

www.Accessories.Ford.ca

We will repair or replace any properly
authorized dealer-installed Ford Original
Accessory found to be defective in
factory-supplied materials or workmanship
during the warranty period, as well as any
component damaged by the defective
accessories.

We will warrant your Ford Original
Accessory through the warranty that
provides the greatest benefit:
•

24 months, unlimited mileage.

•

The remainder of your new vehicle
limited warranty.

Contact an authorized dealer for details
and a copy of the warranty.

Ford Licensed Accessories are the
accessory manufacturer's designs. The
manufacturer develops and therefore
warrants Ford Licensed Accessories, and
does not design or test these accessories
to Ford Motor Company engineering
requirements. Contact an authorized Ford
dealer for the manufacturer’s limited
warranty details, and request a copy of the
Ford Licensed Accessories product limited
warranty from the accessory manufacturer.

For maximum vehicle performance, keep
the following information in mind when
adding accessories or equipment to your
vehicle:
•

When adding accessories, equipment,
passengers and luggage to your
vehicle, do not exceed the total weight
capacity of the vehicle or of the front
or rear axle (GVWR or GAWR as
indicated on the Safety Compliance
Certification label). Ask an authorized
dealer for specific weight information.

•

The Federal Communications
Commission (FCC) and Canadian
Radio Telecommunications
Commission (CRTC) regulate the use
of mobile communications systems
that are equipped with radio
transmitters, for example two-way
radios, telephones and theft alarms.
Any such equipment installed in your
vehicle should comply with Federal
Communications Commission (FCC)
and Canadian Radio
Telecommunications Commission
(CRTC) regulations and should be
installed only by an authorized dealer.

•

An authorized dealer needs to install
mobile communications systems.
Improper installation may harm the
operation of your vehicle, particularly
if the manufacturer did not design the
mobile communication system
specifically for automotive use.

•

If you or an authorized Ford dealer add
any non-Ford electrical or electronic
accessories or components to your
vehicle, you may adversely affect
battery performance and durability. In
addition, you may also adversely affect
the performance of other electrical
systems in the vehicle.

246

Accessories

Ford E-350 (2022 year). Manual in english - page 15
