Emergency Assistance

If you set emergency assistance to always
on, you cannot switch it off with a MyKey.

Do Not Disturb

If you set do not disturb to always on, you
cannot switch it off with a MyKey.

Note:

If a phone is connected using Apple

CarPlay or Android Auto while driving with
a MyKey, the driver can receive phone calls
and text messages even if the do not disturb
restriction is on, and if the vehicle comes
with satellite radio, there is no restriction on
the adult content.

Traction and Stability Control

If you set traction control or stability
control to always on, you cannot switch it
off with a MyKey.

CREATING A MYKEY

E331284

Raise the console storage
compartment lid.

2. Place the passive key in the position

shown, with the buttons facing the rear
of the vehicle.

3. Switch the ignition on.

4. Access the main menu in the

information display and then scroll
through the menus to change the
settings of your MyKey. From the
MyKey menu select the option Create
MyKey See

Instrument Cluster

Display Main Menu

(page 118).

5. Switch the ignition off.

Note:

The programmed restrictions apply

when you key off, open and close driver door
and restart your vehicle with the
programmed key or remote control.

Note:

We recommend that you label this

key.

PROGRAMMING A MYKEY

You can only program MyKeys to the same
settings.

Switch the ignition on using an admin
key.

2. Press the menu button on the steering

wheel to enter the information display
main menu.

3. Select

Settings

4. Select

MyKey

5. Select a setting and press the

button.

6. Configure the setting.

Switch the ignition off.

CLEARING ALL MYKEYS

When you clear all MyKeys, you remove all
restrictions and return all MyKeys to their
original admin key status.

Switch the ignition on using an admin
key.

MyKey™

2. Press the menu button on the steering

wheel to enter the information display
main menu.

3. Select

Settings

4. Select

MyKey

5. Select

Clear MyKeys

6. Press and hold the

button until a

confirmation message appears in the
information display.

CHECKING MYKEY SYSTEM
STATUS

You can find information about the
distance traveled using a MyKey and also
the number of admin keys and MyKeys
created for your vehicle.

Switch the ignition on.

2. Press the menu button on the steering

wheel to enter the information display
main menu.

3. Select

Settings

4. Select

MyKey

5. Select

MyKey Info

USING MYKEY WITH REMOTE
START SYSTEMS

MyKey is not compatible with unapproved,
aftermarket remote start systems. If you
choose to install a remote start system,
see an authorized dealer for an approved
remote start system.

MYKEY – TROUBLESHOOTING

MYKEY – INFORMATION MESSAGES

Description

Message

Displays when trying to create a MyKey and the admin key is
not placed in the backup position. See

Creating a MyKey

(page 66).

Place Key in Backup
Location

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

MyKey™

MYKEY – FREQUENTLY ASKED
QUESTIONS

What is an admin key?

An admin key is a key that you have
not created as a MyKey. See

Creating

a MyKey

(page 66).

Why am I not able to create a MyKey?

You have not placed the admin key in
the backup position. See

Creating a

MyKey

(page 66). The key used to

switch the ignition on is not an admin
key. The key used to switch the ignition
on is the only admin key. There has to
be at least one admin key. You did not
switch the ignition off after creating
the last MyKey.

Why am I not able to program a MyKey?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey

(page 66).

Why am I not able to clear the MyKeys?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey

(page 66).

Why is the MyKey distance not
accumulating?

The key used to start the engine is an
admin key. An admin key and a MyKey
are inside your vehicle. You have not
created any MyKeys. See

Creating a

MyKey

(page 66). You have cleared

the MyKeys. See

Clearing All

MyKeys

(page 66).

Why am I not able to start the engine
with a MyKey?

An admin key and a MyKey are inside
your vehicle. The system recognizes
only the admin key when both are
present.

MyKey™

OPERATING THE DOORS
FROM OUTSIDE YOUR
VEHICLE

UNLOCKING AND LOCKING THE
DOORS USING THE REMOTE
CONTROL

You can only use the remote control when
your vehicle is stationary.

Unlocking the Doors

E267112

Press the button to unlock all
doors.

Locking the Doors

E267111

Press the button to lock all
doors. One short flash of the
turn signal lamps confirms that

your vehicle has locked.

Note:

For more information on operating

the doors from outside your vehicle See

Keyless Entry

(page 74).

UNLOCKING AND LOCKING THE
DOORS USING THE KEY BLADE

If there is a power door lock fault you can
use the key blade to lock and unlock the
doors.

E151956

Turn clockwise to lock.

Turn counterclockwise to unlock.

INDIVIDUALLY UNLOCKING AND
LOCKING THE DOORS USING THE
KEY BLADE

If there is a power door lock fault you can
use the key blade to lock and unlock the
doors.

Doors and Locks

E112203

Lock.

Unlock.

OPERATING THE DOORS
FROM INSIDE YOUR VEHICLE

INDIVIDUALLY UNLOCKING AND
LOCKING THE DOORS USING THE
LOCKING BUTTON

The power door lock control is on the driver
and front passenger door panels.

E138628

Unlock.

Lock.

OPENING THE DOORS FROM
INSIDE YOUR VEHICLE

Pull the interior door handle twice to
unlock and open a rear door. The first pull
unlocks the door and the second pull
opens the door.

AUTOUNLOCK

WHAT IS AUTOUNLOCK

Autounlock is an unlocking feature that
unlocks the vehicle doors when your
vehicle comes to a stop.

AUTOUNLOCK REQUIREMENTS

Autounlock unlocks all the doors when all
of the following occur:
•

The ignition is on, all the doors are
closed and your vehicle is moving at a
speed greater than 12 mph (20 km/h).

•

Your vehicle comes to a stop.

•

You open the driver door within 10
minutes of switching the ignition off or
to the accessory position.

Doors and Locks

SWITCHING AUTOUNLOCK ON
AND OFF

Press the menu button on the steering
wheel to enter the information display
main menu.

2. Select

Settings

3. Select

Vehicle

4. Select

Locks

5. Switch

Autounlock

on or off.

AUTOLOCK

WHAT IS AUTOLOCK

Autolock is a locking feature that locks
your vehicle doors when you start driving.

AUTOLOCK REQUIREMENTS

Autolock locks all the doors when all of the
following occur:
•

All doors are closed.

•

The ignition is on.

•

Your vehicle reaches a speed greater
than 12 mph (20 km/h).

MISLOCK

WHAT IS MISLOCK

Mislock is a locking feature that warns you
if your vehicle has not locked.

MISLOCK LIMITATIONS

When you press the lock button once, the
direction indicators do not flash if any door
or the liftgate or hood is open.

If any door or the liftgate is open.

2. The hood is open.

SWITCHING MISLOCK ON AND
OFF

Press the menu button on the steering
wheel to enter the information display
main menu.

2. Select

Settings

3. Select

Vehicle

4. Select

Locks

5. Switch

Mislock Chirp

on or off.

DOORS AND LOCKS AUDIBLE
WARNINGS

Door Ajar Audible Warning

Sounds when a door is not fully closed and
your vehicle is moving.

DOORS AND LOCKS –
TROUBLESHOOTING

DOORS AND LOCKS – WARNING
LAMPS

Door Ajar Warning Lamp

E249859

It illuminates when you switch
the ignition on and remains on if
any door or the hood is open.

Doors and Locks

DOORS AND LOCKS – INFORMATION MESSAGES

Action

Message

Displays if a door is open. Fully close the door.

Driver Door Ajar

Passenger Door Ajar

Rear Left Door Ajar

Rear Right Door Ajar

Doors and Locks

DOORS AND LOCKS –
FREQUENTLY ASKED QUESTIONS

Can accessories such as steps or
handles be used with the latch
assembly?

Do not use the door latch assembly to
attach any accessory, such as handles
or steps, as this can cause damage to
your vehicle.

Doors and Locks

KEYLESS ENTRY LIMITATIONS

Make sure your remote control is within 3 ft
(1 m) from the front door handles and the
tailgate.

The system could not function if:
•

The remote control remains stationary
for about a minute.

•

The vehicle battery has no charge.

•

The remote control battery has no
charge.

•

There is interference causing issues
with the remote control frequencies.

•

The remote control is too close to
metal objects or electronic devices, for
example keys or a cell phone.

KEYLESS ENTRY SETTINGS

Switching Keyless Entry On and
Off

Switch the ignition on using an original
key that has not been created as a
MyKey.

2. Press

Settings

on the touchscreen.

3. Press

Vehicle Settings

4. Press

Locks

Reprogramming the Unlocking
Function

You can enable two-stage unlocking
function allowing you to unlock only the
driver door when you touch the unlock
sensor.

Press and hold both the lock and unlock
buttons on the remote control for four
seconds to disable or enable two-stage
unlocking.

If you program the unlocking function so
that only the driver door unlocks, you can
unlock all of the other doors from inside
your vehicle using the power door lock
control. You can unlock individual doors
by pulling the interior door handles on
those doors.

USING KEYLESS ENTRY

Unlocking the Doors

E248553

With your passive key within 3 ft (1 m) of
your vehicle, touch the unlock sensor on
the back of the door handle for a brief
period and then pull on the door handle to
unlock, being careful not to touch the lock
sensor at the same time or pull on the door
handle too quickly. The intelligent access
system requires a brief delay to
authenticate your intelligent access key.

Using the Electronic Liftgate with
Passive Key (If Equipped)

E138632

Keyless Entry

(If Equipped)

With your passive key within 3 ft (1 m) of
your vehicle, press the exterior liftgate
release button inside of the liftgate handle.
The liftgate unlocks and opens. See

Opening the Liftgate From Outside
Your Vehicle

(page 80).

Locking the Doors

E248554

With your passive key within 3 ft (1 m) of
your vehicle, touch the outer door handle
lock sensor for approximately one second
to lock, being careful not to touch the
unlock sensor on the back of the door
handle at the same time. After locking, you
can immediately pull on the door handle
to confirm locking occurred without
inadvertently unlocking.

KEYLESS ENTRY –
TROUBLESHOOTING

KEYLESS ENTRY – FREQUENTLY
ASKED QUESTIONS

Why does the keypad not accept the
access code?

If you enter the access code too fast
on the keypad, the unlock function
may not work. Slowly re-enter the
access code.

Why does the passive key not work?

The system deactivates passive keys
left inside your vehicle when you lock
it. You cannot switch the ignition on
using a deactivated passive key. Press
the unlock button on the remote
control to reactivate a passive key.

Why does the keypad not function?

The keypad goes into an anti-scan
mode if you enter a wrong code seven
times. The anti-scan mode disables
the keypad for one minute and the red
light flashes.

Keyless Entry

(If Equipped)

WHAT IS THE KEYLESS ENTRY
KEYPAD

The keyless entry keypad allows you to
lock and unlock your vehicle using the
keypad on the window trim.

KEYLESS ENTRY KEYPAD
LIMITATIONS

The system may not function if:
•

The vehicle battery has no charge.

LOCATING THE KEYLESS
ENTRY KEYPAD

The keypad is near the driver window and
illuminates when you touch it.

E138637

KEYLESS ENTRY KEYPAD
MASTER ACCESS CODE

Unlocking the Doors

E138637

Enter the factory-set five-digit code or your
personal code. You must press each
number within five seconds of each other.

•

Press 3-4 within five seconds to unlock
all doors.

Keyless Entry Keypad

Locking the Doors

E138637

Press and hold

7·8

and

9·0

at the same

time with the driver door closed.

Note:

You do not need to enter the code

first.

KEYLESS ENTRY KEYPAD
PERSONAL ACCESS CODES

Programming a Personal Entry
Code

Enter the five-digit master code.

2. Press

1·2

on the keypad within five

seconds.

3. Enter your personal five-digit code.

You must do this within five seconds
of completing Step 2.

4. Press

1·2

on the keypad to save

personal code 1.

The doors lock then unlock to confirm that
programming was successful.

To program additional personal entry
codes, repeat Steps 1 through 3, then for
Step 4:
•

Press

3·4

to save personal code 2.

•

Press

5·6

to save personal code 3.

•

Press

7·8

to save personal code 4.

•

Press

9·0

to save personal code 5.

If your vehicle comes with SYNC, you can
also program the system with a personal
entry code.

Hints:
•

Do not set a code that uses five of the
same number.

•

Do not use five numbers in sequential
order.

•

The five-digit master code works even
if you have set your own personal code.

Erasing a Personal Code

Enter the five-digit master code.

2. Press and release

1·2

on the keypad

within five seconds.

3. Press and hold

1·2

for two seconds.

You must do this within five seconds
of completing Step 2.

All personal codes erase and only the
five-digit master code works.

Anti-Scan Feature

The keypad goes into an anti-scan mode
if you enter the wrong code seven times.
This mode turns off the keypad for one
minute and the keypad lamp flashes.

The anti-scan feature turns off after:
•

One minute of keypad inactivity.

•

You press the unlock button on the
remote control.

•

You switch the ignition on.

•

You unlock your vehicle using keyless
entry.

Keyless Entry Keypad

USING THE KEYLESS ENTRY
KEYPAD

Unlocking the Doors

E138637

Enter the factory-set five-digit code or your
personal code. You must press each
number within five seconds of each other.

•

Press 3-4 within five seconds to unlock
all doors.

Locking the Doors

E138637

Press and hold

7·8

and

9·0

at the same

time with the driver door closed.

Note:

You do not need to enter the code

first.

KEYLESS ENTRY KEYPAD –
TROUBLESHOOTING

KEYLESS ENTRY KEYPAD –
FREQUENTLY ASKED QUESTIONS

Why does the keypad not accept the
access code?

If you enter the access code too fast
on the keypad, the unlock function
may not work. Slowly re-enter the
access code.

Why does the keypad not function?

The keypad goes into an anti-scan
mode if you enter a wrong code seven
times. The anti-scan mode disables
the keypad for one minute and the red
light flashes.

Keyless Entry Keypad

HOW DOES EASY ENTRY AND
EXIT WORK

Easy entry and exit moves the driver seat
rearward up to 2 in (5 cm) and the steering
column up when you switch the ignition
off. The driver seat and steering column
return to their previous positions when you
switch the ignition on.

Note:

Depending on your vehicle, the

column may move up and in.

SWITCHING EASY ENTRY AND
EXIT ON AND OFF

Using the touchscreen, select

Settings

2. Select

Vehicle

3. Select

Easy Entry/Exit

If you press any adjustment or memory
button when in easy exit mode, the system
cancels the operation.

Easy Entry and Exit

OPENING THE LIFTGATE

OPENING THE LIFTGATE FROM
OUTSIDE YOUR VEHICLE

E138632

Press the control button to unlatch the
liftgate and then lift to open.

Note:

Be careful when opening or closing

the liftgate in a garage or other enclosed
area to avoid damaging the liftgate.

Note:

Do not hang anything, for example a

bike rack, from the glass or liftgate. This
could damage the liftgate and its
components.

Note:

Do not leave the liftgate open while

driving. This could damage the liftgate and
its components.

OPENING THE LIFTGATE USING
THE REMOTE CONTROL

E267940

Press the button twice within
three seconds. The liftgate
unlocks for 45 seconds, during

which time you can open the liftgate using
the outside control button.

Note:

Be careful when opening or closing

the liftgate in a garage or other enclosed
area to avoid damaging the liftgate.

Note:

Do not hang anything, for example a

bike rack, from the glass or liftgate. This
could damage the liftgate and its
components.

Note:

Do not leave the liftgate open while

driving. This could damage the liftgate and
its components.

CLOSING THE LIFTGATE

CLOSING THE LIFTGATE FROM
OUTSIDE YOUR VEHICLE

WARNING:

It is extremely

dangerous to ride in a cargo area, inside
or outside of a vehicle. In a crash, people
riding in these areas are more likely to be
seriously injured or killed. Do not allow
people to ride in any area of your vehicle
that is not equipped with seats and
seatbelts. Make sure everyone in your
vehicle is in a seat and properly using a
seatbelt. Failure to follow this warning
could result in serious personal injury or
death.

WARNING:

Make sure that you fully

close the liftgate to prevent exhaust
fumes from entering your vehicle. If you
are unable to fully close the liftgate,
open the air vents or the windows to
allow fresh air to enter your vehicle.
Failure to follow this instruction could
result in personal injury or death.

Liftgate - Vehicles With: Manual Liftgate

E252964

A handle is inside the liftgate to help with
closing.

Note:

Make sure that you fully close the

liftgate to prevent cargo from falling out.

Liftgate - Vehicles With: Manual Liftgate

Content .. 2 3 4 5 ..
