HYBRID ELECTRIC VEHICLE

INFORMATION –

TROUBLESHOOTING

HYBRID ELECTRIC VEHICLE

INFORMATION – WARNING

LAMPS

E144693

It illuminates if your vehicle has
an electrical component fault or
failure that causes your vehicle

to shutdown or enter a limited operating
mode. A message may appear in the
instrument cluster display.

HYBRID ELECTRIC VEHICLE

INFORMATION – INFORMATION

MESSAGES

Action

Message

Displays when a

malfunction occurs

in the high voltage

electric system.

Stop your vehicle as

soon as it is safe to

do so. Have your

vehicle checked as

soon as possible.

Stop Safely Now

HYBRID ELECTRIC VEHICLE

INFORMATION – FREQUENTLY

ASKED QUESTIONS

How long is the high voltage battery

system designed to last?

The high voltage battery system is
designed to last the life of your vehicle.

Does the high voltage battery require

maintenance?

The high voltage battery does not
require maintenance.

What should I do if the vehicle runs out

of fuel and the high voltage battery is

out of charge?

Refuel and start your vehicle normally.
The engine will recharge the high
voltage battery.

Why does the engine sometimes start

at key-on?

The vehicle's computer will determine
if an engine start is required at key-on.
It starts the engine when necessary for
cabin heating, windshield defrost, or if
the outside temperature is low.

Can I put E15 or E85 in my vehicle, and

how will it affect my fuel economy?

Your hybrid vehicle can use E15 (15%
ethanol, 85% gasoline) fuel, but you
may notice slightly reduced fuel
economy because ethanol contains
less energy per gallon than gasoline.
Your hybrid vehicle is not designed to
use E85 (85% ethanol).

Why does it take a long time before the

engine shuts down?

There are several reasons the engine
stays on for an extended amount of
time when you first start it. One
common reason is to make sure that
the emissions components are warm
enough to minimize tailpipe emission.
As the climate gets cooler, the
engine-on time is extended.

Why does my engine stay on when it is

extremely cold outside?

In order to make sure that the climate
control system can begin heating the
cabin or defrosting the windshield as
soon as a driver requests it, the engine
coolant temperature has to be kept
sufficiently hot. Keeping the engine on
is required to maintain the correct
coolant temperature.

180

Hybrid Electric Vehicle Information

(If Equipped)

PLUG-IN HYBRID ELECTRIC

VEHICLE INFORMATION

WHAT IS A PLUG-IN HYBRID

ELECTRIC VEHICLE

A plug-in hybrid electric vehicle combines
a gasoline engine with an electric motor
and rechargeable high voltage battery
allowing you to use only electricity to
power your vehicle.

HOW DOES A PLUG-IN HYBRID

ELECTRIC VEHICLE WORK

Charging your vehicle adds electrical
energy that propels the vehicle. Regularly
plug in your vehicle to get optimal
electric-only range capability from the high
voltage battery. The system maximizes the
use of electric-only operation in normal
drive mode whenever possible. System
conditions could require the engine to
operate when necessary.

When the electric-only range reaches zero,
the powertrain system switches to hybrid
operation. This means that you have
depleted the energy you gained from
plugging in and charging your vehicle. Both
the gasoline engine and electric motor
power your vehicle and maximize fuel
economy during hybrid operation. You
receive some electric-only driving with
hybrid operation as the powertrain system
maintains the high voltage battery charge
within functional limits.

PLUG-IN HYBRID ELECTRIC

VEHICLE DRIVING

CHARACTERISTICS

The gasoline engine starts and stops to
provide power when required and to save
fuel when not needed. Restarting your
vehicle is not required. Simply step on the
accelerator when you are ready to drive.
When coasting at low speeds, coming to
a stop or standing, the gas engine normally
shuts down and your vehicle operates in
electric-only mode.

Conditions that may cause the gasoline
engine to start or remain running include:

•

Considerable vehicle acceleration.

•

Driving uphill.

•

The high voltage battery charge level
is low.

•

Heating or cooling the vehicle interior
in high or low outside temperatures.

•

The gasoline engine is below normal
operating temperature.

•

Towing a trailer.

•

Certain drive modes could cause the
engine to run. See

Drive Mode

Control

(page 257).

Note:

Having your engine running is not

always an indication of inefficiency. In some
cases, it is actually more efficient than
driving in electric mode.

Your plug-in hybrid electric vehicle has
several EV drive modes to enhance your
driving experience. See

Selecting a

Plug-In Hybrid Electric Vehicle Drive

Mode

(page 259).

Your hybrid vehicle also comes with
standard hydraulic braking and
regenerative braking. Regenerative braking
is performed by your transmission and
captures brake energy and stores it in the
high voltage battery.

181

Hybrid Electric Vehicle Information

(If Equipped)

You could also notice that your engine
continues to run instead of shutting off
during extended downhill driving. The
engine stays on during this engine braking
but is not using any fuel.

You could also hear a slight whine or
whistle when operating your vehicle. This
is the normal operation of the electric
motor in the hybrid system.

PLUG-IN HYBRID ELECTRIC

VEHICLE INDICATORS

E293827

When you start your vehicle, a
green ready indicator light
appears in the instrument cluster

letting you know that your vehicle is ready
for driving.

The engine may not start because your
vehicle has a silent key start feature. This
fuel saving feature allows your vehicle to
be ready to drive without requiring the gas
engine to be running.

The indicator remains on when your vehicle
is on, whether the engine is running or not,
to indicate your vehicle is capable of
movement using the electric motor, gas
engine or both.

Typically, the engine does not start unless
the vehicle is cold, a climate control
change is requested or you press the
accelerator pedal.

WHAT IS LOW ENGINE USE MODE

Low engine use mode maintains proper
engine lubrication at sufficient temperature
and activates when you drive your vehicle
with limited engine operation.

HOW DOES LOW ENGINE USE

MODE WORK

When in low engine use mode, your vehicle
runs the engine as necessary. When low
engine use mode begins, a message
appears in the information display. If low
engine use mode does not complete
before you switch your vehicle off, it
continues the next time you start your
vehicle and the message reappears.

Note:

EV now mode is not available when

in low engine use mode.

Note:

Cold temperatures affect the engine

warm up time and the low engine use mode
may operate more frequently.

Note:

An oil change is not required but gives

you the option of not running a low engine
use cycle. Resetting the oil life monitoring
system suspends the low engine use mode.

PLUG-IN HYBRID ELECTRIC

VEHICLE INFORMATION –

TROUBLESHOOTING

PLUG-IN HYBRID ELECTRIC

VEHICLE INFORMATION –

WARNING LAMPS

E144693

It illuminates if your vehicle's
electrical system requires service
to identify the cause for your

vehicle to shutdown or enter a limited
operating mode. A message may appear
in the instrument cluster display. Have your
vehicle checked as soon as possible.

182

Hybrid Electric Vehicle Information

(If Equipped)

PLUG-IN HYBRID ELECTRIC

VEHICLE INFORMATION –

INFORMATION MESSAGES

Action

Message

Your vehicle needs
confirmation that
you unplugged it
before allowing a
start. You must
make sure your

Vehicle Plugged In

? Yes No

vehicle is
unplugged and you
respond to the
message prompt
before starting your
vehicle.

Your vehicle
detects it is still
plugged in after you
attempt to start it.

Unplug Prior to

Starting Vehicle

Your vehicle
enables the engine
due to the climate
control defrost
setting. This is
normal operation.

Engine Enabled

Due to Defrost

Setting

For full defrost
heat, press the EV
button to select
either EV Later or
EV Auto. The
engine may run to
provide more cabin
heat.

Press EV Button for

Full Defrost

Your vehicle
enables the engine
for system
performance. This
is normal operation.

Engine Enabled for

System Perform-

ance

Action

Message

You can press OK
to enable the
engine temporarily
for increased
performance when
in EV Now mode.

Press OK to Enable

Engine

Displays when in
neutral gear with
the vehicle on. Shift
out of neutral to
maintain full
vehicle function.

In Neutral Depletes

HV Battery, Shift

Out of Neutral for

Full Vehicle Func-

tion

EV functionality is
disabled and the
engine is running to
maintain fuel fresh-
ness.

Fuel Freshness

Engine may run to

maintain fuel fresh-

ness

Displays when a
malfunction occurs
in the high voltage
electric system.
Stop your vehicle as
soon as it is safe to
do so. Have your
vehicle checked as
soon as possible.

Stop Safely Now

183

Hybrid Electric Vehicle Information

(If Equipped)

WHAT IS AUTO-START-STOP

The system helps reduce fuel consumption
by stopping and restarting the engine when
your vehicle has stopped. The engine
restarts when you release the brake pedal.

In some situations, your vehicle could
restart before you release the brake pedal,
for example:

•

To maintain interior comfort.

•

To recharge the battery.

AUTO-START-STOP

PRECAUTIONS

WARNING:

Apply the parking

brake, shift into park (P), switch the
ignition off and remove the key before
you leave your vehicle. Failure to follow
this instruction could result in personal
injury or death.

WARNING:

Apply the parking

brake, shift into park (P), switch the
ignition off and remove the key before
you open the hood or have any service
or repair work completed. If you do not
switch the ignition off, the engine could
restart at any time. Failure to follow this
instruction could result in personal injury
or death.

SWITCHING AUTO-START-

STOP ON AND OFF

The system turns on when you switch the
ignition on.

Press the button to switch the
system off.

Note:

OFF

illuminates in the switch.

Note:

Deactivating the system using the

button lasts only one key cycle.

Press the button again to switch the
system back on.

Note:

The system turns off if it detects a

malfunction. If the system malfunctions,
have your vehicle checked as soon as
possible.

STOPPING THE ENGINE

Stop your vehicle, keep your foot on the
brake pedal and the transmission in drive
(D).

Note:

Power assist steering turns off when

the engine stops.

RESTARTING THE ENGINE

Release the brake pedal or press the
accelerator pedal.

A message appears in the information
display if the system requires you to take
action.

AUTO-START-STOP

INDICATORS

WARNING:

The system may

require the engine to automatically
restart when the auto-start-stop
indicator illuminates green or flashes
amber. Failure to follow this instruction
could result in personal injury.

The Auto-Start-Stop indicator
illuminates green when the
engine stops. It flashes amber

and a message appears when you need to
take action.

184

Auto-Start-Stop

E146361

The Auto-Start-Stop indicator
illuminates gray with a
strikethrough when the system

is not available.

Note:

You can display the reason why the

system is not available in the information
display.

AUTO-START-STOP –

TROUBLESHOOTING

AUTO-START-STOP –

INFORMATION MESSAGES

A message appears in the information
display if the system requires you to take
action.

Action

Condition

Message

Press the brake pedal to
restart the engine.

The system needs to restart
the engine but requires your
confirmation.

Auto StartStop Press Brake
to Start Engine

Press the brake pedal or the
accelerator pedal to restart
the engine.

The system needs to restart
the engine but requires your
confirmation.

Auto StartStop Press a
Pedal to Start Engine

185

Auto-Start-Stop

AUTO-START-STOP –

FREQUENTLY ASKED QUESTIONS
Why does the engine not always

stop when I expect it to?

The system is designed to work in a way
that complements other vehicle systems,
allowing them to operate at optimum
performance.

The system does not stop the engine if:

•

The driver door is open.

•

Your vehicle is at high altitude.

•

The heated windshield is on.

•

The engine is warming up.

•

The outside temperature is too low or
too high.

•

The battery charge is low.

•

The battery temperature is outside the
optimal operating range.

•

The engine is required to run to
maintain interior climate and reduce
fogging.

Why does the engine sometimes

restart when I do not expect it to?

The system is designed to work in a way
that complements other vehicle systems,
allowing them to operate at optimum
performance.

The system restarts the engine if:

•

You switch the heated windshield on.

•

You switch maximum defrost on.

•

Your vehicle starts to roll downhill in
neutral.

•

The engine is required to run to
maintain adequate brake system
assistance.

•

The engine is required to run to
maintain interior climate and reduce
fogging.

Can I permanently switch the

system off?

No. The system plays an important role in
reducing the fuel consumption and the CO

emissions.

Will the frequent engine starts

cause parts to wear out?

Your vehicle has an enhanced battery and
starter motor that are designed for the
increased number of engine starts.

186

Auto-Start-Stop

FUEL AND REFUELING

PRECAUTIONS

WARNING:

Do not overfill the fuel

tank. The pressure in an overfilled tank
may cause leakage and lead to fuel spray
and fire.

WARNING:

The fuel system may

be under pressure. If you hear a hissing
sound near the fuel filler inlet, do not
refuel until the sound stops. Otherwise,
fuel may spray out, which could cause
serious personal injury.

WARNING:

Fuels can cause serious

injury or death if misused or mishandled.

WARNING:

Fuel may contain

benzene, which is a cancer-causing
agent.

WARNING:

When refueling always

shut the engine off and never allow
sparks or open flames near the fuel tank
filler valve. Never smoke or use a cell
phone while refueling. Fuel vapor is
extremely hazardous under certain
conditions. Avoid inhaling excess fumes.

WARNING:

Read and follow all the

instructions on the pump island.

Follow these guidelines when refueling:

•

Extinguish all smoking materials and
any open flames before refueling your
vehicle.

•

Switch the engine off before refueling.

•

Automotive fuels can be harmful or
fatal if swallowed. Fuel is highly toxic
and if swallowed can cause death or
permanent injury. If fuel is swallowed
immediately call a physician, even if no
symptoms are immediately apparent.
The toxic effects of fuel may not be
apparent for hours.

•

Avoid inhaling fuel vapors. Inhaling fuel
vapor can lead to eye and respiratory
tract irritation. In severe cases,
excessive or prolonged breathing of
fuel vapor can cause serious illness and
permanent injury.

•

Avoid getting fuel in your eyes. If you
splash fuel in your eyes, immediately
remove contact lenses, if worn, flush
with water for 15 minutes and seek
medical attention. Failure to seek
proper medical attention could lead to
permanent injury.

•

Fuels can be harmful if absorbed
through the skin. If you splash fuel on
your skin, clothing or both, promptly
remove contaminated clothing and
thoroughly wash your skin with soap
and water. Repeated or prolonged skin
contact causes skin irritation.

•

Be particularly careful if you are taking
Antabuse or other forms of Disulfiram
for the treatment of alcoholism.
Breathing fuel vapors could cause an
adverse reaction, serious personal
injury or sickness. Immediately call a
physician if you experience any adverse
reactions.

187

Fuel and Refueling

FUEL QUALITY

SELECTING THE CORRECT FUEL
Choosing the Right Fuel

E161513

Your vehicle operates on regular unleaded
gasoline with a minimum pump (R+M)/2
octane rating of 87.

Some fuel stations, particularly those in
high altitude areas, offer fuels posted as
regular unleaded gasoline with an octane
rating below 87. The use of these fuels
could result in engine damage that will not
be covered by the vehicle warranty.

For best overall vehicle and engine
performance, premium fuel with an octane
rating of 91 or higher is recommended. The
performance gained by using premium fuel
is most noticeable in hot weather as well
as other conditions, for example when
towing a trailer.

Do not be concerned if the engine
sometimes knocks lightly. However, if the
engine knocks heavily while using fuel with
the recommended octane rating, contact
an authorized dealer to prevent any engine
damage.

We recommend Top Tier detergent
gasolines, where available to help minimize
engine deposits and maintain optimal
vehicle and engine performance. For
additional information, refer to
www.toptiergas.com.

Note:

Use of any fuel for which the vehicle

was not designed can impair the emission
control system, cause loss of vehicle
performance, and cause damage to the
engine which may not be covered by the
vehicle Warranty.

Do not use:

•

Diesel fuel.

•

Fuels containing kerosene or paraffin.

•

Fuel containing more than 15% ethanol
or E85 fuel.

•

Fuels containing methanol.

•

Fuels containing metallic-based
additives, including manganese-based
compounds.

•

Fuels containing the octane booster
additive, methylcyclopentadienyl
manganese tricarbonyl (MMT).

•

Leaded fuel, using leaded fuel is
prohibited by law.

The use of fuels with metallic compounds
such as methylcyclopentadienyl
manganese tricarbonyl (commonly known
as MMT), which is a manganese-based
fuel additive, will impair engine
performance and affect the emission
control system.

Choosing the Right Fuel - Flex Fuel

Vehicles

Flex fuel vehicles have one of the following
identifiers:

•

Yellow fuel filler cap.

•

Yellow bezel around the fuel filler inlet.

•

Yellow fuel filler housing.

•

Yellow E85 label on the fuel tank filler
door.

188

Fuel and Refueling

E161513

Your vehicle operates on regular unleaded
gasoline with a minimum pump (R+M)/2
octane rating of 87 or regular unleaded
gasoline blended with a maximum of 85%
ethanol (E85).

Note:

Use of any fuel for which the vehicle

was not designed can impair the emission
control system, cause loss of vehicle
performance, and cause damage to the
engine which may not be covered by the
vehicle Warranty.

Do not use:

•

Diesel fuel.

•

Fuels containing kerosene or paraffin.

•

Fuels containing more than 85%
ethanol or E100 fuel.

•

Fuels containing methanol.

•

Fuels containing metallic-based
additives, including manganese-based
compounds.

•

Fuels containing the octane booster
additive, methylcyclopentadienyl
manganese tricarbonyl (MMT).

•

Leaded fuel, using leaded fuel is
prohibited by law.

LOCATING THE FUEL FILLER

FUNNEL

The fuel filler funnel is under the luggage
compartment floor covering.

RUNNING OUT OF FUEL

FILLING A PORTABLE FUEL

CONTAINER

WARNING:

Flow of fuel through a

fuel pump nozzle can produce static
electricity. This can cause a fire if you are
filling an ungrounded fuel container.

189

Fuel and Refueling

Use the following guidelines to avoid
electrostatic charge build-up, which can
produce a spark, when filling an
ungrounded fuel container:

•

Only use an approved fuel container to
transfer fuel to your vehicle. Place the
container on the ground when filling it.

•

Do not fill a fuel container when it is
inside your vehicle (including the cargo
area).

•

Keep the fuel pump nozzle in contact
with the fuel container when filling it.

•

Do not use a device that holds the fuel
pump nozzle lever in the fill position.

ADDING FUEL FROM A PORTABLE

FUEL CONTAINER

WARNING:

Do not insert the nozzle

of a fuel container or an aftermarket
funnel into the fuel filler neck. This may
damage the fuel system filler neck or its
seal and cause fuel to run onto the
ground.

WARNING:

Do not pry open the

fuel tank filler valve. This could damage
the fuel system. Failure to follow this
instruction could result in fire, personal
injury or death.

WARNING:

Do not dispose of fuel

in the household refuse or the public
sewage system. Use an authorized waste
disposal facility.

When refueling the vehicle fuel tank from
a fuel container, use the fuel filler funnel
included with your vehicle. See

Locating

the Fuel Filler Funnel

(page 189).

Note:

Do not use aftermarket funnels as

they may not work with the capless fuel
system and can damage it.

When refueling the vehicle fuel tank from
a fuel container, do the following:

Fully open the fuel filler door.

E157

452

2. Fully insert the fuel filler funnel into the

fuel filler inlet.

3. Add fuel to your vehicle from the fuel

container.

4. Remove the fuel filler funnel.

5. Fully close the fuel filler door.

6. Clean the fuel filler funnel and place it

back in your vehicle or correctly dispose
of it.

Note:

If your vehicle runs out of fuel add a

minimum of 1.3 gal (5 L) of fuel to restart
the engine.

Note:

You may need to switch the ignition

from off to on several times after refueling
to allow the fuel system to pump the fuel
from the tank to the engine. When
restarting, cranking time takes a few
seconds longer than normal.

Note:

Extra funnels can be purchased from

an authorized dealer if you choose to
dispose of the funnel.

190

Fuel and Refueling

REFUELING

REFUELING SYSTEM OVERVIEW

E267248

Fuel filler door.

Fuel filler inlet.

Fuel tank filler pipe.

REFUELING YOUR VEHICLE -

EXCLUDING: PLUG-IN HYBRID

ELECTRIC VEHICLE (PHEV)

WARNING:

When refueling always

WARNING:

The fuel system may

be under pressure. If you hear a hissing
sound near the fuel filler inlet, do not
refuel until the sound stops. Otherwise,
fuel may spray out, which could cause
serious personal injury.

WARNING:

Do not pry open the

fuel tank filler valve. This could damage
the fuel system. Failure to follow this
instruction could result in fire, personal
injury or death.

WARNING:

Do not remove the fuel

pump nozzle from its fully inserted
position when refueling.

WARNING:

Stop refueling when

the fuel pump nozzle automatically
shuts off for the first time. Failure to
follow this will fill the expansion space
in the fuel tank and could lead to fuel
overflowing.

WARNING:

Do not overfill the fuel

tank. The pressure in an overfilled tank
may cause leakage and lead to fuel spray
and fire.

WARNING:

Wait at least five

seconds before removing the fuel pump
nozzle to allow any residual fuel to drain
into the fuel tank.

WARNING:

Read and follow all the

instructions on the pump island.

Fully open the fuel filler door.

2. Select the correct fuel pump nozzle for

your vehicle.

191

Fuel and Refueling

39 0

E139202

3. Insert the fuel pump nozzle up to the

first notch on the nozzle A. Keep the
fuel pump nozzle resting on the fuel
tank filler pipe.

E139203

4. Hold the fuel pump nozzle in position

B when refueling. Holding the fuel
pump nozzle in position A can affect
the flow of fuel and shut off the fuel
pump nozzle before the fuel tank is full.

E337395

5. Operate the fuel pump nozzle within

the area shown.

E1 908

19081

6. When the nozzle shuts off, wait at least

5 seconds, then slightly raise the fuel
pump nozzle and slowly remove it.

Fully close the fuel filler door.

Do not attempt to start the engine if you
have filled the fuel tank with incorrect fuel.
Incorrect fuel use could cause damage not
covered by the vehicle Warranty. Have your
vehicle immediately checked.

REFUELING YOUR VEHICLE -

HYBRID ELECTRIC VEHICLE

(HEV)/PLUG-IN HYBRID

ELECTRIC VEHICLE (PHEV)

WARNING:

When refueling always

192

Fuel and Refueling

WARNING:

The fuel system may

be under pressure. If you hear a hissing
sound near the fuel filler inlet, do not
refuel until the sound stops. Otherwise,
fuel may spray out, which could cause
serious personal injury.

WARNING:

Do not pry open the

fuel tank filler valve. This could damage
the fuel system. Failure to follow this
instruction could result in fire, personal
injury or death.

WARNING:

Do not remove the fuel

pump nozzle from its fully inserted
position when refueling.

WARNING:

Stop refueling when

the fuel pump nozzle automatically
shuts off for the first time. Failure to
follow this will fill the expansion space
in the fuel tank and could lead to fuel
overflowing.

WARNING:

Do not overfill the fuel

tank. The pressure in an overfilled tank
may cause leakage and lead to fuel spray
and fire.

WARNING:

Wait at least five

seconds before removing the fuel pump
nozzle to allow any residual fuel to drain
into the fuel tank.

WARNING:

Read and follow all the

instructions on the pump island.

When you stop your vehicle, shift into
park (P) and switch the ignition off.

E293006

2. Press the button on the left side of the

instrument panel next to the headlamp
switch to open the fuel filler door. The
fuel filler door can take up to 15
seconds to open before you can insert
a fuel filler nozzle.

39 0

E139202

3. Insert the fuel pump nozzle up to the

first notch on the nozzle A. Keep it
resting on the cover of the fuel tank
filler pipe opening.

193

Fuel and Refueling

E139203

4. Hold the fuel pump nozzle in position

B when refueling. Holding the fuel
pump nozzle in position A can affect
the flow of fuel and shut off the fuel
pump nozzle before the fuel tank is full.

E337454

5. Operate the fuel pump nozzle within

the area shown.

E1 908

19081

6. When the nozzle shuts off, wait at least

5 seconds, then slightly raise the fuel
pump nozzle and slowly remove it.

Fully close the fuel filler door.

Note:

Leaving the fuel door open could set

a check engine lamp. See

Fuel and

Refueling – Troubleshooting

(page 196).

Complete the refueling process within 20
minutes. If 20 minutes elapses, press the
button on the left side of the instrument
panel again. Fuel pump nozzle automatic
shut off could occur if you do not press the
button on the left side of the instrument
panel.

MANUALLY OPENING THE FUEL

FILLER DOOR - EXCLUDING:

HYBRID ELECTRIC VEHICLE

(HEV)/PLUG-IN HYBRID

ELECTRIC VEHICLE (PHEV)

Your vehicle does not have a fuel tank filler
cap.

Left-hand side. To open the fuel
filler door, press the center rear
edge of the fuel filler door and
then release.

Right-hand side. To open the
fuel filler door, press the center
rear edge of the fuel filler door
and then release.

194

Fuel and Refueling

Left-hand side. Pull the rear of
the fuel filler door to open it.

Right-hand side. Pull the rear of
the fuel filler door to open it.

MANUALLY OPENING THE FUEL

FILLER DOOR

WARNING:

The fuel system may

be under pressure. If you hear a hissing
sound near the fuel filler inlet, do not
refuel until the sound stops. Otherwise,
fuel may spray out, which could cause
serious personal injury.

Note:

The transmission must be in park (P)

or neutral (N).

When using the manual override lever do
the following:

Switch the ignition on.

E297793

Note:

The manual override lever is in the

driver side rear wheel well area.

2. Pull the manual override lever.

3. Switch the ignition off.

4. Complete the refueling process within

20 minutes.

Note:

Only follow this procedure if the fuel

filler door fails to open. If the problem
remains, have your vehicle checked as soon
as possible.

FUEL TANK CAPACITY

Advertised Capacity

The advertised capacity is the maximum
amount of fuel that you can add to the fuel
tank when the fuel gauge indicates empty.

195

Fuel and Refueling

Ford Escape (2022 year). Manual in english - page 11
