Ford Expedition (2022 year). Manual in english

Action

Message

Displays when the four-wheel drive system

resumes normal function.

4x4 Restored

Displays when the four-wheel drive system

detects driving conditions which tempor-

arily require greater four-wheel drive

performance. The system automatically

resumes normal function after the system

no longer detects these driving conditions.

4X4 Temporarily Locked

Displays when the system requires an

additional transmission shift to neutral (N)

to complete a transfer case shift.

Shift to Neutral

216

Four-Wheel Drive

(If Equipped)

WHAT IS THE ELECTRONIC
LIMITED-SLIP DIFFERENTIAL

The electronic limited-slip differential
system directs torque, enabling the vehicle
to drive over terrain and road conditions
that a conventional axle cannot. The
system is active at all times and requires
no input from the driver.

Note:

If your vehicle is not at optimal

operating conditions or a system fault is
present, a warning may display in the
instrument cluster. Depending on the
warning, you may need to service your
vehicle.

Operating the Electronic Limited-Slip
Differential with a Spare or
Mismatched Tires

If your vehicle has an electronic limited-slip
differential, do not use a spare tire of a
different size than the tire provided. If you
have a spare tire installed, a message may
appear indicating the system has disabled
automatically or reduced function to
prevent system overheat and damage. We
recommend you reinstall the repaired or
replaced spare tire as soon as possible.
When you replace the spare tire, the
system resumes normal operation on the
next key cycle.

Trailer Towing

The electronic limited-slip differential
enhances vehicle stability during trailer tow
operation. During high demand trailering
events, such as steep slopes, high speeds
or with a spare tire, the system may provide
a warning in the instrument cluster and

reduce function or enter a temporarily
disabled state. To resume normal function,
stop the vehicle in a safe location and
allow the unit to adequately cool. Once
the system reaches normal operating
temperatures, system function restores
and the electronic limited-slip differential
restored message displays.

ELECTRONIC LIMITED-SLIP
DIFFERENTIAL INDICATORS

E163170

The locker mode may
automatically disengage based
on certain conditions such as

vehicle speed. When engaged, a telltale in
the instrument cluster illuminates amber.
When you exceed the speed the telltale
turns gray, the locker disengages and stays
in standby mode until you meet the speed
conditions. If the system faults and the
locker cannot engage, a warning message
displays in the instrument cluster.

LOCKING AND UNLOCKING
THE ELECTRONIC LIMITED-
SLIP DIFFERENTIAL

E163170

To manually activate or
deactivate the locking feature of
the system, press the electronic

locking differential button.

With the locker engaged, the system
electronically locks the differential causing
both half shafts to turn at the same rate.
This increases traction during off road
events.

217

Electronic Limited-Slip Differential

(If Equipped)

ELECTRONIC LIMITED-SLIP DIFFERENTIAL –
TROUBLESHOOTING

ELECTRONIC LIMITED-SLIP DIFFERENTIAL – INFORMATION MESSAGES

Description and Action

Message

Displays when the system requires service. Have your vehicle

checked as soon as possible.

Check Electronic Limited

Slip Differential

Displays when the system requires service. Have your vehicle

checked as soon as possible.

Electronic Limited Slip

Differential Off See

Owner's Manual

Displays when the electronic limited slip differential system

resumes normal function.

Electronic Limited Slip

Differential Restored to

Normal

Displays if the electronic limited slip differential system

temporarily turns off due to overheating or an undersized

spare tire. If you have an undersized spare tire installed,

replace the spare tire with a full-sized tire as soon as possible.
If not, stop the vehicle in a safe location and allow the system

to cool.

Electronic Limited Slip

Differential Temporarily

Disabled

Displays if the electronic limited slip differential has limited

functionality. This could be due to an undersized spare tire

or caused by the system overheating. If you have an under-

sized spare tire installed, replace the spare tire with a full-

sized tire as soon as possible. If you do not have an under-
sized spare tire installed, the vehicle has reduced function-

ality. Have your vehicle checked as soon as possible.

Electronic Limited Slip

Differential Reduced

Torque

Displays when you select a drive mode that does not allow

the electronic limited slip differential to turn on. This may

also display when the electronic limited slip differential has

a fault and the vehicle requests the locking feature.

Electronic Limited Slip

Differential Locking

Feature Not Available

218

Electronic Limited-Slip Differential

(If Equipped)

BRAKE PRECAUTIONS

WARNING:

Driving your vehicle

with the warning lamp on is dangerous.
A significant decrease in braking
performance may occur. It may take you
longer to stop your vehicle. Have your
vehicle checked as soon as possible.
Driving extended distances with the
parking brake engaged can cause brake
failure and the risk of personal injury.

Wet brakes result in reduced braking
efficiency. Gently press the brake pedal a
few times when leaving a car wash or
driving from standing water to dry the
brakes.

Note:

Depending on applicable laws and

regulations in the country for which your
vehicle was originally built, the stoplamps
could flash during heavy braking. Following
this the hazard warning flashers could also
turn on when your vehicle comes to a stop.

ANTI-LOCK BRAKING SYSTEM

ANTI-LOCK BRAKING SYSTEM
LIMITATIONS

The anti-lock braking system does not
eliminate the risk of crash when:
•

You drive too closely to the vehicle in
front of you.

•

Your vehicle is hydroplaning.

•

You take corners too fast.

•

The road surface is poor.

Note:

If the system activates, the brake

pedal could pulse and travel further.
Maintain pressure on the brake pedal.

BRAKE OVER ACCELERATOR

In the event the accelerator pedal
becomes stuck or entrapped, apply steady
and firm pressure to the brake pedal to
slow the vehicle and reduce engine power.
If you experience this condition, apply the
brakes and bring your vehicle to a safe
stop. Move the transmission to park (P),
switch the engine off and apply the parking
brake. Inspect the accelerator pedal for
any interference. If none are found and the
condition persists, have your vehicle towed
to the nearest authorized dealer.

LOCATING THE BRAKE FLUID
RESERVOIR

See

Under Hood Overview

(page 398).

CHECKING THE BRAKE FLUID

WARNING:

Do not use any fluid

other than the recommended brake fluid
as this will reduce brake efficiency. Use
of incorrect fluid could result in the loss
of vehicle control, serious personal injury
or death.

WARNING:

Only use brake fluid

from a sealed container. Contamination
with dirt, water, petroleum products or
other materials may result in brake
system damage or failure. Failure to
adhere to this warning could result in the
loss of vehicle control, serious personal
injury or death.

WARNING:

Do not allow the fluid

to touch your skin or eyes. If this
happens, rinse the affected areas
immediately with plenty of water and
contact your physician.

219

Brakes

WARNING:

The brake system

could be affected if the brake fluid level
is below the

MIN

mark or above the

MAX

mark on the brake fluid reservoir.

E170684

Park your vehicle on a level surface.

2. Look at the brake fluid reservoir to see

where the brake fluid level is relative
to the

MIN

and the

MAX

marks on the

reservoir.

Note:

To avoid fluid contamination, the

reservoir cap must remain in place and fully
tight, unless you are adding fluid.

Only use fluid that meets our
specifications. See

Capacities and

Specifications

(page 451).

BRAKE FLUID SPECIFICATION

See

Brake Fluid Specification

(page 457).

BRAKES –
TROUBLESHOOTING

BRAKES – WARNING LAMPS

If the ABS indicator illuminates
when you are driving, this
indicates a malfunction. Your

vehicle continues to have normal braking
without the anti-lock braking system
function. See an authorized dealer.

It also momentarily illuminates when you
switch the ignition on to confirm the lamp
is functional. If it does not illuminate when
you switch the ignition on, or begins to
flash at any time, have the system checked
by an authorized dealer.

E270480

The brake indicator momentarily
illuminates when you switch the
ignition on to confirm the lamp

is functional. It may also illuminate when
you apply the parking brake and the
ignition is on. If it illuminates when your
vehicle is moving, make sure the parking
brake is disengaged. If the parking brake
is disengaged, this indicates low brake fluid
level or a brake system fault. See an
authorized dealer.

BRAKES – FREQUENTLY ASKED
QUESTIONS

Is it normal for my brakes to make
noise?

Occasional brake noise is normal. If a
metal-to-metal, continuous grinding,
or continuous squeal sound is present,
the brake lining could be worn-out.
Have the system checked by an
authorized dealer.

220

Brakes

There is an electrical motor sound
when I press on the brake pedal or
activate the park brake switch. Is this
normal?

Yes, those sounds are the electronic
brake booster or the electronic park
brake operating.

Note:

Brake dust could accumulate on the

wheels, even under normal driving
conditions. Some dust is normal as the
brakes wear and does not contribute to
brake noise. See

Cleaning Wheels

(page

415).

221

Brakes

WHAT IS THE ELECTRIC
PARKING BRAKE

The electric parking brake is used to hold
your vehicle on slopes and flat roads.

APPLYING THE ELECTRIC
PARKING BRAKE

WARNING:

Always fully apply the

parking brake and make sure you shift
into park (P). Failure to follow this
instruction could result in personal injury
or death.

WARNING:

If you drive extended

distances with the parking brake applied,
you could cause damage to the brake
system.

E267156

The switch is on the lower part
of the instrument panel.

Pull the switch up.

The red warning lamp flashes during
operation and illuminates when the parking
brake is applied.

Note:

You can apply the electric parking

brake when the ignition is off.

Note:

The electric parking brake could

apply when the transmission selector is in
park (P). See

Park (P)

(page 204).

APPLYING THE ELECTRIC
PARKING BRAKE IN AN
EMERGENCY

You can use the electric parking brake to
slow or stop your vehicle in an emergency.

Pull the switch up and hold it.

The electric parking brake continues to
slow your vehicle down unless you release
the switch.

The red warning lamp illuminates, a tone
sounds and the stoplamps turn on when
you use the electric parking brake in an
emergency.

Note:

Do not apply the electric parking

brake when your vehicle is moving, except
in an emergency. If you repeatedly use the
electric parking brake to slow or stop your
vehicle, you could cause damage to the
brake system.

MANUALLY RELEASING THE
ELECTRIC PARKING BRAKE

Switch the ignition on.

2. Press and hold the brake pedal.

3. Push the switch down.

The red warning lamp turns off.

Pulling Away on a Hill When Towing a
Trailer

Press and hold the brake pedal.

2. Pull the switch upward and hold it.

3. Shift into gear.
4. Press the accelerator pedal until engine

has developed sufficient torque to
prevent your vehicle from rolling down
the hill.

5. Release the switch and pull away in a

normal manner.

AUTOMATICALLY RELEASING
THE ELECTRIC PARKING
BRAKE

Close the driver door.

2. Shift into gear.

222

Electric Parking Brake

3. Press the accelerator pedal and pull

away in a normal manner.

ELECTRIC PARKING BRAKE
AUDIBLE WARNING

Sounds when the parking brake is on and
your vehicle is moving. If the warning tone
continues after you have released the
parking brake, this indicates a malfunction.
Have your vehicle checked as soon as
possible.

RELEASING THE ELECTRIC
PARKING BRAKE IF THE
VEHICLE BATTERY HAS RUN
OUT OF CHARGE

WARNING:

The electric parking

brake does not operate if the vehicle
battery has run out of charge.

Connect a booster battery to the vehicle
battery to release the electric parking brake
if the vehicle battery has run out of charge.
See

Jump Starting the Vehicle

(page

381).

ELECTRIC PARKING BRAKE –
TROUBLESHOOTING

ELECTRIC PARKING BRAKE –
WARNING LAMPS

Brake System

E270480

It illuminates red when you apply
the parking brake and your
vehicle is on. If the lamp flashes
when the parking brake has been
released, this indicates the
parking brake system requires

service. Have your vehicle checked as
soon as possible.

Note:

Lamps may vary depending on region.

Electric Parking Brake

E146190

When the lamp illuminates
yellow, it indicates a malfunction
in the electric parking brake.

Have your vehicle checked as soon as
possible.

223

Electric Parking Brake

ELECTRIC PARKING BRAKE – INFORMATION MESSAGES

Action

Message

The electric parking brake is set and a manual release

is attempted without the brake pedal being pressed.

To Release: Press Brake and

Switch

The electric parking brake is set and an automatic

release is attempted but cannot be performed.

Perform a manual release.

Park Brake Use Switch to

Release

The electric parking brake is set and your vehicle speed

exceeds 3 mph (5 km/h). Release the parking brake

before continuing driving.

Release Park Brake

The electric parking brake is not fully applied.

Park Brake Not Applied

The electric parking brake is not fully released.

Park Brake Not Released

The electric parking brake system has been put into a

special mode that is used to allow service of the rear

brakes. Contact an authorized dealer.

Park Brake Maintenance Mode

The electric parking brake system has detected a

condition that requires service. Some functionality

may still be available. Contact an authorized dealer.

Park Brake Limited Function

Service Required

The electric parking brake system has detected a

condition that requires service. Contact an authorized

dealer.

Park Brake Malfunction Service

Now

224

Electric Parking Brake

WHAT IS REVERSE BRAKING
ASSIST

The system uses sensors on the rear of
your vehicle to detect a possible collision
and applies the brakes to either reduce the
damage from impact, or to assist in
avoiding the collision.

HOW DOES REVERSE
BRAKING ASSIST WORK

Reverse Braking Assist functions when in
reverse (R) and traveling at a speed of
1–7 mph (1.5–12 km/h).

If the system detects an obstacle behind
your vehicle, it provides a warning through
the rear parking aid or cross traffic alert
system.

REVERSE BRAKING ASSIST
PRECAUTIONS

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

To help avoid personal

injury, always use caution when in
reverse (R) and when using the sensing
system.

WARNING:

The system may not

operate properly during severe weather
conditions, for example snow, ice, heavy
rain and spray. Always drive with due
care and attention. Failure to take care
may result in a crash.

WARNING:

Traffic control systems,

fluorescent lamps, inclement weather,
air brakes, external motors and fans may
affect the correct operation of the
sensing system. This may cause reduced
performance or false alerts.

WARNING:

Some situations and

objects prevent hazard detection. For
example low or direct sunlight, inclement
weather, unconventional vehicle types,
and pedestrians. Apply the brakes when
necessary. Failure to follow this
instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

Do not use the system

with accessories that extend beyond the
front or rear of your vehicle, for example
a trailer hitch or bike rack. The system is
not able to make corrections for the
additional length of the accessories.

The system only applies the brakes for a
short period of time when an event occurs.
Act as soon as you notice the brakes apply
in order to remain in control of the vehicle.
If you do not intervene the vehicle may
start to move again.

Note:

Certain add-on devices around the

bumper or fascia may create false alerts.
For example, large trailer hitches, bicycle or
surfboard racks, license plate brackets,
bumper covers or any other device that may
block the normal detection zone of the
system. Remove the add-on device to
prevent false alerts.

Note:

The system does not react to small

or moving objects, particularly those close
to the ground.

Note:

The system does not operate during

hard acceleration or steering.

225

Reverse Braking Assist

Note:

If your vehicle sustains damage to

the bumper or fascia leaving it misaligned
or bent, it could alter the sensing zone
causing inaccurate measurement of
obstacles or false alerts.

Note:

Vehicle loading and suspension

changes can impact the angle of the sensors
and may change the normal detection zone
of the system resulting in inaccurate
measurement of obstacles or false alerts.

Note:

When you connect a trailer, the

system may detect the trailer and provide
an alert, or the system turns off. If the
system does not turn off, switch the system
off manually after you connect the trailer.

Note:

You may experience reduced system

performance on road surfaces that limit
deceleration. For example, roads with ice,
loose gravel, mud or sand.

SWITCHING REVERSE
BRAKING ASSIST ON AND OFF

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Switch

Reverse Brake Assist

on or off.

Note:

The system is unavailable when the

rear parking aid, cross traffic alert or traction
control is off.

Note:

If your vehicle is not equipped with

cross traffic alert the reverse braking assist
relies on input from the rear parking aid and
rear camera sensors.

Note:

The default setting is on in some

regions.

OVERRIDING REVERSE
BRAKING ASSIST

There could be instances when
unexpected or unwanted braking occurs.
Firmly pressing the accelerator pedal or
switching the feature off overrides the
system.

REVERSE BRAKING ASSIST
INDICATORS

If the system determines that a collision
with an obstacle may occur, full braking
may apply. Bring your vehicle to a stop a
safe distance away from the obstacle.

E293490

A message and warning
indicator appear when the
system applies the brakes.

226

Reverse Braking Assist

REVERSE BRAKING ASSIST – TROUBLESHOOTING

REVERSE BRAKING ASSIST – INFORMATION MESSAGES

Action

Message

Make sure that all doors, liftgate and hood

are closed. Drive the vehicle on a straight

road for a short period. Make sure the

parking aids and cross traffic alert systems
are on. If the message remains on, have the

system checked as soon as possible.

Reverse Brake Assist Not Available See

Manual

Displays when a system error has occurred.

Have your vehicle checked as soon as

possible.

Reverse Brake Assist Fault

Displays when reverse brake assist is off.

Reverse Brake Assist Off

227

Reverse Braking Assist

REVERSE BRAKING ASSIST –
FREQUENTLY ASKED QUESTIONS

Why is reverse braking assist unavailable?

•

Make sure the reverse braking assist is
on. See

Switching Reverse Braking

Assist On and Off

(page 226).

•

Make sure that all doors and the
liftgate or tailgate are closed. Drive the
vehicle on a straight road for a short
period. If the message remains, contact
an authorized dealer.

•

Make sure the cross traffic alert system
is on if equipped. See

Switching Cross

Traffic Alert On and Off

(page 311).

•

Make sure the rear parking aid system
is on. See

Rear Parking Aid

(page 247).

•

Make sure the traction control is on.
See

Switching Traction Control On

and Off

(page 234).

Note:

The traction control automatically

turns off if four-wheel drive low and certain
drive modes such as mud/ruts and
snow/sand is activated.

•

The vehicle may have sustained a rear
end impact. Contact an authorized
dealer to have the sensors checked for
proper coverage and operation.

•

An anti-lock brake, traction control or
stability control event may have
occurred. Reverse braking assist
resumes operation when the event is
complete.

•

Make sure the rear view camera and
360 degree camera are not dirty or
obstructed. If dirty, clean the camera.
If the message still appears after
cleaning the camera, wait a short time
for the message to clear. If the
message does not clear, contact an
authorized dealer.

•

Make sure the cross traffic alert and
rear parking aid sensors are not
blocked or faulty. See

Locating the

Cross Traffic Alert Sensors

(page

311). See

Locating the Rear Parking

Aid Sensors

(page 248).

•

You recently had your vehicle serviced,
or the battery disconnected. Drive your
vehicle a short distance to resume
system operation.

•

Reverse braking assist does not
function when you connect a trailer.
Operation resumes when you
disconnect the trailer.

Note:

If the answers to why the system is

unavailable do not assist in returning reverse
braking assist to available, have the system
checked as soon as possible.

228

Reverse Braking Assist

WHAT IS CROSS TRAFFIC
BRAKING

The system is designed to reduce impact
damage or assist in avoiding a collision by
using the sensors on the rear of your
vehicle to detect a possible collision and
applies the brakes.

HOW DOES CROSS TRAFFIC
BRAKING WORK

The system only reacts for vehicles
approaching from the sides when you shift
into reverse (R).

If the system detects a vehicle approaching
your vehicle, it provides a warning through
the cross traffic alert system.

The system only applies the brakes for a
short period of time when an event occurs.
Take action as soon as you notice the
system applying the brakes in order to
remain in control of your vehicle, the
system does not do this for you.

Note:

You need to enable cross traffic alert

for the system to function.

CROSS TRAFFIC BRAKING
PRECAUTIONS

WARNING:

You are responsible for

WARNING:

To help avoid personal

injury, always use caution when in
reverse (R) and when using the sensing
system.

WARNING:

The system may not

operate properly during severe weather
conditions, for example snow, ice, heavy
rain and spray. Always drive with due
care and attention. Failure to take care
may result in a crash.

WARNING:

Traffic control systems,

fluorescent lamps, inclement weather,
air brakes, external motors and fans may
affect the correct operation of the
sensing system. This may cause reduced
performance or false alerts.

WARNING:

Some situations and

objects prevent hazard detection, for
example, inclement weather,
unconventional vehicle types and
pedestrians. Apply the brakes when
necessary. Failure to follow this
instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

Do not use the system

Note:

Certain add-on devices around the

229

Cross Traffic Braking

Note:

If your vehicle sustains damage to

the bumper or fascia leaving it misaligned
or bent, it could alter the sensing zone
causing inaccurate measurement of
obstacles or false alerts.

Note:

Vehicle loading and suspension

changes can impact the angle of the sensors
and may change the normal detection zone
of the system resulting in inaccurate
measurement of obstacles or false alerts.

Note:

When you connect a trailer, the

system may detect the trailer and provide
an alert, or the system turns off. If the
system does not turn off, switch the system
off manually after you connect the trailer.

Note:

You may experience reduced system

performance on road surfaces that limit
deceleration. For example, roads with ice,
loose gravel, mud or sand.

SWITCHING CROSS TRAFFIC
BRAKING ON AND OFF

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Switch

Cross Traffic Braking

on or

off.

OVERRIDING CROSS TRAFFIC
BRAKING

There could be instances when
unexpected or unwanted braking occurs.
Firmly pressing the accelerator pedal or
switching the feature off overrides the
system.

CROSS TRAFFIC BRAKING
INDICATORS

If the system determines that a collision
with an obstacle may occur, full braking
may apply. Bring your vehicle to a stop a
safe distance away from the obstacle.

E293490

A message and warning
indicator appear when the
system applies the brakes.

CROSS TRAFFIC BRAKING – TROUBLESHOOTING

CROSS TRAFFIC BRAKING – INFORMATION MESSAGES

Action

Message

Make sure that all doors, liftgate and hood

are closed. Drive the vehicle on a straight

road for a short period. Make sure the

parking aids and cross traffic alert systems
are on. If the message remains on, have the

system checked as soon as possible.

Reverse Brake Assist Not Available See

Manual

Displays when a system error has occurred.

Have your vehicle checked as soon as

possible.

Reverse Brake Assist Fault

Displays when cross traffic braking is off.

Reverse Brake Assist Off

230

Cross Traffic Braking

CROSS TRAFFIC BRAKING –
FREQUENTLY ASKED QUESTIONS

Why is cross traffic braking unavailable?

•

Make sure the cross traffic alert system
is on. See

Cross Traffic Alert

(page

310).

•

The vehicle has sustained a rear end
impact. Contact an authorized dealer
to have the sensors checked for proper
coverage and operation.

•

An ABS, traction control or stability
control event may have occurred. Cross
traffic braking resumes operation when
the event is complete.

•

Make sure there are no blocked or
faulted sensors. See

Cross Traffic

Alert

(page 310).

•

You recently had your vehicle serviced,
or the battery disconnected. Drive your
vehicle a short distance to resume
system operation.

Note:

If the answers to why the system is

unavailable do not assist in returning cross
traffic braking to available, have the system
checked as soon as possible.

231

Cross Traffic Braking

Ford Expedition (2022 year). Manual in english - page 13
