DAYTIME RUNNING LAMPS -
VEHICLES WITH:
CONFIGURABLE DAYTIME
RUNNING LAMPS

WARNING:

The daytime running

lamps system does not activate the rear
lamps and may not provide adequate
lighting during low visibility driving
conditions. Make sure you switch the
headlamps on, as appropriate, during all
low visibility conditions. Failure to do so
may result in a crash.

Switch the daytime running lamps on or
off using the touchscreen:

Select

Settings

. See

Settings

(page

458).

2. Select

Vehicle

3. Select

Lighting

The daytime running lamps turn on when:
1.

The lamps are on in the information
display.

2. You switch the ignition on.
3. The transmission is not in park (P) for

vehicles with automatic transmissions
or you release the parking brake for
vehicles with manual transmissions.

4. The lighting control is in the autolamps

position.

5. The headlamps are off.

The other lighting control switch positions
do not turn on the daytime running lamps.

If the daytime running lamps are off in the
information display, the lamps stay off in
all switch positions.

DAYTIME RUNNING LAMPS -
VEHICLES WITH: DAYTIME
RUNNING LAMPS (DRL)

WARNING:

The daytime running

The system turns the lamps on in daylight
conditions.

To switch the system on, switch the
lighting control to any position except
headlamps.

FRONT FOG LAMPS

(IF EQUIPPED)

Switching the Front Fog Lamps On
or Off

Only switch the front fog lamps on during
reduced visibility.

You can switch the front fog lamps on if
any of the following occur:
•

You set the lighting control to the
parking lamps position.

•

You set the lighting control to the
headlamps position.

•

You set the lighting control to the
autolamps position and the headlamps
are on.

The front fog lamp button is on the lighting
control.

Press the button to switch the
front fog lamps on or off.

Lighting

Note:

The brightness of the daytime running

lamps may decrease when the front fog
lamps are switched on.

Front Fog Lamp Indicator

It illuminates when you switch
the front fog lamps on.

ADAPTIVE HEADLAMPS

(IF

EQUIPPED)

The headlamp beams move in the same
direction as the steering wheel. This
provides more visibility when driving
around curves.

A. Without adaptive headlamps.
B. With adaptive headlamps.

E161714

The system only works with the lighting
control in the autolamp position.

You can switch the system on or off in the
touchscreen.

Note:

There is a delay of two to five

seconds before the system operates when
you drive your vehicle.

Note:

The system is only active at speeds

above 3 mph (5 km/h).

System Check

(If Equipped)

The system has a power-up movement
check feature. When you start your vehicle,
the lamps track left to right, then back to
center to alert the driver that the system
is working properly.

DIRECTION INDICATORS

Switching the Direction Indicators
On and Off

E242676

Push the lever up or down to switch the
direction indicators on.

Note:

Tap the lever up or down to make the

direction indicators flash three times.

Set the lever to the middle position to
switch the direction indicators off.

Lighting

Direction Indicator

Flashes when you switch the
direction indicators on.

Note:

An increase in the rate of flashing

warns of a failed indicator bulb.

INTERIOR LAMPS

The lamps turn on under the following
conditions:
•

You open any door.

•

You press a button on the remote
control.

•

You press the all lamps on button on
the overhead console.

Front Interior Lamp

E281230

The front interior lamp switches are on the
overhead console.

Note:

The position of each button on the

overhead console depends on your vehicle.

All Lamps On or Off

Press to switch all interior lamps
on or off.

Individual Map Lamps

E262193

Press to switch the left-hand
individual dome lamp on and off.

Press to switch the right-hand
individual dome lamp on and off.

Interior Lamp Function

Press to switch the interior lamp
function on and off.

When the interior lamp function is off and
you open a door, the courtesy and door
lamps stay off.

When the interior lamp function is on and
you open a door, the courtesy and door
lamps turn on.

Note:

The indicator lamp lights amber

when the door function is off.

Rear Interior Lamps

E281231

The rear interior lamps may be above the
rear seat or above the rear windows.

Press to switch the lamps on or
off.

Note:

If you switch the rear lamps on

through the overhead console, you cannot
switch them off with the rear lamp switch.

AMBIENT LIGHTING -
VEHICLES WITH: 8 INCH
CENTER DISPLAY SCREEN

Use the touchscreen to select the
following:

Lighting

E280315

Select the settings option on the
feature bar.

E280617

Select ambient lighting.

E280369

Switching Ambient Lighting On

Touch a color once.

Changing the Color

Touch any color once.

Adjusting the Brightness

Drag the selected color up or down.

Switching Ambient Lighting Off

Touch the selected color once or drag the
selected color down to zero brightness.

AMBIENT LIGHTING -
VEHICLES WITH: 10.1 INCH
CENTER DISPLAY SCREEN

Use the touchscreen to select the
following:

E280315

Select the settings option on the
feature bar.

E280617

Select ambient lighting.

E280370

Switching Ambient Lighting On

Touch a color once.

Changing the Color

Touch any color once.

Adjusting the Brightness

Drag the selected color left or right.

Switching Ambient Lighting Off

Touch the selected color once or drag the
selected color left to zero brightness.

Lighting

WHAT IS AUTOMATIC HIGH
BEAM CONTROL

The system turns on high beams if it is dark
enough and no other traffic is present. If it
detects an approaching vehicle’s
headlamps or tail lamps, or street lighting
ahead, the system turns the high beams
off. Low beams remain on.

A camera sensor, centrally mounted
behind the windshield of your vehicle,
continuously monitors conditions to turn
the high beams on and off.

SWITCHING AUTOMATIC HIGH
BEAM CONTROL ON AND OFF

WARNING:

Do not use the system

in poor visibility, for example fog, heavy
rain, spray or snow.

Press

Settings

2. Press

Vehicle

3. Press

Lighting

Activating the Automatic High
Beam Control

E281240

Switch the lighting control to the
autolamps position. See

Autolamps

(page 88).

Note:

The lighting control defaults to

autolamps each time you switch your
vehicle on.

When active, the high beams turn on if all
of the following occur:
•

The ambient light level is low enough.

•

There is no traffic in front of your
vehicle.

•

The vehicle speed is greater than
approximately 32 mph (51 km/h).

When active, the high beams turn off if any
of the following occur:
•

The ambient light level is high enough
that the system does not require high
beams.

•

The system detects an approaching
vehicle's headlamps or tail lamps.

•

The system detects severe rain, snow
or fog.

•

The camera is blocked.

•

The vehicle speed falls below
approximately 27 mph (44 km/h).

Note:

The deactivation speed is lower on

curves.

Note:

There could be a delay in high beam

reactivation in certain curvy road situations.

Note:

If there is a blocked sensor, the

system may not operate properly. Keep the
windshield free from obstruction or damage.

Note:

The system may not operate properly

in cold or inclement conditions. You can
switch on the high beams by overriding the
system.

Note:

If the system detects a blockage, for

example bird droppings, bug splatter, snow
or ice, the system goes into low beam mode
until you clear the blockage. If there is a
blocked camera, a message may appear in
the information display.

Note:

Using much larger tires or adding

vehicle accessories such as snowplows can
modify your vehicle's ride height and
degrade automatic high beam control
performance.

AUTOMATIC HIGH BEAM
CONTROL INDICATORS

The indicator illuminates to
confirm when the system is
ready to assist.

Automatic High Beam Control

(If Equipped)

OVERRIDING AUTOMATIC
HIGH BEAM CONTROL

WARNING:

The system does not

relieve you of your responsibility to drive
with due care and attention. You may
need to override the system if it does not
turn the high beams on or off.

WARNING:

You may need to

override the system when approaching
other road users.

WARNING:

You may need to

override the system during inclement
weather.

E248603

Push the lever away from you to switch
between high beam and low beam.

Automatic High Beam Control

(If Equipped)

POWER WINDOWS

WARNING:

Do not leave children

unattended in your vehicle and do not
let them play with the power windows.
Failure to follow this instruction could
result in personal injury.

WARNING:

When closing the

power windows, verify they are free of
obstruction and make sure that children
and pets are not in the proximity of the
window openings.

Press the control to open the
window. Lift the control to close
the window.

Note:

If you hear a pulsing noise when just

one of the windows is open. Lower the
opposite window slightly to reduce this
noise.

One-Touch Down

Note:

One-touch down applies to the front

windows only.

Fully press the switch and release it. Press
again or lift it to stop the window.

One-Touch Up

Note:

One-touch up applies to the front

windows only.

Fully lift the switch and release it. Press or
lift it again to stop the window.

Resetting One-Touch Up

Start the engine.

Lift and hold the window switch until
you fully close the door window.
Continue to hold the switch for a few
seconds after you close the window.

2. Release the window switch.

3. Press and hold the window switch until

you fully open the door window.

4. Release the window switch.

5. Lift and hold the window switch until

you fully close the window.

6. Test for correct window operation by

carrying out the one-touch down and
one-touch up features.

Bounce-Back

The window stops when closing. It reverses
some distance if there is an obstacle in the
way.

Overriding the Bounce-Back Feature

WARNING:

If you override

bounce-back, the window does not
reverse if it detects an obstacle. Take
care when closing the windows to avoid
personal injury or damage to your
vehicle.

The window stops if you release the switch
before the window fully closes. Pull up the
window switch and hold within a few
seconds of the window reaching the
bounce-back position. The window travels
up with no bounce-back protection.

Window Lock

E295318

Windows and Mirrors

Press the control to lock or unlock the rear
window controls. It illuminates when you
lock the rear window controls.

Accessory Delay

You can use the window switches for
several minutes after you switch the
ignition off or until you open either front
door.

GLOBAL OPENING

You can use the remote control to open
the windows with the ignition off.

Note:

You can enable or disable this feature

in the information display, or see an
authorized dealer. See

General

Information

(page 116).

Note:

To operate this feature, accessory

delay must not be active.

Remote Control Front Windows

After you unlock your vehicle with the
remote control, you can open the windows
for a short period of time. Press and hold
the remote control unlock button to open
the windows. Release the button once
movement starts. Press the lock or unlock
button to stop movement.

EXTERIOR MIRRORS -
EXCLUDING: ST

Power Exterior Mirrors

WARNING:

Do not adjust the

mirrors when your vehicle is moving. This
could result in the loss of control of your
vehicle, serious personal injury or death.

E295322

Power-folding mirror control.

Window lockout.

Adjustment control.

Right-hand mirror.

Left-hand mirror.

To adjust your mirrors, switch your vehicle
on with the ignition in accessory mode or
the engine running and then:
1.

Select the mirror you want to adjust.
The control light turns on.

2. Use the adjustment control to adjust

the position of the mirror.

3. Press the mirror control again. The

control light turns off.

Fold-Away Exterior Mirrors

Push the mirror toward the door window
glass. Make sure that you fully engage the
mirror in its support when returning it to its
original position.

Auto-Folding Mirrors

(If Equipped)

The exterior mirrors fold in toward the
glass after you place the transmission into
park (P), turn off the vehicle and lock the
vehicle. The exterior mirrors unfold and
return to their driving position after you
unlock the vehicle.

Windows and Mirrors

You can switch this feature on and off
through the information display. See

General Information

(page 116).

You can fold the mirrors on demand by
pressing the power-folding mirror control
on the door. The control lights and the
mirrors fold in toward the glass. Press the
control again to unfold the mirrors. The
control light turns off.

Note:

If you use the power-folding control

to fold the mirrors on demand with the auto
fold feature on, you must use the control
again to unfold them.

Loose Mirror

If you manually fold your power-folding
mirrors, they may not work properly even
after you re-position them. You need to
reset them if:
•

The mirrors vibrate when you drive.

•

The mirrors feel loose.

•

The mirrors do not stay in the folded or
unfolded position.

•

One of the mirrors is not in its normal
driving position.

To reset the power-fold feature, use the
power-folding mirror control to fold and
unfold the mirrors. You may hear a loud
noise as you reset the power-folding
mirrors. This sound is normal. Repeat this
process as needed each time you manually
fold the mirrors.

Heated Exterior Mirrors

(If Equipped)

See

Heated Exterior Mirrors

(page 143).

Memory Mirrors

(If Equipped)

You can save and recall the mirror
positions through the memory function.
See

Memory Function

(page 151).

Auto-dimming Feature

(If Equipped)

The driver exterior mirror dims when the
interior auto-dimming mirror turns on.

Direction Indicator Mirrors

(If Equipped)

When the vehicle is running, the
forward-facing portion of the appropriate
mirror housing blinks when you switch on
the direction indicator.

Puddle Lamps

(If Equipped)

The lamps on the bottom part of the mirror
housing light when you use your
transmitter to unlock the doors or when
you open a door.

360-Degree Camera

(If Equipped)

See

360 Degree Camera

(page 240).

Blind Spot Information System

See

Blind Spot Information System

(page 263).

EXTERIOR MIRRORS - ST

Power Exterior Mirrors

WARNING:

Do not adjust the

mirrors when your vehicle is moving. This
could result in the loss of control of your
vehicle, serious personal injury or death.

Windows and Mirrors

E295322

Power-folding mirror control.

Window lockout.

Adjustment control.

Right-hand mirror.

Left-hand mirror.

To adjust your mirrors, switch your vehicle
on - with the ignition in accessory mode or
the engine running and then:
1.

Select the mirror you want to adjust.
The control lights.

2. Use the adjustment control to adjust

the position of the mirror.

3. Press the mirror control again. The

control light turns off.

Fold-Away Exterior Mirrors

Push the mirror toward the door window
glass. Make sure that you fully engage the
mirror in its support when returning it to its
original position.

Auto-Folding Mirrors

The exterior mirrors automatically fold in
toward the glass after you place the
transmission into park (P), turn off the
vehicle, open and close the driver's side
door and lock the vehicle. The exterior
mirrors automatically unfold and return to
their driving position after you unlock the
vehicle and open and close the driver's side
door.

You can switch this feature on and off
through the information display. See

General Information

(page 116).

Note:

If you use the power-folding control

to fold the mirrors on demand with the auto
fold feature on, you must use the control
again to unfold them.

Loose Mirror

If you manually fold your power-folding
mirrors, they may not work properly even
after you re-position them. You need to
reset them if:
•

The mirrors vibrate when you drive.

•

The mirrors feel loose.

•

The mirrors do not stay in the folded or
unfolded position.

•

One of the mirrors is not in its normal
driving position.

Windows and Mirrors

Heated Exterior Mirrors

See

Heated Exterior Mirrors

(page 143).

Memory Mirrors

You can save and recall the mirror
positions through the memory function.
See

Memory Function

(page 151).

Auto-dimming Feature

The driver exterior mirror dims when the
interior auto-dimming mirror turns on.

Direction Indicator Mirrors

When the vehicle is running, the
forward-facing portion of the appropriate
mirror housing blinks when you switch on
the direction indicator.

Puddle Lamps

The lamps on the bottom part of the mirror
housing light when you use your
transmitter to unlock the doors or when
you open a door.

Blind Spot Information System

See

Blind Spot Information System

(page 263).

INTERIOR MIRROR

WARNING:

Do not adjust the

mirrors when your vehicle is moving. This
could result in the loss of control of your
vehicle, serious personal injury or death.

Note:

Do not clean the mirror housing or

glass with harsh abrasives, fuel or other
petroleum-based cleaning products.

You can adjust the interior mirror to your
preference. Some mirrors also have a
second pivot point. This lets you move the
mirror head up or down and from side to
side.

Manual Dimming Mirror

Pull the tab below the mirror toward you
to reduce the effect of bright light from
behind.

Automatic Dimming Mirror

(If Equipped)

Note:

Do not block the sensors on the front

and back of the mirror. A rear center
passenger or raised rear center head
restraint may also block light from reaching
the sensor.

The mirror dims to reduce the effect of
bright light from behind. It returns to
normal when the bright light from behind
is no longer present or if you shift into
reverse (R).

SUN VISORS

E138666

Rotate the sun visor toward the side
window and extend it rearward for extra
shade.

Windows and Mirrors

Illuminated Vanity Mirror

E162197

Lift the cover to switch the lamp on.

SUN SHADES

Rear Side Windows

E74809

Pull the blind up and attach it to the hooks
A.

MOONROOF

(IF EQUIPPED)

WARNING:

Do not leave children

unattended in your vehicle and do not
let them play with the moonroof. Failure
to follow this instruction could result in
personal injury.

WARNING:

When closing the

moonroof, verify that it is free of
obstruction and make sure that children
and pets are not in the proximity of the
roof opening.

The moonroof controls are on the
overhead console and have a one-touch
open and close feature. To stop it during
one-touch operation, press the control a
second time.

Opening and Closing the Moonroof

E295253

Moonroof open.

Press and

release to open the moonroof.

Moonroof vent or close.

Press

and release to vent or close the
moonroof.

100

Windows and Mirrors

Sunshade open.

Press and

release to open the sunshade.
The sunshade opens with the
moonroof. You can also
manually open the sunshade
with the moonroof closed.

Sunshade close.

Press and

release to close the sunshade.

Note:

The sunshade stops short of the

fully open position for the comfort of rear
passengers. To fully open the sunshade,
press the control again.

Note:

When closing, the sunshade stops

at the first panel for the dual panel
moonroof. Press and release again to
continue to fully close the sunshade.

Rear SunShade Opening and
Closing

(If Equipped)

E297640

Sunshade close.

Press and

release to close the sunshade.

Sunshade open.

Press and

release to open the sunshade.
The sunshade opens with the
moonroof. You can also
manually open the sunshade
with the moonroof closed.

Note:

The rear sunshade open and close

controls can be on the rear console or fold
down armrest bezel.

Note:

The sunshade stops short of its fully

opened position for the comfort of rear
passengers. To fully open the sunshade,
press the control again.

Bounce-Back

The moonroof reverses some distance if it
detects an obstacle when closing.

To override this feature, press and hold the
moonroof close control within two seconds
after the roof comes to a stop following a
bounce-back reversal.

101

Windows and Mirrors

GAUGES - VEHICLES WITH: 6.5 INCH INSTRUMENT CLUSTER
DISPLAY SCREEN

E282067

Tachometer.

Information bar.

Speedometer.

Fuel gauge.

Information display.

Engine coolant temperature gauge.

Information Bar

Displays information related to the
navigation, outside air temperature,
odometer and distance to empty.

Information Display

Displays information related to the
navigation, outside air temperature,
odometer and distance to empty.

Information Display

Information that appears depends on your
vehicle settings. See

General

Information

(page 116).

Fuel Gauge

The fuel gauge indicates about how much
fuel is in the fuel tank.

The arrow adjacent to the fuel pump
symbol indicates on which side of your
vehicle the fuel filler door is located.

102

Instrument Cluster

Note:

The fuel gauge may vary slightly

when your vehicle is moving or on a slope.

Low Fuel Reminder

A low fuel level reminder displays and
sounds when the distance to empty
reaches 75 mi (120 km) to empty for
MyKey, and at 50 mi (80 km), 25 mi
(40 km), 10 mi (20 km) and 0 mi (0 km)
for all vehicle keys.

Note:

The low fuel reminder can appear at

different fuel gauge positions depending on
fuel economy conditions. This variation is
normal.

Distance to Empty

Indicates the approximate distance your
vehicle can travel on the fuel remaining in
the tank. Changes in driving pattern can
cause the value to not only decrease but
also increase or stay constant for periods
of time.

Engine Coolant Temperature
Gauge

WARNING:

Do not remove the

coolant reservoir cap when the engine is
on or the cooling system is hot. Wait 10
minutes for the cooling system to cool
down. Cover the coolant reservoir cap
with a thick cloth to prevent the
possibility of scalding and slowly remove
the cap. Failure to follow this instruction
could result in personal injury.

Indicates engine coolant temperature. At
normal operating temperature, the level
indicator will be in the normal range. If the
engine coolant temperature exceeds the
normal range, stop your vehicle as soon as
safely possible, switch off the engine and
let the engine cool.

GAUGES - VEHICLES WITH:
12.3 INCH INSTRUMENT
CLUSTER DISPLAY SCREEN

Note:

Clusters shown in single gauge view.

Note:

Displays may appear slightly different

depending on region.

103

Instrument Cluster

E281475

Gauge display.

Speedometer.

Information bar.

Information display.

Fuel gauge.

Gauge Display

Displays different gauge selections
depending on supported options. Options
include Tachometer or Engine Coolant
Temperature.

Information Bar

Displays information related to the current
audio source, navigation, outside air
temperature and distance to empty.

Information Display

Information that appears depends on
current gauge view and on-demand
settings. See

General Information

(page

116).

Fuel Gauge

The fuel gauge indicates about how much
fuel is in the fuel tank.

The arrow adjacent to the fuel pump
symbol indicates on which side of your
vehicle the fuel filler door is located.

Note:

The fuel gauge may vary slightly

when your vehicle is moving or on a slope.

Low Fuel Reminder

104

Instrument Cluster

Ford Explorer (2022 year). Manual in english - page 6
