Ford Police Interceptor Utility (2022 year). Manual in english - page 19

Fuel Tank

Capacities

Quantity

Variant

18.0 gal (68.1 L)

All.

Grease

Materials

Specification

Name

ESA-M1C75-B

Motorcraft® Premium Long-Life Grease(U.S.)
Motorcraft® Premium Long-Life Grease / Graisse
longue durée de qualité première Motor-
craft®(Canada)
XG-1-E1(U.S. & Canada)

ESB-M1C93-B

Motorcraft® Multi-Purpose Grease Spray(U.S.)
Motorcraft® Multi-Purpose Grease Spray / Graisse
tout usage en aérosol Motorcraft®(Canada)
XL-5-A(U.S. & Canada)

Hydraulic Brake System

Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid(U.S.)
Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid / Liquide de frein automobile
haute performance DOT 4 LV Motorcraft®(Canada)
PM-20(U.S. & Canada)

Note:

We recommend using DOT 4 Low

Viscosity (LV) High Performance Brake Fluid
or equivalent meeting WSS-M6C65-A2. Use
of any fluid other than the recommended
fluid could cause reduced brake
performance and not meet our performance
standards. Keep brake fluid clean and dry.
Contamination with dirt, water, petroleum
products or other materials could result in
brake system damage and possible failure.

Locks

295

Capacities and Specifications

Materials

Specification

Name

Motorcraft® Penetrating and Lock Lubricant(U.S.)
Motorcraft® Penetrating Fluid / Liquide dégrippant
Motorcraft®(Canada)
XL-1(U.S.)
CXC-51-A(Canada)

Transfer Case

Capacities

Quantity

Variant

1.1 qt (1 L)

All.

Materials

Specification

Name

WSS-M2C938-AMERCON® LV,

Motorcraft® MERCON® LV Automatic Transmission
Fluid(U.S.)
Motorcraft® MERCON® LV Automatic Transmission
Fluid / Huile pour boîte automatique MERCON® LV
Motorcraft®(Canada)
XT-10-QLVC(U.S.)
CXT-10-LV6(Canada)

Front Axle

Capacities

Quantity

Variant

0.6 qt (0.6 L)

All-wheel drive.

296

Capacities and Specifications

Materials

Specification

Name

WSL-M2C192-A

Motorcraft® SAE 75W-140 Synthetic Rear Axle
Lubricant(U.S.)
Motorcraft® SAE 75W-140 Synthetic Rear Axle
Lubricant / Lubrifiant synthétique pour pont arrière
SAE 75W-140 Motorcraft®(Canada)
XY-75W140-QL(U.S.)
CXY-75W140-1L(Canada)

Rear Axle

Capacities

Quantity

Variant

1.9 qt (1.8 L)

All.

Materials

Specification

Name

WSS-M2C942-A

Motorcraft® SAE 75W-85 Premium Synthetic
Hypoid Gear Lubricant(U.S.)
Motorcraft® SAE 75W-85 Premium Synthetic
Hypoid Gear Lubricant / Huile synthétique de haute
qualité pour engrenages hypoïdes SAE 75W-85
Motorcraft®(Canada)
XY-75W85-QL(U.S. & Canada)

Washer Reservoir

Capacities

Quantity

Variant

Fill as required.

All.

297

Capacities and Specifications

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concen-
trate with Bitterant(U.S.)
Motorcraft® Premium Quality Windshield Washer
Fluid / Liquide lave-glace de haute qualité Motor-
craft®(Canada)
ZC-32-B2(U.S.)
CXC-37-F/M(Canada)

BULB SPECIFICATION CHART

Replacement bulbs are specified in the
chart below. Headlamp bulbs must be
marked with an authorized D.O.T. marking
for North America to make sure they have
the proper lamp performance, light
brightness, light pattern and safe visibility.
The correct bulbs will not damage the
lamp assembly or void the lamp assembly
warranty and will provide quality bulb
illumination time.

Exterior Lamps

Power (Watt)

Specification

Lamp

LED.

Front park lamps.

LED.

Front side marker lamp.

LED.

Front warning lamp.

LED.

Front direction indicator.

LED.

Daytime running lamps.

LED.

Headlamp low beam.

LED.

Headlamp high beam.

LED.

Front auxiliary warning lamp.

LED.

Exterior mirror warning lamp.

LED.

Rear side marker lamp.

298

Capacities and Specifications

Power (Watt)

Specification

Lamp

LED.

Rear quarter window warning lamp.

LED.

Rear auxiliary warning lamp.

LED.

Brake and rear lamp.

LED.

Central high mounted brake lamp.

3757NAK, PY27/7W

Rear direction indicator.

W21W

Reversing lamp.

W5W

License plate lamp.

LED.

Spot Lamp.

Note:

LED lamps are not serviceable. See an authorized dealer if they fail.

Interior Lamps

Power (Watt)

Specification

Lamp

LED.

All interior lamps.

Note:

LED lamps are not serviceable. See an authorized dealer if they fail.

299

Capacities and Specifications

GENERAL INFORMATION

WARNING:

Driving while distracted

hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Radio Frequencies and Reception
Factors

Note:

Listening to loud audio for long

periods of time could damage your hearing.

Radio Reception Factors

The further you travel from an AM or FM station, the
weaker the signal and the weaker the reception.

Distance and strength

Hills, mountains, tall buildings, bridges, tunnels, freeway
overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with the reception.

Terrain

When you pass a ground-based broadcast repeating
tower, a stronger signal may overtake a weaker one and
result in the audio system muting.

Station overload

AUDIO UNIT

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

E286494

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Note:

Some features, such as satellite

radio, may not be available in your location.
Check with an authorized dealer.

Note:

The touchscreen system controls

most of the audio features.

Accessing the Sound Settings

Press and release the button.

300

Audio System

Accessing the System Settings

E142607

Press and release the button.

Adjusting the Volume

E248939

Turn to adjust the volume.

Changing Radio Stations

E248947

In radio mode, turn to search through the
radio frequency band. In satellite radio
mode, turn to find the previous or next
available satellite radio station.

Pausing or Playing Media

In media mode, press and
release the button to pause
playback. Press the button again

to resume playback.

In radio mode, press and release the button
to mute the radio. Press the button again
to unmute.

Returning to the Previous Screen

E281480

Press and release the button.

Selecting Media

E100027

Press the button to select media
mode.

Press the button again to display

the available media sources. Repeatedly
press the button to scroll through the
available media sources.

301

Audio System

Scrolling Through the Menu
Options

E248947

Selecting a Menu Option

E248946

Selecting the Radio

Press release the button to
select radio mode.

Press and release the button

again to display the available radio
sources. Repeatedly press the button to
scroll through the available radio sources.

Switching the Audio Unit On and
Off

Press and release the button.

Switching the Display On and Off

E272035

Press and release the button.

Using a Cell Phone

Press and release to make a call
from a recent call list, contact
list or dial a number.

Using Seek, Fast Forward and
Reverse

Press and release the button to
skip to the next track.

Press and hold the button to fast

forward through the track.

Press and release the button to
return to the beginning of a track.

Repeatedly press the button to

return to previous tracks.

Press and hold the button to fast rewind.

In radio mode, select a frequency band and
press and release either button. The
system stops at the first station it finds in
that direction.

In satellite radio mode, press and release
to select the next or previous satellite radio
station. If you select a specific category,
such as jazz, rock or news, press to find the
next or previous station in the category you
select.

302

Audio System

USB PORT

WARNING:

Driving while distracted

USB A

E201595

USB C

E301114

The USB port allows you to plug in media
playing devices, memory sticks and charge
devices.

Note:

We recommend using only USB-IF

certified cables and adapters. Non-certified
cables and adapters may not work.

Locating the USB Ports

The USB ports may be in the following
locations:

•

Inside the media bin.

•

Inside the center console.

•

On the lower instrument panel.

Note:

The number and type of USB ports

may vary depending on your vehicle.

Note:

Not all USB ports in your vehicle have

data transfer capabilities. See

Auxiliary

Power Points

(page 115).

303

Audio System

GENERAL INFORMATION

WARNING:

Driving while distracted

About SYNC

The system allows you to interact with the
entertainment, information and
communication systems on your vehicle
using voice commands and a touchscreen.
The system provides easy interaction with
audio, phone, navigation, mobile apps and
settings.

Note:

You can switch the system on and

use it for up to an hour without switching
the ignition on.

Note:

You can use the system after you

switch the ignition off for up to 10 minutes
or until you open a door.

Note:

For your safety, some features are

speed-dependent. Their use is limited to
when your vehicle speed is less than 3 mph
(5 km/h).

Using the Touchscreen

E293823

Status bar.

Home screen.

Clock. See

Settings

(page 335).

Outside air temperature.

Feature bar.

Status Bar

Cell phone microphone muted.

Audio system muted.

Software update installed.

Wi-Fi connected.

Cell phone roaming.

Text message received.

304

SYNC™ 3

(If Equipped)

Automatic crash notification
system off.

Cell phone network signal
strength.

Vehicle data sharing on.

Vehicle location sharing on.

Vehicle data and vehicle location
sharing on.

Wireless charger active.

Feature Bar

E100027

Select to use the radio, a USB, a
media player or a

Bluetooth®

device. See

Entertainment

(page 312).

E283811

Select to adjust climate settings
See

Climate

(page 322).

Select to make calls and access
the phonebook on your cell
phone. See

Phone

(page 324).

Select to use the navigation
system. See

Navigation

(page

326).

Select to search for and use
compatible apps on your iOS or
Android device. See

Apps

(page

332).

E280315

Select to adjust system settings.
See

Settings

(page 335).

Cleaning the Touchscreen

See

Cleaning the Interior

(page 239).

Updating the System

Updating the System Using a USB Drive

Downloading an Update

Go to the SYNC update page on the
local Ford website.

2. Download the update.

Note:

The website notifies you if an update

is available.

3. Insert a USB drive into your computer.

Note:

The USB drive needs to be empty and

meet the minimum requirements detailed
on the website.

4. Follow the instructions provided to

download the update to the USB drive.

Installing an Update

Note:

You can use the system when an

installation is in progress.

Disconnect all other USB devices from
the USB ports.

2. Connect the USB drive with the update

to a USB port.

Note:

Installation starts automatically

within 10 minutes.

Updating the System Using a Wi-Fi
Network Connection

Connecting to a Wi-Fi Network

E280315

Select the settings option on the
feature bar.

Select

Automatic Updates

2. Select

System Wi-Fi

3. Switch

System Wi-Fi

on.

4. Select

Available Wi-Fi Networks

5. Select an available Wi-Fi network.

Note:

Enter the network password to

connect to a secure network.

305

SYNC™ 3

(If Equipped)

Switching Automatic System Updates
On

E280315

Select the settings option on the
feature bar.

Select

Automatic Updates

2. Switch

Automatic System Updates

on.

The system is now set to check for and
receive system updates when it is
connected to a Wi-Fi network.

Note:

You can use the system when a

download is in progress.

Note:

If the system is disconnected from

the Wi-Fi network when a download is in
progress, the download continues the next
time the system is connected to a Wi-Fi
network.

Additional Information and
Assistance

For additional information and assistance,
we recommend that you contact an
authorized dealer or refer to the local Ford
website.

USING VOICE RECOGNITION

The system allows you to interact with the
entertainment, information and
communication systems on your vehicle
using voice commands. This allows you
to keep your hands on the steering wheel
and focus on what is in front of you.

E142599

Press the voice control button
on the steering wheel and wait
for the voice prompt.

Note:

Press the voice control button again

to interrupt a voice prompt and begin
speaking.

Note:

Turn the volume control when a voice

prompt plays to adjust the volume.

Note:

Press and hold the voice control

button on the steering wheel to use Siri on
your iOS device.

The following voice commands are
designed to help you from any screen:
•

List of Commands

•

Help

The following tables list some of the more
frequently used voice commands. For a
complete list of voice commands, refer to
our website.

General

Description

Voice Command

Get a list of voice commands for a specific feature.

___ List of Commands

Cancel an active voice session.

Cancel

Get a list of voice commands for a specific feature.

___ Help

Return to the previous screen.

Go back

Go to the main menu.

Main Menu

306

SYNC™ 3

(If Equipped)

Description

Voice Command

Go to the next page.

Go to the previous page.

Add the name of the feature to the command.

Entertainment

Audio Source

Description

Voice Command

Use the radio.

Radio

Use the CD player.

CD Player

Use a

Bluetooth®

device.

Bluetooth Stereo

Use a USB or media player.

USB

Radio

Description

Voice Command

Listen to AM radio.

Tune to a specific AM frequency.

AM ___

Listen to SiriusXM radio.

Sirius Channel ___

Listen to FM radio.

Tune to a specific FM frequency.

FM ___

Add the radio frequency to two decimal places to the command.

You can say the Sirius channel name or number such as "Sirius Channel 16" or "Sirius

The Pulse".

307

SYNC™ 3

(If Equipped)

USB and Media Player

Description

Voice Command

Play your music by category.

Play Album ___

Play Artist ___

Play Genre ___

Play Playlist ___

Play Song ___

Play Audiobook ___

Play Podcast ___

Browse music on a USB device.

Browse All Albums

Browse All Artists

Browse All Audiobooks

Browse All Genres

Browse All Playlists

Browse All Podcasts

Browse All Songs

Browse your music by category on a USB device.

Browse Album ___

Browse Artist ___

Browse Audiobook ___

Browse Genre ___

Browse Playlist ___

Browse Podcast ___

Add an album name, artist name, audiobook name, genre name, playlist name, podcast

name or track name to the command. Say the name exactly as it appears on your device.

Climate

(If Equipped)

You can control the temperature of the
vehicle using voice commands.

___ is a dynamic listing, meaning that for
climate voice commands it can be the
desired degrees for the temperature
setting.

308

SYNC™ 3

(If Equipped)

To adjust the temperature, say:

Description

Voice command

Adjust the temperature between 60–85°F

(15.5–29.5°C).

Set Temperature ___

Phone

Description

Voice Command

Pair a cell phone or

Bluetooth®

-enabled device.

Pair Phone

Redial the last number that you dialed.

Redial

Dial a number.

Dial ___

Call a specific contact from your phonebook.

Call ___

Call a specific contact from your phonebook at a

specific location.

Call ___ ___

Listen to a text message.

Listen to Message

Listen to a specific text message from a list of text
messages.

Listen to Message ___

Reply to the last text message.

Reply to Message

Add the number you want to dial to the command.

Add a contact name from your phonebook to the command. Say the first and last name

of your contact exactly as it appears on your device.

Add a contact name and location from your phonebook to the command. Say the first

and last name of your contact exactly as it appears on your device.

309

SYNC™ 3

(If Equipped)

Navigation

(If Equipped)

Setting a Destination

Description

Voice Command

Enter a destination address. When prompted,
provide the house number, the street and city.

Find an Address

Search for a point of interest by name or by category.

Find a Place

Search for a nearby point of interest by category.

Find the Next ___

Search for a point of interest category.

Find a POI Category

Set your saved home address as your destination.

Drive Home

Set your saved place of work as your destination.

Drive to Work

Display and select from a list of previous destina-
tions.

Show Previous Destinations

Display and select from a list of favorite destinations.

Show Favorites

Add a point of interest category or the name of a major brand or chain to the command.

Route Guidance

Description

Voice Command

Cancel the current route.

Cancel Route

Select an alternate route.

Detour

Repeat the last guidance prompt.

Repeat Instruction

Display an overview of the route.

Show Route

Display a list of traffic events on your route.

Show Traffic

Display the map on the touchscreen.

Show Map

Display a two-dimensional map with north toward
the top of the touchscreen.

North Up

Display a two-dimensional map with the direction
you are traveling toward the top of the touchscreen.

Heading Up

Display a three-dimensional map with the direction
you are traveling toward the front.

Show 3D

310

SYNC™ 3

(If Equipped)

Content .. 17 18 19 20 ..
