Ford Mustang Mach-E (2022 year). Manual in english

E353985

3. Set preferred charging times for

weekday and/or weekend by pressing
and dragging along the 24 hour time
wheel. You can set up to two blocks of
time (charge windows). Press next
once you have your desired time
settings for weekday and weekend.

Note:

Selecting all or none of the 24 hours

results in any time of day given equal priority
for charging.

4. The summary screen displays your

settings for this location. Press save or
press the left arrow to go back and
change your settings. Whenever your
vehicle is at a saved charging location,
the charge settings screen displays the
location name, and the charging times
are based on your preferred time
settings for that location plus the next
departure time.

Note:

Reaching your max charge level by

your next departure time is always the
priority. When charge times are set, charging
outside your preferred charging time
windows could be necessary in order to
finish by your next departure time. In this
case, the vehicle will typically begin charging
right away after plugging in.

Departure and Comfort Setup

Follow these steps to set departure times
and cabin comfort level.

Press the edit button for departure and
comfort on the charge settings screen.

2. Select a time for each day of the week

you want your settings to apply. Select
the hour and minutes as well as your
desired comfort level. Your selected
days/times now display your departure
and comfort settings. Press Save to
apply your settings. The next departure
display on the charge settings screen
will update appropriately.

Note:

Save your departure settings before

selecting additional days/times. The
process must be repeated in order to add
additional unique departure times and
comfort levels.

Note:

Cabin conditioning comfort level may

vary depending on if you plug into a normal
household outlet or a higher power outlet
or charging station. The power available for
conditioning is limited to the charging
station power available. At low ambient
temperatures and low charge power, a
small amount of high voltage battery power
in addition to the charging power could be
used to heat the cabin.

Note:

The departure and comfort settings

can also be accessed through the separate
vehicle settings departure and comfort
button. Press the edit button from this
screen to begin the settings process outlined
above.

USING FORDPASS AND
CHARGING

The FordPass App allows you to do the
following:

•

Monitor and manage your vehicle's
charging, including charge schedules
and preferences.

•

Locate a charger and activate a charger
on the FordPass Charging Network.

179

Charging Your Vehicle

•

Plan a trip and charging options along
your route.

•

Check charging station plug availability.

•

Initiate a charge session automatically
at Plug and Charge capable charge
stations.

•

Control your Ford Connected Charge
Station remotely.

•

Override charge preferences and
starting and stopping charging.

For more information, visit

www.owner.ford.com

CHARGING YOUR VEHICLE
HINTS

We recommend limiting the amount of DC
charges, and ending DC charges at 80%
state of charge as charging between 80
and 100% can incur high charging costs
due to the time to completion. Frequent
use of DC charging could result in reducing
your battery’s efficiency and lifespan. This
is more pronounced on the standard range
battery pack versus the extended range
battery pack.

In cold temperatures, you may notice that
DC charging takes longer when the
ambient temperature drops below 50°F
(10°C). Shutting off climate control or
reducing climate control temperature and
fan settings for the first 10 to 15 minutes of
DC charging will allow the battery to warm
up and improve the charging rate.

Note:

When the temperature is below

freezing, fully turning off cabin heat for the
first 10 to 15 minutes of DC charging could
significantly improve the charging rate.

CHARGING YOUR VEHICLE –
TROUBLESHOOTING

CHARGING YOUR VEHICLE –
WARNING LAMPS

E228962

Plugged into charger.

CHARGING YOUR VEHICLE – INFORMATION MESSAGES

Action

Message

Your vehicle needs confirmation it is unplugged before
allowing a start. You must make sure your vehicle is unplugged
and you respond to the message promptly before starting
your vehicle.

Vehicle Plugged In ? Yes

Indicates that HV battery can no longer support the 12V
battery. Plug In your vehicle to charge the high voltage battery
and maintain the 12V battery at a healthy state.

Plug in to Maintain 12V

Battery

The vehicle is plugged in and a fault has been detected with
the charge station or charging cord. Please check the charging
cord and the charging station or electrical supply.

Charge Station Fault See

Manual

180

Charging Your Vehicle

CHARGING YOUR VEHICLE –
FREQUENTLY ASKED QUESTIONS

Why does my vehicle not charge with
the mobile charger?

Ensure you properly connect the
connector and control box. Unplug the
charge coupler from the vehicle and
unplug the connector from the wall
outlet. Then check the connector to
be sure that the connector is
connected properly into the mobile
charger control box. If the mobile
charger is warm or in a hot
environment, try charging in a cooler
area. Try a different outlet or a
different connector if you have one
available. If the problem persists,
contact an authorized EV certified
dealer.

Why does my vehicle have a hum or fan
noise when charging?

A hum or a fan noise could be present
when charging the high voltage
battery. This is a normal operation as
your vehicle is keeping the battery cool
while charging.

181

Charging Your Vehicle

AUTOMATIC TRANSMISSION
PRECAUTIONS

WARNING:

When your vehicle is

stationary, keep the brake pedal fully
pressed when shifting gears. Failure to
follow this instruction could result in
personal injury, death or property
damage.

WARNING:

Do not apply the brake

pedal and accelerator pedal
simultaneously. Applying both pedals
simultaneously for more than a few
seconds will limit power, which may
result in difficulty maintaining speed in
traffic and could lead to serious injury.

WARNING:

Apply the parking

brake, shift into park (P), switch the
vehicle off and remove the key or remote
control before you leave your vehicle.
Failure to follow this instruction could
result in personal injury or death.

Note:

You may not be able to shift out of

park (P) unless the intelligent access key is
inside your vehicle.

AUTOMATIC TRANSMISSION
POSITIONS

PARK (P)

WARNING:

Move the transmission

selector lever to park (P) only when your
vehicle is stationary.

This position locks the driveline and
prevents the wheels from turning. Come
to a complete stop before putting your
vehicle into and out of park (P). A tone
sounds when you shift to park (P).

The electric parking brake could apply
when you shift to park (P) without the
brake pedal fully pressed. The electric
parking brake applies when you shift to
park (P) on large slopes. The electric
parking brake releases with the drive away
release function or manually. See

Electric

Parking Brake

(page 189).

Note:

A warning tone sounds if you open

the driver door and you have not shifted the
transmission selector to park (P).

REVERSE (R)

WARNING:

Move the transmission

selector lever to reverse (R) only when
your vehicle is stationary.

This position allows your vehicle to move
backward. Come to a complete stop
before shifting into and out of reverse (R).

NEUTRAL (N)

WARNING:

In neutral (N) your

vehicle is free to roll.

In neutral (N) power is not transmitted to
the driven wheels.

DRIVE (D)

Drive (D) is the normal driving position, and
allows your vehicle to move forward.

182

Automatic Transmission

LOW (L)

You can activate this position at any
vehicle speed which provides an increased
level of deceleration when you lift off the
accelerator pedal. You can use low (L) at
all times, if desired, but improving
drivability while descending grades is the
intent. Entering low (L) does not take any
actions if one pedal drive is active

SHIFTING YOUR VEHICLE INTO
GEAR

E334919

Your vehicle has an electronic transmission
selector. The transmission selector is on
the center console. You can select
positions by rotating the transmission
selector to

PRNDL

•

Park (P).

•

Reverse (R).

•

Neutral (N).

•

Drive (D).

•

Low (L).

Putting your vehicle in gear:

Fully press down the brake pedal.

2. Rotate the gear selector knob to the

desired position mode you want to
select.

3. The gear selector indicates the position

selected.

4. Release the brake pedal and your

transmission remains in the selected
position.

Note:

Your gear selector knob can rotate

clockwise past drive (D), but the gear
selection stays in drive (D). Your gear
selector can rotate counterclockwise past
park (P) with the brake pedal pressed, but
the gear selector stays in park (P).

Note:

If you attempt to leave your vehicle

when it is in gear, your vehicle automatically
shifts into park (P). See

How Does

Automatic Return to Park (P) Work

(page

184).

TEMPORARY NEUTRAL MODE

WHAT IS TEMPORARY NEUTRAL
MODE

This mode keeps your vehicle in neutral
(N), for a limited time, when you exit your
vehicle or switch your vehicle off.

Note:

Do not tow your vehicle in this mode.

TEMPORARY NEUTRAL MODE
LIMITATIONS

Your vehicle could shift to park (P) after
30 minutes, or when the vehicle battery
charge level is low. Prolonged use of this
mode can cause the vehicle battery to run
out of charge.

Do not tow your vehicle in this mode.
Failure to follow these instructions could
result in vehicle damage not covered by
the vehicle warranty.

ENTERING TEMPORARY
NEUTRAL MODE

Power your vehicle on.

183

Automatic Transmission

2. Bring your vehicle to a complete stop.

3. Press and hold the brake pedal.

4. Shift into neutral (N).

Note:

An instructional message appears.

5. Press the low (L) button.

Note:

A confirmation message appears

when your vehicle enters the mode.

6. Release the brake pedal.

Note:

Your vehicle is free to roll.

Switch your vehicle off.

Note:

Do not tow your vehicle in this mode.

Note:

The neutral (N) indicator on the

transmission selector may flash in this
mode.

EXITING TEMPORARY NEUTRAL
MODE

Press the brake pedal.

2. Shift into park (P), or power your

vehicle on and shift into drive (D) or
reverse (R).

AUTOMATIC RETURN TO
PARK (P)

WHAT IS AUTOMATIC RETURN TO
PARK (P)

Your vehicle shifts into park (P) if you
attempt to exit your vehicle without the
transmission in park (P).

HOW DOES AUTOMATIC RETURN
TO PARK (P) WORK

Your vehicle shifts to park (P) when your
vehicle is stationary and any of the
following occur:
•

You switch the vehicle off.

•

You open the driver door with the driver
seatbelt unfastened.

•

You unfasten the driver seatbelt with
the driver door open.

Note:

Do not use Automatic Return to Park

when your vehicle is moving, except in an
emergency. See

Powering Off

(page 155).

AUTOMATIC RETURN TO PARK
(P) LIMITATIONS

Automatic return to park may not work if
the door ajar switch is malfunctioning.

See an authorized dealer if any of the
following occur:

•

Door ajar indicator does not illuminate
with the driver door open.

•

Door ajar indicator illuminates with the
driver door closed.

•

Transmission not in park message
appears with the driver door closed,
after you shift out of park (P).

184

Automatic Transmission

HOW DOES ALL-WHEEL DRIVE
WORK

The all-wheel drive system is designed to
continuously monitor and adjust power
delivery to the front and rear wheels to
optimize both traction and handling.

There is further information on driving in
unique driving conditions. See

Driving

Hints

(page 281).

ALL-WHEEL DRIVE
PRECAUTIONS

WARNING:

Do not become

overconfident in the ability of all-wheel
drive vehicles. Although an all-wheel
drive vehicle may accelerate better than
a two-wheel drive vehicle in low traction
situations, it won't stop any faster than
two-wheel drive vehicles. Always drive
at a safe speed.

ALL-WHEEL DRIVE
LIMITATIONS

The all-wheel drive system is not intended
for use with mismatched tires.

Different tire sizes between the front and
rear axles can cause system damage.

ALL-WHEEL DRIVE – TROUBLESHOOTING

ALL-WHEEL DRIVE – INFORMATION MESSAGES

Action

Message

The all-wheel drive system temporarily turns off to protect

itself from overheating.

AWD Temporarily

Disabled

The all-wheel drive system is not operating properly. If the

warning stays on or continues to come on, contact an

authorized dealer.

AWD Off

The all-wheel drive system will resume normal function.

AWD Restored

185

All-Wheel Drive

(If Equipped)

BRAKE PRECAUTIONS

WARNING:

Driving your vehicle

with the warning lamp on is dangerous.
A significant decrease in braking
performance may occur. It may take you
longer to stop your vehicle. Have your
vehicle checked as soon as possible.
Driving extended distances with the
parking brake engaged can cause brake
failure and the risk of personal injury.

Wet brakes result in reduced braking
efficiency. Gently press the brake pedal a
few times when leaving a car wash or
driving from standing water to dry the
brakes.

Note:

Depending on applicable laws and

regulations in the country for which your
vehicle was originally built, the stoplamps
could flash during heavy braking. Following
this the hazard warning flashers could also
turn on when your vehicle comes to a stop.

ANTI-LOCK BRAKING SYSTEM

ANTI-LOCK BRAKING SYSTEM
LIMITATIONS

The anti-lock braking system does not
eliminate the risk of a crash when:
•

You drive too close to the vehicle in
front of you.

•

Your vehicle is hydroplaning.

•

You take corners too fast.

•

The road surface is poor.

BRAKE OVER ACCELERATOR

In the event the accelerator pedal
becomes stuck or entrapped, apply steady
and firm pressure to the brake pedal to
slow the vehicle and reduce power. If you
experience this condition, apply the brakes
and bring your vehicle to a safe stop. Move
the transmission to park (P), switch the
power off and apply the parking brake.
Inspect the accelerator pedal for any
interference. If none are found and the
condition persists, have your vehicle towed
to the nearest authorized dealer.

LOCATING THE BRAKE FLUID
RESERVOIR

See

Under Hood Overview

(page 305).

CHECKING THE BRAKE FLUID

WARNING:

Do not use any fluid

other than the recommended brake fluid
as this will reduce brake efficiency. Use
of incorrect fluid could result in the loss
of vehicle control, serious personal injury
or death.

WARNING:

Only use brake fluid

from a sealed container. Contamination
with dirt, water, petroleum products or
other materials may result in brake
system damage or failure. Failure to
adhere to this warning could result in the
loss of vehicle control, serious personal
injury or death.

WARNING:

Do not allow the fluid

to touch your skin or eyes. If this
happens, rinse the affected areas
immediately with plenty of water and
contact your physician.

186

Brakes

WARNING:

The brake system

could be affected if the brake fluid level
is below the

MIN

mark or above the

MAX

mark on the brake fluid reservoir.

E170684

Park your vehicle on a level surface.

2. Look at the brake fluid reservoir to see

where the brake fluid level is relative
to the

MIN

and the

MAX

marks on the

reservoir.

Note:

To avoid fluid contamination, the

reservoir cap must remain in place and fully
tight, unless you are adding fluid.

Only use fluid that meets our
specifications. See

Capacities and

Specifications

(page 346).

BRAKE FLUID SPECIFICATION

See

Brake Fluid Specification

(page 348).

BRAKES –
TROUBLESHOOTING

BRAKES – WARNING LAMPS

If the ABS indicator illuminates
when you are driving, this
indicates a malfunction. Your

vehicle continues to have normal braking
without the anti-lock braking system
function. See an authorized dealer.

It also momentarily illuminates when you
switch the ignition on to confirm the lamp
is functional. If it does not illuminate when
you switch the ignition on, or begins to
flash at any time, have the system checked
by an authorized dealer.

E270480

The brake indicator momentarily
illuminates when you switch the
ignition on to confirm the lamp

is functional. It may also illuminate when
you apply the parking brake and the
ignition is on. If it illuminates when your
vehicle is moving, make sure the parking
brake is disengaged. If the parking brake
is disengaged, this indicates low brake fluid
level or a brake system fault. See an
authorized dealer.

BRAKES – FREQUENTLY ASKED
QUESTIONS

Is occasional brake noise normal

Occasional brake noise is normal. If a
metal-to-metal, continuous grinding
or continuous squeal sound is present,
the brake linings could be worn-out.
Have the system checked by an
authorized dealer.

187

Brakes

WHAT IS THE ELECTRIC
PARKING BRAKE

The electric parking brake is used to hold
your vehicle on slopes and flat roads.

APPLYING THE ELECTRIC
PARKING BRAKE

WARNING:

Always fully apply the

parking brake and make sure you shift
into park (P). Failure to follow this
instruction could result in personal injury
or death.

WARNING:

If you drive extended

distances with the parking brake applied,
you could cause damage to the brake
system.

WARNING:

The electric parking

brake does not operate if the vehicle
battery has run out of charge.

E267156

The electronic parking brake
switch is on the center console.

Pull the switch up.

The red warning lamp flashes during
operation and illuminates when the parking
brake is applied.

Note:

You can apply the electric parking

brake when the power is off.

Note:

The electric parking brake could

apply when you shift into park (P). See

Park

(P)

(page 182).

APPLYING THE ELECTRIC
PARKING BRAKE IN AN
EMERGENCY

You can use the electric parking brake to
slow or stop your vehicle in an emergency.

Pull the switch up and hold it.

The electric parking brake continues to
slow your vehicle down unless you release
the switch.

The red warning lamp illuminates, a tone
sounds and the stoplamps turn on when
you use the electric parking brake in an
emergency.

Note:

Do not apply the electric parking

brake when your vehicle is moving, except
in an emergency. If you repeatedly use the
electric parking brake to slow or stop your
vehicle, you could cause damage to the
brake system.

MANUALLY RELEASING THE
ELECTRIC PARKING BRAKE

Switch the power on.

2. Press and hold the brake pedal.

3. Push the switch down.

The red warning lamp turns off.

AUTOMATICALLY RELEASING
THE ELECTRIC PARKING
BRAKE

Close the driver door.

2. Shift into gear.

3. Press the accelerator pedal and pull

away in a normal manner.

189

Electric Parking Brake

ELECTRIC PARKING BRAKE
AUDIBLE WARNING

Sounds when the parking brake is on and
your vehicle is moving. If the warning tone
continues after you have released the
parking brake, this indicates a malfunction.
Have your vehicle checked as soon as
possible.

RELEASING THE ELECTRIC
PARKING BRAKE IF THE
VEHICLE BATTERY HAS RUN
OUT OF CHARGE

See

Jump Starting the Vehicle

(page

289).

ELECTRIC PARKING BRAKE –
TROUBLESHOOTING

ELECTRIC PARKING BRAKE –
WARNING LAMPS

Brake System

E270480

It illuminates red when you apply
the parking brake and your
vehicle is on. If the lamp flashes
when the parking brake has been
released, this indicates the
parking brake system requires

service. Have your vehicle checked as
soon as possible.

Note:

Lamps may vary depending on region.

Electric Parking Brake

E146190

When the lamp illuminates
yellow, it indicates a malfunction
in the electric parking brake.

Have your vehicle checked as soon as
possible.

190

Electric Parking Brake

ELECTRIC PARKING BRAKE – INFORMATION MESSAGES

Park Brake

Action

Message

The parking brake is set, if the vehicle is in gear and you drive

your vehicle more than 3 mph (5 km/h). If the warning stays
on after the parking brake is released, contact an authorized

dealer as soon as possible.

Park Brake Engaged

The electric parking brake is set and a manual release is

attempted without the brake pedal being pressed.

To Release: Press Brake

and Switch

The electric parking brake is set and an automatic release is

attempted but cannot be performed. Perform a manual

release.

Park Brake Use Switch

to Release

The electric parking brake is set and your vehicle speed

exceeds 3 mph (5 km/h). Release park brake before continued

driving.

Release Park Brake

The electric parking brake is not fully applied.

Park Brake Not Applied

The electric parking brake is not fully released.

Park Brake Not Released

The electric parking brake system has been put into a special
mode that is used to allow service of the rear brakes. Contact

an authorized dealer.

Park Brake Maintenance

Mode

The electric park brake system has detected a condition that

requires service. Some functionality may still be available.

Contact your authorized dealer.

Park Brake Limited

Function Service

Required

The electric parking brake system has detected a condition

that requires service. Contact your authorized dealer.

Park Brake Malfunction

Service Now

Numerous park brake applies have overheated the system.

Wait 2 minutes before attempting to apply again.

Park Brake System

Overheated

191

Electric Parking Brake

WHAT IS REVERSE BRAKING
ASSIST

The system uses sensors on the rear of
your vehicle to detect a possible collision
and applies the brakes to either reduce the
damage from impact, or to assist in
avoiding the collision.

HOW DOES REVERSE
BRAKING ASSIST WORK

Reverse Braking Assist functions when in
reverse (R) and traveling at a speed of
1–7 mph (1.5–12 km/h).

If the system detects an obstacle behind
your vehicle, it provides a warning through
the rear parking aid or cross traffic alert
system.

REVERSE BRAKING ASSIST
PRECAUTIONS

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

To help avoid personal

injury, always use caution when in
reverse (R) and when using the sensing
system.

WARNING:

The system may not

operate properly during severe weather
conditions, for example snow, ice, heavy
rain and spray. Always drive with due
care and attention. Failure to take care
may result in a crash.

WARNING:

Traffic control systems,

fluorescent lamps, inclement weather,
air brakes, external motors and fans may
affect the correct operation of the
sensing system. This may cause reduced
performance or false alerts.

WARNING:

Some situations and

objects prevent hazard detection. For
example low or direct sunlight, inclement
weather, unconventional vehicle types,
and pedestrians. Apply the brakes when
necessary. Failure to follow this
instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

Do not use the system

with accessories that extend beyond the
front or rear of your vehicle, for example
a trailer hitch or bike rack. The system is
not able to make corrections for the
additional length of the accessories.

The system only applies the brakes for a
short period of time when an event occurs.
Act as soon as you notice the brakes apply
in order to remain in control of the vehicle.
If you do not intervene the vehicle may
start to move again.

Note:

Certain add-on devices around the

bumper or fascia may create false alerts.
For example, large trailer hitches, bicycle or
surfboard racks, license plate brackets,
bumper covers or any other device that may
block the normal detection zone of the
system. Remove the add-on device to
prevent false alerts.

Note:

The system does not react to small

or moving objects, particularly those close
to the ground.

Note:

The system does not operate during

hard acceleration or steering.

192

Reverse Braking Assist

Note:

If your vehicle sustains damage to

the bumper or fascia leaving it misaligned
or bent, it could alter the sensing zone
causing inaccurate measurement of
obstacles or false alerts.

Note:

Vehicle loading and suspension

changes can impact the angle of the sensors
and may change the normal detection zone
of the system resulting in inaccurate
measurement of obstacles or false alerts.

Note:

When you connect a trailer, the

system may detect the trailer and provide
an alert, or the system turns off. If the
system does not turn off, switch the system
off manually after you connect the trailer.

Note:

You may experience reduced system

performance on road surfaces that limit
deceleration. For example, roads with ice,
loose gravel, mud or sand.

SWITCHING REVERSE
BRAKING ASSIST ON AND OFF

Access the vehicle drawer on the
touchscreen.

2. Press

SETTINGS

3. Press

Driver Assistance

4. Switch

Reverse Brake Assist

on or off.

Note:

The system is unavailable when the

rear parking aid, cross traffic alert or traction
control is off.

Note:

If your vehicle is not equipped with

cross traffic alert the reverse braking assist
relies on input from the rear parking aid and
rear camera sensors.

Note:

The default setting is on in some

regions.

OVERRIDING REVERSE
BRAKING ASSIST

There could be instances when
unexpected or unwanted braking occurs.
Firmly pressing the accelerator pedal or
switching the feature off overrides the
system.

REVERSE BRAKING ASSIST
INDICATORS

If the system determines that a collision
with an obstacle may occur, full braking
may apply. Bring your vehicle to a stop a
safe distance away from the obstacle.

E293490

A message and warning
indicator appear when the
system applies the brakes.

193

Reverse Braking Assist

REVERSE BRAKING ASSIST – TROUBLESHOOTING

REVERSE BRAKING ASSIST – INFORMATION MESSAGES

Action

Message

Make sure that all doors, liftgate and hood

are closed. Drive the vehicle on a straight

road for a short period. Make sure the

parking aids and cross traffic alert systems
are on. If the message remains on, have the

system checked as soon as possible.

Reverse Brake Assist Not Available See

Manual

Displays when a system error has occurred.

Have your vehicle checked as soon as

possible.

Reverse Brake Assist Fault

Displays when reverse brake assist is off.

Reverse Brake Assist Off

194

Reverse Braking Assist

Ford Mustang Mach-E (2022 year). Manual in english - page 11
