Ford Maverick (2022 year). Manual in english - page 4

CREATING A MYKEY -
VEHICLES WITH: PUSH
BUTTON START

E349250

Place the remote control in the backup
slot.

Note:

You can program the restrictions to

all keys but one. Any keys that you did not
program are administrator keys or admin
keys.

2. Switch the ignition on.

3. Access the main menu in the

information display and then scroll
through the menus to change the
settings of your MyKey. From the
MyKey menu select the option Create
MyKey. See

Instrument Cluster

Display

(page 116).

4. When prompted, hold the OK button

until you see a message informing you
to label this key as a MyKey. The
programmed restrictions apply when
you switch the vehicle off, open and
close the driver door and restart your
vehicle with the programmed key or
remote control.

5. Switch the ignition off.

You successfully created a MyKey.

You can also program configurable
settings for the keys.

Note:

We recommend that you label this

key.

PROGRAMMING A MYKEY

You can program the restrictions to all keys
but one. Any keys that you did not program
are administrator keys or admin keys.

Note:

You can use admin keys to Create a

MyKey, Program MyKey settings and Clear
all MyKey restrictions.

MyKey™

E349250

Insert the key you want to program into
the ignition. If your vehicle has a
push-button start, place the remote
control in the backup slot.

2. Switch the ignition on.

3. Access the main menu in the

information display and then scroll
through the menus to change the
settings of your MyKey. From the
MyKey menu select the option Create
MyKey. See

Instrument Cluster

Display

(page 116).

4. When prompted, hold the OK button

5. Switch the ignition off.

You successfully created a MyKey. Make
sure you label it so you can distinguish it
from the admin keys.

You can also program configurable
settings for the keys.

CLEARING ALL MYKEYS

When you clear your MyKeys, you remove
all restrictions and return all MyKeys to
their original admin key status at once. To
clear all MyKeys of all MyKey settings, use
the information display.

Switch the ignition on using an admin
key.

2. Access the main menu in the

information display and then scroll
through the menus to begin clearing
your MyKey programming. See

Instrument Cluster Display

(page

116).

3. Follow the instructions in the display.

4. A confirmation message appears in the

display after you finish clearing your
MyKeys.

Note:

When you clear your MyKeys, you

remove all restrictions and return all MyKeys
to their original admin key status. You
cannot remove the MyKey restrictions
individually.

CHECKING MYKEY SYSTEM
STATUS

You can find information about your
programmed MyKeys by using the
information display. See

Instrument

Cluster Display

(page 116).

MyKey™

MyKey Distance

Tracks the distance when drivers use a
MyKey. The only way to delete the
accumulated distance is by using an admin
key to clear all MyKeys. If the distance does
not accumulate as expected, then the
intended user is not using the MyKey, or an
admin key user recently cleared and then
recreated a MyKey.

Number of MyKeys

Indicates the number of MyKeys
programmed to your vehicle. Use this
feature to detect how many MyKeys you
have for your vehicle and determine when
all MyKeys have been deleted.

Number of Admin Keys

Indicates how many admin keys are
programmed to your vehicle. Use this
feature to determine how many admin
keys you have for your vehicle, and detect
if an additional MyKey has been
programmed.

USING MYKEY WITH REMOTE
START SYSTEMS

MyKey is not compatible with unapproved,
aftermarket remote start systems. If you
choose to install a remote start system,
see an authorized dealer for an approved
remote start system.

MYKEY – TROUBLESHOOTING

MYKEY – INFORMATION MESSAGES - VEHICLES WITHOUT: PUSH
BUTTON START

Description

Message

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

MyKey™

MYKEY – INFORMATION MESSAGES - VEHICLES WITH: PUSH BUTTON
START

Description

Message

Displays when trying to create a MyKey and the admin key is
not placed in the backup position. See

Creating a MyKey

(page 68).

Place Key in Backup
Location

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

MyKey™

MYKEY – FREQUENTLY ASKED
QUESTIONS - VEHICLES
WITHOUT: PUSH BUTTON START

What is an admin key?

An admin key is a key that you have
not created as a MyKey. See

Creating

a MyKey

(page 67).

Why am I not able to create a MyKey?

The key used to switch the ignition on
is not an admin key. The key used to
switch the ignition on is the only admin
key. There has to be at least one admin
key.

Why am I not able to program a MyKey?

The key used to switch the ignition on
is not an admin key. You have not
created any MyKeys. See

Creating a

MyKey

(page 67).

Why am I not able to clear the MyKeys?

The key used to switch the ignition on
is not an admin key. You have not
created any MyKeys. See

Creating a

MyKey

(page 67).

Why is the MyKey distance not
accumulating?

The key used to start the engine is an
admin key. You have not created any
MyKeys. See

Creating a MyKey

(page 67). You have cleared the
MyKeys. See

Clearing All MyKeys

(page 69).

MYKEY – FREQUENTLY ASKED
QUESTIONS - VEHICLES WITH:
PUSH BUTTON START

What is an admin key?

An admin key is a key that you have
not created as a MyKey. See

Creating

a MyKey

(page 68).

Why am I not able create a MyKey?

You have not placed the admin key in
the backup position. See

Creating a

MyKey

(page 68). The key used to

switch the ignition on is not an admin
key. The key used to switch the ignition
on is the only admin key. There has to
be at least one admin key. You did not
switch the ignition off after creating
the last MyKey.

Why am I not able to program a MyKey?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey

(page 68).

Why am I not able to clear the MyKeys?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey

(page 68).

Why is the MyKey distance not
accumulating?

The key used to start the engine is an
admin key. An admin key and a MyKey
are inside your vehicle. You have not
created any MyKeys. See

Creating a

MyKey

(page 68). You have cleared

the MyKeys. See

Clearing All

MyKeys

(page 69).

Why am I not able to start the engine
with a MyKey?

An admin key and a MyKey are inside
your vehicle. The system recognizes
only the admin key when both are
present.

MyKey™

OPERATING THE DOORS
FROM OUTSIDE YOUR
VEHICLE

UNLOCKING AND LOCKING THE
DOORS USING THE REMOTE
CONTROL

You can only use the remote control when
your vehicle is stationary.

Unlocking the Doors

E267112

Press the button to unlock all
doors.

Locking the Doors

E267111

Press the button to lock all
doors. One short flash of the
turn signal lamps confirms that

your vehicle has locked.

Note:

For more information on operating

the doors from outside your vehicle See

Keyless Entry

(page 77).

UNLOCKING AND LOCKING THE
DOORS USING THE KEY BLADE

If there is a power door lock fault, you can
use the key blade to lock and unlock the
driver door.

E328009

Lock.

Unlock.

INDIVIDUALLY UNLOCKING AND
LOCKING THE DOORS USING THE
KEY BLADE

If there is a power door lock fault you can
use the key blade to lock and unlock the
doors.

E112203

Lock.

Unlock.

OPERATING THE DOORS
FROM INSIDE YOUR VEHICLE

UNLOCKING AND LOCKING THE
DOORS USING THE CENTRAL
LOCKING

The power door lock control is on the driver
door.

E267112

Press the button to unlock all
doors.

Doors and Locks

E267111

Press the button to lock all
doors.

INDIVIDUALLY UNLOCKING AND
LOCKING THE DOORS USING THE
LOCKING BUTTON

The power door lock control is on the driver
and front passenger door panels.

E196954

Unlock.

Lock.

OPENING THE DOORS FROM
INSIDE YOUR VEHICLE

Pull the interior door handle twice to
unlock and open a rear door. The first pull
unlocks the door and the second pull
opens the door.

AUTOUNLOCK

WHAT IS AUTOUNLOCK

Autounlock is an unlocking feature that
unlocks the vehicle doors when your
vehicle comes to a stop.

AUTOUNLOCK REQUIREMENTS

Autounlock unlocks all the doors when all
of the following occur:
•

The ignition is on, all the doors are
closed and your vehicle is moving at a
speed greater than 12 mph (20 km/h).

•

Your vehicle comes to a stop.

•

You open the driver door within 10
minutes of switching the ignition off or
to the accessory position.

SWITCHING AUTOUNLOCK ON
AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Switch

Autounlock

on or off.

AUTOLOCK

WHAT IS AUTOLOCK

Autolock is a locking feature that locks
your vehicle doors when you start driving.

AUTOLOCK REQUIREMENTS

Autolock locks all the doors when all of the
following occur:
•

All doors are closed.

•

The ignition is on.

•

Your vehicle reaches a speed greater
than 12 mph (20 km/h).

MISLOCK

WHAT IS MISLOCK

Mislock is a locking feature that warns you
if your vehicle has not locked.

Doors and Locks

MISLOCK LIMITATIONS

When you press the lock button once, the
direction indicators do not flash if:
•

Any door or the liftgate is open.

•

The hood is open.

When you press the lock button twice
within three seconds, the horn sounds if:
•

Any door or the liftgate is open.

•

The hood is open.

If you switch mislock off, the horn does not
sound if you press the lock button on the
remote control when a door is open.

SWITCHING MISLOCK ON AND
OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Switch

Mislock Chirp

on or off.

DOORS AND LOCKS AUDIBLE
WARNINGS

Door Ajar Audible Warning

Sounds when a door is not fully closed and
your vehicle is moving.

DOORS AND LOCKS –
TROUBLESHOOTING

DOORS AND LOCKS – WARNING
LAMPS

Door Ajar Warning Lamp

E249859

It illuminates when you switch
the ignition on and remains on if
any door or the hood is open.

DOORS AND LOCKS – INFORMATION MESSAGES

Action

Message

Displays if a door is open. Fully close the door.

Driver Door Ajar

Passenger Door Ajar

Rear Left Door Ajar

Rear Right Door Ajar

Doors and Locks

DOORS AND LOCKS –
FREQUENTLY ASKED QUESTIONS

Can accessories such as steps or
handles be used with the latch
assembly?

Do not use the door latch assembly to
attach any accessory, such as handles
or steps, as this can cause damage to
your vehicle.

Doors and Locks

KEYLESS ENTRY LIMITATIONS

Make sure your remote control is within 3 ft
(1 m) from the front door handles and the
tailgate.

The system could not function if:
•

The remote control remains stationary
for about a minute.

•

The vehicle battery has no charge.

•

The remote control battery has no
charge.

•

There is interference causing issues
with the remote control frequencies.

•

The remote control is too close to
metal objects or electronic devices, for
example keys or a cell phone.

KEYLESS ENTRY SETTINGS

Switching Keyless Entry On and
Off

Switch the ignition on using an original
key that has not been created as a
MyKey.

2. Using the information display controls

on the steering wheel, select

Settings

3. Select

Vehicle Settings

4. Select

Locks

Reprogramming the Unlocking
Function

You can enable two-stage unlocking
function allowing you to unlock only the
driver door when you touch the unlock
sensor.

Press and hold both the lock and unlock
buttons on the remote control for four
seconds to disable or enable two-stage
unlocking.

If you program the unlocking function so
that only the driver door unlocks, you can
unlock all of the other doors from inside
your vehicle using the power door lock
control. You can unlock individual doors
by pulling the interior door handles on
those doors.

USING KEYLESS ENTRY

Unlocking the Doors

E248553

With your passive key within 3 ft (1 m) of
your vehicle, touch the unlock sensor on
the back of the door handle for a brief
period and then pull on the door handle to
unlock, being careful not to touch the lock
sensor at the same time or pull on the door
handle too quickly. The intelligent access
system requires a brief delay to
authenticate your intelligent access key.

Locking the Doors

E248554

With your passive key within 3 ft (1 m) of
your vehicle, touch the outer door handle
lock sensor for approximately one second
to lock, being careful not to touch the
unlock sensor on the back of the door
handle at the same time. After locking, you
can immediately pull on the door handle
to confirm locking occurred without
inadvertently unlocking.

Keyless Entry

(If Equipped)

KEYLESS ENTRY –
TROUBLESHOOTING

KEYLESS ENTRY – FREQUENTLY
ASKED QUESTIONS

Why does the passive key not work?

The system deactivates passive keys
left inside your vehicle when you lock
it. You cannot switch the ignition on
using a deactivated passive key. Press
the unlock button on the remote
control to reactivate a passive key.

Keyless Entry

(If Equipped)

WHAT IS THE KEYLESS ENTRY
KEYPAD

The keyless entry keypad allows you to
lock and unlock your vehicle using the
keypad on the window trim.

KEYLESS ENTRY KEYPAD
LIMITATIONS

The system may not function if:
•

The vehicle battery has no charge.

LOCATING THE KEYLESS
ENTRY KEYPAD

The keypad is near the driver window and
illuminates when you touch it.

E138637

KEYLESS ENTRY KEYPAD
MASTER ACCESS CODE

What Is the Master Access Code

The master access code is a factory-set
five-digit entry code. You can operate the
keypad with the master access code at
any time. The master access code is on the
owner’s wallet card in the glove box and
is available from an authorized dealer.

KEYLESS ENTRY KEYPAD
PERSONAL ACCESS CODES

Programming a Personal Entry
Code

Enter the five-digit master code.

2. Press

1·2

on the keypad within five

seconds.

3. Enter your personal five-digit code.

You must do this within five seconds
of completing Step 2.

4. Press

1·2

on the keypad to save

personal code 1.

The doors lock then unlock to confirm that
programming was successful.

To program additional personal entry
codes, repeat Steps 1 through 3, then for
Step 4:
•

Press

3·4

to save personal code 2.

•

Press

5·6

to save personal code 3.

•

Press

7·8

to save personal code 4.

•

Press

9·0

to save personal code 5.

If your vehicle comes with SYNC, you can
also program the system with a personal
entry code.

Keyless Entry Keypad

(If Equipped)

Hints:
•

Do not set a code that uses five of the
same number.

•

Do not use five numbers in sequential
order.

•

The five-digit master code works even
if you have set your own personal code.

Erasing a Personal Code

Enter the five-digit master code.

2. Press and release

1·2

on the keypad

within five seconds.

3. Press and hold

1·2

for two seconds.

You must do this within five seconds
of completing Step 2.

All personal codes erase and only the
five-digit master code works.

Anti-Scan Feature

The keypad goes into an anti-scan mode
if you enter the wrong code seven times.
This mode turns off the keypad for one
minute and the keypad lamp flashes.

The anti-scan feature turns off after:
•

One minute of keypad inactivity.

•

You press the unlock button on the
remote control.

•

You switch the ignition on.

•

You unlock your vehicle using keyless
entry.

USING THE KEYLESS ENTRY
KEYPAD

Unlocking the Doors

E138637

Enter the factory-set five-digit code or your
personal code. You must press each
number within five seconds of each other.

•

Press 3-4 within five seconds to unlock
all doors.

Keyless Entry Keypad

(If Equipped)

Locking the Doors

E138637

Press and hold

7·8

and

9·0

at the same

time with the driver door closed.

Note:

You do not need to enter the code

first.

KEYLESS ENTRY KEYPAD –
TROUBLESHOOTING

KEYLESS ENTRY KEYPAD –
FREQUENTLY ASKED QUESTIONS

Why does the keypad not accept the
access code?

If you enter the access code too fast
on the keypad, the unlock function
may not work. Slowly re-enter the
access code.

Why does the keypad not function?

The keypad goes into an anti-scan
mode if you enter a wrong code seven
times. The anti-scan mode disables
the keypad for one minute and the red
light flashes.

Keyless Entry Keypad

(If Equipped)

TAILGATE PRECAUTIONS

WARNING:

It is extremely

dangerous to ride in a cargo area, inside
or outside of a vehicle. In a crash, people
riding in these areas are more likely to be
seriously injured or killed. Do not allow
people to ride in any area of your vehicle
that is not equipped with seats and
seatbelts. Make sure everyone in your
vehicle is in a seat and properly using a
seatbelt. Failure to follow this warning
could result in serious personal injury or
death.

OPENING THE TAILGATE

OPENING THE TAILGATE FROM
OUTSIDE YOUR VEHICLE

E348034

Pull up on the handle to release the
tailgate.

Note:

You may need to unlock the tailgate

first.

OPENING THE TAILGATE TO THE
MIDDLE POSITION

Open the tailgate.

2. Lower the tailgate.

E351595

3. Raise the tailgate slightly to allow slack

in the tailgate cables and unlatch them.

E351596

4. Move the tailgate cables and secure

them to the tailgate strikers.

Note:

Attach both cables when using the

tailgate in the middle position.

Note:

Attach the safety bracket when using

the tailgate in the middle position.

When hauling cargo using the tailgate
middle position, make sure the load is
evenly distributed and supported using the
support locations in the pickup bed. See

Locating the Pickup Bed Slots

(page

260).

Note:

Secure all cargo.

Note:

The maximum load capacity for the

middle position is 500 lb (226 kg).

Tailgate

LOCKING AND UNLOCKING
THE TAILGATE

Manual

E348035

Lock.

Unlock.

Insert the ignition key into the tailgate
lock.

2. Turn it to the left to lock the tailgate.

3. Turn it to the right to unlock the

tailgate.

Power

You can lock and unlock the tailgate with
the remote control or power door unlock
control.

REMOVING AND INSTALLING
THE TAILGATE

WARNING:

Always properly secure

cargo to prevent shifting cargo or cargo
falling from the vehicle. Failure to do so
could result in compromised vehicle
stability and serious personal injury to
vehicle occupants or others.

E189556

Unlatch the tailgate.

2. Disconnect the power door locks in-line

connector. It is under the pickup box
on the right-hand side of the vehicle
near the spare tire.

3. Install a protective cap on the in-line

connector portion that remains under
the pickup box.

Note:

A protective cap should be in the

glove compartment.

4. Partially lower the tailgate. Carefully

feed the tailgate harness up through
the gap between the pickup box and
the bumper and place it out of the way
under the pickup box.

5. Lower the tailgate.

E355264

Tailgate

Content .. 2 3 4 5 ..
