Washer Reservoir

Capacities

Quantity

Variant

0.5 gal (1.89 L)

All.

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concen-
trate with Bitterant(U.S.)
Motorcraft® Premium Quality Windshield Washer
Fluid / Liquide lave-glace de haute qualité Motor-
craft®(Canada)
ZC-32-B2(U.S.)
CXC-37-F/M(Canada)

215

Capacities and Specifications

AUDIO UNIT

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

You can access your audio features with
the touchscreen and steering wheel
controls.

The power button is to the left of the
display screen.

USB PORT

The USB port is on the bottom of the
instrument panel.

The USB port allows you to plug in media
playing devices, memory sticks and charge
supported devices.

216

Audio System

GENERAL INFORMATION

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Getting to Know Your System

The SYNC 3 system allows you to interact
with a variety of features using the
touchscreen and voice commands. By
integrating with your Bluetooth-enabled
phone, the touchscreen provides easy
interaction with audio, multimedia,
navigation and your phone's SYNC 3
compatible apps.

Using the Touchscreen

To operate the touchscreen, you can
simply touch the item or option that you
want to select. The button changes color
when you select it.

The SYNC 3 layout allows you to quickly
select the feature you wish to use.

E207614

217

SYNC™ 3

Action and Description

Menu Item

Item

This bar displays icons and messages pertaining to current
system activities including voice commands and phone
functions such as text messages.

Status Bar

A

This button is available on the main screens. Pressing it
takes you to the home screen view.

Home

B

This shows the current time. You can set the clock manually
or have it controlled by the vehicle's GPS location.  See

Settings

 (page 253).

Clock

C

This displays the current outside temperature.

Outside
Temperature

D

You can touch any of the buttons on this bar to select a
feature.

Feature Bar

E

The touchscreen allows you quick access
to all of your comfort, navigation,
communication and entertainment
options. Using the status and feature bar
you can quickly select the feature you want
to use.

Note:

Your system is equipped with a

feature that allows you to access and
control audio features for 10 minutes after
you switch the ignition off (and no doors
open).

The Status Bar

Additional icons also display in the status
bar depending on market, vehicle options
and current operation. If a feature is not
active, the icon does not display. Certain
icons may move to the left or right
depending on what options are active.

218

SYNC™ 3

E223058

Description

Item

Callout

This icon displays when your phone's microphone is
muted. A caller cannot hear you.

Microphone Mute

A

This icon displays when the audio system is muted.

Mute

B

This icon displays when SYNC 3 has received a soft-
ware update. Pressing the icon will show more details
about the new software.

Download

C

This icon appears if a Wi-Fi network is connected.

Wi-Fi

D

This icon displays when an available Wi-Fi network
is within range.

Wi-Fi in Range

E

This icon displays when your cell phone is roaming.

Roaming

F

This icon displays when you receive a text message
on your phone.

Text Message

G

219

SYNC™ 3

Description

Item

Callout

This icon displays when 911 Assist is set to off and
your phone is connected to SYNC.

911 Assist Off

H

This icon displays when there is an active Bluetooth
alert.

Bluetooth Alert

I

This icon displays to show an active Bluetooth
connection.

Bluetooth

J

Messages may also appear in the status
bar to provide you with notifications. You
can select the message to view the
associated feature.

Feature Bar

Functions

Feature Bar Item

Allows you to control the media playing in
your vehicle. You can control all audio
features including AM, FM radio, and media
streaming over a Bluetooth device or
through a USB connection.

Audio

Allows you to make calls, receive calls, and
access the phonebook of your connected
device.

Phone

Allows you to see your vehicle's location on
a virtual road map, get driving directions to
your destination and find points of interest
along your route.

Navigation

Connect and control SYNC 3 compatible
apps running on your iphone or android
device.

Apps

You can customize your system with
various settings for the touchscreen display,
feature preferences, and how you want to
interact with your vehicle.

Settings

Cleaning the Touchscreen

You can remove fingerprints with a dry,
clean, soft cloth.

If dirt or fingerprints are still on the screen,
apply a small amount of alcohol to the
cloth and try to clean it again.

220

SYNC™ 3

Note:

 Do not use detergent or any type of

solvent to clean the touchscreen.

Note:

Do not pour or spray alcohol onto the

touchscreen.

Using Voice Recognition

Using voice commands allows you to keep
your hands on the wheel and focus on
what is in front of you. The system provides
feedback through audible tones, prompts,
questions and spoken confirmations
depending on the situation and the chosen
level of interaction (voice settings).

The system also asks short questions
(confirmation prompts) when it is not sure
of your request or when there are multiple
possible responses to your request.

When using voice commands, words and
icons may appear in the status bar
indicating the status of the voice command
session.  See

Using Voice Recognition

(page 228).

Using the Steering Wheel Controls

You can use different controls on your
steering wheel to interact with the
touchscreen system in different ways.

VOL:

 Control the volume of audio output.

Voice:

 Press to start a voice session. Press

again to stop the voice prompt and
immediately begin speaking. Press and
hold to end a voice session.

SEEK NEXT:

•

While in radio mode, press to seek
between memory presets.

•

While in USB or Bluetooth Audio, press
to seek between songs or press and
hold to fast seek.

SEEK PREVIOUS:

•

While in radio mode, press to seek
between memory presets.

•

While in USB or Bluetooth Audio, press
to seek between songs or press and
hold to fast seek.

See

Steering Wheel

 (page 56).

Using Your Bezel Controls

•

Power:

 Switch the audio system on

and off.

•

DISP:

 Switch the display on or off. You

can also touch the screen to switch the
display back on.

911 Assist

WARNING:

Unless the 911 Assist

setting is set on before a crash, the
system will not dial for help which could
delay response time, potentially
increasing the risk of serious injury or
death after a crash.

WARNING:

Do not wait for 911

Assist to make an emergency call if you
can do it yourself. Dial emergency
services immediately to avoid delayed
response time which could increase the
risk of serious injury or death after a
crash. If you do not hear 911 Assist within
five seconds of the crash, the system or
phone may be damaged or
non-functional.

WARNING:

Always place your

phone in a secure location in your vehicle
so it does not become a projectile or get
damaged in a crash. Failure to do so may
cause serious injury to someone or
damage the phone which could prevent
911 Assist from working properly.

Note:

The SYNC 911 Assist feature must be

set on before the incident.

221

SYNC™ 3

Note:

The SYNC 911 Assist feature only

operates in the U.S., Canada or in a territory
in which 911 is the emergency number.

Note:

Before setting this feature on, make

sure that you read the 911 Assist Privacy
Notice later in this section for important
information.

Note:

If any user sets 911 Assist to on or off,

that setting applies for all paired phones. If
911 Assist is switched off and the phone is
connected to SYNC, an icon displays on the
status bar.

Note:

Every phone operates differently.

While SYNC 911 Assist works with most
cellular phones, some may have trouble
using this feature.

If a crash deploys an airbag (excluding
knee airbags and rear inflatable safety
belts [if equipped]) or activates the fuel
pump shut-off, your SYNC-equipped
vehicle may be able to contact emergency
services by dialing 911 through a paired and
connected Bluetooth-enabled phone. You
can learn more about the 911 Assist
feature, by visiting:

Website

www.owner.ford.com
www.syncmyride.ca
www.syncmaroute.ca

For important information about airbag
deployment and the fuel pump shut-off
please see the Supplementary Restrains
and Roadside Emergencies sections of
your owner manual.

To switch 911 Assist on and off please view
the settings information. See

Settings

(page 253).

To make sure that 911 Assist works
correctly:
•

SYNC must be powered and working
properly at the time of the incident and
throughout feature activation and use.

•

The 911 Assist feature must be set on
before the incident.

•

You must pair and connect a
Bluetooth-enabled and compatible
cell phone to SYNC.

•

A connected Bluetooth-enabled phone
must have the ability to make and
maintain an outgoing call at the time
of the incident.

•

A connected Bluetooth-enabled phone
must have adequate network coverage,
battery power and signal strength.

•

The vehicle must have battery power
and be located in the U.S., Canada or
in a territory in which 911 is the
emergency number.

In the Event of a Crash

Not all crashes will deploy an airbag or
activate the fuel pump shut-off (the
triggers for 911 Assist). If a connected cell
phone sustains damage or loses its
connection to SYNC during a crash, SYNC
will search for and try to connect to a
previously paired cell phone; SYNC will
then attempt to call the emergency
services.

Before making the call:
•

SYNC provides a short window of time
(about 10 seconds) to cancel the call.
If you fail to cancel the call, SYNC
attempts to dial 911.

•

SYNC says the following, or a similar
message: "SYNC will attempt to call
911, to cancel the call, press Cancel on
your screen or press and hold the
phone button on your steering wheel."

222

SYNC™ 3

If you do not cancel the call, and SYNC
makes a successful call, a pre-recorded
message plays for the 911 operator, and
then the occupant(s) in your vehicle is able
to talk with the operator. Be prepared to
provide your name, phone number and
location immediately, because not all 911
systems are capable of receiving this
information electronically.

911 Assist May Not Work If

•

Your cellular phone or 911 Assist
hardware sustains damage in a crash.

•

The vehicle's battery or the SYNC
system has no power.

•

The phone(s) thrown from your vehicle
are the ones paired and connected to
the system.

911 Assist Privacy Notice

When you switch on 911 Assist, it may
disclose to emergency services that your
vehicle has been in a crash involving the
deployment of an airbag or activation of
the fuel pump shut-off. Certain versions or
updates to 911 Assist may also be capable
of electronically or verbally disclosing to
911 operators your vehicle location or other
details about your vehicle or crash to assist
911 operators to provide the most
appropriate emergency services. If you do
not want to disclose this information, do
not switch the feature on.

Safety Information

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any

hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

•

Do not attempt to service or repair the
system. Have an authorized dealer
check your vehicle.

•

Do not operate playing devices if the
power cords or cables are broken, split
or damaged. Place cords and cables
out of the way, so they do not interfere
with the operation of pedals, seats,
compartments or safe driving abilities.

•

Do not leave playing devices in your
vehicle during extreme conditions as it
could cause them damage. See your
device's user guide for further
information.

•

For your safety, some SYNC 3 functions
are speed-dependent. Their use is
limited to when your vehicle is traveling
at speeds under 3 mph (5 km/h). Make
sure that you review your device's
manual before using it with SYNC 3.

Speed-restricted Features

Some features of this system may be too
difficult to use while your vehicle is moving
so they are restricted from use unless your
vehicle is stationary.

•

Screens crowded with information,
such as Point of Interest reviews and
ratings, movie times or ski conditions.

•

Any action that requires you to use a
keyboard is restricted, such as entering
a navigation destination or editing
information.

•

All lists are limited so the user can view
fewer entries (such as phone contacts
or recent phone call entries).

223

SYNC™ 3

See the following chart for more specific

examples.

Restricted features

Pairing a Bluetooth phone.

Cellular Phone

Browsing of list entries is limited for phone contacts and
recent phone calls.

Enabling Valet Mode.

System Functionality

Editing settings for the rear view camera.

Editing Wi-Fi settings.

Wi-Fi

Editing the list of wireless networks.

Connecting to a new Wi-Fi network.

Viewing received text messages.

Text Messages

Using the keyboard to enter a destination.

Navigation

Adding or editing Navigation Favorites entries or Avoid
Areas.

Creating a SYNC Owner Account

Why do I need a SYNC owner account?

•

Essential for keeping up with the latest
software and connected features.

•

Access to customer support for any
questions you may have.

•

Maintain account permissions.

Visit the website to sign up and register.

Website

www.owner.ford.com
www.syncmyride.ca
www.syncmaroute.ca

Updating Your System

You can choose to download the update
onto a USB drive or use Wi-Fi to deliver
automatic updates.

USB Updates

To use the USB update you need to log
into your owner account and visit the SYNC
software update page.

Website

www.owner.ford.com
www.syncmyride.ca
www.syncmaroute.ca

The website notifies you if an update is
available. You can then select to download
the update.

You will need an empty USB drive. Please
check the website for minimum
requirements. Once you have inserted the
USB drive into your computer, choose to
start the download. Follow the instructions
provided to download the files to the USB
drive.

224

SYNC™ 3

The installation of most files occurs in the
background, and does not interrupt your
use of the system. Navigation updates
cannot be installed in the background,
because the files are too large.

To install the update in your vehicle,
remove anything that is plugged in the USB
ports on the media hub and plug in the
USB drive containing the update. When
the USB drive is plugged in, the installation
should begin immediately. After a
successful installation, the update is
available the next time the vehicle is
started.

Please refer to the website for any further
actions.

Updating Over Wi-Fi

To update your System over Wi-Fi your
vehicle must be within the range of a Wi-Fi
access point. Data rates may apply.

To connect your system to Wi-Fi,
select:

Menu Item

Settings

Wi-Fi

You can then select your
Wi-Fi network. You may
have to enter the security
code if the network is
secured. The system
confirms when it has
connected to the network.

Available
Wi-Fi
Networks

You must also give the system permission
to update automatically. Upon vehicle
delivery, the System asks you if you would
like to use the automatic update feature.
If you agree to automatic updates, you can
press OK to confirm. If this selection does
not appear upon vehicle delivery you can
access it through the General Settings. See

Settings

 (page 253).  You can also perform

a master reset.  See

SYNC™ 3

Troubleshooting

 (page 264).

If you would like to switch this feature
on later, select:

Menu Item

Settings

General

From this menu, you can
enable automatic updates.
If you have not done so
already, the system
prompts you to set up a
Wi-Fi connection when you
enable this feature.

Automatic
System
Updates

When Wi-Fi and automatic updates are
enabled, your system checks for software
updates periodically. If a new version is
available, it downloads at that time.
Software downloads can take place for up
to 30 minutes after you have switched your
vehicle off. The updates do not interrupt
the normal use of your SYNC 3 system. If
a download does not complete for any
reason, the download continues where it
left off at the next Wi-Fi connected
opportunity. Upon activation of an update,
a banner displays on the touchscreen
indicating the system update. Select the
icon to see more detail. This icon displays
for two ignition cycles.

225

SYNC™ 3

To switch this feature off:

Menu Item

Settings

General

In this menu selection, you
can change the selection
for automatic updates to
OFF.

Automatic
System
Updates

Support

The SYNC support team is available to
help you with any questions you are not
able to answer on your own.

Monday-Saturday, 8:30am-8:00pm EST.

United States: 1-800-392-3673.

Canada: 1-800-565-3673.

Times are subject to change due to
holidays.

Privacy Information

When you connect a cellular phone to
SYNC 3, the system creates a profile within
your vehicle that links to that cellular
phone. This profile helps in offering you
more cellular features and operating more
efficiently. Among other things, this profile
may contain data about your cellular
phone book, text messages (read and

unread), and call history, including history
of calls when your cell phone was not
connected to the system. In addition, if you
connect a media device, the system
creates and retains an index of supported
media content. The system also records a
short diagnostic log of approximately 10
minutes of all recent system activity. The
log profile and other system data may be
used to improve the system and help
diagnose any problems that may occur.

The cellular profile, media device index,
and diagnostic log remain in your vehicle
unless you delete them and are generally
accessible only in your vehicle when the
cellular phone or media player is
connected.

If you no longer plan to use the system or
your vehicle, we recommend you perform
a Master Reset to erase all stored
information. You can find more information
about the Master Reset in General
Settings.  See

Settings

 (page 253).  System

data cannot be accessed without special
equipment and access to your vehicle's
SYNC 3 module. Ford Motor Company and
Ford of Canada do not access the system
data for any purpose other than as
described absent consent, a court order,
or where required by law enforcement,
other government authorities, or other third
parties acting with lawful authority. Other
parties may seek to access the information
independently of Ford Motor Company and
Ford of Canada.

226

SYNC™ 3

HOME SCREEN

E207616

Home screen display

Tile

Item

Shows the active media source.

Audio

A

The name of the connected phone appears on the screen. The
status of the phone features also appear. This includes signal
strength, battery charge, 911 assist setting state (On or Off),
text messaging and roaming.

Phone

B

This map displays your current location or current route in real
time.

Navigation

C

When you have navigation active, you also see the next turn
and the length of time and distance to your destination.

You can touch any of the feature displays
to access that feature.

Anytime you select the home button, the
system returns you to this screen.

227

SYNC™ 3

USING VOICE RECOGNITION

The SYNC 3 system allows you to use voice
commands to control features like audio
and climate controls. By using voice
commands, you can keep your hands on
the wheel and your eyes on the road.

You can access each feature controlled by
SYNC 3 through a variety of commands.

E142599

To activate the SYNC 3 voice
commands push the voice
button on the steering wheel and

wait for the prompt.

___ is a dynamic listing, meaning that it can
be the name of anything, such as artist, the
name of contact or number. The context
and the description of the command tell
you what to say for this dynamic option.

There are some commands that work for
every feature, these commands are:

Action and Description

Voice Command

Brings you to the main menu.

Main Menu

Returns you to the previous screen.

Go back

Ends the voice session.

Cancel

Gives you a list of possible voice commands.

List of Commands

You can name any feature and the system gives a list of
commands available for the feature. For example, you could
say:

___ List of Commands

Phone List of Commands

Navigation List of Commands

You can use this command to view the next page of options on
any screen where multiple pages of choices are given.

Next Page

You can use this command to view the previous page of options
on any screen where multiple pages of choices are given.

Previous Page

Gives you available commands you can use on the current
screen.

Help

Included here are some of the most
popular commands for each SYNC 3
feature.

Audio Voice Commands

___ is a dynamic listing, meaning that for
audio voice commands it can be the name
of a Sirius channel or a channel number, a
radio frequency number, or the name of an
artist, album, song or a genre.

228

SYNC™ 3

To control the media features, press the voice button and when prompted, say:

Description

Voice Command

You can say the Sirius channel name or number
such as "Sirius channel 16".

1

Sirius Channel ___

You can also tune to a Sirius channel by saying the channel's name, such as "The Pulse".

Allows you to tune to a specific FM or AM
frequency such as "FM 88.7" or "AM 1580".

AM ___

FM ___

Allows you to tune to a specific HD frequency
such as “FM 88.7 HD 1”.

1

FM ___ HD ___

Allows you to listen to music on your

Bluetooth®

connected device.

Bluetooth Audio

Allows you to listen to music on your USB
connected device.

USB

For USB audio only, you can say the name of an
artist, album, song or a genre to listen to that
selection. Your system must finish indexing
before this option is available. For example, you
could say "Play artist The Beatles" or "Play song
Penny Lane".

Play Genre ___

Play Playlist ___

Play Artist ___

Play Album ___

Play Podcast ___

Play Song ___

Play Audiobook ___

For USB audio only, you can say the name of an
artist, album, or a genre to browse by that selec-
tion. Your system must finish indexing before this
option is available. For example you can say
"Browse artist The Beatles" or "Browse genre
folk".

Browse ___

Browse Artist ___

Browse Album ___

Browse Genre ___

Browse Playlist ___

Browse Audiobook ___

Browse Podcast ___

1

This option may not be available in all markets or may require a subscription.

229

SYNC™ 3

Climate Voice Commands

 (If Equipped)

You can control the temperature of the
vehicle using voice commands.

___ is a dynamic listing, meaning that for
climate voice commands it can be the
desired degrees for the temperature
setting.

To adjust the temperature, say:

Description

Voice Command

Adjust the temperature between 60–85°F

(15.5–29.5°C).

Set the Temperature to ____

Phone Voice Commands

Pairing a Phone

You can use voice commands to connect
your

Bluetooth®

-enabled phone to the

system.

To pair your phone, press the voice button and when prompted, say:

Description

Voice Command

Follow the on-screen instructions to complete the pairing

process.  See

Settings

 (page 253).

Pair Phone

Making Calls

___ is a dynamic listing, meaning that for
phone voice commands it can be the name
of the contact you wish to call or the digits
you want to dial.

Press the voice button and say a command similar to the following:

Description

Voice Command

Allows you to call a specific contact from your phonebook
such as "Call Jenny".

Call ___

Allows you to call a specific contact from your phonebook
at a specific location such as "Call Jenny at Home".

Call ___ at ___

Allows you to dial a specific number such as “Dial 867-5309”.

Dial ___

230

SYNC™ 3
