Ford F-450 (2022 year). Manual in english

ACCESSING THE TRIP
COMPUTER - VEHICLES WITH:
2.3 INCH SCREEN

Use the instrument cluster display
controls to navigate the home screen.

2. Select

Trip 1

Trip 2

3. Select a setting and press the

button.

ACCESSING THE TRIP
COMPUTER - VEHICLES WITH:
4.2 INCH SCREEN

Use the instrument cluster display
controls to navigate the home screen.

2. Select

Trip/Fuel

3. Press the

button.

4. Select

Trip 1

Trip 2

ACCESSING THE TRIP
COMPUTER - VEHICLES WITH:
8 INCH SCREEN

Use the instrument cluster display
controls to navigate the home screen.

2. Select

Trip/Fuel

3. Press the

button.

4. Select

Trip 1

Trip 2

RESETTING THE TRIP
COMPUTER

Use the instrument cluster display
controls to navigate the home screen.

2. Select the trip screen you want to reset.

3. Press and hold the

button until the

system reset confirmation appears.

RESETTING THE INDIVIDUAL
TRIP VALUES

Use the instrument cluster display
controls to navigate the home screen.

2. Select

Trip 1

Trip 2

3. Press and hold the

button until the

system reset confirmation appears.

CONFIGURING THE TRIP
COMPUTER

Use the instrument cluster display
controls to navigate the home screen.

2. Select

Trip 1

Trip 2

3. Select a setting and press the

button.

4. Select values to display.

TRIP DATA

Trip 1 and 2

Provides trip timer, trip average fuel
economy and total trip distance traveled.
For hybrid vehicles, the trip also shows the
distance traveled on electric power only.

Note:

Trip 1 and 2 are selectable screens.

See

Accessing the Trip Computer

(page

145).

This Trip

Provides trip timer, trip average fuel
economy, total trip distance traveled, and
distance traveled on electric power only
with the engine off. If the gasoline engine
has not turned on during the trip then trip
average fuel economy is not shown. This
Trip resets each time you start your vehicle.

Note:

This trip is a selectable screen. See

Accessing the Trip Computer

(page 145).

145

Trip Computer

WHAT IS REMOTE START

The system allows you to remotely start
your vehicle and to adjust the interior
temperature according to the settings that
you chose.

REMOTE START
PRECAUTIONS

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

REMOTE START LIMITATIONS

Remote start does not work under the
following conditions:

•

The alarm horn is sounding.

•

The hood is open.

•

The transmission is not in park (P).

•

The ignition is on.

•

The battery voltage is below the
minimum operating voltage.

Note:

Do not use remote start if your fuel

level is low.

Note:

You can use remote start with

FordPass. See

Connecting the Vehicle to

a Wi-Fi Network

(page 498).

ENABLING REMOTE START

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Switch

Remote Start

on or off.

Note:

To remote start with FordPass, make

sure that the modem is enabled. See

Connecting FordPass to the Modem

(page 502).

REMOTELY STARTING AND
STOPPING THE VEHICLE

Remotely Starting the Vehicle

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

Note:

You can also use FordPass to start

the vehicle.

Note:

The turn signal lamps flash twice.

Note:

The parking lamps turn on when the

vehicle is running.

Note:

The horn sounds if the system fails

to start.

Note:

All other vehicle systems remain off

when you have remotely started the vehicle.

Note:

The vehicle remains secured when

you have remotely started the vehicle. A
valid key must be inside your vehicle to
switch the ignition on and drive your vehicle.

Remotely Stopping the Vehicle

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

146

Remote Start

(If Equipped)

EXTENDING THE REMOTE
START DURATION

To extend the remote start duration during
remote start, do the following:

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

If the duration is set to 15 minutes, the
duration extends by another 15 minutes.
This provides a total of 30 minutes.

Note:

Remote start can only be extended

once.

Note:

A maximum of two remote starts, or

one remote start with an extension, are
allowed. To reset the restart procedure
switch the vehicle to on, then to off.

REMOTE START REMOTE
CONTROL INDICATORS

Remote Control Feedback

An LED on the remote control provides
status feedback of remote start or stop
commands.

Status

LED

Remote start

successful.

Solid green.

Remote stop

successful.

Solid red.

Request failed or

status not received.

Blinking red.

Status incomplete.

Blinking green.

REMOTE START SETTINGS

SWITCHING CLIMATE CONTROL
AUTO MODE ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Remote Start Setup

3. Press

Climate Control

4. Select

Vehicle

5. Switch

Auto

on or off.

Note:

If you switch the auto mode on, the

system attempts to heat or cool the interior
to 72°F (22°C).

Note:

When you switch the ignition on, the

climate control system returns to the last
used settings.

SWITCHING CLIMATE CONTROL
LAST SETTINGS ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Switch

Last settings

on or off.

Note:

If you switch the last settings on, the

system remembers the last used settings.

SWITCHING THE HEATED SEAT
SETTINGS ON AND OFF

(If Equipped)

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Seats

5. Switch

Auto

on or off.

Note:

If you switch the heated seat settings

on, the heated seats turn on during cold
weather.

147

Remote Start

(If Equipped)

SWITCHING THE HEATED
STEERING WHEEL SETTINGS ON
AND OFF

(If Equipped)

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Seats and Steering Wheel

5. Switch

Auto

on or off.

Note:

If you switch the heated steering

wheel settings on, the heated steering wheel
turns on during cold weather.

SETTING THE REMOTE START
DURATION

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Duration

Note:

Wait a few seconds before remotely

starting the vehicle after the vehicle stops
running.

148

Remote Start

(If Equipped)

IDENTIFYING THE CLIMATE
CONTROL UNIT

E351167

Depending on your vehicle options, the
controls could look different than what you
see here.

SWITCHING CLIMATE
CONTROL ON AND OFF

Press the button.

SWITCHING RECIRCULATED
AIR ON AND OFF

E351062

Press the button to recirculate
air currently in the passenger
compartment.

Note:

Recirculated air may turn off

automatically, or prevent you from switching
on in all air flow modes except MAX A/C to
reduce the risk of fogging. Recirculation may
also turn on and off automatically in various
air distribution control combinations to
improve heating or cooling efficiency.

SWITCHING AIR
CONDITIONING ON AND OFF

Press the button.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

SWITCHING DEFROST ON AND
OFF

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen to switch the
windshield air vents on.

E244097

Make sure that the instrument
panel air vents are switched off.

Make sure that the footwell air
vents are switched off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Press the button.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

149

Climate Control - Vehicles With: Automatic Temperature

Control

SWITCHING MAXIMUM
COOLING ON AND OFF

Press the button.

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
REAR WINDOW ON AND OFF

(IF

EQUIPPED)

E351061

Press the button to clear the rear
window of thin ice and fog. The
heated rear window turns off

after a short period of time.

Note:

This button also activates the heated

mirrors.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window as this could cause damage to
the heated rear window grid lines not
covered by the vehicle Warranty.

SETTING THE BLOWER MOTOR
SPEED

E266187

E266186

Press up or down on the control
to select the blower motor
speed.

SETTING THE TEMPERATURE

E244115

Turn the control on the left-hand side of
the climate control to set the left-hand
temperature.

Note:

This control also sets the right-hand

side temperature when you switch off dual
zone mode.

Turn the control on the right-hand side of
the climate control to set the right-hand
temperature.

DIRECTING THE FLOW OF AIR

Directing Air to the Windshield Air
Vents

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen.

Directing Air to the Instrument
Panel Air Vents

E265283

Press the button to activate the
selection screen.

150

Climate Control - Vehicles With: Automatic Temperature

Control

E244097

Press the button on the
touchscreen.

Directing Air to the Footwell Air
Vents

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen.

AUTO MODE

SWITCHING AUTO MODE ON AND
OFF

Press the button to switch auto
mode on. Repeatedly press the
button to adjust auto mode.

Note:

When you switch auto mode on,

lights on the blower motor control do not
illuminate to indicate the blower motor
speed.

Adjust the blower motor control or air
distribution control to switch auto mode
off.

AUTO MODE INDICATORS

The indicators are on the Auto Mode
button.

Description

Auto Mode Indicator

Status

The blower motor speed is reduced. Use this setting to
minimize the amount of noise from the blower motor. This
setting increases the time taken to cool the interior.

One indicator illumin-
ated.

The blower motor speed is moderate.

Two indicators illumin-
ated.

The blower motor speed is increased. Use this setting to
reduce the time taken to cool the interior. This setting
increases the amount of noise from the blower motor.

Three indicators illumin-
ated.

151

Climate Control - Vehicles With: Automatic Temperature

Control

SWITCHING DUAL MODE ON AND
OFF

E265280

Press the button.

CLIMATE CONTROL HINTS

General Hints

•

Prolonged use of recirculated air may
cause the windows to fog up.

•

You may feel a small amount of air
from the footwell air vents regardless
of the air distribution setting.

•

To reduce humidity build-up inside your
vehicle, do not drive with the system
switched off or with recirculated air
always switched on.

•

Do not place objects under the front
seats as this may interfere with the
airflow to the rear seats.

•

Remove any snow, ice or leaves from
the air intake area at the base of the
windshield.

•

To improve the time to reach a
comfortable temperature in hot
weather, drive with the windows open
until you feel cold air through the air
vents.

Automatic Climate Control

•

Adjusting the settings when your
vehicle interior is extremely hot or cold
is not necessary. Automatic mode is
best recommended to maintain set
temperature.

•

The system adjusts to heat or cool the
interior to the temperature you select
as quickly as possible.

•

For the system to function efficiently,
the instrument panel and side air vents
should be fully open.

•

If you press

AUTO

during cold outside

temperatures, the system directs air
flow to the windshield and side window
air vents. In addition, the blower motor
may run at a slower speed until the
engine warms up.

•

If you press

AUTO

during hot

temperatures and the inside of the
vehicle is hot, the system uses
recirculated air to maximize interior
cooling. Blower motor speed may also
reduce until the air cools.

Quickly Heating the Interior

Press

AUTO

2. Adjust the temperature function to the

setting you prefer.

Recommended Settings for
Heating

Press

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Quickly Cooling the Interior

Press

MAX A/C

Recommended Settings for
Cooling

Press

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Defogging the Side Windows in
Cold Weather

Press and release defrost or maximum
defrost.

152

Climate Control - Vehicles With: Automatic Temperature

Control

IDENTIFYING THE CLIMATE
CONTROL UNIT

E351180

Depending on your vehicle options, the
controls could look different than what you
see here.

SWITCHING CLIMATE
CONTROL ON AND OFF

Press the button.

SWITCHING RECIRCULATED
AIR ON AND OFF

Press the button to recirculate
air currently in the passenger
compartment.

Note:

Recirculated air may turn off

SWITCHING AIR
CONDITIONING ON AND OFF

Press the button.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

SWITCHING DEFROST ON AND
OFF

Press the button to switch the
windshield air vents on.

E244097

Make sure that the instrument
panel air vents are switched off.

Make sure that the footwell air
vents are switched off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Turn the temperature control
clockwise past the highest
setting to maximize defrosting.

Note:

The temperature control springs back

to the highest setting.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

SWITCHING MAXIMUM
COOLING ON AND OFF

Turn the temperature control
counterclockwise past the
lowest setting to maximize

cooling.

Note:

The temperature control springs back

to the lowest setting.

154

Climate Control - Vehicles With: Manual Temperature Control

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
REAR WINDOW ON AND OFF

(IF

EQUIPPED)

Press the button to clear the rear
window of thin ice and fog. The
heated rear window turns off

after a short period of time.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window as this could cause damage to
the heated rear window grid lines not
covered by the vehicle Warranty.

SWITCHING THE HEATED
MIRRORS ON AND OFF

E266189

Press the button.

SETTING THE BLOWER MOTOR
SPEED

Note:

Lights on the control illuminate to

indicate the blower motor speed.

Note:

When you switch the blower motor

off, air conditioning turns off and the
windows could fog up.

SETTING THE TEMPERATURE

E244106

Turn the temperature control
counterclockwise for cooler temperature
settings.

Turn the temperature control clockwise
for warmer temperature settings.

DIRECTING THE FLOW OF AIR

Directing Air to the Windshield Air
Vents

Press the button.

Directing Air to the Instrument
Panel Air Vents

E244097

Press the button.

Directing Air to the Footwell Air
Vents

Press the button.

155

Climate Control - Vehicles With: Manual Temperature Control

CLIMATE CONTROL HINTS

General Hints

•

Prolonged use of recirculated air may
cause the windows to fog up.

•

You may feel a small amount of air
from the footwell air vents regardless
of the air distribution setting.

•

To reduce humidity build-up inside your
vehicle, do not drive with the system
switched off or with recirculated air
always switched on.

•

Do not place objects under the front
seats as this may interfere with the
airflow to the rear seats.

•

Remove any snow, ice or leaves from
the air intake area at the base of the
windshield.

•

To improve the time to reach a
comfortable temperature in hot
weather, drive with the windows open
until you feel cold air through the air
vents.

Quickly Heating the Interior

Adjust the blower motor speed to the
highest speed setting.

2. Adjust the temperature control to the

highest setting.

3. Direct air to the footwell air vents.

Recommended Settings for
Heating

Adjust the blower motor speed to the
center setting.

2. Adjust the temperature control to the

midway point of the hot settings.

3. Direct air to the footwell air vents.

Quickly Cooling the Interior

Turn the temperature control
counterclockwise past the lowest
setting.

2. Drive with the windows open for a short

period of time.

Recommended Settings for
Cooling

Adjust the blower motor speed to the
center setting.

2. Adjust the temperature control to the

midway point of the cold settings.

3. Direct air to the instrument panel air

vents.

Defogging the Side Windows in
Cold Weather

Direct air to the instrument panel and
windshield air vents.

2. Press and release

A/C

3. Adjust the temperature control to the

setting you prefer.

4. Adjust the blower motor speed to the

highest setting.

5. Direct air toward the side windows.

6. Close the instrument panel air vents.

156

Climate Control - Vehicles With: Manual Temperature Control

FRONT SEAT PRECAUTIONS

WARNING:

Sitting improperly, out

of position or with the seatback reclined
too far can take weight off the seat
cushion and affect the decision of the
passenger sensing system, resulting in
serious injury or death in the event of a
crash. Always sit upright against your
seat back, with your feet on the floor.

WARNING:

Do not recline the seat

backrest too far as this can cause the
occupant to slide under the seatbelt,
resulting in personal injury in the event
of a crash.

WARNING:

Do not place objects

higher than the top of the seat backrest.
Failure to follow this instruction could
result in personal injury or death in the
event of a sudden stop or crash.

WARNING:

Do not adjust the driver

seat or seat backrest when your vehicle
is moving. This may result in sudden seat
movement, causing the loss of control
of your vehicle.

SITTING IN THE CORRECT
POSITION

E68595

When you use them properly, the seat,
head restraint, seatbelt and airbags will
provide optimum protection in the event
of a crash.

We recommend that you follow these
guidelines:
•

Sit in an upright position with the base
of your spine as far back as possible.

•

Do not recline the seat backrest so that
your torso is more than 30 degrees
from the upright position.

•

Adjust the head restraint so that the
top of it is level with the top of your
head and as far forward as possible.
Make sure that you remain
comfortable.

•

Keep sufficient distance between
yourself and the steering wheel. We
recommend a minimum of 10 in
(25 cm) between your breastbone and
the airbag cover.

•

Hold the steering wheel with your arms
slightly bent.

158

Front Seats

•

Bend your legs slightly so that you can
press the pedals fully.

•

Position the shoulder strap of the
seatbelt over the center of your
shoulder and position the lap strap
tightly across your hips.

Make sure that your driving position is
comfortable and that you can maintain full
control of your vehicle.

MANUAL SEATS

HEAD RESTRAINT COMPONENTS

E327921

The head restraints consist of:

An energy absorbing head
restraint.

Two steel stems.

Guide sleeve adjust and release
button.

Guide sleeve unlock and remove
button (If equipped).

ADJUSTING THE HEAD
RESTRAINT

WARNING:

Fully adjust the head

restraint before you sit in or operate your
vehicle. This will help minimize the risk
of neck injury in the event of a crash. Do
not adjust the head restraint when your
vehicle is moving.

WARNING:

The head restraint is a

safety device. Whenever possible it
should be installed and properly
adjusted when the seat is occupied.
Failure to adjust the head restraint
properly could reduce its effectiveness
during certain impacts.

WARNING:

Adjust the head

restraints for all passengers before you
drive your vehicle. This will help minimize
the risk of neck injury in the event of a
crash. Do not adjust the head restraints
when your vehicle is moving.

Note:

Adjust the seat backrest to an upright

driving position before adjusting the head
restraint. Adjust the head restraint so that
the top of it is level with the top of your head
and as far forward as possible. Make sure
that you remain comfortable. If you are
extremely tall, adjust the head restraint to
its highest position.

Pull the head restraint up to raise it.

To lower the head restraint:

Press and hold the adjust and release
button.

2. Push the head restraint down.

159

Front Seats

E327919

For vehicles with tilting head restraints:

Adjust the seat backrest to an upright
driving or riding position.

2. Pivot the head restraint forward toward

your head to the preferred position.

After the head restraint reaches the
forward-most tilt position, pivot it forward
again to release it to the rearward, untilted
position.

Note:

Do not attempt to force the head

restraint backward after it is tilted. Instead,
continue tilting it forward until the head
restraint releases to the upright position.

REMOVING THE HEAD RESTRAINT

Pull up the head restraint until it
reaches the highest adjustment
position.

2. Press and hold the adjust and release

button and the unlock and remove
button.

3. Pull up the head restraint.

Note:

Your vehicle may have a front row

center head restraint that you cannot adjust
or remove.

INSTALLING THE HEAD
RESTRAINT

Align the steel stems into the guide sleeves
and push the head restraint down until it
locks.

MOVING THE SEAT BACKWARD
AND FORWARD

WARNING:

Do not adjust the driver

seat or seat backrest when your vehicle
is moving. This may result in sudden seat
movement, causing the loss of control
of your vehicle.

WARNING:

Make sure the seat fully

locks into place by rocking it backward
and forward. Not securing the seat into
the locked position can be dangerous in
a crash and could cause serious personal
injury or death.

E308316

160

Front Seats

Ford F-450 (2022 year). Manual in english - page 9
