Mercury Mountaineer (2010 year). Manual - part 22

IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT

4.0L V6 engine

1. Engine oil filler cap

2. Engine oil dipstick (out of view)

3. Brake fluid reservoir

4. Power distribution box

5. Battery

6. Power steering fluid reservoir

7. Radiator cap

8. Engine coolant reservoir

9. Air filter assembly

10. Washer fluid reservoir

Maintenance and Specifications

337

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

4.6L V8 engine

1. Air filter assembly

2. Engine oil filler cap

3. Engine oil dipstick

4. Brake fluid reservoir

5. Power distribution box

6. Battery

7. Power steering fluid reservoir

8. Radiator cap

9. Engine coolant reservoir

10. Windshield washer fluid reservoir

Maintenance and Specifications

338

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

WINDSHIELD WASHER FLUID

Add fluid to fill the reservoir if the
level is low. In very cold weather, do
not fill the reservoir completely.

Only use a washer fluid that meets Ford specification WSB-M8B16–A2.
Do not use any special washer fluid such as windshield water repellent
type fluid or bug wash. They may cause squeaking, chatter noise,
streaking and smearing. Refer to the Maintenance product
specifications and capacities section in this chapter.

State or local regulations on volatile organic compounds may restrict the
use of methanol, a common windshield washer antifreeze additive.
Washer fluids containing non-methanol antifreeze agents should be used
only if they provide cold weather protection without damaging the
vehicle’s paint finish, wiper blades or washer system.

WARNING: If you operate your vehicle in temperatures below
40°F (5°C), use washer fluid with antifreeze protection. Failure

to use washer fluid with antifreeze protection in cold weather could
result in impaired windshield vision and increase the risk of injury or
accident.

Do not put washer fluid in the engine coolant reservoir. Washer
fluid placed in the cooling system may harm engine and cooling
system components.

Checking and adding washer fluid for the liftgate

Washer fluid for the liftgate is supplied by the same reservoir as the
windshield.

Maintenance and Specifications

339

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

CHANGING THE WIPER BLADES

1. Pull the wiper arm away from the
vehicle. Turn the blade at an angle
from the wiper arm. Push the lock
pin manually to release the blade
and pull the wiper blade down
toward the windshield to remove it
from the arm.

2. Attach the new wiper to the
wiper arm and press it into place
until a click is heard.

Replace wiper blades at least once
per year for optimum performance.

Poor wiper quality can be improved
by cleaning the wiper blades and
the windshield. Refer to Windows
and wiper blades in the Cleaning chapter.

To prolong the life of the wiper blades, it is highly recommended to
scrape off the ice on the windshield before turning on the wipers. The
layer of ice has many sharp edges and can damage the micro edge of the
wiper rubber element.

Changing the rear window wiper blade

To replace the rear wiper blade:

1. Pull the wiper arm as far away from the glass as possible. Do not use
excessive force because it can break the wiper arm. Hold it there until
the next step.

2. Grasp the wiper blade and rotate
it away from the wiper arm using
moderate force until it disengages
from the wiper arm.

3. Once the wiper blade is loose,
slide it away from the wiper arm.

Maintenance and Specifications

340

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

4. To attach the new wiper to the
wiper arm, align the cross pin and
keyway (denoted with the arrows)
and firmly press the wiper blade
into the wiper arm until an audible
snap is heard.

ENGINE OIL

Checking the engine oil

Refer to the scheduled maintenance information for the appropriate
intervals for checking the engine oil.

1. Make sure the vehicle is on level ground.

2. Turn the engine off and wait 15 minutes for the oil to drain into the
oil pan.

3. Set the parking brake and ensure the gearshift is securely latched in P
(Park).

4. Open the hood. Protect yourself from engine heat.

5. Locate and carefully remove the engine oil level dipstick.
• 4.0L V6 engine

Maintenance and Specifications

341

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

• 4.6L V8 engine

6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again.
• If the oil level is between the lower and upper holes, the oil level

is acceptable, DO NOT ADD OIL.

• If the oil level is below the lower hole, add enough oil to raise the

level within the lower and upper holes.

• 4.0L V6 engine

Maintenance and Specifications

342

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

• 4.6L V8 engine

• Oil levels above the upper hole may cause engine damage. Some oil

must be removed from the engine by an authorized dealer.

7. Put the dipstick back in and ensure it is fully seated.

Adding engine oil

1. Check the engine oil. For instructions, refer to Checking the engine
oil in this chapter.

2. If the engine oil level is not within the normal range, add only certified
engine oil of the recommended viscosity. Remove the engine oil filler cap
and use a funnel to pour the engine oil into the opening.

3. Recheck the engine oil level. Make sure the oil level is not above the
upper hole on the engine oil level dipstick.

4. Install the dipstick and ensure it is fully seated.

5. Fully install the engine oil filler cap by turning the filler cap clockwise
until three clicks can be heard.

To avoid possible oil loss, DO NOT operate the vehicle with the
engine oil level dipstick and/or the engine oil filler cap removed.

Maintenance and Specifications

343

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

Engine Oil Recommendations

4.0L V6 Engine

Look for this certification
trademark.

Use SAE 5W-30 engine oil

Only use oils “Certified For Gasoline Engines” by the American
Petroleum Institute (API). An oil with this trademark symbol conforms
to the current engine and emission system protection standards and fuel
economy requirements of the International Lubricant Standardization and
Approval Committee (ILSAC), comprised of U.S. and Japanese
automobile manufacturers.

To protect your engine and engine’s warranty, use Motorcraft SAE 5W-30
or an equivalent SAE 5W-30 oil meeting Ford specification
WSS-M2C929-A. Refer to Maintenance product specifications and
capacities later in this section for more information.

Do not use supplemental engine oil additives, cleaners or other engine
treatments. They are unnecessary and could lead to engine damage that
is not covered by Ford warranty.

Change your engine oil according to the appropriate schedule listed in
the scheduled maintenance information.

Ford production and Motorcraft replacement oil filters are designed for
added engine protection and long life. If a replacement oil filter is used
that does not meet Ford material and design specifications, start-up
engine noises or knock may be experienced.

It is recommended you use the appropriate Motorcraft oil filter or
another with equivalent performance for your engine application.

Maintenance and Specifications

344

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

4.6L 3V V8 Engine

Look for this certification
trademark.

Use SAE 5W-20 engine oil

To protect your engine and engine’s warranty, use Motorcraft SAE 5W-20
or an equivalent SAE 5W-20 oil meeting Ford specification
WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and
durability performance meeting all requirements for your
vehicle’s engine. Refer to Maintenance product specifications and
capacities later in this section for more information.

Do not use supplemental engine oil additives, cleaners or other engine
treatments. They are unnecessary and could lead to engine damage that
is not covered by Ford warranty.

Change your engine oil according to the appropriate schedule listed in
the scheduled maintenance information.

It is recommended you use the appropriate Motorcraft oil filter or
another with equivalent performance for your engine application.

Maintenance and Specifications

345

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

BATTERY

Your vehicle is equipped with a
Motorcraft maintenance-free battery
which normally does not require
additional water during its life of
service.

If your battery has a cover/shield, make sure it is reinstalled
after the battery has been cleaned or replaced.

For longer, trouble-free operation, keep the top of the battery clean and
dry. Also, make certain the battery cables are always tightly fastened to
the battery terminals.

If you see any corrosion on the battery or terminals, remove the cables
from the terminals and clean with a wire brush. You can neutralize the
acid with a solution of baking soda and water.

It is recommended that the negative battery cable terminal be
disconnected from the battery if you plan to store your vehicle for an
extended period of time. This will minimize the discharge of your battery
during storage.

Note: Electrical or electronic accessories or components added to
the vehicle by the dealer or the owner may adversely affect
battery performance and durability.

WARNING: Batteries normally produce explosive gases which
can cause personal injury. Therefore, do not allow flames, sparks

or lighted substances to come near the battery. When working near the
battery, always shield your face and protect your eyes. Always provide
proper ventilation.

WARNING: When lifting a plastic-cased battery, excessive
pressure on the end walls could cause acid to flow through the

vent caps, resulting in personal injury and/or damage to the vehicle or
battery. Lift the battery with a battery carrier or with your hands on
opposite corners.

Maintenance and Specifications

346

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

WARNING: Keep batteries out of reach of children. Batteries
contain sulfuric acid. Avoid contact with skin, eyes or clothing.

Shield your eyes when working near the battery to protect against
possible splashing of acid solution. In case of acid contact with skin or
eyes, flush immediately with water for a minimum of 15 minutes and
get prompt medical attention. If acid is swallowed, call a physician
immediately.

WARNING: Battery posts, terminals and related accessories
contain lead and lead compounds. Wash hands after handling.

Because your vehicle’s engine is electronically controlled by a computer,
some control conditions are maintained by power from the battery. When
the battery is disconnected or a new battery is installed, the engine must
relearn its idle and fuel trim strategy for optimum driveability and
performance. To begin this process:

1. With the vehicle at a complete stop, set the parking brake.

2. Put the gearshift in P (Park), turn off all accessories and start the
engine.

3. Run the engine until it reaches normal operating temperature.

4. Allow the engine to idle for at least one minute.

5. Turn the A/C on and allow the engine to idle for at least one minute.

6. Release the parking brake. With your foot on the brake pedal and with
the A/C on, put the vehicle in D (Drive) and allow the engine to idle for
at least one minute.

7. Drive the vehicle to complete the relearning process.
• The vehicle may need to be driven 10 miles (16 km) or more to

relearn the idle and fuel trim strategy.

• If you do not allow the engine to relearn its idle trim, the idle

quality of your vehicle may be adversely affected until the idle
trim is eventually relearned.

If the battery has been disconnected or a new battery has been installed,
the clock and radio settings must be reset once the battery is
reconnected. Additionally, the power running boards, if equipped, will
default to the off mode and must be turned on again.

Maintenance and Specifications

347

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

• Always dispose of automotive

batteries in a responsible manner.
Follow your local authorized
standards for disposal. Call your
local authorized recycling center
to find out more about recycling
automotive batteries.

ENGINE COOLANT

Checking engine coolant

The concentration and level of engine coolant should be checked at the
intervals listed in scheduled maintenance information. The coolant
concentration should be maintained at 50/50 coolant and distilled water,
which equates to a freeze point of -34°F (-36°C). Coolant concentration
testing is possible with a hydrometer or antifreeze tester. The level of
coolant should be maintained at the FULL COLD level in the coolant
reservoir. If the level falls below, add coolant per the instructions in the
Adding engine coolant section.

Your vehicle was factory-filled with a 50/50 engine coolant and water
concentration. If the concentration of coolant falls below 40% or above
60%, the engine parts could become damaged or not work properly. A
50/50 mixture of coolant and water provides the following:
• Freeze protection down to -34°F (-36°C).
• Boiling protection up to 265°F (129°C).
• Protection against rust and other forms of corrosion.
• Enables calibrated gauges to work properly.
When the engine is cold, check the level of the engine coolant in the
reservoir.

RETURN

RECYCLE

Maintenance and Specifications

348

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

• 4.0L V6 engine

• 4.6L V8 engine

• The engine coolant should be at the FULL COLD level or within the

COLD FILL RANGE as listed on the engine coolant reservoir
(depending upon application).

• Refer to scheduled maintenance information for service interval

schedules.

• Be sure to read and understand Precautions when servicing your

vehicle in this chapter.

If the engine coolant has not been checked at the recommended interval,
the engine coolant reservoir may become low or empty. If the reservoir is
low or empty, add engine coolant to the reservoir. Refer to Adding
engine coolant in this chapter.

Note: Automotive fluids are not interchangeable; do not use engine
coolant, antifreeze or windshield washer fluid outside of its specified
function and vehicle location.

Maintenance and Specifications

349

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

Adding engine coolant

When adding coolant, make sure it is a 50/50 mixture of engine coolant
and distilled water. Add the mixture to the coolant reservoir, when the
engine is cool, until the appropriate fill level is obtained.

WARNING: Do not add engine coolant when the engine is hot.
Steam and scalding liquids released from a hot cooling system

can burn you badly. Also, you can be burned if you spill coolant on hot
engine parts.

WARNING: Do not put engine coolant in the windshield washer
fluid container. If sprayed on the windshield, engine coolant

could make it difficult to see through the windshield.

• Do not mix coolants. Add the coolant type originally equipped

in your vehicle. Refer to Maintenance product specifications and
capacities in this chapter.

Note: Do not use stop leak pellets or cooling system sealants/additives
as they can cause damage to the engine cooling and/or heating systems.
This damage would not be covered under your vehicle’s warranty.
• A large amount of water without engine coolant may be added, in case

of emergency, to reach a vehicle service location. In this instance, the
cooling system must be drained and refilled with a 50/50 mixture of
engine coolant and distilled water as soon as possible. Water alone
(without engine coolant) can cause engine damage from corrosion,
overheating or freezing.

• Do not use alcohol, methanol, brine or any engine coolants

mixed with alcohol or methanol antifreeze (coolant). Alcohol
and other liquids can cause engine damage from overheating or
freezing.

• Do not add extra inhibitors or additives to the coolant. These

can be harmful and compromise the corrosion protection of the engine
coolant.

For vehicles with overflow coolant systems with a non-pressurized cap
on the coolant recovery system, add coolant to the coolant recovery
reservoir when the engine is cool. Add the proper mixture of coolant and
water to the FULL COLD level. For all other vehicles which have a
coolant degas system with a pressurized cap, or if it is necessary to
remove the coolant pressure relief cap on the radiator of a vehicle with
an overflow system, follow these steps to add engine coolant.

Maintenance and Specifications

350

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

WARNING: To reduce the risk of personal injury, make sure the
engine is cool before unscrewing the coolant pressure relief cap.

The cooling system is under pressure; steam and hot liquid can come
out forcefully when the cap is loosened slightly.

Add the proper mixture of coolant and water to the cooling system by
following these steps:

1. Before you begin, turn the engine off and let it cool.

2. When the engine is cool, wrap a thick cloth around the coolant
pressure relief cap on the coolant reservoir (a translucent plastic bottle).
Slowly turn cap counterclockwise (left) until pressure begins to release.

3. Step back while the pressure releases.

4. When you are sure that all the pressure has been released, use the
cloth to turn it counterclockwise and remove the cap.

5. Fill the coolant reservoir slowly with the proper coolant mixture, to
within the COLD FILL RANGE or the FULL COLD level on the reservoir.
If you removed the radiator cap in an overflow system, fill the radiator
until the coolant is visible and radiator is almost full.

6. Replace the cap. Turn until tightly installed. Cap must be tightly
installed to prevent coolant loss.

After any coolant has been added, check the coolant concentration (refer
to Checking engine coolant). If the concentration is not 50/50
(protection to –34°F/–36°C), drain some coolant and adjust the
concentration. It may take several drains and additions to obtain a 50/50
coolant concentration.

Whenever coolant has been added, the coolant level in the coolant
reservoir should be checked the next few times you drive the vehicle. If
necessary, add enough 50/50 concentration of engine coolant and
distilled water to bring the liquid level to the proper level.

If you have to add more than 1.0 quart (1.0 liter) of engine coolant per
month, have your authorized dealer check the engine cooling system.
Your cooling system may have a leak. Operating an engine with a low
level of coolant can result in engine overheating and possible engine
damage.

Recycled engine coolant

Ford Motor Company does NOT recommend the use of recycled engine
coolant since a Ford-approved recycling process is not yet available.

Maintenance and Specifications

351

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

Used engine coolant should be disposed of in an appropriate

manner. Follow your community’s regulations and standards for recycling
and disposing of automotive fluids.

Coolant refill capacity

To find out how much fluid your vehicle’s cooling system can hold, refer
to Maintenance product specifications and capacities in this chapter.

Fill your engine coolant reservoir as outlined in Adding engine coolant
in this section.

Severe climates

If you drive in extremely cold climates (less than –34°F [–36°C]):
• It may be necessary to increase the coolant concentration

above 50%.

• NEVER increase the coolant concentration above 60%.
• Increased engine coolant concentrations above 60% will

decrease the overheat protection characteristics of the engine
coolant and may cause engine damage.

• Refer to the chart on the coolant container to ensure the

coolant concentration in your vehicle will provide adequate
freeze protection at the temperatures in which you drive in the
winter months.

If you drive in extremely hot climates:
• It is still necessary to maintain the coolant concentration

above 40%.

• NEVER decrease the coolant concentration below 40%.
• Decreased engine coolant concentrations below 40% will

decrease the corrosion protection characteristics of the engine
coolant and may cause engine damage.

• Decreased engine coolant concentrations below 40% will

decrease the freeze protection characteristics of the engine
coolant and may cause engine damage.

• Refer to the chart on the coolant container to ensure the

coolant concentration in your vehicle will provide adequate
protection at the temperatures in which you drive.

Vehicles driven year-round in non-extreme climates should use a 50/50
mixture of engine coolant and distilled water for optimum cooling system
and engine protection.

Maintenance and Specifications

352

2010 Mountaineer (mnt)
Owners Guide (own2002), 1st Printing
USA (fus)

Content .. 20 21 22 23 ..
