STEERING WHEEL CONTROLS

Radio control features

Press MEDIA to select:
• AM, FM1, FM2, or CD
• SAT1, SAT2 or SAT3 (Satellite

Radio mode).

• LINE IN (Auxiliary input jack)

In Radio mode:

• Press

to access the

next/previous preset station.

In CD mode:

• Press

to listen to the

next track on the disc.

In Satellite radio mode:

• Press

to advance

through preset channels.

In any mode:
• Press VOL + or VOL - to adjust

the volume.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

SYNC system hands free control
features

Press

briefly to use the voice

command feature. You will hear a
tone and LISTENING will appear in
the radio display. Press and
hold

to exit voice command.

Press

to activate phone mode or

answer a phone call. Press VOL + or
− to adjust volume. Press and
hold

to end a call or exit phone mode.

Press

to scroll through various menus and selections. Press

OK to confirm your selection.

For further information on the SYNC system, refer to the SYNC
supplement.

Navigation system/SYNC hands
free control features (if
equipped)

Press

control briefly until the

voice

icon appears on the

Navigation display to use the voice
command feature.

Press

to activate phone mode or

answer a phone call. Press VOL + or
− to adjust volume. Press and
hold

to exit phone mode or end a call.

For further information on the Navigation system/SYNC system, refer to
the Navigation and SYNC supplements.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

MOON ROOF (IF EQUIPPED)

You can move the glass panel of the moon roof back to open or tilt up
(from the closed position) to ventilate the vehicle.

WARNING: Do not let children play with the moon roof or leave
children unattended in the vehicle. They may seriously hurt

themselves.

To open the moon roof:

The moon roof is equipped with an
automatic, one-touch, express
opening, closing and venting feature.
Press and release the rear portion of
the control. To stop motion at any
time during the one-touch
operation, press the control a
second time.

WARNING: When closing the moon roof, you should verify that
it is free of obstructions and ensure that children and/or pets are

not in the proximity of the moon roof opening.

To close the moon roof:

The moon roof is equipped with an automatic, one-touch, express closing
feature. Press and release the front portion of the control. To stop
motion at any time during the one-touch closing, press the control again.

Bounce-back:

When an obstacle has been detected in the moon roof opening as the
moon roof is closing, the moon roof will automatically open and stop at a
prescribed position. This is known as “bounce-back”. If the ignition is
turned off (without accessory delay being active) during bounce-back,
the moon roof will move until the bounce-back position is reached.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Bounce-back override:

To override bounce-back, press and hold the front portion of the control.
For example: Bounce-back can be used to overcome the resistance of ice
on the moon roof or seals. If during a bounce-back condition, the control
is released to the neutral position, then held in the one-touch position
within two seconds after the moon roof reaches the bounce-back
position, the moon roof will travel with no bounce-back protection.
If the control is released before the moon roof reaches fully closed or the
ignition is turned off (without accessory delay being active), the moon
roof will stop. Security override can be used if the moon roof movement
is restricted in some way, for example, if there is ice on the moon roof or
seals.

To vent:
• To tilt the moon roof into the vent position (when the glass panel is

closed), press and release the front portion of the control.

• To close the moon roof from the vent position, press and hold the rear

portion of the control until the glass panel stops moving.

The moon roof has a sliding shade that can be opened or closed when
the glass panel is shut. To close the shade, pull it toward the front of the
vehicle

Accessory delay:

With accessory delay, the window switches, audio system, and moon roof
(if equipped) may be used for up to 10 minutes after the ignition switch
is turned off or until any door is opened

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

100

POSITIVE RETENTION FLOOR MAT

WARNING: Do not install additional floor mats on top of the
factory installed floor mats as they may interfere with the

accelerator or the brake pedals.

Position the floor mat so that the
eyelet is over the pointed end of the
retention post. Make sure that the
mat does not interfere with the
operation of the accelerator or the
brake pedal. To remove the floor
mat, reverse the installation
procedure.

INTERIOR TRUNK CONTROL

Press the remote trunk release
control on the instrument panel to
the left of the steering wheel.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

101

KEYS

Your vehicle is equipped with two
Integrated Keyhead Transmitters
(IKTs). The IKT functions as both a
programmed ignition key that
operates all the locks and starts the
vehicle, and a remote entry
transmitter.

Your IKTs are programmed to your vehicle; using a non-programmed key
will not permit your vehicle to start. If you lose your authorized dealer
supplied IKTs, replacement IKTs are available through your authorized
dealer. Standard SecuriLock™ keys without remote entry transmitter
functionality can also be purchased from your authorized dealer if
desired.

Always carry a spare key with you in case of an emergency.

For more information regarding programming replacement IKTs, refer to
the SecuriLock™ passive anti-theft system section later in this chapter.

Note: Your vehicle’s IKTs were
issued with a security label on them
that provides important vehicle key
cut information. It is recommended
that you maintain the label in a safe
place for future reference, such as
the inside front cover of this
Owner’s Guide.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

102

Recommended handling of the Integrated Keyhead Transmitter (IKT)

To avoid inadvertently activating the remote entry functions of your
vehicle, it is recommended that the Integrated Keyhead Transmitter
(IKT) be handled properly when starting and turning off your vehicle.

When inserting the IKT into the
ignition cylinder, place your thumb
on the center thumb rest of the IKT
and forefinger on the logo badge on
the opposite side.

To gain more leverage when rotating
the IKT in the ignition lock cylinder,
you can readjust the location of
your thumb to grasp the IKT on the
outer edge next to the

control.

Likewise, when rotating the IKT to
the off position in the ignition lock
cylinder, the bottom edge of the IKT
adjacent to the

control can be

utilized.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

103

POWER DOOR LOCKS
• Press the

control to unlock all

doors.

• Press the

control to lock all

doors.

Smart locks

This feature attempts to help prevent you from locking yourself out of
the vehicle if your key is still in the ignition.

When you open one of the front doors and you lock the vehicle with the
power door lock control (on the driver or passenger door trim panel), all
the doors will lock, then all doors will automatically unlock reminding
you that your key is still in the ignition.

The vehicle can still be locked, with the key in the ignition, using the
manual lock control on the door, locking the driver’s door with a key, or
using the lock control on the remote entry transmitter portion of your
Integrated Keyhead Transmitter.

If both front doors are closed, the vehicle can be locked from any
method, regardless of whether the key is in the ignition or not.

Autolock feature

The autolock feature will lock all the doors when:
• all the doors are closed,
• the ignition is in the on position,
• you shift into any gear putting the vehicle in motion, and
• the vehicle attains a speed greater than 12 mph (20 km/h).
The autolock feature repeats when:
• any door is opened then closed while the ignition is in the on position

and the vehicle speed is 9 mph (15 km/h) or lower, and

• the vehicle then attains a speed greater than 12 mph (20 km/h).
Note: The autolock feature is not available on vehicles equipped with a
manual transmission

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

104

Deactivating/activating autolock feature

Your vehicle comes with the autolock features activated; there are four
methods to enable/disable this feature:
• Through your authorized dealer,
• by using a power door unlock/lock sequence, or
• by using the keyless entry pad (if equipped).
• by using the instrument cluster message center. Refer to Message

center in the Instrument Cluster chapter.

Note: The autolock feature can be activated/deactivated independently
of the autounlock feature.

Before starting, ensure the ignition is in the off position and all vehicle
doors are closed. You must complete Steps 1–5 within 30 seconds or the
procedure will have to be repeated. If the procedure needs to be
repeated, wait a minimum of 30 seconds before beginning again.

1. Place the key in the ignition and
turn the ignition to the on position.

2. Press the power door unlock
control on the door panel three
times.

3. Turn the ignition from the on
position to the off position.

4. Press the power door unlock control on the door panel three times.

5. Turn the ignition back to the on position. The horn will chirp one time
to confirm programming mode has been entered and is active.

6. To enable/disable the autolock feature, press the unlock control, then
press the lock control. The horn will chirp once if autolock was
deactivated or twice (one short and one long chirp) if autolock was
activated.

7. Turn the ignition to the off position. The horn will chirp once to
confirm the procedure is complete.

Keyless entry keypad procedure

1. Turn the ignition to the 1 off
position.

2. Close all the doors.

3. Enter factory–set 5–digit entry
code.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

105

4. Press and hold the 3

• 4. While holding the 3 • 4 press the 7 • 8.

5. Release the 7

• 8.

6. Release the 3

• 4.

The user should receive a horn chirp to indicate the system has been
disabled or a chirp followed by a honk to indicate the system has been
enabled.

Autounlock feature

The autounlock feature will unlock all the doors when:

• the ignition is in the on position, all the doors are closed, and the

vehicle has been in motion at a speed greater than 12 mph (20 km/h);

• the vehicle has then come to a stop and the ignition is turned to the

off or accessory position; and

• the driver door is opened within 10 minutes of the ignition being

transitioned to the off or accessory position.

Note: The doors will not autounlock if the vehicle has been
electronically locked before the driver door is opened.

Note: The autounlock feature is disabled on vehicles equipped with a
manual transmission.

Deactivating/activating autounlock feature

Your vehicle comes with the autounlock features activated; there are four
methods to enable/disable this feature:
• Through your authorized dealer,
• by using a power door unlock/lock sequence, or
• by using the keyless entry keypad (if equipped) or
• by using the instrument cluster message center. Refer to Message

center in the Instrument Cluster chapter.

Note: The autounlock feature can be activated/deactivated
independently of the autolock feature.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

106

1. Place the key in the ignition and
turn the ignition to the on position.

2. Press the power door unlock
control on the door panel three
times.

3. Turn the ignition from the on
position to the off position.

4. Press the power door unlock control on the door panel three times.

5. Turn the ignition back to the on position. The horn will chirp one time
to confirm programming mode has been entered and is active.

6. To enable/disable the autounlock feature, press the lock control, then
press the unlock control. The horn will chirp once if autounlock was
deactivated or twice (one short and one long chirp) if autounlock was
activated.

7. Turn the ignition to the off position. The horn will chirp once to
confirm the procedure is complete.

Keyless entry keypad procedure

1. Turn the ignition to the 1 off
position.

2. Close all the doors.

3. Enter factory–set 5–digit entry
code.

4. Press and hold the 3

• 4. While holding the 3 • 4, press and release

the 7

• 8. While still holding the 3 • 4, press and release the 7 • 8 a

second time.

5. Release the 3

• 4.

The user should receive a horn chirp to indicate the system has been
disabled or a chirp followed by a honk to indicate the system has been
enabled.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

107

CHILDPROOF DOOR LOCKS
• When these locks are set, the

rear doors cannot be opened from
the inside.

• The rear doors can be opened

from the outside when the doors
are unlocked.

The childproof locks are located on
rear edge of each rear door and
must be set separately for each
door. Setting the lock for one door
will not automatically set the lock for both doors.
• Insert the key and turn to the lock position (key at an angle) to

engage the childproof locks.

• Insert the key and turn to the unlock position (key horizontal) to

disengage the childproof locks.

INTERIOR LUGGAGE COMPARTMENT RELEASE

Your vehicle is equipped with a mechanical interior luggage compartment
release handle that provides a means of escape for children and adults in
the event they become locked inside the luggage compartment.

Adults are advised to familiarize themselves with the operation and
location of the release handle.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

108

To open the luggage compartment
door (lid) from within the luggage
compartment, pull the illuminated
“T” shaped handle and push up on
the trunk lid. The handle is
composed of a material that will
glow for hours in darkness following
brief exposure to ambient light.

The “T” shaped handle will be
located either on the luggage
compartment door (lid) or inside
the luggage compartment near the
tail lamps.

WARNING: Keep vehicle
doors and luggage

compartment locked and keep
keys and remote transmitters out
of a child’s reach. Unsupervised
children could lock themselves in
the trunk and risk injury. Children
should be taught not to play in
vehicles.

WARNING: Do not leave children, unreliable adults, or animals
unattended in the vehicle. On hot days, the temperature in the

trunk or vehicle interior can rise very quickly. Exposure of people or
animals to these high temperatures for even a short time can cause
death or serious heat-related injuries, including brain damage. Small
children are particularly at risk.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

109

REMOTE ENTRY SYSTEM

The Integrated Keyhead Transmitter (IKT) complies with part 15 of the
FCC rules and with RSS-210 of Industry Canada. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

The typical operating range for your IKT is approximately 33 feet
(10 meters). A decrease in operating range could be caused by:
• weather conditions,
• nearby radio towers,
• structures around the vehicle, or
• other vehicles parked next to your vehicle.
The IKT allows you to:
• remotely unlock the vehicle

doors.

• remotely lock all the vehicle

doors.

• remotely open the trunk.
• activate the personal alarm.
• arm and disarm the perimeter

anti-theft system.

• operate the illuminated entry

feature.

The remote entry lock/unlock feature operates in any ignition position
except while the key is held in the start position. The panic feature
operates with the key in the off position.

If there are problems with the remote entry system, make sure to take
ALL Integrated Keyhead Transmitters with you to the authorized
dealer in order to aid in troubleshooting the problem.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

110

Unlocking the doors/two stage unlock

1. Press

and release to unlock the driver’s door. Note: The interior

lamps will illuminate.

2. Press

and release again within five seconds to unlock all the doors.

The remote entry system activates the illuminated entry feature; this
feature turns on the lamps for 25 seconds or until the ignition is turned
to the on position.

The inside lights will not turn off if:
• they have been turned on using the dimmer control or
• any door is open.
The battery saver feature will turn off the interior lamps 30 minutes after
the ignition is turned to the off position.

Two stage unlocking may be disabled or re-enabled by simultaneously
pressing the

and

controls on the IKT for four seconds (disabling

two stage unlock allows all vehicle doors to unlock simultaneously). The
turn lamps will flash twice to indicate that two-stage unlock was enabled
or disabled.

Locking the doors

1. Press

and release to lock all the doors. The turn lamps will flash.

2. Press

and release again within three seconds to confirm that all

the doors are closed. Note: The doors will lock again, the horn will chirp
and the turn lamps will flash once if all the doors and trunk are closed.

Note: If any door or the trunk is not closed, or if the hood is not closed
in vehicles equipped with the perimeter alarm feature, the horn will
chirp twice and the lamps will not flash.

Car finder

Press

twice within three seconds. The horn will chirp and the turn

lamps will flash. It is recommended that this method be used to locate
your vehicle, rather than using the panic alarm.

Sounding a panic alarm

Press

to activate the alarm. The horn will sound and the turn lamps

will flash for a maximum of three minutes. Press again or turn the
ignition to the on position to deactivate, or wait for the alarm to time out
in three minutes.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

111

Note: The panic alarm will only operate when the ignition is in the off
position.

Opening the trunk

Press

twice within three seconds to open the trunk.

• Ensure that the trunk is closed and latched before driving your

vehicle. Failure to properly latch the trunk may cause objects to fall
out or block the driver’s rear view.

Replacing the battery

The Integrated Keyhead Transmitter uses one coin type three-volt
lithium battery CR2032 or equivalent.

To replace the battery:

1. Twist a thin coin in the slot of the
IKT near the key ring in order to
remove the battery cover.

2. Do not wipe off any grease on the
battery terminals on the back
surface of the circuit board.

3. Remove the old battery.
Note: Please refer to local
regulations when disposing of
transmitter batteries.

4. Insert the new battery. Refer to the instructions inside the IKT for the
correct orientation of the battery. Press the battery down to ensure that
the battery is fully seated in the battery housing cavity.

5. Snap the battery cover back onto the key.

Note: Replacement of the battery will not cause the IKT to become
deprogrammed from your vehicle. The IKT should operate normally after
battery replacement.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

112

Mercury Milan Hybrid (2010 year). Manual - part 7
