Mercury Montego (2007 year). Manual

7. A/C: Press to activate/deactivate air conditioning. Use with
recirculated air to improve cooling performance and efficiency. Engages
automatically in AUTO, defrost and floor/defrost.

8. Airflow direction control: Press to toggle through the air
distribution modes listed below. The selected mode will be shown in the
display.

: Distributes air through the instrument panel and center console

vents (if equipped).

: Distributes air through the instrument panel, floor and center

console vents (if equipped).

: Distributes air through the floor vents. Note: You may notice a

small amount of air flowing from the demister and defroster vents.

: Distributes air through the windshield defroster, demister and floor

vents.

9. Manual override controls: Allows you to manually select where
airflow is directed. To return to full automatic control, press AUTO.

10.

Driver heated seat control: Press to heat the driver seat. Press

once to activate high heat (two indicator lights). Press again to activate
low heat (one indicator light). Press again to deactivate the driver
heated seat. Note: The heated seat feature will remain on for
approximately ten minutes.

11.

Front fan speed control: Press to manually increase or

decrease the fan speed. To return to automatic fan operation, press
AUTO.

12. EXT: Press to display outside temperature. Press again to display
cabin temperature settings.

13. F/C (Temperature conversions): Press to switch temperature
display between ° Fahrenheit and ° Celsius.

14. OFF: Outside air is shut out and the climate control system is turned
off.

15. Driver temperature control: Press to increase/decrease the
temperature on the driver side of the cabin. Sets the passenger side
temperature also when DUAL is disengaged. The recommended vehicle
cabin setting is between 72°F (22°C) and 75°F (24°C).

16. AUTO: Press to engage automatic temperature control. Select the
desired temperature using the temperature control. The system will
automatically determine fan speed, airflow location, A/C on or off, and
outside or recirculated air, to heat or cool the vehicle to reach the
desired temperature.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Climate Controls

Operating tips
• To reduce fog build up on the windshield during humid weather, place

the air flow selector in the

position.

• To reduce humidity build up inside the vehicle: do not drive with the

airflow selector in the OFF or with recirculated air engaged.

• Do not put objects under the front seats that will interfere with the

airflow to the back seats.

• Remove any snow, ice or leaves from the air intake area at the base of

the windshield.

• For maximum cooling performance (MAX A/C):
In AUTO mode, press AUTO control and set to desired temperature.

In manual override control, select

, A/C and recirculated

air

and set the temperature to 60°F (16°C). Set the fan to the

highest speed initially, then adjust to maintain passenger comfort.
• To improve the A/C cool down, drive with the windows slightly open

for 2–3 minutes after starting the vehicle or until the vehicle has
“aired out.”

In extremely cold temperatures, to maximize overall heater performance
it is suggested to not operate the auxiliary system (if so equipped) until
the engine temperature gauge crosses into the normal operating range.

To aid in side window defogging/demisting in cold weather:

1. Select

2. Select A/C.

3. Adjust the temperature control to maintain comfort.

4. Set the fan to the highest speed.

5. Direct the outer instrument panel vents towards the side windows.

Do not place objects on top of the instrument panel as these
objects may become projectiles in a collision or sudden stop.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Climate Controls

REAR WINDOW DEFROSTER

The rear defroster control is located on the climate control panel and
works to clear the rear window of fog and thin ice.

The ignition must be in the 3 (RUN) position to operate the rear window
defroster.

The rear defroster turns off automatically after 10 minutes or when the
ignition is turned to the 1 (LOCK) position. To manually turn off the
defroster before 10 minutes have passed, push the control again.

Do not use razor blades or other sharp objects to clean the inside
of the rear window or to remove decals from the inside of the
rear window. This may cause damage to the heated grid lines and
will not be covered by your warranty.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Climate Controls

HEADLAMP CONTROL

Turns the lamps off.

Turns on the parking lamps,

instrument panel lamps, license
plate lamps and tail lamps.

Turns the headlamps on.

Autolamp control (if equipped)

The autolamp system provides light
sensitive automatic on-off control of
the exterior lights normally
controlled by the headlamp control.
• To turn autolamps on, rotate the

control counterclockwise to

• To turn autolamps off, rotate the

control clockwise to

The autolamp system also keeps the
lights on for a predetermined
amount of time after the ignition switch is turned to LOCK. You can
change the amount of time the lamps stay on by using the programming
procedure that follows:

Autolamps - Programmable exit delay

Programmable exit delay allows the length of the autolamp exit delay to
be changed.

To program the auto lamp exit time delay:

1. Start with the ignition in the LOCK position and the headlamp control
in the autolamp position.

2. Turn the headlamp switch to

3. Turn the ignition switch to RUN and then back to LOCK.

4. Turn the headlamp switch to the autolamp position. The headlamps
will turn on.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

5. Wait the desired amount of time for the exit delay you want (up to
three minutes), then turn the headlamp switch to

. The headlamps

will turn off.

Foglamp control (if equipped)

With the ignition on, the foglamps
can be turned on when the
headlamp control is pulled toward
you and is in any of the following
positions:
• Parking lamps
• Low beams
• Autolamps (when active)
The foglamps will not operate when
the high beams are active.

High beams

Pull the lever towards you, to the
second detent, to activate. Pull the
lever towards you again to
deactivate.

Flash to pass

Pull toward you, to the first detent,
to activate and release to deactivate.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

Daytime running lamps (DRL) (if equipped)

Turns the headlamps on with a reduced output.

To activate:
• the ignition must be in the ON position,
• the headlamp control is in the OFF, autolamps or parking lamp

position and

• the transmission must be out of the Park position.

Always remember to turn on your headlamps at dusk or during
inclement weather. The Daytime Running Lamp (DRL) system

does not activate the tail lamps and generally may not provide
adequate lighting during these conditions. Failure to activate your
headlamps under these conditions may result in a collision.

PANEL DIMMER CONTROL

Use to adjust the brightness of the
instrument panel and all applicable
switches in the vehicle during
headlamp and parklamp operation.

Move the control to the full upright
position, past detent, to turn on the
interior lamps.

AIMING THE HEADLAMPS

The headlamps on your vehicle are properly aimed at the assembly plant.
If your vehicle has been in an accident the alignment of your headlamps
should be checked by your authorized dealer.

Vertical aim adjustment

1. Park the vehicle directly in front of a wall or screen on a level surface,
approximately 25 feet (7.6 meters) away.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

• (1) 8 feet (2.4 meters)
• (2) Center height of lamp to

ground

• (3) 25 feet (7.6 meters)
• (4) Horizontal reference line
2. Measure the height of the
headlamp bulb center from the
ground and mark an 8 foot (2.5
meter) horizontal reference line on
the vertical wall or screen at this
height (a piece of masking tape works well).

3. Turn on the low beam headlamps to illuminate the wall or screen and
open the hood.

To see a clearer light pattern for adjusting, you may want to block the
light from one headlamp while adjusting the other.

4. On the wall or screen you will
observe an area of high intensity
light. The top of the high intensity
area should touch the horizontal
reference line, if not, the beam will
need to be adjusted using the next
step.

5. Locate the vertical adjuster on
each headlamp. Using a Phillips #2
screwdriver, turn the adjuster either
clockwise (to adjust down) or
counterclockwise (to adjust up).
The horizontal edge of the brighter
light should touch the horizontal
reference line.

6. Close the hood and turn off the
lamps.

HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS
NON-ADJUSTABLE.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

TURN SIGNAL CONTROL
• Push down to activate the left

turn signal.

• Push up to activate the right turn

signal.

INTERIOR LAMPS

Dome lamps and map lamps

The map lamps are located on the
overhead console. Press the controls
on either side of each map lamp to
turn on the lamps.

Your vehicle may also have reading
lamps within the rear dome lamp(s).

Press the switches on either side of
the dome lamp to turn on the
lamps.

BULB REPLACEMENT

Headlamp Condensation

The headlamps are vented to equalize pressure. When moist air enters
the headlamp(s) through the vents, there is a possibility that
condensation can occur. This condensation is normal and will clear
within 45 minutes of headlamp operation.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

Using the right bulbs
Replacement bulbs are specified in the chart below. Headlamp bulbs
must be marked with an authorized “D.O.T.” for North America and an
“E” for Europe to ensure lamp performance, light brightness and pattern
and safe visibility. The correct bulbs will not damage the lamp assembly
or void the lamp assembly warranty and will provide quality bulb burn
time.

Function

Number of bulbs

Trade

number

*Headlamp high beam

9005

*Headlamp low beam

D1R (HID)

Sidemarker lamp

194A

(amber)

Park/turn signal lamp

3157AK or

3157A

(amber)

*Stop/tail lamp

N/A

LED

Backup lamp

921

Rear turn signal lamp

3157A

(amber)

License plate lamp

168

*High-mount brake lamp

N/A

LED

Foglamp (if equipped)

9145 (H10)

Map lamp

12V6W

Dome/reading lamp

578

All replacement bulbs are clear in color except where noted.

To replace all instrument panel lights - see your authorized dealer.

*To replace these lamps - see your authorized dealer.

Replacing the interior bulbs
Check the operation of all bulbs frequently.

Replacing exterior bulbs
Check the operation of all the bulbs frequently.

Replacing headlamp bulbs
If either the low beam or high beam headlamp bulb fails, take
your vehicle to your authorized dealer to have it replaced.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

Replacing HID headlamp bulbs

The low beam headlamps on your vehicle use a “high intensity discharge”
source. These lamps operate at a high voltage. The bulb is NOT
replaceable. When the bulb is burned out, the bulb assembly must be
replaced by your authorized dealer.

Replacing front parking lamp/turn signal bulbs

1. Make sure headlamp switch is in the OFF position, then open the
hood.

2. Turn the front wheels inboard and loosen the three screws on the
splash shield in front of the tire.

3. Remove the bulb socket by
turning it counterclockwise and
pulling it straight out.

4. To remove the bulb, pull it
straight out of the bulb socket.

Install the new bulb(s) in reverse order.

Replacing front sidemarker bulbs

1. Make sure headlamp switch is in the OFF position, then open the
hood.

2. Turn the front wheels inboard and loosen the three screws on the
splash shield in front of the tire.

3. Locate the sidemarker lamp
electrical connector and remove it
by pulling it straight off.

4. Remove the bulb socket by
turning it counterclockwise and
pulling it straight out.

5. To remove the bulb, pull it
straight out of the bulb socket.

Install the new bulb(s) in reverse order.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

Replacing turn signal lamp/backup lamp bulbs

The backup lamp and turn signal lamp bulbs are located in the tail lamp
assembly. Follow the same steps to replace either bulb.

1. Turn signal lamp

2. Backup lamp

1. Make sure the headlamp switch is in the OFF position and open the
trunk.

2. Remove the cargo net fastener. Carefully pull the carpet away to
expose the backside of the tail lamp assembly.

3. Remove the nut and washer assemblies, then pull the lamp assembly
away from the vehicle.

4. Remove the bulb socket by
rotating it counterclockwise, then
pulling it out of the lamp assembly.

5. Pull the bulb straight from the
socket.

Install new bulb(s) in reverse order.

Replacing brake and tail lamp bulbs

These must be replaced by your authorized dealer.

Replacing high-mount brake lamp bulbs

This must be replaced by your authorized dealer.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

Replacing license plate lamp bulbs

1. Make sure the headlamp switch is
in the OFF position, then remove
the two screws and the license plate
lamp assembly.

2. Remove bulb socket by turning
counterclockwise.

3. Carefully pull the bulb out from
the socket.

Install new bulb(s) in reverse order.

Replacing foglamp bulbs

1. Make sure the foglamp switch is
in the OFF position.

2. Remove the bulb socket from the
foglamp by turning
counterclockwise.

3. Disconnect the electrical
connector.

Install the new bulb in reverse order.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Lights

MULTI-FUNCTION LEVER

Windshield wiper: For intermittent
operation, move control up one
position.

Adjust the rotary control to the
desired speed setting.

Mist function: To activate mist,
push control down from the OFF
position and release to get one wipe.

For normal or low speed wiper
operation, move control up two
positions from OFF.

For high speed wiper operation,
move control up three positions
from OFF.

Windshield washer: Pull the end
of the stalk towards you:
• briefly: causes a single swipe of

the wipers without washer fluid.

• a quick pull and hold: the wipers

will swipe three times with
washer fluid.

• a long pull and hold: the wipers and washer fluid will be activated for

up to ten seconds.

Note: Do not operate the washer when the washer reservoir is empty.
This may cause the washer pump to overheat. Check the washer fluid
level frequently. Do not operate the wipers when the windshield is dry.
This may scratch the glass, damage the wiper blades and cause the wiper
motor to burn out. Before operating the wiper on a dry windshield,
always use the windshield washer. In freezing weather, be sure the wiper
blades are not frozen to the windshield before operating the wipers.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Driver Controls

TILT STEERING WHEEL

To adjust the steering wheel:

1. Pull down and hold the steering
wheel release control.

2. Move the steering wheel up or
down until you find the desired
location.

3. Pull the steering wheel release
control up. This will lock the
steering wheel in position.

Never adjust the steering wheel when the vehicle is moving.

ILLUMINATED VISOR MIRROR

Lift the mirror cover to turn on the
visor mirror lamp. The visor will
slide back and forth on the rod for
increased sunlight coverage.

Slide on rod feature

Rotate the visor towards the side
window and extend it rearward for
additional sunlight coverage.

Note: To stow the visor back into
the headliner, visor must be
retracted before moving it back
towards the windshield.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Driver Controls

INSTRUMENT PANEL STORAGE COMPARTMENT

The storage compartment may be
used to secure sunglasses or similar
sized objects. Press the control to
open the storage compartment.

OVERHEAD CONSOLE

The appearance of your vehicle’s overhead console will vary according to
your option package.

Storage compartment

Press the latch to open the storage
compartment. The door will open
slightly and can be moved to full
open.

The storage compartment may be
used to secure sunglasses or a
similar object.

CLOCK (IF EQUIPPED)

Press and release the button to
adjust forward.

Press and hold to fast forward.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Driver Controls

CENTER CONSOLE

Your vehicle may be equipped with a
variety of console features. These
include:
• Utility compartment with power

point

• Gear Shift
• Cup holders
• Rear vent (if equipped)

Use only soft cups in the cupholder. Hard objects can injure you
in a collision.

AUXILIARY POWER POINT (12VDC)

Power outlets are designed for accessory plugs only. Do not insert
any other object in the power outlet as this will damage the
outlet and blow the fuse. Do not hang any type of accessory or
accessory bracket from the plug. Improper use of the power
outlet can cause damage not covered by your warranty.

The auxiliary power points are
located on the instrument panel and
in the center console utility
compartment.

Do not use the power point for
operating the cigarette lighter
element (if equipped).

To prevent the fuse from being
blown, do not use the power
point(s) over the vehicle capacity of
12 VDC/180W.

To prevent the battery from being discharged, do not use the power
point longer than necessary when the engine is not running.

Always keep the power point caps closed when not being used.

Cigar/Cigarette lighter (if equipped)

Do not plug optional electrical accessories into the cigarette lighter
socket.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Driver Controls

Mercury Montego (2007 year). Manual - part 4
