Ford Super Duty (2017 year). Manual - part 39

You can enable or disable this feature
through the information display. See
Information Displays (page 111).

REAR SEATS

Folding Up the Rear Seat Cushion

The rear seat has a split 60/40 cushion.
You can flip each seat cushion up into a
vertical storage position.

E181250

Rotate the seat cushion up until it locks
into the vertical storage position.

Cushion Lock (If Equipped)

The locking key is in the keyfob. See
Remote Control (page 54).

E224956

Turn the key to lock or unlock.

Returning the Seat to the Seating
Position

WARNING

Check under the seat cushion to
make sure no cargo or objects are
under the seat cushion before

returning the seat cushion to its original
position, and that the seat cushion locks
into place. Failure to do so may prevent
the seat from operating properly in the
event of a crash, which could increase the
risk of serious injury.

E166704

Pull the control on the bottom of the seat
cushion to release it from the storage
position.

159

HEATED SEATS

(If Equipped)

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must exercise care when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that insulates against
heat, such as a blanket or cushion. This
may cause the heated seat to overheat.
Do not puncture the seat with pins, needles
or other pointed objects. This may damage
the heating element which may cause the
heated seat to overheat. An overheated
seat may cause serious personal injury.

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

Note: The heated seats may remain on
after you remote start your vehicle, based
on your remote start settings. The heated
seats may also turn on when you start your
vehicle if they were on when you switched
your vehicle off.

Rear Heated Seats

(If Equipped)

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

The rear seat heat controls are on the rear
of the center console.

160

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

The heated seat module resets at every
ignition run cycle. While the ignition is in
the on position, press the heated seat
switch to enable heating mode. When
activated, they turn off automatically when
you switch off the engine.

CLIMATE CONTROLLED SEATS

(If Equipped)

Heated Seats

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

Note: After 60 minutes of operation, the
heated seats switch off. Press the heated
seat symbol to switch the heated seats on.

Cooled Seats

Note: The engine must be running to use
this feature.

E146309

161

Press the cooled seat symbol to cycle
through the various cool settings and off.
More indicator lights indicate cooler
settings.

Note: The cooled seats may remain on after
you remote start your vehicle, based on your
remote start settings. The heated seats may
also turn on when you start your vehicle if
they were on when you switched your
vehicle off.

Note: After 60 minutes of operation, the
cooled seats switch off. Press the cooled
seat symbol to switch the cooled seats on.

Climate Controlled Seat Air Filter
Replacement

The climate controlled seat system
includes air filters. You must replace them
periodically.

The filter is located under each front seat.
Access the filter from the second row
footwell area. Move the front seats all the
way to the full front and full up positions
to ease access.

E146319

To remove a filter:

Turn the vehicle off.

2. Push up on the outside rigid edge of

the filter until the tabs are released,
then remove the filter.

E146321

To install a filter:

First, position the filter in its housing
making sure that the far forward end
is all the way up in the housing.

2. Push in on the center of the outside

edge of the filter and rotate clockwise
into the housing until it clips into
position.

FRONT SEAT ARMREST

(If

Equipped)

E223578

Press the control to release the cushion
latch.

162
