Ford Galaxy / Ford S-MAX. Manual - part 385
Requirements: Stage IV, Removal and
Installation).
Turbocharger.
*
REFER to: Turbocharger (303-04G Fuel
Charging and Controls - Turbocharger - 2.0L
Duratorq-TDCi (DW) Diesel, Diagnosis and
Testing).
*
Slipping clutch (If
equipped).
*
REFER to: Manual Transaxle and Clutch (308-
00 Manual Transmission/Transaxle and Clutch -
General Information, Diagnosis and Testing).
*
Low cylinder
compression.
*
REFER to:
Engine
(303-01F Engine - 2.0L
Duratorq-TDCi (85kW/115PS) - DW/2.0L
Duratorq-TDCi (100kW/136PS) - DW/2.0L
Duratorq-TDCi (103kW/140PS) - DW, Emission
Requirements: Stage IV, Diagnosis and
Testing).
*
ECT sensor.
*
REFER to the WDS.
*
MAF sensor.
*
REFER to the WDS.
*
MAP sensor.
*
REFER to the WDS.
*
Fuel injector(s).
*
REFER to the WDS.
*
Intake air shut-off
throttle.
*
CHECK the intake air shut-off throttle butterfly
for obstructions and correct operation.
REFER to the WDS.
*
*
Intake air shut-off
throttle vacuum
control solenoid.
*
CHECK the intake air shut-off throttle vacuum
control solenoid vacuum lines for kinks or
restrictions.
REFER to the WDS.
*
*
Engine cuts out
during hard
acceleration
CMP sensor.
*
REFER to the WDS.
*
CKP sensor.
*
REFER to the WDS.
*
FRP sensor.
*
REFER to the WDS.
*
Fuel pump fuel
pressure regulator.
*
REFER to the WDS.
*
Fuel pump.
*
REFER to the WDS.
*
