Ford Ranger EV (2001 year). Manual - part 289

2001 RANGER ELECTRIC VEHICLE

150-119

CONNECTOR FACES

CIRCUIT FUNCTION

C2990

14401

STEERING WHEEL SENSOR

4

3

2

1

1

2

3

4

3226 (BK/LG)

3227 (RD)

3228 (BN)

295 (LB/PK)

Ground

Steering Wheel Sensor A" Signal

Steering Wheel Sensor B" Signal

Electronic Cluster Feed

PIN

CIRCUIT

CIRCUIT FUNCTION

C2991

WAĆ0397Ć2

POSITIVE TEMPERATURE COEFFICIENT (PTC)

OVER TEMPERATURE SWITCH

1

3036 (YE/WH)

PTC Reference Signal

PIN

CIRCUIT

CIRCUIT FUNCTION

C2992

WAĆ0397Ć2

POSITIVE TEMPERATURE COEFFICIENT (PTC)

OVER TEMPERATURE SWITCH

1

3037 (GY/WH)

Plenum Over Temperature

PIN

CIRCUIT

3

2

1

CIRCUIT FUNCTION

C2993

WAĆ0397Ć2

RECIRCULATION VACUUM PRESSURE SENSOR

1

2

3

3068 (BN/PK)

3067 (LB/RD)

3066 (OG/YE)

Ground

Vacuum Solenoid Sensor Signal

5V Power

PIN

CIRCUIT

2001 RANGER ELECTRIC VEHICLE

150-120

CONNECTOR FACES

1

2

3052 (YE/LG)

57 (BK)

Recirculation Vacuum Solenoid

Ground

C2994

PIN

CIRCUIT

CIRCUIT FUNCTION

RECIRCULATION VACUUM SOLENOID

WAĆ0397Ć2

1

2

3050 (WH/OG)

3060 (GY/RD)

InĆCar Temperature Sensor

Cabin Temperature Reference

C2997

PIN

CIRCUIT

CIRCUIT FUNCTION

INĆCAR TEMPERATURE SENSOR

14401

1

2

2

1

3837 (GY/YE)

3011 (BK/OG)

3012 (WH)

3010 (TN)

3013 (GY/BK)

3835 (YE/WH)

3836 (YE/LB)

-

3014(BK/WH)

3015 (WH/RD)

APS1 Ground

APS2 Ground

APS2 Signal

APS2 +5V Reference

APS3 +5V Reference

APS1 Signal

APS1 +5V Reference

NOT USED

APS3 Ground

APS3 Signal

A

B

C

D

E

F

G

H

J

K

C2995

PIN

CIRCUIT

CIRCUIT FUNCTION

ACCELERATION POSITION SENSOR (APS)

K

J

H

G

A

B

C

D

F

E

2001 RANGER ELECTRIC VEHICLE

150-121

CONNECTOR FACES

3054(BK/LG)

19 (LB/RD)

57 (BK)

3053 (BN/WH)

-

-

Fresh/Recirculation LED

Instrument Panel Lamps Feed

Ground

Fresh/Recirculation Switch

NOT USED

NOT USED

1

2

3

4

5

6

C2998

PIN

CIRCUIT

CIRCUIT FUNCTION

FRESH/RECIRCULATION SELECT SWITCH

1

2

3

4

5

6

2001 RANGER ELECTRIC VEHICLE

150-122

CONNECTOR FACES

C2999M

3068

(BN/PK)

3067

(LB/RD)

57

(BK)

3037

(GY/WH)

3066

(OG/YE)

3052

(YE/LG)

C2999F

1

4

3

2

1

WAĆ0397

3066

(OG/YE)

3068

(BN/PK)

3067

(LB/RD)

57

(BK)

14401

2

3

4

5

6

10

9

8

7

6

4

3

2

1

5

4

3

2

1

7

8

9

10

3052

(YE/LG)

3036

(YE/WH)

3037

(GY/WH)

3036

(YE/WH)

14B326ĆD

3133 (WH)

3132 (YE)

3134(OG)

3131 (RD)

C3985F

C3985M

3132 (YE)

14B326ĆC

3133 (WH)

3134(OG)

3131 (RD)
