2001 RANGER ELECTRIC VEHICLE

150-39

CONNECTOR FACES

C250

AIR BAG DIAGNOSTIC MODULE

14401

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

–

364 (BK/LG)
614 (GY/OG)
615 (GY/WH)
70 (LB/WH)
607 (LB/OG)
616 (PK/BK)
1112 (WH/LG)

1113 (YE/LG)

649 (BK/OG)

–
–

NOT USED
Power (Hot in Run)
Driver Air Bag
Driver Air Bag
Data Link Connector
Passenger Air Bag Module
Passenger Air Bag
Passenger Air Bag Deactivation (PAD)

Module

Passenger Air Bag Deactivation (PAD)

Module Illumination

Ground
NOT USED
NOT USED

1
2
3
4
5
6
7
8

9

10

11

12

PIN

CIRCUIT

CIRCUIT FUNCTION

364 (BK/LG)

–
–
–
–
–
–

608 (BK/YE)
649 (BK/YE)

–
–
–

619 (PK/WH)
183 (TN/YE)

Power (Hot in Run)
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
Warning Indicators
Ground
NOT USED
NOT USED
NOT USED
Crash Sensors
Generic Electronic Module (GEM)

13
14
15
16
17
18
19
20
21
22
23
24
25
26

PIN

CIRCUIT

CIRCUIT FUNCTION

2001 RANGER ELECTRIC VEHICLE

150-40

CONNECTOR FACES

57 (BK)

C252F

C252M

14401

14630/19A041

1

2

3

4

5

6

7

8

9

10

11

12

13

1415

16

1

2

3

4

6

7

9

11

15

14

16

13

5

12

8

10

805 (WH/LG)

761 (GY/RD)

57 (BK)

811 (DG/OG)

314(TN/LB)

542 (YE)

313 (WH/YE)

117 (PK/BK)

118 (PK/OG)

119 (PK/YE)

544 (PK)

120 (PK/LG)

543 (DG)

400 (LB/BK)

805 (WH/LG)

761 (GY/RD)

811 (DG/OG)

314(TN/LB)

542 (YE)

313 (WH/YE)

117 (PK/BK)

118 (PK/OG) 119 (PK/YE)

544 (PK)

120 (PK/LG)

543 (DG)

400 (LB/BK)

2001 RANGER ELECTRIC VEHICLE

150-41

CONNECTOR FACES

44 (LB)

378 (BN/YE)

-

385 (WH/RD)

2 (WH/RD)

-

-

3 (LG/WH)

511 (LG)

374(DB/WH)

1

2

3

4

5

6

7

8

9

10

Turn Signal Flasher, to Turn Signal

Switch

Trailer Tow Connector, Output

NOT USED

Voltage Supplied At All Times

(Overload Protected)

Turn Lamps, Feed, Right Front

NOT USED

NOT USED

Turn Lamps, Feed, Left Front

Brake Pedal Position Switch, to

Stoplamps

Trailer Tow Connector, Output

C253

PIN

CIRCUIT

CIRCUIT FUNCTION

MULTIFUNCTION SWITCH

14A320

6

5

1

4

8

9

2

3

7

10

684(PK/YE)

15 (RD/YE)

13 (RD/BK)

359 (GY/RD)

632 (GY/OG)

680 (LB/OG)

196 (DB/OG)

1

2

3

4

5

6

7

Wiper/Washer, Input

Power (Hot with Headlamps On)

Power (Hot with Low Beams On)

Signal, Return

Power (Hot with High Beams On)

Wiper/Washer, Delay Input

Voltage Supplied At All Times

(Overload Protected)

C254

PIN

CIRCUIT

CIRCUIT FUNCTION

MULTIFUNCTION SWITCH

14A320

6

4

1

2

3

5

7

2001 RANGER ELECTRIC VEHICLE

150-42

CONNECTOR FACES

1

2

3

4

5

6

-

-

1112 (WH/LB)

649 (BK/OG)

364(BK/LG)

1113 (YE/LG)

NOT USED

NOT USED

Passenger Air Bag Diagnostic (PAD)

Module

Ground

Power (Hot in Run)

Passenger Air Bag Deactivation Module

Illumination

C256

PIN

CIRCUIT

CIRCUIT FUNCTION

PASSENGER AIR BAG DEACTIVATION (PAD) SWITCH

14401

1

2

3

4

5

6

A (YE/RD)

383 (RD/WH)

-

57 (BK)

-

-

-

378 (BN/YE)

1

2

3

4

5

6

7

8

Hazard Flasher Relay Control

Power (Hot At All Times)

NOT USED

Ground

NOT USED

NOT USED

NOT USED

Rear Hazard Only Relay Control

C257

PIN

CIRCUIT

CIRCUIT FUNCTION

HAZARD SWITCH

14401

5

1

6

2

7

3

8

4
