2001 RANGER ELECTRIC VEHICLE
54-7
AIR CONDITIONER/HEATER
A/C INVERTER
MOTOR CONTROLLER
(IMC)
3152
DG
3153
WH
3154
BK
C1902
A/C
COMPRESSOR
POWER DISTRIBUTION
(HIGH VOLTAGE)
PAGE 13Ć32
3150
DB
3151
WH
A
B
C
WARNING: This system contains highĆvoltage
componentsand wiring. Do not attempt any
service procedures without direction from the
workshop manual. Failure to follow this
warning may result in severe personal injury
or death.
EXCEPT POSTAL
M
+
-
Z
Y
X
H. V INPUT
Refer to Location Index, Cell 152, for Component,
Connector, Splice, Ground and Base Part Number
descriptions and locations.
