Ford Ranger EV (2001 year). Manual - part 223
2001 RANGER ELECTRIC VEHICLE
13-33
POWER DISTRIBUTION (HIGH VOLTAGE)
UPPER
BATTERY
HEATER
3709
RD
57
BK
C1861
57
BK
LOWER
BATTERY
HEATER
57
BK
C1863
1201
DB/WH
C1862
1161
DB/OG
C
B
A
D
E
C1864
3403
OG
3403
OG
250A
0V
TRACTION
BATTERY
FUSE
TRACTION BATTERY PACK
PAGES 16Ć6, 16Ć7
SEE TRACTION
BATTERY SYSTEM
PAGES 16Ć6, 16Ć7
CONTACTOR
BOX
PAGE 16Ć11
TRACTION
BATTERY
SUPPORT
TRAY
3134 OG
3134 OG
H
3133 WH
3133 WH
I
3131 RD
3131 RD
J
K
C3985
C1935
3132
YE
3134
OG
3132
YE
3132
YE
3133 WH 3131 RD
3180
OG
3180
OG
3181
OG
3181
OG
C3994
TRACTION
INVERTER
MODULE (TIM)
PAGE 26Ć4
TO HIGH VOLTAGE POWER
DISTRIBUTION BOX (HVPDB)
PAGE 13Ć32
C1859
+312V
S1954
WITH
LEAD
ACID
BATTERY
HEATERS
WARNING: This system contains highĆvoltage
componentsand wiring. Do not attempt any
service procedures without direction from the
workshop manual. Failure to follow this
warning may result in severe personal injury
or death.
+
3410
YE
3410
YE
C1982
C1980
INTERLOCK
PAGE 20Ć1
EMERGENCY
POWER OFF
(EPO)/
INTERLOCK
SYSTEM
PAGE 20Ć1
974
OG
6
