Ford Ranger EV (2001 year). Manual - part 207
20A
DASHED
COMPONENT
BOX
ONLY PART OF THE
COMPONENT IS SHOWN
ON THE PAGE; THE
COMPONENT IS SHOWN
COMPLETE IN ANOTHER
LOCATION
COMPONENT
WITH
CONNECTORS
SCREW TERMINAL
ON COMPONENT
SOLID STATE
SEALED
ELECTRONIC
COMPONENT
ANY CIRCUITRY
SHOWN INSIDE THE
BOX IS A FUNCTIONAL
EQUIVALENT ONLY
AND IS NOT EXACT
GROUND
CONNECTION
BATTERY
14 GA DG
FUSIBLE LINK
63
RD
981
RD/WH
SOLID WIRES
STRIPED WIRES
FUSE
CURRENT
RATING
CIRCUIT
BREAKER
CURRENT
RATING
MAXI-FUSE
or
FUSIBLE LINK
CARTRIDGE
CURRENT RATING
WIRE SIZE AND COLOR
S100
SPLICE OR
CRIMP
TERMINAL
REVERSING
LAMPS
“REFERENCE”
WIRES
COMPLETE WIRING
SHOWN ON
ANOTHER PAGE
FROM
POWER
“CUT” WIRES
REFERENCED
BETWEEN PAGES
ARROWS SHOW
CURRENT FLOW
FROM POWER
TO GROUND
ALTERNATE
CIRCUIT
PATHS
MANUAL
TRANSMISSION
C305F
A
A
+
–
30A
20A
TO
LOAD
AUTOMATIC
TRANSMISSION
C305M
C305M
2001 ELECTRIC RANGER VEHICLE
2-7
HOW TO USE THIS MANUAL
ELECTRICAL SYMBOLS
