Ford Fiesta (2011 year). Manual

16. N O T E : This step is only necessary when

installing a new component.

Torque: 55 Nm

E99063

17. WARNING: Make sure that new bolts are

installed.

NOTE: This step is only necessary when
installing a new component.

Torque: 101 Nm

E103376

Installation

1. To install, reverse the removal procedure.

Refer to: Front Toe Adjustment (204-00

Suspension System - General Information,
General Procedures).

G1062441en

502-00-

Uni-Body, Subframe and Mounting System

502-00-

REMOVAL AND INSTALLATION

201

Supplemental Restraint System (SRS) Health and Safety

Precautions

WARNINGS:

Only qualified technicians are allowed to
work on pyrotechnic components.

INHALED: Exposure to pyrotechnic residue
may cause low blood pressure, severe
headache, irritation of mucous membranes,
fainting, shortness of breath or rapid pulse.
Move a victim to fresh air. Seek immediate
medical attention.

EYE CONTACT: Exposure to unburned
pyrotechnic residue may cause irritation,
burning and etching of the eyes. Flush
immediately with plenty of cold running
water for at least 15 minutes. Seek
immediate medical attention.

EYE CONTACT: Exposure to burned
pyrotechnic residue may cause irritation,
burning and etching of the eyes. Flush
immediately with diluted boric acid
solution. Seek immediate medical
attention.

SKIN CONTACT: Unburned pyrotechnic
residue may be rapidly absorbed through
the skin in toxic quantities. Wash
immediately with plenty of soap and water.
Seek medical attention.

SKIN CONTACT: Burned pyrotechnic
residue may be rapidly absorbed through
the skin in toxic quantities. Wash with
plenty of water. Do not use soap. Seek
medical attention.

SWALLOWED: Unburned pyrotechnic
residue is extremely toxic. If conscious
drink plenty of water then induce vomiting.
Seek immediate medical attention. If
unconscious, or in convulsions do not
attempt to induce vomiting or give
anything by mouth. Seek immediate
medical attention.

SWALLOWED: Burned pyrotechnic residue
is extremely toxic. Drink plenty of water
and seek immediate medical attention.

The deployment key must only be
accessible to authorized personnel.

Make sure that the deployment key remains
removed from the deployment equipment
except during deployment.

If permenantly disabling or enabling the
passenger air bag a new seat belt for
vehicles without or with a passenger air
bag must be installed.

Undeployed pyrotechnic components must
not be deployed in the vehicle.

Pyrotechnic components must be deployed
following local regulations.

Check thoroughly that no loose objects
can be spread during the deployment of
pyrotechnic components.

Pyrotechnic components must be
transported following local regulations.

Never carry out any electrical measurement
on disconnected, undeployed pyrotechnic
components.

Pyrotechnic components must not be
disassembled.

Pyrotechnic components are not
interchangeable between vehicles.

Always carry a live air bag module away
from the body with the air bag or trim cover
pointing upwards.

Live air bag modules must be placed in a
suitable cage when removed from the
vehicle. The air bag or trim cover must be
facing upwards.

Do not install a rearward facing child safety
seat to the passenger seat with an
activated passenger air bag.

CAUTIONS:

Pyrotechnic components must not be
subjected to temperatures higher than
110°C.

Never install aftermarket accessories to
the vehicle on or adjacent to the
supplemental restraint system module.

G548998en

General Information

DESCRIPTION AND OPERATION

502-00-

201

Wheel and Tire

Removal

CAUTIONS:

Do not use heat to loosen a seized wheel
nut.

Do not use power tools on locking wheel
nuts.

1. Loosen: 360°

E102024

and Lifting, Description and Operation).

E102026

Installation

1. WARNING: Make sure that the mating

faces are clean and free of corrosion
and foreign material

NOTE: Only tighten the nuts finger tight at this
stage.

E102026

2. Lower the vehicle.

3. Tighten the wheel nuts in the sequence shown.

Torque: 103 Nm

E102025

G1062448en

Wheels and Tires

REMOVAL AND INSTALLATION

Refer to: Jacking and Lifting

(100-02

Jacking

502-00-

201
