Ford Fiesta (2011 year). Manual - part 56
In-Vehicle Crossbeam
General Equipment
Adhesive Tape
General Equipment
TORX screwdriver
Removal
NOTE: Removal steps in this procedure may
contain installation details.
1.
Refer to: Heater Core Housing (412-01 Climate
Control, Removal and Installation).
Refer to: Heater Core and Evaporator Core
Housing - Vehicles With: Manual Temperature
Control (412-01 Climate Control, Removal and
Installation).
Refer to: Heater Core and Evaporator Core
Housing - Vehicles With: Automatic
Temperature Control (412-01 Climate Control,
Removal and Installation).
2.
Refer to: Supplemental Restraint System (SRS)
Health and Safety Precautions
(100-00
General Information, Description and
Operation).
3.
E100581
4.
Torque: 8 Nm
E100582
x6
1
x6
5. Depending on the vehicle variant, steering
wheels with a different design for cut marks can
be fitted.
G1083866en
501-12-
54
Instrument Panel and Console
501-12-
54
REMOVAL AND INSTALLATION
201
