Occupant Restraints — Active

501-20a-9

REMOVAL AND INSTALLATION (Continued)

2.  Remove the safety belt anchor.

Using the special tool, remove the bolt
Remove the safety belt anchor

Item

Description

1

Bolt Corflex (Pt of item 3)

2

Belt & Retractor Asy Rr

3

C Pillar Trim

Item

Description

4

Safety belt trim (Pt of item 2)

1

Belt & Rectractor Asy Rr

5

Bolt 7/16 20

2

Bolt Corflex (Pt of item 1)

4.  Remove the child safety seat tether anchor

3.  Remove the safety belt trim

(Sedan only)

Prise off the safety belt trim from the package

Using a 5mm hexagon key, remove the bolt

tray trim (Sedan only)

Remove the child safety seat tether anchor on

Remove the safety belt trim from C pillar

the package tray trim

(Wagon only)

Remove firtree clips

Item

Description

Item

Description

1

Safety belt trim (Pt of item 3)

1

Plug

2

Bolt Corflex (Pt of item 3)

2

Bracket - Child Seat Back Mount

3

Belt & Rectractor Asy Rr

5.  Remove the package tray trim. Refer to Section

4

Pkg Tray Trim

501-05.

Remove the pillar trim (Wagon only). Refer to

Section 501-05.

G32456 en

501-20a-10

Occupant Restraints — Active

501-20a-10

REMOVAL AND INSTALLATION (Continued)

6.  Remove the rear safety belt retractor.

3.  Remove the safety belt trim

Feed the safety belt webbing through the

Prise off the safety belt trim from the package

package trim opening

tray trim

Using the special tool, remove the bolt (s)
Remove the rear safety belt retractor

Installation
1.  To install, reverse the removal procedure.

NOTE: Make sure to tighten all bolts to

specification.
NOTE: Make sure the safety belt webbing is not

twisted prior to installation.
NOTE: Make sure to align and install the safety

belt retractor locating tab into the package tray

panel before installing the bolt.

2.  Check the active restraint system for correct

operation.

4.  Remove the child safety seat tether anchor

(Sedan only)

Rear Centre Safety Belt Retractor —

Using a 5mm hexagon key, remove the bolt

Sedan

Remove the child safety seat tether anchor on

the package tray trim

Removal

Remove firtree clips

1.  Remove the rear seat cushion. Refer to Section

501-10.

2.  Remove the safety belt buckle and rear center

anchor.

Remove the nut
Remove the safety belt anchor

Item

Description

1

Plug

2

Bracket - Child Seat Back Mount

5.  Remove the package tray trim. Refer to Section

501-05.

Item

Description

1

Belt & Retrractor Asy Rr Ctr

2

Nut  M12

G32456 en

501-20a-11

Occupant Restraints — Active

501-20a-11

REMOVAL AND INSTALLATION (Continued)

6.  Remove the rear centre safety belt retractor.

3.  To install, reverse the removal procedure.

NOTE: Make sure to tighten all nuts to

Feed the safety belt webbing through the

specification.

package trim opening
Using the special tool, remove the bolt

NOTE: Make sure the safety belt webbing is not

twisted prior to installation.

Remove the rear center safety belt retractor

NOTE: Make sure the safety belt buckles are

accessible after repositioning the seat.

Item

Description

1

Bolt Corflex (Pt of item 2)

Item

Description

2

Belt & Retractor Asy Rr Ctr

1

Rear centre safety belt buckle/mini buckle

Installation

2

Nut  M12

1.  To install, reverse the removal procedure.

NOTE: Make sure to tighten all nuts and bolts to

Rear Centre Safety Belt Rectractor —

specification.

Wagon

NOTE: Make sure the safety belt webbing is not

Removal and Installation

twisted prior to installation.

1.  Unbuckle mini buckle.

NOTE: Make sure to align and install the safety

belt retractor locating tab into the package tray



1.  Insert a paper clip end into a hole on the

panel before installing the bolt.

under side of the mini buckle.

2.  Check the active restraint system for correct

operation.

Rear Centre Safety Belt

Buckle/Minibuckle — Wagon

Removal
1.  Remove the rear seat cushion. Refer to Section

501-10.

2.  Remove the safety belt buckle and rear center

anchor.

Remove the nut
Remove the rear center safety belt

buckle/minibuckle

G32459 en

501-20a-12

Occupant Restraints — Active

501-20a-12

REMOVAL AND INSTALLATION (Continued)

2.  Remove the safety belt buckles.

2.  Remove the safety belt guide.

Remove the nut.

Prise off the safety belt guide from the seat

back.

Sedan

3.  Disassemble the rear 60/40 split seat back. Refer

Wagon

to Section 501-10.

Remove seat back trim and pad.

4.  Remove the safety belt retractor.

Remove the nut
Remove the rear safety belt retractor

Item

Description

1

Rear centre safety belt buckles

2

Nut  M12

Remove the rear center safety belt buckles

Installation

Item

Description

1.  To install, reverse the removal procedure.

1

Belt & Retractor Asy Rr

NOTE: Make sure to tighten all nuts to

2

Nut 7/16 20 Unf Hex Flg

specification.

5.  To install, reverse the removal procedure.

NOTE: Make sure the safety belt webbing is not

twisted prior to installation.

NOTE: Make sure to tighten all nuts and bolts to

specification.

NOTE: Make sure the safety belt buckles are

accessible after repositioning the seat.

NOTE: Make sure the safety belt webbing is not

twisted prior to installation.

6.  Check the active restraint system for correct

operation.

Rear Centre Safety Belt Buckles

Removal
1.  Remove the rear seat cushion. Refer to Section

501-10.
