501-10-29 Seating 501-10-29

DISASSEMBLY AND ASSEMBLY (Continued)

3.  Disconnect wiring plug(s).

7.  Undo pre-tensioner mounting bolt.

4.  Remove switch assembly from side cover housing

8.  Remove pretensioner wiring loom connector

using a flat bladed instrument to dislodge the

through space on top of seat track.

switch assembly.

Memory Module

Disassembly and Assembly
1.  Remove Seat from vehicle (Refer to Seats in this

section).

2.  Unclip underseat wiring loom retention protecting

cover.

9. Remove

pretensioner

assembly.

Seat Operating Switch

Disassembly and Assembly
1.  Remove outer side trims.

3.  Unplug the white memory module plugs.

2.  Remove outer side cover (Refer to Outer Side

Cover in this section).

G73271 en

501-10-30 Seating 501-10-30

DISASSEMBLY AND ASSEMBLY (Continued)

4.  Undo two retaining mounting screws.

4.  Turn seat over and undo four cushion retaining

nuts.

5.  Remove memory module.

5.  Remove front seat cushion from track.

 CAUTION: Take care during removal

6.  Undo three black J clips (rear and sides).

process not to break off top mounting boss.

Front Seat Cushion (2-way)

Disassembly and Assembly
1.  Remove seat from vehicle (Refer to Seats in this

section).

 WARNING: Wait at least one minute after

disconnecting the battery ground cable before

disconnecting any supplemental restraint

system electrical connector. Failure to follow

this warning could cause premature

deployment and may result in personal injury.

2.  Remove pre-tensioner cable fir tree clips.

NOTE: Leave pretensioner fitted to track.

7.  Undo front white J clip.

NOTE: White clip is glued to seat.

3.  Remove front seat back (Refer to Front Seat Back

in this section).

8.  Remove cover from foam as per seat back foam

disassembly instructions.

Front Seat Cushion (4-way & 6-way

non-memory)

Disassembly and Assembly
1.  Perform steps 1,2,3 from 2-way front seat cushion

disassembly.

G73271 en

501-10-31 Seating 501-10-31

DISASSEMBLY AND ASSEMBLY (Continued)

2.  Remove three fir tree clips.

3.  Perform steps 4,5,6,7,8,9 of front seat cushion

(2-way) disassembly.

Front Seat Cushion (6-way memory)

Disassembly and Assembly
1.  Remove seat from vehicle (Refer to Seats in this

section).

2.  Unclip wiring loom retention nappy.
3.  Remove pre-tensioner cable fir tree clips.
4.  Remove front seat back (Refer to Front Seat Back

in this section).

5.  Unclip wiring loom clip from cushion frame using

long nose pliers.

6.  Undo two memory module mounting screws.
7.  Undo the memory module.
8.  Per step 3 above on 4-way seat (Refer to Front

Seat Back in this section).

 CAUTION: Be careful not to break off top

lug during removal process.

G73275 en

501-11-1

Glass, Frames and Mechanisms

501-11-1

SECTION : 501-11 Glass, Frames and Mechanisms

VEHICLE APPLICATION : 2003.0 BA Falcon
CONTENTS

PAGE

DESCRIPTION AND OPERATION

  Glass, Frames and Mechanisms   ..........................................................................................501-11-2

DIAGNOSIS AND TESTING

  Glass, Frames and Mechanisms   ..........................................................................................501-11-3

REMOVAL AND INSTALLATION

  Window Control Switch   .........................................................................................................501-11-4

  Front Door Window Glass   .....................................................................................................501-11-4

  Rear Door Window Glass — Moveable   ................................................................................501-11-5

  Rear Door Quarter Window Glass — Sedan   ........................................................................501-11-5

  Rear Quarter Glass — Wagon   ..............................................................................................501-11-6

  Rear Door Quarter Glass — LWB   ........................................................................................501-11-7

  Rear Door Quarter Glass — Ute  ...........................................................................................501-11-7

  Front Door Window Regulator   ..............................................................................................501-11-8

  Rear Door Window Regulator   ...............................................................................................501-11-8

  Fixed (Stationary) Glass Replacement   .................................................................................501-11-9

  Front Windshield Glass   .........................................................................................................501-11-9

  Rear Windshield Glass — Sedan   .......................................................................................501-11-12

  Liftgate Glass — Wagon   .....................................................................................................501-11-13

  Rear Windshield Glass — Ute   ............................................................................................501-11-13
