501-10-5 Seating 501-10-5
DIAGNOSIS AND TESTING (Continued)
Diagnostic Flash Code Phases
Phase
Seat does
1
Flash out high value (count number of times light turns off).
2
Green light ON for about 1 second.
3
Flash out low value(count number of times light turns off).
4
Green light ON for about 3 seconds.
5
Pressing memory button ‘2’ will go to the next DTC.
Return to phase 1 and start again
NOTE: Check codes against table.
Diagnostic Test Codes
Flash Codes
First
group
Second group
Code
Action
1
1
6 way seat
Ensure seat is 6 way.
1
2
10 way seat
Ensure seat is 10 way.
1
3
No Priority Data
Go to J1.
1
4
No Priority Frame Synchronisation
Go to J1.
1
5
No Ignition
Go to K1.
1
6
No Reverse
Go to K1.
2
1
No Fore lift motor sensor
Go to I1.
2
2
No Aft lift motor sensor
Go to I1.
2
3
No Track motor sensor
Go to D3&I1.
2
5
No Recliner motor sensor
Go to I1.
2
6
No lumbar motor sensor
Go to I1.
3
1
Button stuck (Memory)
Replace button/board which ever is at
fault.
3
2
Button stuck (Position, including
Replace switch pack.
lumbar)
3
3
Button stuck (Pedals)
Replace button.
3
4
LH mirror not responding or faulty
Replace Mirror.
3
5
RH mirror not responding or faulty
Replace Mirror.
3
6
Mirror button pack not responding or
Replace Mirror botton pack.
faulty
6
3
Internal error
Replace Module.
6
6
End of errors
No Action
NOTE: After finishing repeat to ensure DTC is current
fault code.
