412-04-29 Control
Components 412-04-29
DIAGNOSIS AND TESTING (Continued)
NOTE: The cabin temperature sensor is an integral
part of the ICC, and is not a separately serviceable
item. It the sensor is faulty, the complete ICC must be
replaced. Section 413-08
PINPOINT TEST Q : SUNLOAD SENSOR/TWILIGHT SENSOR OPERATION (HIGH SERIES/ACC)
NOTE: REFER to Section 412-02 SYMPTOM CHART BEFORE PROCEEDING
Test Step
Result / Action to Take
Q1
Refer to Section 417-01, for Sun Load Sensor Pinpoint Test.
NOTE:
Activation of the battery saver supply (J3/3, refer Section
419-10) provides power to the sunload.twilight sensor module. With
the ignition on and the battery saver supply active, the BEM reads the
signals from the sensor. The BEM transmits the sunload data over the
CAN bus to the climate control module. This sensor also controls the
Auto Headlight on function. Refer to Auto Headlight section.
NOTE:
DTC’s will not be available for invalid data signalled with the
ignition switch in either the accessories or the start position. The
output voltage from the sunload sensor is available at pin (J2/1. refer
section 419-10), it is in the range of five to zero volts.
A12342 en
