The lines show a projected vehicle path
and the approximate distance from the
rear bumper to an object.

E142132

A

B

C

A

B

C

D

Red - Zone

A

Amber - Zone

B

 (If Equipped)

Green - Zone

C

Black - center line of the
projected vehicle path

D

Note: When reversing with a trailer the
camera will show the direction of your
vehicle and not the direction of the trailer.

Note: When reversing with a trailer the
screen does not display the lines.

Switching the Rear View Camera
Off

The image does not display when you
move the gearshift lever into Park (P).

Vehicles With Rear View Camera Delay

To turn this feature on See Settings (page
359).

The display will automatically switch off
after disengaging reverse (R) gear.

The system will automatically switch off
when your vehicle speed is above 5.0 mph
(8 km/h).

Note: Depending upon which type of
multimedia display you have, the rear view
camera delay is always on, it cannot be
switched off.

Vehicles With Parking Aid

The display will show a colored distance
bar. This indicates the approximate
distance from the rear bumper to an
object.

These are color coded as follows:
•

Red - Zone

•

Amber - Zone

•

Green - Zone

 (If Equipped)

PRINCIPLE OF OPERATION

Cruise control lets you maintain a set
speed without keeping your foot on the
accelerator pedal. You can use cruise
control when your vehicle speed is greater
than 20 mph (30 km/h).

USING CRUISE CONTROL

WARNINGS

Do not use cruise control on winding
roads, in heavy traffic or when the
road surface is slippery. This could

result in loss of vehicle control, serious
injury or death.

When you are going downhill, your
vehicle speed could increase above
the set speed. The system does not

apply the brakes.

E142437

The cruise controls are on the steering
wheel.

Note: Cruise control disengages if your
vehicle speed decreases more than 10 mph
(16 km/h) below the set speed when driving
uphill.

Switching Cruise Control On

Press and release ON.

E71340

The indicator appears in the
information display.

Setting the Cruise Speed

1.

Drive to desired speed.

2. Press and release SET+.

3. Take your foot off the accelerator

pedal.

Changing the Set Speed

•

Press and release SET+ or SET-. When
you select km/h as the display
measurement in the information
display the set speed changes in
approximately 2 km/h increments.
When you select mph as the display
measurement in the information
display the set speed changes in
approximately 1 mph increments.

•

Press the accelerator or brake pedal
until you reach the desired speed. Press
and release SET+.

•

Press and hold SET+ or SET-. Release
the control when you reach the desired
speed.

Canceling the Set Speed

Pull and release CAN or tap the brake
pedal.  The set speed does not erase.

Resuming the Set Speed

Pull and release RES.

Switching Cruise Control Off

Press and release OFF when the system is
in standby mode or switch the ignition off.

Note: You erase the set speed when you
switch the system off.

BLIND SPOT INFORMATION
SYSTEM

WARNING

To help avoid injuries, NEVER use the
Blind Spot Information System as a
replacement for using the interior

and exterior mirrors or looking over your
shoulder before changing lanes. The Blind
Spot Information System is not a
replacement for careful driving.

A

A

E124788

The Blind Spot Information System is
designed to aid you in detecting vehicles
that may have entered the blind spot zone
(A). The detection area is on both sides of
your vehicle, extending rearward from the
exterior mirrors to approximately 13 ft
(4 m) beyond the bumper. The system is
designed to alert you if certain vehicles
enter the blind spot zone while driving.

Note: The Blind Spot Information System
does not prevent contact with other vehicles
or objects; nor detect parked vehicles,
people, animals or infrastructure (fences,
guardrails, trees). It’s only designed to alert
you to vehicles in the blind spot zones.

Note: When a vehicle passes quickly
through the blind spot zone, typically fewer
than two seconds, the system does not
trigger.

Using the System

The Blind Spot Information System turns
on when you start the engine and you drive
your vehicle forward above 5 mph
(8 km/h).

For automatic transmissions, the Blind
Spot Information System remains on while
the transmission is in drive (D). If shifted
into reverse (R) or park (P) the Blind Spot
Information System turns off. Once shifted
back into drive (D), the Blind Spot
Information System turns back on when
you drive your vehicle above 5 mph
(8 km/h).

For manual transmissions, the Blind Spot
Information System is on for all gears
except the reverse (R).

Note: The Blind Spot Information System
does not function in reverse (R) or park (P).

System Lights and Messages

E142442
