SETTINGS

A

B

C

D

E

F

E161968

Message

Item

Clock

A

Display

B

Sound

C

Vehicle

D

Settings

E

Help

F

Clock

Under this menu, you can set the clock,
access and adjust the display, sound and
vehicle settings as well as access settings
for specific modes or the help feature.

To make adjustments using the touchscreen, select:

Action and Description

Message

Press the settings icon.

Settings

Press the + or - to adjust the time.

Clock

From this screen, you can also make other adjustments such
as 12-hour or 24-hour mode, activate GPS time synchroniza-
tion and have the system automatically update new time
zones.

Action and Description

Message

You can also turn the outside air temperature display off and
on. It appears at the top center of the touchscreen, next to
the time and date.

Note: You cannot manually set the date. Your vehicle’s GPS does this for you.

Note: If the battery has been disconnected, your vehicle needs to acquire a GPS signal to
update the clock. Once your vehicle acquires the signal, it may take a few minutes for the
update to display the correct time.

Display

You can adjust the display using the
touchscreen or the voice button on the
steering wheel controls.

To make adjustments using the touchscreen, select:

Action and Description

Menu Item

Press the settings icon.

Settings

Display

Then select from the following:

Allows you to switch the display off. It also allows you to set the screen
to a certain brightness or have the system automatically change based
on the outside light level.

Mode

If you also select:

These features will allow you to adjust the dimming of
your screen.

Auto

Night

Allows you to display the default photo or upload your own.

Edit Wallpaper

When set to On, lets you use the automatic dimming feature.

Auto Dim

When set to Off you are able to adjust the brightness of the screen.

Make the screen display brighter or dimmer.

Brightness

Allows you to adjust screen dimming as the outside lighting conditions
change from day to night.

Auto Dim
Manual Offset

E142599

To make adjustments using the voice
button, press the button and when
prompted, say:

Voice command

Display Settings

Uploading Photos for Your Home
Screen Wallpaper

Note: You cannot load photos directly from
your camera. You must access the photos
either from your USB mass storage device
or from an SD card.

Note: Photographs with extremely large
dimensions (such as 2048 x 1536) may not
be compatible and appear as a blank
(black) image on the display.

The system allows you to upload and view
up to 32 photos.

To access, press:

To upload your photos, select:

Action and Description

Message

Press the settings icon.

Settings

Display

Follow the system prompts to upload your photographs.

Edit Wallpaper

Only the photograph(s), which meets the
following conditions will display:
•

Compatible file formats are as follows:
JPG, GIF, PNG, BMP.

•

Each file must be 1.5 MB or less.

•

Recommended dimensions: 800 x 384.

Sound

To make adjustments using the
touchscreen, select:

Message

Settings

Sound

Then select from the following:

Bass

Midrange

Treble

Message

Set Balance and Fade

Occupancy Mode

Speed Compensated Volume

DSP

Note:  Your vehicle may not have all of
these sound settings.

Vehicle

To make adjustments using the
touchscreen, select:

Message

Settings

Vehicle

Then select from the following:

*

Vehicle Health Report

Message

Camera Settings

Message

Enable Valet Mode

*

 US only

Vehicle Health Report (If Equipped, US Only)

To make adjustments using the touchscreen, select:

Action and Description

Message

Press the settings icon.

Settings

Vehicle

Vehicle Health

Turn on and off and set the mileage interval at which you
would like to receive the reports. Press the ? for more
information on these selections.

Automatic Reminders

Mileage Interval (Miles)

To run the vehicle health report immediately.

Run Vehicle Health
Report Now

You can find more information on Vehicle Health Report in this chapter.

Camera Settings

This menu allows you to access settings
for your rear view camera.

To make adjustments using the touchscreen, select:

Action and Description

Message

Press the settings icon.

Settings

Vehicle

Camera Settings

Then select from the following:

Enhanced Park Aids

Rear Camera Delay

You can find more information on the rear view camera system in another chapter.  See
Parking Aids (page 135).
