To use SelectShift, move the gearshift
lever into S (Sport). Use the +/- buttons
on the side of your gearshift lever to
manually change gears.

•

Press the (+) button to upshift.

•

Press the (-) button to downshift.

Note: After you have assumed manual
control with SelectShift your vehicle will
remain in this mode until you return the
gearshift lever from S (Sport), back to D
(Drive).

Upshift to the recommended shift speeds
according to the following chart:

Upshifts when accelerating (recom-

mended for best fuel economy)

Shift from:

15 mph (24 km/h)

1 - 2

25 mph (40 km/h)

2 - 3

40 mph (64 km/h)

3 - 4

45 mph (72 km/h)

4 - 5

50 mph (80 km/h)

5 - 6

The instrument cluster will display the
selected gear that you are currently in and
a shift indicator arrow to assist in
optimizing shifting.

SelectShift will automatically make some
shifts for you in the event that your engine
speed is running at too high, or too low an
RPM.

Note: Engine damage may occur if
excessive engine revving is held without
shifting.

Brake-Shift Interlock

WARNINGS

Do not drive your vehicle until you
verify that the brake lamps are
working.

WARNINGS

When doing this procedure, you will
be taking the vehicle out of park
which means the vehicle can roll

freely. To avoid unwanted vehicle
movement, always fully set the parking
brake prior to doing this procedure. Use
wheel chocks if appropriate.

If the parking brake is fully released,
but the brake warning lamp remains
illuminated, the brakes may not be

working properly. See your authorized
dealer.

Use the brake shift interlock lever to move
the gearshift lever from the park position
in the event of an electrical malfunction or
if your vehicle has a dead battery.

Apply the parking brake and turn the
ignition off before performing this
procedure.

1.

Insert a screwdriver (or similar tool)
between the shifter bezel and the top
finish panel.

2. Use the tool to unsnap the shifter bezel

from the finish panel.

E142627

3. Locate the white lever located on the

left side of the shifter.

4. Using the tool move the white lever

towards the rear of the shifter.

5. While holding the white lever in the rear

position, move the shifter from the park
position.

6. Press the shifter bezel back into the top

finish panel until it snaps back into
position.

7.

Apply the brake pedal, start the vehicle
and release the parking brake.

Note: See your authorized dealer as soon
as possible if this procedure is used.

If Your Vehicle Gets Stuck In Mud
or Snow

Note: Do not rock the vehicle if the engine
is not at normal operating temperature or
damage to the transmission may occur.

Note: Do not rock the vehicle for more than
a minute or damage to the transmission and
tires may occur, or the engine may overheat.

If your vehicle gets stuck in mud or snow,
it may be rocked out by shifting between
forward and reverse gears, stopping
between shifts in a steady pattern. Press
lightly on the accelerator in each gear.

GENERAL INFORMATION

Note: Occasional brake noise is normal. If
a metal-to-metal, continuous grinding or
continuous squeal sound is present, the
brake linings may be worn-out. Have the
system checked by an authorized dealer. If
your vehicle has continuous vibration or
shudder in the steering wheel while braking,
have it checked by an authorized dealer.

Note: Brake dust may accumulate on the
wheels, even under normal driving
conditions. Some dust is inevitable as the
brakes wear and does not contribute to
brake noise.  See Cleaning the Alloy
Wheels (page 218).

Note: Depending on applicable laws and
regulations in the country for which your
vehicle was originally built, your brake lamps
may flash during heavy braking. Following
this, your hazard lights may also flash when
your vehicle comes to a stop.

E144522

See Warning Lamps and
Indicators (page 81).

Wet brakes result in reduced braking
efficiency. Gently press the brake pedal a
few times when driving from a car wash or
standing water to dry the brakes.

Brake Over Accelerator

In the event the accelerator pedal
becomes stuck or entrapped, apply steady
and firm pressure to the brake pedal to
slow the vehicle and reduce engine power.
If you experience this condition, apply the
brakes and bring your vehicle to a safe
stop. Move the transmission to park (P),
switch the engine off and apply the parking
brake. Inspect the accelerator pedal for
any interference. If none are found and the
condition persists, have your vehicle towed
to the nearest authorized dealer.

Brake Assist

Brake assist detects when you brake
rapidly by measuring the rate at which you
press the brake pedal. It provides
maximum braking efficiency as long as you
press the pedal, and can reduce stopping
distances in critical situations.

Anti-lock Brake System

This system helps you maintain steering
control during emergency stops by keeping
the brakes from locking.

This lamp momentarily
illuminates when you turn the
ignition on. If the light does not

illuminate during start up, remains on or
flashes, the system may be disabled. Have
the system checked by an authorized
dealer. If the anti-lock brake system is
disabled, normal braking is still effective.

E144522

If the brake warning lamp
illuminates when you release the
parking brake, have the system

checked by an authorized dealer.

HINTS ON DRIVING WITH
ANTI-LOCK BRAKES

Note: When the system is operating, the
brake pedal will pulse and may travel
further. Maintain pressure on the brake
pedal. You may also hear a noise from the
system. This is normal.

The anti-lock braking system will not
eliminate the risks when:
•

You drive too closely to the vehicle in
front of you.

•

Your vehicle is hydroplaning.

•

You take corners too fast.

•

The road surface is poor.

PARKING BRAKE

WARNING

Always set the parking brake fully
and make sure you shift the gearshift
lever to park (P). Switch the ignition

off and remove the key whenever you leave
your vehicle.

Note: Do not press the release button while
pulling the lever up.

To apply the parking brake:

1.

Press the foot brake pedal firmly.

2. Pull the parking brake lever up to its

fullest extent.

Note: If you park your vehicle on a hill and
facing uphill, shift the gearshift lever to park
(P) and turn the steering wheel away from
the curb.

Note: If you park your vehicle on a hill and
facing downhill, shift the gearshift lever to
park (P) and turn the steering wheel toward
the curb.

To release the parking brake:

1.

Press the brake pedal firmly.

2. Pull the lever up slightly.

3. Press the release button and push the

lever down.

HILL START ASSIST

WARNINGS

The system does not replace the
parking brake. When you leave your
vehicle, always apply the parking

brake. Failure to leave your vehicle securely
parked may lead to a crash or injury.  See
Parking Brake (page 130).

WARNINGS

You must remain in your vehicle once
the system activates. Failure to
follow this warning could result in

serious personal injury or death.

During all times, you are responsible
for controlling your vehicle,
supervising the system and

intervening, if required. Failure to take care
may result in the loss of control of your
vehicle, serious personal injury or death.

The system will turn off if a
malfunction is apparent or if you rev
the engine excessively. Failure to

take care may result in the loss of control
of your vehicle, serious personal injury or
death.

The system makes it easier to pull away
when your vehicle is on a slope without the
need to use the parking brake.

When the system is active, your vehicle will
remain stationary on the slope for two to
three seconds after you release the brake
pedal. This allows time to move your foot
from the brake to the accelerator pedal.
The brakes are released automatically
once the engine has developed sufficient
torque to prevent your vehicle from rolling
down the slope. This is an advantage when
pulling away on a slope, for example from
a car park ramp, traffic lights or when
reversing uphill into a parking space.

The system will turn on automatically on
any slope which can result in significant
vehicle rollback.

Using Hill Start Assist

1.

Press the brake pedal to bring your
vehicle to a complete standstill. Keep
the brake pedal pressed. If equipped
with a manual transmission, also press
the clutch pedal.
