Settings

Warning

Display

Compass

Convenience

Calibrate

Set Zone

Create MyKey

Create MyKey

MyKey

Always On

Traction Ctrl

User selectable

Always On

911 Assist

User selectable

Choose your applicable setting

Max Speed

Choose your applicable setting

Speed Warning

Volume Limiter

Always On

Do Not Disturb

User selectable

Clear MyKey

Clear MyKeys

CLOCK

Type 1

To adjust the clock, switch the ignition on
and press buttons H or M on the
information and entertainment display as
necessary.

Type 2

Note: Use the information display to adjust
the clock.  See  (page 85).

TRIP COMPUTER

Resetting the Trip Computer

Press and hold OK on the current screen
to reset the respective trip, distance, time
and average fuel information.

Trip Odometer

Registers the distance traveled of
individual journeys.

Distance to Empty

Indicates the approximate distance your
vehicle will travel on the fuel remaining in
the tank. Changes in driving pattern may
cause the value to vary.

Average Fuel

Indicates the average fuel consumption
since the function was last reset.

Digital Speedometer

The speed your vehicle is traveling at will
display as a digital number.

PERSONALIZED SETTINGS

Measure Units

To swap between imperial and metric
units, scroll to this display and press the
OK button.

Swapping between imperial and metric
units will affect the following displays:
•

Distance to empty.

•

Average fuel consumption.

•

Instantaneous fuel consumption.

•

Average speed.

Switching Chimes Off

The following chimes can be switched off:
•

Warning messages.

•

Information messages.

INFORMATION MESSAGES

E130248

Press the OK button to acknowledge and
remove some messages from the
information display. Other messages will
be removed automatically after a short
time.

Certain messages need to be confirmed
before you can access the menus.

The message indicator
illuminates to supplement some
messages. It will be red or amber

depending on the severity of the message
and will remain on until the cause of the
message has been rectified.

Some messages will be supplemented by
a system specific symbol with a message
indicator.

Note: Depending on the options on your
vehicle, not all of the messages will display
or be available. Certain messages may be
abbreviated or shortened depending upon
which instrument cluster type you have.

Airbag

Action

Message Indic-

ator

Message

Have your vehicle checked by an authorized

dealer as soon as possible.

Amber

Airbag fault

Service now

Alarm

Action

Message Indic-

ator

Message

Displays when the alarm has been triggered

due to unauthorized entry.  See Passive

Anti-Theft System (page 58).

Amber

Alarm activated

Check Vehicle

Have your vehicle checked by an authorized

dealer as soon as possible.

-

Alarm fault

Service required

Battery and Charging System

Action

Message Indic-

ator

Message

Stop your vehicle as soon as it is safe to do

so and switch the ignition off. Have your

vehicle checked by an authorized dealer as

soon as possible.

Red

Electrical system over-

voltage

Stop safely

Displays to warn of a low battery condition.

Turn off all unnecessary electrical

accessories. Have your vehicle checked by

an authorized dealer as soon as possible.

Amber

Battery low

See manual

Blind Spot Information and Cross Traffic Alert System

Action

Message

Indicator

Message

Displayed when the blind spot information

system and cross traffic alert system sensors

are blocked.  See Blind Spot Information

System (page 141).

Amber

BLIS Low visibility See

manual

Displayed when a fault with the system has
occurred. Contact your authorized dealer as

soon as possible.

Amber

BLIS: X sensor fault

Service required

Displayed when the system is not available due

to trailer use.  See Blind Spot Information

System (page 141).

Amber

BLIS not available Trailer

attached

Displayed when the system detects a vehicle.

See Blind Spot Information System (page

141).

Amber

Cross Traffic Vehicle

coming from X

Displayed when the blind spot information

system and cross traffic alert system sensors

are blocked.  See Blind Spot Information

System (page 141).

Amber

Cross Traffic Sensor

blocked See manual

Displays when the system requires service due

to a malfunction. Contact your authorized

dealer.

Amber

Cross Traffic fault

Service required

Displayed when the system is not available due

to trailer use.  See Blind Spot Information

System (page 141).

-

Cross Traffic disabled

Trailer attached

Doors Open

Action

Message Indic-

ator

Message

Vehicle is moving. Stop your vehicle as soon

as safely possible and close.

Red

Driver door ajar

Vehicle is moving. Stop your vehicle as soon

as safely possible and close.

Red

Driver side rear door ajar

Vehicle is moving. Stop your vehicle as soon

as safely possible and close.

Red

Passenger door ajar
