CHILD SAFETY LOCKS

WARNING

You cannot open the doors from
inside if you have put the child safety
locks on.

E189148

The childproof locks are located on the
rear edge of each rear door and must be
set separately for each door.

Left-Hand Side

Turn counterclockwise to lock and
clockwise to unlock.

Right-Hand Side

Turn clockwise to lock and
counterclockwise to unlock.

PRINCIPLE OF OPERATION

WARNINGS

Always drive and ride with your
seatback upright and the lap belt
snug and low across the hips.

To reduce the risk of injury, make
sure children sit where they can be
properly restrained.

Never let a passenger hold a child on
his or her lap while your vehicle is
moving. The passenger cannot

protect the child from injury in a crash.

All occupants of your vehicle,
including the driver, should always
properly wear their safety belts, even

when an airbag supplemental restraint
system is provided. Failure to properly wear
your safety belt could seriously increase
the risk of injury or death.

It is extremely dangerous to ride in a
cargo area, inside or outside of a
vehicle. In a crash, people riding in

these areas are more likely to be seriously
injured or killed. Do not allow people to ride
in any area of your vehicle that is not
equipped with seats and safety belts. Be
sure everyone in your vehicle is in a seat
and using a safety belt properly.

In a rollover crash, an unbelted
person is significantly more likely to
die than a person wearing a safety

belt.

Each seating position in your vehicle
has a specific safety belt assembly
which is made up of one buckle and

one tongue that are designed to be used
as a pair. 1) Use the shoulder belt on the
outside shoulder only. Never wear the
shoulder belt under the arm. 2) Never
swing the safety belt around your neck over
the inside shoulder. 3) Never use a single
belt for more than one person.

WARNINGS

When possible, all children 12 years
old and under should be properly
restrained in a rear seating position.

Failure to follow this could seriously
increase the risk of injury or death.

Safety belts and seats can become
hot in a vehicle that has been closed
up in sunny weather; they could burn

a small child. Check seat covers and
buckles before you place a child anywhere
near them.

Front and rear seat occupants,
including pregnant women, should
wear safety belts for optimum

protection in an accident.

All seating positions in your vehicle have
lap and shoulder safety belts. All
occupants of the vehicle should always
properly wear their safety belts, even when
an airbag supplemental restraint system
is provided.

The safety belt system consists of:
•

Lap and shoulder safety belts.

•

Shoulder safety belt with automatic
locking mode, (except driver safety
belt).

•

Height adjuster at the front outboard
seating positions.

•

Safety belt pretensioner at the front
outboard seating positions.

•

Belt tension sensor at the front
outboard passenger seating position.

•

Safety belt warning light and chime.

•

Crash sensors and monitoring system
with readiness indicator.

The safety belt pretensioners at the front
seating positions are designed to tighten
the safety belts when activated. In frontal
and near-frontal crashes, the safety belt
pretensioners may be activated alone or,
if the crash is of sufficient severity, together
with the front airbags. The pretensioners
may also activate when the Safety Canopy
is deployed.

FASTENING THE SEATBELTS

The front outboard and rear safety
restraints in the vehicle are combination
lap and shoulder belts.

E142587

1.

Insert the safety belt tongue into the
proper buckle (the buckle closest to
the direction the tongue is coming
from) until you hear a snap and feel it
latch. Make sure the tongue is securely
fastened in the buckle.

E142588

2. To unfasten, press the release button

and remove the tongue from the
buckle.

Using Safety Belts During
Pregnancy

WARNING

Always ride and drive with your seat
back upright and the safety belt
properly fastened. The lap portion of

the safety belt should fit snug and be
positioned low across the hips. The
shoulder portion of the safety belt should
be positioned across the chest. Pregnant
women should also follow this practice.
See the following figure.

E170730

Pregnant women should always wear their
safety belt. The lap belt portion of a
combination lap and shoulder belt should
be positioned low across the hips below
the belly and worn as tight as comfort will
allow. The shoulder belt should be
positioned to cross the middle of the
shoulder and the center of the chest.

Safety Belt Locking Modes

WARNINGS

After any vehicle crash, the safety
belt system at all passenger seating
positions must be checked by an

authorized dealer to verify that the
automatic locking retractor feature for
child seats is still functioning properly. In
addition, all safety belts should be checked
for proper function.

Safety belt and retractor assemblies
must be replaced if the safety belt
assembly automatic locking retractor

feature, or any other safety belt function
is not operating correctly when checked
by an authorized dealer. Failure to replace
the safety belt and retractor assembly
could increase the risk of injury in a crash.

All safety belts in your vehicle are
combination lap and shoulder belts. The
driver safety belt has the first type of
locking mode, and the front outboard
passenger and rear seat safety belts have
both types of locking modes described as
follows:

Vehicle Sensitive Mode

This is the normal retractor mode, which
allows free shoulder belt length
adjustment to your movements and
locking in response to vehicle movement.
For example, if the driver brakes suddenly
or turns a corner sharply, or the vehicle
receives an impact of approximately 5 mph
(8 km/h) or more, the combination safety
belts will lock to help reduce forward
movement of the driver and passengers.

In addition, the retractor is designed to lock
if the webbing is pulled out too quickly. If
this occurs, let the safety belt retract
slightly and pull webbing out again in a
slow and controlled manner.

Automatic Locking Mode

In this mode, the shoulder belt is
automatically pre-locked. The safety belt
will still retract to remove any slack in the
shoulder belt. The automatic locking mode
is not available on the driver safety belt.

When to Use the Automatic Locking
Mode

This mode should be used any time a child
safety seat, except a booster, is installed
in passenger front or rear seating positions.
Children 12 years old and under should be
correctly restrained in a rear seating
position whenever possible.  See Child
Safety (page 15).
