Ford Taurus (2018 year). Manual - part 22

Settings

Display

Compass

Normal or Towing

DTE calcula-
tion

Easy Entry/Exit

Autolock

Locks

Convenience

Autounlock

All Doors or Driver First

Remote Unlock

Remaining Life XXX% - Hold OK to Reset

Oil Life
Reset

Auto or Last Settings

Climate Control

Remote
Start

Automatic or Off

Seats and Wheel or
Front Seats

5, 10 or 15 minutes

Duration

System

Remote Open

Windows

Remote Close

Courtesy Wipe

Wipers

Rain Sensing

1 Year, 2 Years, 3 Years or 4 Years

Tire Mobility
Kit

Hold OK to Create MyKey

Create
MyKey

MyKey

Always On or User Selectable

911 Assist

Traction
Ctrl

80 mph (130 km/h) or Off

Max Speed

Settings

Volume Limiter

Always On or User Selectable

Do Not
Disturb

Hold OK to Clear All MyKeys

Clear
MyKeys

Note:

Some MyKey items only appear if a

MyKey is set.

Information Display Controls
(Type 2)

E215228

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

•

Press and hold the left arrow button at
any time to return to the main menu
display (escape button).

•

Press the OK button to choose and
confirm settings or messages.

Main Menu

From the main menu bar on the left side
of the information display, you can choose
from the following categories:

•

Display Mode.

•

Trip 1 & 2.

•

Fuel Economy.

•

Driver Assist.

•

Settings.

Scroll up or down to highlight one of the
categories and then press the right arrow
key or OK to enter into that category. Press
the left arrow key as needed to exit back
to the main menu.

Display Mode

Use the up or down arrow buttons to
choose between the following display
options.

Display Mode

XXX mi (km) to empty, Fuel gauge and Total odometer

Option 1

Round tachometer, Fuel gauge and Total odometer

Option 2

Round tachometer, Engine coolant temp gauge, Fuel gauge and Total
odometer

Option 3

Digital speedometer, Fuel gauge and Total odometer

Option 4

Regardless of display mode chosen, when you use the SelectShift Automatic™ trans-
mission (SST), the cluster will change to the round tachometer if not already selected.

XXX mi (km) to empty

Shows approximate fuel level before the
fuel tank reaches empty. The value is
dynamic and can change (raise or lower)
depending on driving style.

Fuel gauge

Switch the ignition on. The fuel gauge
indicates approximately how much fuel is
in the fuel tank. The arrow next to the fuel
pump symbol shows the fuel filler door
side of your vehicle. When the fuel level
becomes low, the level indicator changes
to amber. When the fuel level becomes
critically low, the level indicator changes
to red.

Note:

The fuel gauge level may vary slightly

when your vehicle is moving or when driving
on a slope.

Note:

When a MyKey is in use, low fuel

warnings display earlier.

Round tachometer

Indicates the engine speed in revolutions
per minute. Driving with your tachometer
pointer continuously at the top of the scale
may damage the engine. During SelectShift
Automatic™ transmission (SST) use, the
currently selected gear appears in the
display.

Engine coolant temperature gauge

Indicates engine coolant temperature. At
normal operating temperature, the level
indicator is in the normal range. If the
engine coolant temperature exceeds the
normal range, stop your vehicle as soon as
safely possible, switch off the engine and
let the engine cool.

Trip 1 & 2

You can access the menu using the
information display control.

Note:

Some options may appear slightly

different or not at all if the items are
optional.

Trip 1 & 2

Trip distance

Trip 1 & 2

Elapsed trip time

Average fuel economy

Hold OK to Reset

•

Trip distance — shows the accumulated trip distance.

•

Elapsed trip time— timer stops when the vehicle is turned off and restarts when the
vehicle is restarted.

•

Average fuel economy — shows the average fuel economy for a given trip.

Note:

You can reset your trip information by pressing and holding the OK button on the left

hand steering wheel controls.

Fuel Economy

Use the left or right arrow buttons to
choose the desired fuel economy display.

Fuel Economy

30 Min Fuel History

Inst Fuel Economy

Fuel Economy

-

X

Instantaneous fuel usage

X

-

Fuel usage over a 30 minute

time span

Always Present

Average MPG

Always Present

XXX mi (km) to E

•

Inst Fuel Economy - This display shows a visual graph of your instantaneous fuel
economy.

•

30 Min Fuel History - This display shows a bar chart of your fuel history.

Note:

You can reset your average fuel economy by pressing and holding the OK button on

the left hand steering wheel controls.

Driver Assist

In this mode, you can configure different
driver setting choices.

Note:

Some items are optional and may

not appear.
