2. Follow the prompts on the

touchscreen.

3. Follow the prompts that appear on

your phone to allow access to Apple
CarPlay.

After completing the setup, your phone
connects to CarPlay automatically when
plugged into a USB port.

To disable this feature from the
Settings screen, select:

Menu Item

Apple CarPlay Preferences

Your device is listed if SYNC detects
Apple CarPlay. Select the name of your
device and select:

Disable

To return to SYNC 3, go to the Apple
CarPlay home screen and select the SYNC
app.

Note: Contact Apple for Apple CarPlay
support.

Android Auto

Android Auto is compatible with most
devices with Android 5.0 or newer.

1.

Download the Android Auto app to
your device from Google Play to
prepare your device (this may require
mobile data usage).

Note: The Android Auto App may not be
available within your current market.

2. Plug your device into a USB port.  See

USB Port (page 459).

3. To switch this feature on from the

Settings screen, scroll left on the
screen and select:

Menu Item

Android Auto Preferences

Enable Android Auto

Note: Android Auto must be switched on
after plugging in your device.

To disable this feature from the
Settings screen, select:

Menu Item

Android Auto Preferences

Your device is listed if SYNC detects
Android Auto. Select the name of your
device and select:

Disable

Note: You may need to slide your Settings
screen to the left to select Apple CarPlay
Preferences or Android Auto Preferences.

To return to SYNC 3, select the
speedometer icon in the Android Auto
menu bar at the bottom of the
touchscreen, and then touch the option to
return to SYNC.

Note: Contact Google for Android Auto
support.

NAVIGATION

Your navigation system is comprised of
two main features, destination mode and
map mode.

 (If Equipped)

Map Mode

Map mode shows advanced viewing
comprised of 2D city maps, 3D landmarks
and 3D city models (when available). 2D
city maps show detailed outlines of
buildings, visible land use, landscape
features, and detailed railroad
infrastructure for the most essential cities
around the globe.

3D landmarks appear as clear, visible
objects that are typically recognizable and
have a certain tourism value.

3D city models are complete 3D models
of entire city areas including navigable
roads, parks, rivers and rendered buildings.
3D landmarks and city models appear in
3D map mode only. Coverage of these
varies and improves with updated map
releases.

E207752

Select the zoom in icon to see a
closer view of the map.

E207753

Select the zoom out icon to see
a farther away view of the map.

You can adjust the view in preset
increments. You can also pinch to zoom in
or out of the map.

The information bar tells you the names
of streets, cities or landmarks as you hover
over them with the crosshair curser.

You can change your view of the map by
tapping on the location indicator icon on
the right hand side of the screen. You can
choose from the following options:

E207750

Heading up (2D map) This
always shows the direction of
forward travel to be upward on
the screen. This view is available
for map scales up to 3 mi (5 km).

E207749

North up (2D map) always
shows the northern direction to
be upward on the screen.

E207748

3D map mode provides an
elevated perspective of the map.
Adjust this viewing angle and
rotate the map 180 degrees by
touching the map twice, and

then dragging your finger along the shaded
bar with arrows at the bottom of the map.

E207751

Re-center the map by pressing
this icon whenever you scroll the
map away from your vehicle’s
current location.

E251780

E251779

Mute: Press to mute the audio
navigation guidance. Press the
button again to un-mute the
guidance.

E207754

Points of Interest (POI)
grouping icon: You can choose
up to three POI icons to display
on the map. If the chosen POIs
are located close together or are

at the same location a box is used to
display a single category icon instead of
repeating the same icon, in order to reduce
clutter. When you select the box on the
map, a pop-up appears indicating how
many POIs are in this location. Select the
pop up to see a list of the available POIs.
You can scroll through and select POIs
from this list.

If your vehicle is low on charge or fuel,
station icons automatically display on the
map.

 (If Equipped)

If you have subscribed to SiriusXM Traffic
and Travel Link (where available), traffic
flow will be indicated on the map by green
(clear), yellow (slowing), and red
(stopped) road highlights. Traffic flow is
indicated where the information is
available and varies across the US.

You can choose to display traffic icons on
the map representing twelve different
types of incidents.  See Settings (page
546).

You can set a destination by hovering
above a location and selecting:

Button

Start

Destination Mode

To set a destination, press:

Description

Menu Item

Destination

Enter a navigation destination in any of the following formats:

Street Address

Search

(number, street, city, state)

For example "12 Mainstreet Dearborn MI"

Partial Address
(number, street) if searching in current state
(number, street and zip code (or postal code in Canada)) if searching
out of state
You can enter unique addresses that contain door number prefixes
with or without the prefix. For example, you could enter "6N340
Fairway Lane" or "340 Fairway Lane".

City

(name or zip code)

Point of Interest

(name or category)

Intersection

(street 1 / street 2)
(street 1 and street 2)
(street 1 & street 2)
(street 1 @ street 2)
(street 1 at street 2)

 (If Equipped)

Description

Menu Item

Latitude and Longitude

(##.###### , ##.######)
This is in a decimal degrees format, one to six decimal places are
accepted.

You are given autocomplete options below the address bar to select
as you type.
If you do not give an exact destination, a menu displays with your
possible selections.

Collections of your last 40 navigation destinations display here.

Previous Destina-
tions

You can select any option from the list to select it as your destination.

Select this option to remove all previous destinations.

Delete
All

Select to navigate to your set Home destination.

Home

The time it takes to travel from your current location to Home displays.
To set your Home, press:

A prompt appears asking if you would like to create a
favorite for home. Select:

Home

Enter a location into the search bar and press:

Yes

Save

Select to navigate to your set Work destination.

Work

The time it takes to travel from your current location to Work displays.
To set your Work:

A prompt appears asking if you would like to create a
favorite for work. Select:

Work

Enter a location into the search bar and press:

Yes

Save

Favorites include any location you have previously saved.

Favorites

To add Favorites:

Select this button and enter a location into the destination
bar.

Add a
Favorite

Select this option to have the system locate the address
you have entered.

Search

Select this button when the address you have entered
appears on the screen.

Save

 (If Equipped)
