Ford Super Duty (2018 year). Manual - part 40

REAR SEATS

 (If Equipped)

Folding Up the Rear Seat Cushion

The rear seat has a split 60/40 cushion.
You can flip each seat cushion up into a
vertical storage position.

E181250

Rotate the seat cushion up until it locks
into the vertical storage position.

Cushion Lock (If Equipped)

The locking key is in the keyfob.  See
Remote Control (page 56).

E224956

Turn the key to lock or unlock.

Returning the Seat to the Seating
Position

WARNING

Check under the seat cushion to
make sure no cargo or objects are
under the seat cushion before

returning the seat cushion to its original
position, and that the seat cushion locks
into place. Failure to do so may prevent
the seat from operating properly in the
event of a crash, which could increase the
risk of serious injury.

E166704

Pull the control on the bottom of the seat
cushion to release it from the storage
position.

Rear Under Seat Storage

 (If Equipped)

The rear seat has storage space under the
seat cushion.

E162739

A

Lift the lever and flip up the seat cushion
to access the storage space and the power
point (A).

E162740

To remove the storage space divider,
squeeze the sides and lift it from the
storage tub.

E162741

Use your vehicle key to lock the storage
space.

HEATED SEATS

 (If Equipped)

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must exercise care when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that insulates against
heat, such as a blanket or cushion. This
may cause the heated seat to overheat.
Do not puncture the seat with pins, needles
or other pointed objects. This may damage
the heating element which may cause the
heated seat to overheat. An overheated
seat may cause serious personal injury.

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

Note: The heated seats may remain on
after you remote start your vehicle, based
on your remote start settings. The heated
seats may also turn on when you start your
vehicle if they were on when you switched
your vehicle off.

Rear Heated Seats

 (If Equipped)

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must exercise care when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that insulates against
heat, such as a blanket or cushion. This
may cause the heated seat to overheat.
Do not puncture the seat with pins, needles
or other pointed objects. This may damage
the heating element which may cause the
heated seat to overheat. An overheated
seat may cause serious personal injury.

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

The rear seat heat controls are on the rear
of the center console.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

The heated seat module resets at every
ignition run cycle. While the ignition is in
the on position, press the heated seat
switch to enable heating mode. When
activated, they turn off automatically when
you switch off the engine.

CLIMATE CONTROLLED SEATS

(If Equipped)

Heated Seats

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must use caution when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that may block the
heat, such as a blanket or cushion. This can
cause the heated seat to overheat. Do not
puncture the seat with pins, needles or
other pointed objects. This damages the
heating element and can cause the heated
seat to overheat. An overheated seat may
cause serious personal injury.

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

Note: The heated seats may remain on
after you remote start your vehicle, based
on your remote start settings. The heated
seats may also turn on when you start your
vehicle if they were on when you switched
your vehicle off.

Note: After 60 minutes of operation, the
heated seats switch off. Press the heated
seat symbol to switch the heated seats on.

Cooled Seats

Note: The engine must be running to use
this feature.

E146309

Press the cooled seat symbol to cycle
through the various cool settings and off.
More indicator lights indicate cooler
settings.

Note: The cooled seats may remain on after
you remote start your vehicle, based on your
remote start settings. The heated seats may
also turn on when you start your vehicle if
they were on when you switched your
vehicle off.

Note: After 60 minutes of operation, the
cooled seats switch off. Press the cooled
seat symbol to switch the cooled seats on.

Climate Controlled Seat Air Filter
Replacement

Your vehicle has lifetime air filters that are
integrated with the seats. Regular
maintenance or replacement is not
required.

FRONT SEAT ARMREST

 (If

Equipped)

E223578

1.

Press the control to release the cushion
latch.

2. Lift the cushion to gain access to the

storage compartment.
