Ford Ranger (2011 year). Manual - part 5

would like to delete, press SEEK

or preset #6. The song will

appear in the display for confirmation. Press SEEK

or preset #6

again and the display will read SONG DELETED. If you do not want
to delete the currently listed song, press

to select

either RETURN or CANCEL.
Note: If there are no songs presently saved, the display will read NO
SONGS.

• DELETE ALL SONGS: Press SEEK

or preset #6 to delete all

song titles from the system’s memory. The display will read ARE YOU
SURE ? Press SEEK

or preset #6 to confirm deletion of all saved

songs and the display will read ALL DELETED.
Note: If there are no songs presently saved, the display will read NO
SONGS.

• ENABLE ALERTS / DISABLE ALERTS: Press SEEK

or preset

#6 to enable/disable the satellite alert status which alerts you when
your selected songs are playing on a satellite radio channel. (The
system default is disabled.) SONG ALERTS ENABLED/DISABLED will
appear in the display. The menu listing will display the opposite state.
For example, if you have chosen to enable the song alerts, the menu
listing will read DISABLE as the alerts are currently on, so your other
option is to turn them off.

Satellite radio is available only with a valid SIRIUS

威 radio

subscription. Check with your authorized dealer for availability.

Autoset: Press

to set the strongest local radio stations

for AM/FM1/FM2 without losing your original manually set preset
stations.
When the six strongest stations are filled, the station stored in preset #1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.

Bass: Press

to decrease/increase the bass setting.

Treble: Press

to decrease/increase the treble setting.

Balance: Press

to adjust the audio between the left and

right speakers.

Fade: Press

to adjust the audio between the front and

rear speakers.

Next/previous directory: In MP3 mode, press

to go to

the previous/next directory.

Entertainment Systems

Flat file/directory mode: In MP3 mode, use

to select

flat file mode or directory mode.

Normal / Track title / File name: Use

to scroll through MP3

display options (track #, normal music name or file name).

5. TUNE: Press to manually go
down/up (

) the radio

frequency and also to select various
settings in menu mode.

6. SHUFF (Shuffle): Press to play
the current CD/MP3 tracks in
random order. In MP3 directory
mode, press to play the tracks within the current directory in random
order.

7. REPEAT: Press to repeat the
current CD/MP3 track. The selection
will repeat continuously until
deactivated. Press REPEAT again to deactivate.

8. FF (Fast forward): Press to
manually advance in a CD/MP3
track.

9. REW (Rewind): Press to
manually reverse in a CD/MP3 track.

10. Memory presets: To set a
station: Select frequency band
AM/FM; tune to a station, press and
hold a preset button until sound returns. To recall a previously set
station, press the desired memory preset button briefly. You can save up
to 18 stations, six in AM, six in FM1 and FM2.

In satellite radio mode (if equipped), there are 18 available presets,
six each for SAT1, SAT2 and SAT3. To save satellite channels in your
memory presets, tune to the desired channel then press and hold a
preset control until sound returns.
Satellite radio is available only with a valid SIRIUS

威 subscription.

Check with your authorized dealer for availability.

REW

Entertainment Systems

11. SEEK/TRACK: Press to access
the previous/next (

) strong

station. In CD/MP3 mode, press to
advance to the previous/next

(

) track.

In satellite radio mode (if equipped), press

SEEK

to seek

to the previous/next channel.

In CATEGORY MODE, press

SEEK

to select a channel within

that category. Press and hold

SEEK

to fast seek through the

previous /next channels.

In TEXT MODE, press

SEEK

to view the previous/additional

display text.
Satellite radio is available only with a valid SIRIUS

威 subscription.

Check with your authorized dealer for availability.

12. TEXT/SCAN: In radio and CD
mode, press for a brief sampling of
radio stations or CD tracks. Press
again to stop.

In MP3 mode, press and release to view the next 12 characters in the
MP3 music name/file name of the current MP3 track and directory.
Press and hold to hear a brief sampling of MP3 tracks.
In MP3 directory mode, press and hold to hear a brief sampling of all
tracks in the current directory. Press and hold again to stop.

In satellite radio mode (if equipped), press and release to view the
Satellite text message. Press and hold to hear a brief sampling of the
next channels. Press and hold again to stop

13. AM/FM: Press to select
AM/FM1/FM2 frequency band.

14. AUX: Press repeatedly to scroll
through SAT1, SAT2, SAT3 (Satellite
Radio modes, if equipped) and LINE
IN (Auxiliary audio mode, if equipped).
For further information on Auxiliary audio mode, refer to Auxiliary
input jack later in this chapter.
Satellite radio is available only with a valid SIRIUS

威 subscription.

Check with your authorized dealer for availability.

Entertainment Systems

15. ON/OFF/Volume: Press to turn
on/off. Turn to increase/decrease
volume.
If the volume is set above a certain
level and the ignition is turned off,
the volume will come back on at a
“nominal” listening level when the ignition switch is turned back on.

16. CD: Press to enter CD/MP3
mode. If a CD is already present in
the system, the disc will begin to
play.

17. CD slot: Insert a CD label side
up.

Auxiliary input jack (Line in)-(if equipped)

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

drivers use extreme caution when using any device or feature that may
take their focus off the road. Your primary responsibility is the safe
operation of the vehicle. We recommend against the use of any
handheld device while driving and that you comply with all applicable
laws.

Your vehicle may be equipped with
an auxiliary input jack (AIJ). The
auxiliary input jack provides a way
to connect your portable music
player to the in-vehicle audio
system. This allows the audio from a
portable music player to be played
through the vehicle speakers with
high fidelity. To achieve optimal
performance, please observe the
following instructions when
attaching your portable music
device to the audio system.

Entertainment Systems
