Ford Police Interceptor Utility (2018 year). Manual - part 59

Vehicle Jacking

E142551

Block the diagonally opposite wheel.

E145908

2. The vehicle jacking points are shown

here, and are depicted on the warning
label on the jack.

3. Small arrow-shaped marks on the sills

show the location of the jacking points.

E201156

4. Raise the wheel by turning the jack

handle clockwise.

5. Remove the lug nuts with the lug

wrench.

6. Replace the flat tire with the spare tire,

marking sure the valve stem is facing
outward. Reinstall the lug nuts until the
wheel is snug against the hub. Do not
fully tighten the lug nuts until the wheel
has been lowered.

Lower the wheel by turning the jack
handle counterclockwise.

E75442

8. Remove the jack and fully tighten the

lug nuts in the order shown. See
Technical Specifications (page 241).

Stowing the Spare Tire and Jack

E226575

Adjust the jack to the proper height to
install the wrench. Turn the jack lead
screw until the arrow on the upper link
is slightly below the circle indicator
shown on the lower link.

E226576

2. Push the button (A) to retract the

wrench handle and place the wrench
over the raised tab on the lower link
and drop the tang (B) through the hole
in the diagonally opposite upper link.
Turn the lead screw of jack clockwise
until the arrow aligns with the circle
indicator to secure the wrench onto the
jack.

3. Place the jack over the mounting

bracket on the floor of the spare tire
well.

4. Replace the spare over the jack and

secure with the wing nut.

TECHNICAL SPECIFICATIONS

Wheel Lug Nut Torque Specifications

WARNING

When a wheel is installed, always remove any corrosion, dirt or foreign materials
present on the mounting surfaces of the wheel or the surface of the wheel hub,
brake drum or brake disc that contacts the wheel. Make sure that any fasteners

that attach the rotor to the hub are secured so they do not interfere with the mounting
surfaces of the wheel. Installing wheels without correct metal-to-metal contact at the
wheel mounting surfaces can cause the wheel nuts to loosen and the wheel to come off
while your vehicle is in motion, resulting in loss of control.

lb.ft (Nm)

Bolt size

110 lb.ft (149 Nm)

1/2-20 x 1.5

Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford

recommended replacement fasteners.

Retighten the lug nuts to the specified torque within 100 miles (160 kilometers) after any
wheel disturbance (such as tire rotation, changing a flat tire, wheel removal).

E145950

Wheel pilot bore

Inspect the wheel pilot bore and
mounting surface prior to installation.
Remove any visible corrosion or loose
particles.

ENGINE SPECIFICATIONS - 3.5L ECOBOOST™

3.5L EcoBoost

Engine

214

Cubic inches

Minimum 87 octane

Required fuel

1-4-2-5-3-6

Firing order

Coil on plug

Ignition system

0.033 - 0.037 in (0.75 mm - 0.85 mm)

Spark plug gap

10.0:1

Compression ratio

Drivebelt Routing

3.5L EcoBoost Engine

E191904

ENGINE SPECIFICATIONS - 3.7L

3.7L V6
