Ford Police Interceptor Sedan (2018 year). Manual - part 21

WARNINGS

The adjustable head restraint is a
safety device. Whenever possible it
should be installed and properly

adjusted when the seat is occupied. An
improperly adjusted head restraint may
provide reduced protection to an occupant
during certain rear impacts.

Install the head restraint properly to
help minimize the risk of neck injury
in the event of a crash.

Note:

Adjust the seatback to an upright

driving position before adjusting the head
restraint. Adjust the head restraint so that
the top of it is level with the top of your head
and as far forward as possible. Make sure
that you remain comfortable. If you are
extremely tall, adjust the head restraint to
its highest position.

Front seat head restraints

E138642

The head restraints consist of:

An energy absorbing head
restraint.

A

Two steel stems.

B

Guide sleeve adjust and release
button.

C

Guide sleeve unlock and remove
button.

D

Adjusting the Head Restraint

Raising the Head Restraint

Pull the head restraint up.

Lowering the Head Restraint

1.

Press and hold button C.

2. Push the head restraint down.

Removing the Head Restraint

1.

Pull the head restraint up until it
reaches its highest position.

2. Insert a tool, such as a large paper clip,

into the pin hole located on the side of
the guide sleeve adjust and release
button (D).

3. Press and hold buttons C and D.
4. Pull the head restraint up.

Installing the Head Restraint

Align the steel stems into the guide sleeves
and push the head restraint down until in
locks.

Tilting Head Restraints

 (If Equipped)

The front head restraints tilt for extra
comfort. To tilt the head restraint, do the
following:

E144727

1.

Adjust the seatback to an upright
driving or riding position.

2. Pivot the head restraint forward toward

your head to the desired position.

After the head restraint reaches the
forward-most tilt position, pivoting it
forward again will then release it to the
rearward, un-tilted position.

MANUAL SEATS

 (If Equipped)

Moving the Seat Backward and
Forward

WARNINGS

Do not adjust the driver seat or seat
backrest when your vehicle is
moving. This may result in sudden

seat movement, causing the loss of control
of your vehicle.

Make sure the seat fully locks into
place by rocking it backward and
forward. Not securing the seat into

the locked position can be dangerous in a
crash and could cause serious personal
injury or death.

E190838

Recline Adjustment

WARNINGS

Always drive and ride with your
seatback upright and the lap belt
snug and low across the hips.

Do not place cargo or any objects
behind the seat backrest before
returning it to the original position.

Pull on the seat backrest to make sure that
it has fully latched after returning the seat
backrest to its original position. An
unlatched seat may become dangerous if
you stop suddenly or have a crash.

E201584

Lumbar Adjustment

 (If Equipped)

E201585

POWER SEATS

 (If Equipped)

WARNINGS

Do not adjust the driver seat or
seatback when your vehicle is
moving. Adjusting your seatback

while your vehicle is in motion may cause
loss of control of your vehicle.

Do not place cargo or any objects
behind the seatback before returning
it to the original position.

E201586

The control is located on the outboard side
of the seat. Move the switch in the direction
of the arrow to raise or lower the seat
cushion or to move the seat forward,
backward, up or down.

12 Volt DC Power Point

WARNING

Do not plug optional electrical
accessories into the cigar lighter
socket. Incorrect use of the cigar

lighter can cause damage not covered by
the vehicle warranty, and can result in fire
or serious injury.

Note:

When you switch the ignition on, you

can use the socket to power 12 volt
appliances with a maximum current rating
of 15 amps.

If the power supply does not work after you
switch the ignition off, switch the ignition
on.
Note:

Do not hang any accessory from the

accessory plug.

Note:

Do not use the power point over the

vehicle capacity of 12 volt DC 180 watts or
a fuse may blow.

Note:

Always keep the power point caps

closed when not in use.

Do not insert objects other than an
accessory plug into the power point.  This
damages the power point and may blow
the fuse.

Run the vehicle for full capacity use of the
power point.

To prevent the battery from running out of
charge:
•

Do not use the power point longer than
necessary when the vehicle is not
running.

•

Do not leave devices plugged in
overnight or when you park your vehicle
for extended periods.

Locations

Power points may be in the following
locations:
•

On the front of the center console.

•

Inside the center console.
